Guardian Diablo SRL-LE User manual

Product Name: Diablo 2.5 Cable Tie-Back SRL-LE
Instruction Manual
Part #: 11108; 11109
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction 1
Applicable Safety Standards 1
Worker Classifications 1
Safety Information 10
Product Specific Applications 2
Limitations 2 - 3
Components and Specifications 4
Maintenance, Cleaning, and Storage 7
Inspection 8
Installation and Use 4 - 6
Inspection Log 9
Labels 11

Introduction
Thank you for purchasing a Guardian Fall
Protection Diablo 2.5 Cable Tie-Back SRL-LE.
This manual must be read and understood
in its entirety, and used as part of an
employee training program as required by
OSHA or any applicable state agency.
This and any other included instructions
must be made available to the user of
the equipment. The user must understand
how to safely and effectively use the
Diablo 2.5 Cable Tie-Back SRL-LE, and all fall
safety equipment used in combination
with the Diablo 2.5 Cable Tie-Back SRL-LE.
User Information
Date of First Use:
Serial #:
Trainer:
User:
Applicable Safety Standards
When used according to instruction specifications, this product meets or exceeds all applicable OSHA 1926
Subpart M and OSHA 1910 standards for fall protection. Applicable standards and regulations depend on the
type of work being done, and also might include state-specific regulations. Consult regulatory agencies for
more information on fall protection systems and associated components.
Worker Classifications
!
CAUTION
Understand the following definitions of those who
work near or who may be exposed to fall hazards.
Qualified Person: A person with an accredited degree or certification, and with extensive experience or
sufficient professional standing, who is considered proficient in planning and reviewing the conformity of fall
protection and rescue systems.
Competent Person: A highly trained and experienced person who is ASSIGNED BY THE EMPLOYER to be
responsible for all elements of a fall safety program, including, but not limited to, its regulation, management,
and application. A person who is proficient in identifying existing and predictable fall hazards, and who has
the authority to stop work in order to eliminate hazards.
Authorized Person: A person who is assigned by their employer to work around or be subject to potential or
existing fall hazards.
It is the responsibility of a Qualified or Competent person to supervise the job site and ensure all
applicable safety regulations are complied with.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
1

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
2
Product Specific Applications
Restraint: Diablo 2.5 Cable Tie-Back SRL-LEs may be used in Restraint applications. Restraint systems
prevent workers from reaching the leading edge of a fall hazard. Always account for fully
deployed length of lanyard/SRL. Structure must withstand loads applied in the directions
permitted by the system of at least 1,000 lbs. No free fall is permitted. Restraint systems may
only be used on surfaces with slopes up to 4/12 (vertical/horizontal). Applicable D-rings: Dorsal,
Chest, Side, Shoulder.
!
WARNING
Use of equipment in unintended applications may result in serious
injury or death. Maximum 1 attachment per connection point.
Personal Fall Arrest: Diablo 2.5 Cable Tie-Back SRL-LEs may be used in Personal Fall Arrest
applications as a component of a MAXIMUM 1 Personal Fall Arrest System (PFAS). Structure must
withstand loads applied in the directions permitted by the system of at least 5,000 lbs. Applicable
D-ring: Dorsal.
• Free fall, LE Use: Maximum 5’.
• Free fall, non-LE Use: Maximum 2’.
For all applications, worker weight capacity range (including all clothing, tools, and equipment):
LE Use: 130-310 lbs.
Non-LE Use: 130-420 lbs.
Limitations
Fall Clearance: There must be sufficient
clearance below the anchorage connector
to arrest a fall before the user strikes the
ground or an obstruction. When calculating
fall clearance, account for a MINIMUM 2’
safety factor, deceleration distance, user
height, length of lanyard/SRL, harness
stretch, and all other applicable factors.
Diagram shown is an example fall
clearance calculation ONLY.
Swing Falls: Prior to installation or use, make
considerations for eliminating or minimizing
all swing fall hazards. Swing falls occur when
the anchor is not directly above the location
where a fall occurs. Always work as close to
in line with the anchor point as possible.
Swing falls significantly increase the likelihood
of serious injury or death in the event of a fall.
Diablo 2.5 Cable Tie-Back SRL-LE recommended
fall clearance (does not factor in any potential
swing fall hazards). Clearance numbers specified
based on lifeline installed vertically overhead
and in-line with worker:
• LE Use: 13‘-17’
• Non-LE Use: 5½’ (no free fall) to 7½’ (maximum 2’ free fall)
*Eliminate Swing Fall whenever
possible! If Swing Fall exists,
always account for additional
fall clearance.
Anchor Point
at Foot Level
Class B SRL
SRL-LE
4.5’
to
8.5’
5’
2’
1.5’
Work Surface
4.5’
2’
2’
1.5’
2’
max.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
3
Components and Specifications
Compatibility: When making connections with Diablo 2.5 Cable Tie-Back SRL-LE, eliminate all possibility of
roll-out. Roll-out occurs when interference between a hook and the attachment point causes the hook gate to
unintentionally open and release. All connections must be selected and deemed compatible with Diablo Cable
Tie-Back SRL-LE by a Competent Person. All connector gates must be self-closing and self-locking, and
withstand minimum loads of 3,600 lbs. See the following for examples of compatible/incompatible
connections:
Connector
closed and
locked to
D-ring. OK.
Two or more
snap hooks or
carabiners
connected to
each other. NO.
Two connectors
to same
D-ring. NO.
Connector
directly to
horizontal
lifeline. NO.
Connector
to integral
lanyard.
NO.
Connector
directly to
webbing.
NO.
Incompatible
or irregular
application,
which may
increase risk
of roll-out. NO.
Part # Description
11108
11109
Diablo 2.5 Cable Tie-Back SRL-LE w/Steel Snap Hook End. Single Leg.
Diablo 2.5 Cable Tie-Back SRL-LE w/Steel Snap Hook Ends. Dual Leg Kit.
Materials: galvanized steel, aluminum,
glass-filled nylon, rubber, polyester, and nylon.
Average arrest force: 900 lbs.
Maximum arrest force:1,800 lbs.
Maximum deceleration distance (non-LE): 54”.
Maximum deceleration distance (LE): 54” - 102”.
Lifeline length: 8’.
Tie-back webbing length: 3’.
Cable
Lifeline
Tie-Back
Snap Hook
SRL Bracket
Shock Absorber/
Back Pad
Housing
Tie-Back
Webbing
Rubber
Stopper

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
4
Installation and Use
!
WARNING
In tie-back applications, snap hook must ONLY be attached
to tie-back webbing. NEVER attach snap hook to cable lifeline.
1. All PFAS components must be selected and deemed compatible with Diablo 2.5 Cable Tie-Back SRL-LE by
Competent Person.
2. Ensure structure to which Diablo 2.5 Cable Tie-Back SRL-LE is to be attached, and on which work is to be
performed, is free of all hazards, including, but not limited to, debris, rot, rust, sharp or abrasive edges and
surfaces, and hazardous materials.
3. Eliminate or minimize all risk of swing fall hazard.
4. Ensure 100% tie-off will be maintained at all times, which may require the use of a back-up or
supplementary fall protection system.
5. Always minimize lifeline contact with sharp or abrasive edges and surfaces.
6. For Dual-Leg Kit, only work with one leg attached, except when transitioning between anchor points. When
transitioning between anchor points, first connect second leg to applicable anchor point, then disconnect other
leg from previous anchor point prior to beginning any work. Always ensure 100% tie-off is maintained.
7. Diablo 2.5 Cable Tie-Back SRL-LE may be used in either tie-back or standard applications. Adhere to the
applicable method of installation and use.
Always use Diablo 2.5 Cable Tie-Back SRL-LE in combination with anchor
point that eliminates as much slack in lifeline as possible. Competent
Person must ensure that anchor point location will not introduce
potential free fall greater than what is permitted by the system.
!
WARNING
To install Diablo 2.5 Cable Tie-Back SRL-LE to harness:
1. Compress and hold both release buttons on SRL Bracket and slide pin to open position. Do not attempt to
open or otherwise modify bracket that is connected to Diablo 2.5 Cable Tie-Back SRL-LE.
Release
buttons

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
5
2. At web loop immediately beneath harness dorsal D-ring, slide SRL Bracket pin through loop and lock closed.
It may be necessary to slightly loosen web loop to accommodate pin. Always re-tighten web loop after install.
Depending on SRL Bracket design, either ensure green indicator IS fully visible, or that red indicator
IS NOT visible.
Note: With Diablo 2.5 Cable Tie-Back SRL-LE attached to harness as shown, it is permitted to connect a
separate connecting device to the harness dorsal D-ring. However, never work with more than one
connecting device attached to an anchorage connector at any time.
SRL Bracket installed at web loop.
Green indicator visible -
OK to use.
Red indicator visible -
DO NOT use.
Diablo SRL-LE back pad hook and loop fastener straps
secured around harness shoulder straps.
3. Secure Diablo SRL-LE back pad around harness shoulder straps with provided hook and loop fastener straps
as shown.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
6
SRL-LE Additional Use Instructions:
ALWAYS adhere to the following warnings and specifications when using SRL-LEs.
!
WARNING
Tie-Back:
A) Attach Diablo 2.5 Cable Tie-Back
SRL-LE to harness.
B) Wrap Diablo 2.5 Cable Tie-Back
SRL-LE tie-back webbing around
selected structural anchor. Ensure
potential free fall does not exceed
what is permitted by the system, as
determined by Competent Person.
C) Attach snap hook to
webbing BELOW rubber stopper.
NEVER attach tie-back hook to
cable lifeline or anything other
than tie-back webbing.
Standard:
A) Attach Diablo 2.5 Cable Tie-Back SRL-LE to harness.
B) Attach snap hook to compatible overhead anchorage connector. Ensure potential free fall does not
exceed what is permitted by the system, as determined by Competent Person.
Snap hook attached to
tie-back webbing. OK.
NEVER attach snap
hook to cable lifeline.
Diablo 2.5 Cable Tie-Back SRL-LEs are tested and certified for horizontal use over a steel edge without burrs. Diablo
Cable Tie-Back SRL-LEs may be used over similar surfaces, such as metal sheeting or other steel formations.
The allowable angle of redirection of the lifeline portion of Diablo 2.5 Cable Tie-Back SRL-LEs at the leading edge
of a fall hazard MUST be at least 90° (see Image 1).
Anchor point MUST be situated no lower than the leading edge of applicable fall hazard(s).
Prior to use, a Competent Person MUST calculate adequate fall clearance (see pg. 3).
ALWAYS attach to anchorage connector that will allow for required setback distance (see Image 2).

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
7
Setback Distance
Image 1 Image 2
Leading Edge
X≤90°
X≥90°
Setback distance: As determined by product testing, Guardian Fall Protection Diablo 2.5 Cable Tie-Back
SRL-LEs are not required to be setback any specific distance from the leading edge of applicable fall
hazard(s).
Diablo 2.5 Cable Tie-Back SRL-LE may be used in combination with horizontal lifelines. All installation, set-up, and
use of horizontal lifelines must be done under the supervision of a Qualified Person.
NEVER work on the far side of an opening that is opposite the Diablo 2.5 Cable Tie-Back SRL-LE anchorage point.
In the event of a fall over the edge, special rescue measures may be necessary. Always account for use of
Diablo 2.5 Cable Tie-Back SRL-LE in job site rescue plan developed by job site Competent Person.
Maintenance, Cleaning, and Storage
If Diablo 2.5 Cable Tie-Back SRL-LE fails inspection in any way, immediately remove it from service, and contact
Guardian to inquire about its return or repair.
Cleaning after use is important for maintaining the safety and longevity of Diablo 2.5 Cable Tie-Back SRL-LE.
Remove all dirt, corrosives, and contaminants from Diablo 2.5 Cable Tie-Back SRL-LE before and after each use. If
Diablo 2.5 Cable Tie-Back SRL-LE cannot be cleaned with plain water, use mild soap and water, then rinse and wipe
dry. NEVER clean Diablo 2.5 Cable Tie-Back SRL-LE with corrosive substances.
When not in use, store equipment where it will not be affected by heat, light, excessive moisture, chemicals,
or other degrading elements.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
8
Prior to EACH use, inspect Diablo 2.5 Cable Tie-Back SRL-LE for deficiencies, including, but not limited to,
corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive
heating, alteration, broken stitching, fraying, bird-caging, and missing or illegible labels.
Pay careful attention to cable swage (located beneath rubber stopper) and ensure no damage is present at
location where swage contacts lifeline. IMMEDIATELY remove Diablo 2.5 Cable Tie-Back SRL-LE from service if
defects or damage are found, or if exposed to forces of fall arrest. Ensure fall arrest indicator (broken stitching
at location shown below) is not deployed. During inspection, consider all applications and hazards Diablo 2.5
Cable Tie-Back SRL-LE has been subjected to.
Ensure that applicable work area is free of all damage, including, but not limited to, debris, rot, rust, decay,
cracking, and hazardous materials. Ensure that selected work area will support the application-specific
minimum loads set forth in this instruction manual. Work area MUST be stable.
At least every 12 months, a Competent Person other than the user must inspect Diablo 2.5 Cable
Tie-Back SRL-LE. Competent Person inspections MUST be recorded in inspection log in instruction
manual and on equipment inspection grid label. The Competent Person must sign their initials in the
box corresponding to the month and year the inspection took place.
Immediately remove from service if indicator stitching shows any signs of damage:
Inspection
Intact indicator stitching - OK to use.
Broken/damaged indicator stitching - Immediately remove from service!

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
9
Inspection Log
Date of First Use: __________________.
Product lifetime is indefinite, as long as it passes pre-use and Competent Person inspections. User must
inspect prior to EACH use. Competent Person other than user must complete formal inspection at least
every 12 months. Competent Person to inspect and initial.
This inspection log must be specific to one Diablo 2.5 Cable Tie-Back SRL-LE. Separate inspection logs must
be used for each Diablo 2.5 Cable Tie-Back SRL-LE. All inspection records must be made visible and
available to all users at all times.
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.
