Guardian 15220 User manual

Product Name: Screw-Down G-Rail Base
Instruction Manual
Part #: 15220
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction 1
Applicable Safety Standards 1
Worker Classifications 1
Product Specific Applications 1
Components and Specifications 2
Maintenance, Cleaning, and Storage 3
Inspection 3
Installation and Use 2
Inspection Log 3
Labels 3

Introduction
Thank you for purchasing a Guardian Fall
Protection Screw-Down G-Rail Base. This
manual must be read and understood in
its entirety, and used as part of an
employee training program as required
by OSHA or any applicable state agency.
This and any other included instructions
must be made available to the user of the
equipment. The user must understand how
to safely and effectively use the
Screw-Down G-Rail Base, and all fall safety
equipment used in combination with the
Screw-Down G-Rail Base.
User Information
Date of First Use:
Serial #:
Trainer:
User:
Applicable Safety Standards
When used according to instruction specifications, this product meets or exceeds all applicable OSHA 1926
Subpart M and OSHA 1910 standards for fall protection. Applicable standards and regulations depend on the
type of work being done, and also might include state-specific regulations. Consult regulatory agencies for
more information on fall protection systems and associated components.
Worker Classifications
!
CAUTION
Understand the following definitions of those who
work near or who may be exposed to fall hazards.
Qualified Person: A person with an accredited degree or certification, and with extensive experience or
sufficient professional standing, who is considered proficient in planning and reviewing the conformity of fall
protection and rescue systems.
Competent Person: A highly trained and experienced person who is ASSIGNED BY THE EMPLOYER to be
responsible for all elements of a fall safety program, including, but not limited to, its regulation, management,
and implementation. A person who is proficient in identifying existing and predictable fall hazards, and who
has the authority to stop work in order to eliminate hazards.
Authorized Person: A person who is assigned by their employer to work around or be subject to potential or
existing fall hazards.
It is the responsibility of a Qualified or Competent person to supervise the job site and ensure all
applicable safety regulations are complied with.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
1
Product Specific Applications
Fall Prevention: Screw-Down G-Rail Base may be used as a component in Fall Prevention
applications ONLY. Fall Prevention Systems are placed around the leading edges of any and all
fall hazards to prevent a worker from going over an edge, and may be used in substitute of
Fall Protection or safety netting systems. Installation requirements for Screw-Down G-Rail Base
set forth in this manual MUST be adhered to. Personal Fall Arrest, Work Positioning, Climbing,
Rescue, and any other systems must NEVER be connected to Fall Prevention Systems.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
2
Maintenance, Cleaning, and Storage
If Screw-Down G-Rail Base fails inspection in any way, immediately remove it from service, and contact
Guardian to inquire about its return or repair.
Cleaning after use is important for maintaining the safety and longevity of Screw-Down G-Rail Base. Remove
all dirt, corrosives, and contaminants from Screw-Down G-Rail Base before and after each use. If Screw-Down
G-Rail Base cannot be cleaned with plain water, use mild soap and water, then rinse and wipe dry. NEVER
clean Screw-Down G-Rail Base with corrosive substances.
When not in use, store equipment where it will not be affected by heat, light, excessive moisture, chemicals,
or other degrading elements.
Installation and Use
Components and Specifications
Materials:
powder-coated steel.
Prior to installation, plan your system:
Always ensure that complete G-Rail System, of which Screw-Down G-Rail Base is a component, is fully
compliant with all applicable OSHA regulations. Always adhere to all instructions provided with equipment.
G-Rail equipment instructions provided separately.
Assembly and use:
Concrete fastener hole (qty. 4)
Wood/metal fastener hole (qty. 20)
G-Rail post
installation location
Locking pin
Minimum substrate requirements:
• Wood: 5/8” CDX
• Metal: 24 gauge
• Concrete: 6”, 2,500 psi.
Substrate fastener requirements:
• Wood: #14-10, 2” wood deck screws (qty. 20).
• Metal: #14-10, 2“ metal deck screws (qty. 20).
• Concrete: ½” x 3” concrete bolts (qty. 4).
1. Select installation location for all Screw-Down G-Rail Bases. Ensure that spacing will facilitate installation
of applicable length G-Rails.
2. Maximum substrate slope is 4/12. This supersedes the 1/12 maximum slope for the G-Rail, which applies
to freestanding systems only.
3. Per substrate requirement, install all Screw-Down G-Rail Bases with all applicable fasteners. All fasteners
must be fully embedded in substrate.
4. Repeat installation process for all Screw-Down G-Rail Bases, ensuring that fully installed system will prevent
access to all applicable fall hazards.
5. Install G-Rail by inserting post into Screw-Down G-Rail Base and securing with locking pin.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
3
Prior to EACH use, inspect Screw-Down G-Rail Base for deficiencies, including, but not limited to, corrosion,
deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating,
alteration, and missing or illegible labels. IMMEDIATELY remove Screw-Down G-Rail Base from service if defects
or damage are found. Ensure that applicable work area is free of all damage, including, but not limited to,
debris, rot, rust, decay, cracking, and hazardous materials.
At least every 12 months, a Competent Person other than the user must inspect Screw-Down G-Rail Base.
Competent Person inspections MUST be recorded in inspection log in instruction manual. The
Competent Person must sign their initials in the box corresponding to the month and year the
inspection took place.
During inspection, consider all applications and hazards Screw-Down G-Rail Base has been subjected to.
Inspection
Inspection Log
Date of First Use: __________________.
Product lifetime is indefinite, as long as it passes
pre-use and Competent Person inspections. User
must inspect prior to EACH use. Competent Person
other than user must complete formal inspection
at least every 12 months. Competent Person to
inspect and initial.
This inspection log must be specific to one Screw-Down G-Rail Base. Separate inspection logs must be
used for each Screw-Down G-Rail Base. All inspection records must be made visible and available to all
users at all times.
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.
85348 (Rev. A)
Labels
90923 (Rev. A)
Screw-Down
G-Rail Base
Part #: 15220
DOM:
Serial #:
