GOperating instruction
Controls and Displays
AMeasuring station
1. LED indicator
2. Battery compartment
3. RESET button
=restoresfactory settings
4. CHANNEL button =channel
selection
5. Recess for wall mounting
6. °C/°F button =switches between
°C and °F
7. LCDdisplay
1. Explanation of Warning Symbols
and Notes
Warning
This symbol is used to indicate safety
instructions or to draw your attention to
specichazards and risks.
Note
This symbol is used to indicate
additional information or important
notes.
2. Package Contents
•TS33C Outdoor Sensor
•These operating instructions
3. Safety Notes
•The product is intended for private,
non-commercial use only.
•Do not operate the product outside the
power limits given in the specications.
•Do not use the product in moist
environments and avoid splashes.
•Do not use the product in the
immediate vicinity of heaters or other
heat sources or in direct sunlight.
•Do not use the product in areas where
the use of electronic devices is not
permitted.
•Do not put the product near
interference elds, metal frames,
computers, TVs, etc. Electronic devices
and window frames can negatively
affect the product’sfunctionality.
•Do not drop the product and do not
expose it to any major shocks.
•Do not open the device or continue to
operate it if it becomes damaged.
•Do not attempt to service or repair the
product yourself.Leave any and all
service work to qualied experts.
•Keep the packaging material out of
the reach of children due to the risk of
suffocation.
•Dispose of packaging material
immediately according to locally
applicable regulations.
•Do not modify the product in any way.
Doing so voids the warranty.
Warning –Batteries
•Immediately remove and dispose of
dead batteries from the product.

3
Warning –Batteries
•Only use batteries (or rechargeable
batteries) that match the specied
type.
•Do not mix old and new batteries or
batteries of adifferent type or make.
•When inserting batteries, note the
correct polarity (+ and -markings) and
insert the batteries accordingly.Failure
to do so could result in the batteries
leaking or exploding.
•Do not overcharge batteries.
•Keep batteries out of the reach of
children.
•Do not short circuit the batteries/
rechargeable batteries and keep
them away from uncoated metal
objects.
4. Getting Started
Inserting the battery
•Open the battery compartment
(2), insert the batteries with the
correct polarity and close the battery
compartment (2). The outdoor sensor is
now ready for operation.
Replacing the batteries
•Open the battery compartment (2),
remove and properly dispose of the
dead batteries and insert two new AA
batteries with the correct polarity.Then
close the battery compartment cover.
Note
Beforeuse, make surethat you insert
the batteries in the measuring station
rst and then in the base station.
5. Installation
Note –Installation
•We recommend initially placing the
base and measuring stations in the
intended locations without installing
them and making all the settings
described in 6. Operation.
•Only install the stations once
the appropriate settings have
been made and astable wireless
connection is established.
Note
•The wireless transmission range
between the measuring and base
stations is up to 30 metres in open
spaces.
Beforeinstallation, ensurethat
wireless transmission will not
be disrupted by interference or
obstacles like buildings, trees,
vehicles, high-voltage lines, etc.
•Beforethe nal installation, ensure
that thereissucient reception
between the intended installation
locations.

4
Note
•When installing the measuring
station, ensurethat it is protected
from direct sunlight and rain.
•The international standardheight for
measuring air temperatureis1.25 m
(4 ft) above ground.
Warning
•Buy special or suitable installation
material from aspecialised dealer
for wall-mounting.
•Ensurethat no faulty or damaged
parts areinstalled.
•Never apply force during installation.
This could damage the product.
•Beforeinstallation, ensurethat
the chosen wall is suitable for the
weight to be installation, and make
surethat thereare no electrical
wires, water,gas or other lines in the
wall at the installation site.
•Youcan position the measuring station
on alevel outdoor surface using
the base.
•We recommend installing the
measuring station securely on an
outdoor wall.
•Install an anchor,screw,nail, etc. in the
wall of your choice.
•Hang the measuring station using the
opening intended for this purpose (5).
6. Operation
6.1. Default setting
•After opening the battery compartment,
rst choose the channel using the
CHANNEL button.
•Only then, insert the batteries into the
battery compartment with the correct
polarity.
•Press the RESET button.
•Then replace the battery compartment
on the outdoor sensor.
6.2. Connection to the measuring
station
•To connect the measuring station and
the outdoor sensor,place the two
devices as close together as possible.
•After you insert the batteries, the base
station automatically searches for a
connection to the measuring station
and performs initial setup.
•If the device does not connect
automatically,the manual search
program on the base station must
be started.
Note
•Initial setup takes approx. 2minutes.
•During the connection attempt, the
measuring station radio symbol (1)
will ash.
•Do not press any buttons during
setup. Otherwise, values may not be
transmitted correctly and thereisa
risk of value errors and inaccuracies.

5
Note
•The setup process is completed
when the indoor and outdoor
measurement data is displayed on
the base station.
•The measured value is automatically
updated by the base device about
every 45 seconds.
•If the temperatureisoutside of the
measuring range, LL.L (lower than
minimum temperature) or HH.H (higher
than maximum temperature) will appear
on the temperaturedisplay.
6.3. Selecting the channel/Other
measuring stations
Note
•Youcan connect up to three different
measuring stations to the outdoor
sensor.Ensurethat the base and
measuring stations areset to the
same channel. Visit www.hama.com
for suitable measuring stations.
•The transmission channel on the
supplied measuring station can be
changed/set (CH1, CH2, CH3).
6.4. Low battery charge
Measuring station
If the batteries need to be replaced, the
symbol for low battery charge will
appear next to the outdoor temperature
display on the base device. Replace the
batteries immediately.
Note –Replacing the
batteries
•Note that the stations have to be
resynchronised each time after
you change the batteries in the
measuring or base station.
•To do this, remove the batteries from
the other station and then reinsert
them, or change them as required.
6.5. Reset
Press the RESET button (3) to restart the
station. The measuring station returns to
the factory settings.
7. Care and Maintenance
•Only clean this product with aslightly
damp, lint-free cloth and do not use
aggressive cleaning agents.
•Make surethat water does not get into
the product.
8. Warranty Disclaimer
Hama GmbH &CoKG assumes no liability
and provides no warranty for damage
resulting from improper installation/
mounting, improper use of the product
or from failuretoobserve the operating
instructions and/or safety notes.

6
9. Technical Data
Measuring station
Power supply 1.5 V
2xAA batteries
Measuring range
Thermometer
Hygrometer
Barometer
-20°C –+60°C/ -4°F –140°F
25% –95%
-
Measurement increments
Temperature
Humidity
0.1°C /0.2°F
1%
Measuring cycle
thermometer/hygrometer
Barometer
~45s
-
DCF radio-controlled clock No
Hygrometer Yes
Thermometer Yes
Barometer No
Moon phases -
Max. number of measuring stations 3
Frequency 433 MHz
Range ≤30 m

7
10. Declaration of Conformity
Hereby,Hama GmbH &CoKG declares that the radio equipment type
[00104985] is in compliance with Directive 2014/53/EU.The full text of the
EU declaration of conformity is available at the following internet address:
www.hama.com ->00104985->Downloads.
Frequency band(s) 433 MHz
Maximum radio-frequency
power transmitted 0,031 mW

8
Bedienungselemente und Anzeigen
AMessstation
1. LED-Anzeige
2. Batteriefach
3. RESET-Knopf
=Zurücksetzung auf
Werkseinstellung
4. CHANNEL-Taste =Kanalauswahl
5. Aussparung für Wandmontage
6. °C/°F-Taste =Wechsel zwischen
°C und °F
7. LCDDisplay
1. Erklärung von Warnsymbolen
und Hinweisen
Warnung
Wirdverwendet, um
Sicherheitshinweise zu kennzeichnen
oder um Aufmerksamkeit auf
besondereGefahren und Risiken
zu lenken.
Hinweis
Wirdverwendet, um zusätzlich
Informationen oder wichtige Hinweise
zu kennzeichnen.
2. Packungsinhalt
•Außensensor TS33C
•diese Bedienungsanleitung
3. Sicherheitshinweise
•Das Produkt ist für den
privaten, nicht-gewerblichen
Haushaltsgebrauch vorgesehen.
•Betreiben Sie das Produkt
nicht außerhalb seiner in den
technischen Daten angegebenen
Leistungsgrenzen.
•Verwenden Sie das Produkt nicht
in einer feuchten Umgebung und
vermeiden Sie Spritzwasser.
•Betreiben Sie das Produkt nicht in
unmittelbarer Nähe der Heizung,
anderer Hitzequellen oder in direkter
Sonneneinstrahlung.
•Benutzen Sie das Produkt nicht in
Bereichen, in denen elektronische
Produkte nicht erlaubt sind.
•Positionieren Sie das Produkt
nicht in der Nähe von Störfeldern,
Metallrahmen, Computern und
Fernsehern etc. Elektronische Geräte
sowie Fensterrahmen beeinträchtigen
die Funktion des Produktes negativ.
•Lassen Sie das Produkt nicht fallen
und setzen Sie es keinen heftigen
Erschütterungen aus.
•Öffnen Sie das Produkt nicht und
betreiben Sie es bei Beschädigungen
nicht weiter.
•Versuchen Sie nicht, das Produkt
selbst zu warten oder zu
reparieren. Überlassen Sie jegliche
Wartungsarbeit dem zuständigen
Fachpersonal.
•Halten Sie Kinder unbedingt von dem
Verpackungsmaterial fern, es besteht
Erstickungsgefahr.
DBedienungsanleitung

9
•Entsorgen Sie das Verpackungsmaterial
sofort gemäß den örtlich gültigen
Entsorgungsvorschriften.
•Nehmen Sie keine Veränderungen
am Produkt vor.Dadurch verlieren sie
jegliche Gewährleistungsansprüche.
Warnung –Batterien
•Entfernen und entsorgen Sie
verbrauchte Batterien unverzüglich
aus dem Produkt.
•Verwenden Sie ausschließlich
Akkus (oder Batterien), die dem
angegebenen Typentsprechen.
•Mischen Sie alte und neue
Batterien nicht, sowie Batterien
unterschiedlichen Typs oder
Herstellers.
•Beachten Sie unbedingt die
korrekte Polarität (Beschriftung
+und -) der Batterien und legen
Sie diese entsprechend ein. Bei
Nichtbeachtung besteht die Gefahr
des Auslaufens oder einer Explosion
der Batterien.
•Laden Sie Batterien nicht.
•Bewahren Sie Batterien außerhalb
der Reichweite von Kindern auf.
•Schließen Sie Akkus/Batterien nicht
kurz und halten Sie sie von blanken
Metallgegenständen fern.
4. Inbetriebnahme
Batterie einlegen
•Öffnen Sie das Batteriefach (2),
legen Sie die Batterie/n polrichtig ein
und schließen Sie das Batteriefach
(2) wieder.Der Außensensor ist
betriebsbereit.
Batterien wechseln
•Öffnen Sie das Batteriefach (2),
entnehmen und entsorgen Sie
die verbrauchten Batterien und
legen Sie zwei neue AA Batterien
polrichtig ein. Schließen Sie die
Batteriefachabdeckung anschließend.
Hinweis
Beachten Sie, dass Sie bei der
Inbetriebnahme immer zuerst die
Batterien in die Messstation, und dann
in die Basisstation einlegen.
5. Montage
Hinweis –Montage
•Es wirdempfohlen, die Basis- und
Messstation zunächst an den
gewünschten Aufstellorten ohne
Montage zu platzieren und alle
Einstellungen -wie in 6. Betrieb
beschrieben –vorzunehmen.
•Montieren Sie erst nach
korrekter Einstellung und stabiler
Funkverbindung die Station/en.
