Guardian Halo Big Block SRL User manual

Do not throw instructions away.
Read and understand instructions before
using this equipment.
Parts: , , , 
Instruction Manual
HALO BIG BLOCK SRL
 Rev. F
2 Introduction
2 Product Specific Applications
2 Applicable Safety Standards
2 For All Product Applications
2 Worker Classifications
3 Compatibility
3 Limitations
3 Maintenance, Cleaning, and Storage
3 Installation and Use
4 Product Specifications & Materials
5 Safety Information
6 Labels
7 Diagrams
8 Inspection
9 Inspection Log

2
Product Specific Applications
May be used to support a MAXIMUM 1 in
a Personal Fall Arrest System (PFAS)
for use in Fall Arrest applications.
Structure must withstand loads applied in the
directions permitted by the system of at least
5,000 lbs (22,2 kN). No free fall is permitted. SRL
must always be positioned at or above harness
dorsal D-ring AND at or below anchor point.
D-ring: Dorsal.
For All Product Applications
Maximum user weight (including all
clothing, tools, and equipment) is:
OSHA: 100 - 420 lb (45 - 191 kg)
Applicable Safety Standards
Meets or exceeds:
OSHA 1910.140
OSHA 1926.502
Introduction
Thank you for purchasing a Guardian Halo
Big Block SRL. This manual must be read and
understood in its entirety, and used as part of an
employee training program as required by OSHA
or any applicable state agency. This and any other
included instructions must be made available
to the user of the equipment. The user must
understand how to safely and eectively use the
Halo Big Block SRL, and all fall safety equipment
used in combination with the Halo Big Block SRL.
Authorized Person: A person who is
assigned by their employer to work around or
be subject to potential existing fall hazards.
It is the responsibility of a Qualified or
Competent person to supervise the job site
and ensure all applicable safety regulations
are complied with.
Worker Classifications
Qualified Person: A person with an
accredited degree or certification, and with
extensive experience or suicient professional
standing, who is considered proficient in
planning/reviewing the conformity of fall
protection and rescue systems.
Competent Person: A highly trained and
experienced person who is ASSIGNED BY
THE EMPLOYER to be responsible for all
elements of a fall safety program, including,
but not limited to, its regulation, management,
and application. A person who is proficient
in identifying existing and predictable fall
hazards, and who has the authority to stop
work in order to eliminate hazards.
CAUTION! Understand the following
definitions of those who work near or who
may be exposed to fall hazards.
WARNING! Use of equipment in
unintended applications may result
in serious injury or death. Maximum 1
attachment per connection point.
Halo Big Block SRL may be used in
Travel Restraint applications. Restraint
systems prevent workers from reaching
the leading edge of a fall hazard.
Always account for fully deployed length of
lanyard/SRL. Structure must withstand loads
applied in the directions permitted by the
system of at least 1,000 lbs (4,4 kN). No free fall is
permitted. Restraint systems may only be used
on surfaces with slopes up to 4/12 (vertical/
horizontal).
D-rings: Dorsal, Chest, Side, Shoulder.

3
Maintenance, Cleaning, and
Storage
If Halo Big Block SRL fails inspection in any way,
immediately remove it from service, and contact
Guardian to inquire about its return or repair.
Cleaning after use is important for maintaining
the safety and longevity of Halo Big Block SRL.
Remove all dirt, corrosives, and contaminants
from Halo Big Block SRL before and after each
use. If Halo Big Block SRL cannot be cleaned with
plain water, use mild soap and water, then rinse
and wipe dry. NEVER clean Halo Big Block SRL
with corrosive substances. When not in use, store
equipment where it will not be affected by heat,
light, excessive moisture, chemicals, or other
degrading elements.
Limitations
Fall Clearance: There must be sufficient
clearance below the work surface to arrest a
fall before the user strikes the ground or an
obstruction. When calculating fall clearance,
account for a MINIMUM 2 ft (0,6 m) safety factor,
deceleration distance, user height, length of
lanyard/SRL, harness stretch, free fall, and all
other applicable factors.
See Diagram B on page 7.
Swing Falls: Prior to installation or use, make
considerations for eliminating or minimizing all
swing fall hazards. Swing falls occur when the
anchor is not directly above the location where
a fall occurs. Always work as close to in line
with the anchor point as possible. Swing falls
significantly increase the likelihood of serious
injury or death in the event of a fall.
Compatibility
When making connections to the Halo Big Block
SRL, eliminate all possibility of roll-out. Roll-out
occurs when interference between a connector
and the attachment point causes the connector
gate to unintentionally open and release.
All connections must be selected and deemed
compatible with Halo Big Block SRL by a
Competent Person.
All connector gates must be self-closing, self-locking,
and withstand a minimum load of 3,600 lb (16 kN).
See Diagram A on page 7.
Installation and Use
WARNING! Guardian Halo Big Block
SRLs MUST NEVER be used in Leading
Edge (LE) applications.
No free fall is allowed.
ALWAYS avoid lifeline contact with sharp or
abrasive edges and surfaces.
Prior to Installation, plan your system
1. All components of the PFAS must be selected
and deemed compatible with SRL by a
Competent Person.
2. Ensure structure to which SRL is to be
attached, and on which work is to be
performed, is free of all hazards, including,
but not limited to, debris, rot, rust, sharp or
abrasive edges and surfaces, and hazardous
materials.
3. Halo Big Block SRL may be used in stationary
applications only; attach Halo Big Block SRL
carabiner to selected anchorage connector,
and attach snap hook to applicable harness
D-ring.
4. Ensure 100% tie-o will be maintained at all
times, which may require the use of a back-up
or supplementary fall protection system.

4
Materials
stainless steel, galvanized steel, brass, and
aluminum.
Part # Length Description
10917 50 ft (15,2 m) 3/16” Galvanized Cable SRL w/Swivel Top & Snap Hook
10918 65 ft (19,8 m) 3/16” Stainless Steel Cable SRL w/Carabiner, Swivel Top, Snap Hook
10937 50 ft (15,2 m) 3/16” Galvanized Cable SRL w/Swivel Top & Snap Hook
10938 65 ft (19,8 m) 3/16” Stainless Steel Cable SRL w/Carabiner, Swivel Top, Snap Hook
Specifications
Maximum Deceleration
Distance: 3 ft 6 in (1.1 m)
Maximum Arrest Force: 1,800 lb (8 kN)
Average Arrest Force: 900 lb (4 kN)
Minimum Fall Clearance: 7 ft (2,1 m)
See Diagram B on page 7.
Carabiner Connection
Point
Lifeline Handle
Housing
Handle
Connector

5
Safety Information
WARNING! Failure to understand and
comply with safety regulations may result
in serious injury or death. Regulations
included herein are not all-inclusive, are
for reference only, and are not intended
to replace a Competent Person's (CP)
judgment or knowledge of federal or state
standards.
Do not alter equipment.
Do not misuse equipment.
Workplace conditions, including, but not limited
to, flame, corrosive chemicals, electrical shock,
sharp objects, machinery, abrasive substances,
weather conditions, and uneven surfaces, must
be assessed by a Competent Person before fall
protection equipment is selected.
The analysis of the workplace must anticipate
where workers will be performing their duties,
the routes they will take to reach their work, and
the potential and existing fall hazards they may
be exposed to. Fall protection equipment must be
chosen by a Competent Person. Selections must
account for all potential hazardous workplace
conditions. All fall protection equipment should
be purchased new and in an unused condition.
Fall protection systems must be selected and
installed under the supervision of a Competent
Person, and used in a compliant manner. Fall
protection systems must be designed in a
manner compliant with all federal, state, and
safety regulations. Forces applied to anchors
must be calculated by a Competent Person.
Unless explicitly stated otherwise, the maximum
allowable free fall distance for lanyards must not
exceed 6’ (1.8 m).
Harnesses and connectors selected must be
compliant with manufacturer’s instructions, and
must be of compatible size and configuration.
Snap hooks, carabiners, and other connectors
must be selected and applied in a compatible
fashion. All risk of disengagement must be
eliminated. All snap hooks and carabiners must
be self-locking and self-closing, and must never
be connected to each other.
See Diagram A on page 7.
A pre-planned rescue procedure in the case
of a fall is required. The rescue plan must be
project-specific. The rescue plan must allow for
employees to rescue themselves, or provide an
alternative means for their prompt rescue. Store
rescue equipment in an easily accessible and
clearly marked area.
Training of Authorized Persons to correctly erect,
disassemble, inspect, maintain, store, and use
equipment must be provided by a Competent
Person. Training must include the ability to
recognize fall hazards, minimize the likelihood of
fall hazards, and the correct use of personal fall
arrest systems.
NEVER use fall protection equipment of any kind
to hang, lift, support, or hoist tools or equipment,
unless explicitly certified for such use.
Equipment subjected to forces of fall arrest must
immediately be removed from use.
Age, fitness, and health conditions can seriously
affect the worker should a fall occur. Consult a
doctor if there is any reason to doubt a user’s
ability to withstand and safely absorb fall arrest
forces or perform set-up of equipment. Pregnant
women and minors must not use this equipment.
Physical harm may still occur even if fall safety
equipment functions correctly. Sustained post-
fall suspension may result in serious injury or
death. Use trauma relief straps to reduce the
effects of suspension trauma.

6
Labels
GUARDIAN
HALO
Self-Retracting Lifeline
OSHA 1926.502 & 1910.140
WARNING!
Not suitable for leading edge use
Nunca deben usarse en aplicaciones
de borde expuesto
2
1
2
Prior to use, fully read and understand all manufacturer’s instructions provided with equipment at time of shipment. USE:
This device is only for use by one person as a fall arrester. Only make connections directly to attachment point on safety
harness. Guard against swing-fall by keeping the lifeline vertically overhead. Ensure that connection to anchorage is secured
properly before use. Avoid contact with sharp or abrasive edges and surfaces, and thermal, electrical, and chemical hazards.
May be used as a component of a PFAS in HLL applications. Design, installation, and utilization of HLLs must be supervised
by a Qualified Person. Unsuitable for horizontal use. Competent Person must calculate fall clearance prior to use; refer to
instructions for details. Clearance number specified is based on lifeline installed vertically overhead and in-line with worker.
INSPECTION: Prior to each use, inspect device per instructions, including locking function (sharp pull to test), retraction
function, legibility of labels, evidence of defects, damage, or missing parts, and condition of connectors, housing, fasteners,
and lifeline (inspect full length). Inspection by Competent Person required at least every 12 months. Immediately remove from
service if impact indicator on hook displays red. Lifeline: 3/16” (4,7 mm) Galvanized Steel Lifeline Length: 50 ft (15,2 m) User
Weight Range (including tools and equipment): 130-310 lb (59-141 kg)
Maximum Arresting Force: 1,800 lb (8 kN) Average Arresting Force: 900 lb (4 kN) Maximum Arresting Distance: 42 in (1,1 m)
Min. Fall clearance: 7 ft (2,1 m) Part#: 90513 Rev: G Serial # LOT # Mfg. Date Part # 10917 HEIGHT SAFETY. SIMPLIFIED.
guardianfall.com
Part # Date of Manufacture Lot # Serial # Date: Initials: Date of First Use:
1

7
Diagram B - Fall Clearance
CAUTION! Fall clearance
calculation shown below is
based on a standing worker
falling directly in-line with
anchor point.
SAMPLE CALCULATION ONLY.
Always refer to connector
instructions for product-
specific clearance
information.
WARNING!Eliminate Swing Fall whenever
possible! Swing falls increase the risk of
striking objects or the ground in the event of
a fall. If swing fall exists, always account for
additional fall clearance.
■ Deceleration
■ Harness Stretch
■ Safety Factor
■ Swing Fall
Diagram A - Connections

 


1ft6in(0.5m)
2ft(0.6m)
Swing Fall
3ft6in
(1.1 m)
Maximum Arrest
Distance/
Deceleration:
3 ft 6 in (1.1 m)

8
Inspection
Prior to EACH use, inspect Halo Big Block
SRL for deficiencies, including, but not limited
to, corrosion, deformation, pits, burrs, rough
surfaces, sharp edges, cracking, rust, paint
buildup, excessive heating, alteration, broken
stitching, fraying, bird-caging, and missing or
illegible labels. Inspect full length of lifeline.
Pay careful attention to cable swage (located
beneath rubber stopper) and ensure no damage
is present at location where swage contacts
lifeline. Inspect impact indicator (Shown Below)
to see if product has undergone deployment.
IMMEDIATELY remove Halo Big Block SRL from
service if defects or damage are found.
Prior to EACH use, check lifeline retraction by
pulling out a minimum 4’ (1.2 m) and allowing it
to retract under light tension; lifeline must retract
completely. Pull lifeline sharply to test braking
function; brakes must engage.
Depending on model or configuration, check
shock pack for signs of deployment, and/or fall
arrest indicator for signs of activation. Indicator
will display red if unsafe for use. IMMEDIATELY
remove from service if Halo Series SRL does not
function properly, of if exposed to forces of fall
arrest.
Ensure that applicable work area is free of all
damage, including, but not limited to, debris, rot,
rust, decay, cracking, and hazardous materials.
Ensure that selected work area will support the
application-specific minimum loads set forth
in this instruction manual. Work area MUST be
stable.
At least every 12 months, a Competent Person
(CP) other than the user must inspect SRL.
Inspections MUST be recorded in inspection
log in instruction manual and on equipment
inspection grid label. The Competent
Person must sign their initials in the box
corresponding to the month and year the
inspection took place.
During inspection, consider all applications and
hazards the SRL has been subjected to.
Product lifetime is indefinite as long as it passes
pre-use and Competent Person inspections.
This inspection log must be specific to one SRL.
Separate inspection logs must be used for each
SRL. All inspection records must be made visible
and available to all users at all times. If equipment
fails inspection it must be discarded immediately.
Example Impact
Indicator
Green: Undeployed
Red: Deployed

9
Serial No: Date of first issue:
Model #: User:
Date: Results/Condition: Inspected by: Next Inspection Date:
Inspection Log

10
Notes
