H&S WIDE BODY Installation and maintenance instructions

WARNING
READ AND UNDERSTAND THIS MANUAL
BEFORE OPERATING THIS EQUIPMENT.
UNSAFE OPERATION OR MAINTENANCE
OF THIS EQUIPMENT CAN RESULT IN
INJURY OR DEATH.
“WIDE BODY’’ FORAGE BOX
OPERATOR'S MANUAL &
PARTS LIST
HSMFG0316
Manufactured By
H&S MANUFACTURING CO., INC.
P.O. BOX 768 • [phone] FAX [phone]
MARSHFIELD, WISCONSIN 54449

CONTENTS
Warranty & Warranty Registration Card .............................................................. 1-2
Dealer Pre-Delivery & Delivery Checklist ...............................................................3
Be Alert Symbol ....................................................................................... 4
Explanation of Safety Signs ............................................................................ 5
Warning - Danger Decals .... .......................................................................... 6
Warning - Owner Must Read and Understand .... ...................................................... 7
Adjustments .................................................................... . . . . . . . . . . . . . . . . . . . . . .10
Lubrication Guide ....................................................................................11
Operation .............................................................................................9
Decal Location & Identification ....................................................................12-13
Ordering Parts - About Improvements ................................................................13
Parts . .............................................................................................14-26
Before Operation .. . .. .. .. .. .. .. .. .. .... .. .. .... .. .. .. ... .. .. .. .. .. .. .. ... .. .. ..........9

DEALER PRE-DELIVERY CHECK LIST
After the Forage Box has been completely set-up, check to be certain it is in correct running
order before delivering to the customer. The following is a list of points to inspect. Check off each
item as you have made the proper adjustments and found the item operating satisfactorily.
___ Forage Box was not damaged in shipment. Check for dents and loose or missing parts.
Report damage immediately to H&S Manufacturing Co., Inc
____ Forage Box has been correctly assembled according to instructions in this manual.
____ All Shields and Guards are in place and fastened.
____ All Grease Fittings have been lubricated. See lubrication guide in this manual.
____ Hoses & fittings if applicable, are properly attached and there are no visible leaks.
____ All Mechanisms are operating trouble free.
____ All Roller Chains are at proper tension.
____ Apron Chains are adjusted properly.
____ All Bolts and Fasteners are tight.
____ All Decals are in place and legible.
(Remove Dealers File Copy At Perforation)
(Dealer’s Name) Model Number
(Signature of Pre-Delivery Inspector) (Inspection Date)
Serial Number
DEALER DELIVERY CHECK LIST
This check list that follows is an important reminder of valuable information that should be passed on
to the customer at the time this Power Box is delivered.
Check off each item as you explain it to the customer.
This pre-delivery check list, when properly filled out and signed assures the customer that the
pre-delivery service was satisfactorily performed.
____ Explain to the customer that the pre-delivery inspection was made.
____ Explain to the customer all the safety precautions they must exercise when operating this unit.
____ Explain recommended loads for different types of materials.
____ Explain to customer that regular lubrication is required for proper operation and long life of machine.
____ Show customer the lubrication section of Owner’s Manual.
____ Give the customer Owner’s Manual and make sure he reads and understands all operating and
service instructions.
____ Have customer sign a completed “Warranty Registration,’’ and mail it promptly.
Date Delivered ________________________
Dealer’s Name ______________________________
By ________________________________________
-3-
Note: Warranty is not valid until warranty card is completed and returned to H&S Mfg. Co., Inc.
Signature of Original Buyer ________________________________________

THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR
PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER:
THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE
CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO
PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.
H&S MANUFACTURING CO. INC.
BE
ALERT! IS
YOUR
INVOLVED.
SAFETY
-4-
SAFETY INFORMATION

RECOGNIZE SAFETY INFORMATION
This is the safety-alert symbol. When you see this
symbol on your machine or in this manual, be alert to
the potential for personal injury.
Follow recommended precautions and safe
operating practices.
UNDERSTAND SIGNAL WORDS
A signal word—DANGER, WARNING, or
CAUTION — is used with the safety-alert
symbol. DANGER identifies the most serious hazards.
Safety signs with signal word DANGER or
WARNING are typically near specific hazards.
General precautions are listed on CAUTION safety
signs.
FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages
in this manual, and all safety
signs on your machine. Follow all
recommended precautions and safe
operating pro-cedures.
-5-
CAUTION
WARNING
CAUTION
SAFETY INFORMATION
Keep signs in good condition. Immediately replace any missing or damaged signs.
OBSERVE MAXIMUM TRANSPORT SPEED
The maximum transport speed for this implement is 32 km/h (20 m.p.h.).
Some tractors are capable of operating at speeds that exceed the maximum
transport speed of this implement. Regardless of the maximum speed capability
of the tractor being used to tow this implement, do not exceed the implement’s
maximum transport speed.
Exceeding the implements maximum transport speed can result in:
* Loss of control of the tractor/implement combinatio
* Reduced or no ability to stop during brakin
* Implement tire failur
* Damage to the implement structure or its component
Use additional caution and reduce speed when towing under adverse surface
conditions, when turning, and when on inclines.
Do not attempt transport if the fully loaded implement weighs more than 1.5 times
the weight of the tractor.

-6-

W A R N I N G
TO PREVENT SERIOUS INJURY OR DEATH;
BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING
INFORMATION. IN ADDITION, MAKE SURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS
WITH THIS EQUIPMENT, WHETHER FAMILY MEMBER OR EMPLOYEE, IS FAMILIAR WITH THESE
SAFETY PRECAUTIONS. KNOW HOW TO STOP UNLOADING MECHANISM BEFORE STARTING IT.
If the machine becomes clogged, disengage truck or tractor hydraulics, stop the truck or tractor
engine, and allow all mechanisms to stop before cleaning or working on the machine.
DO NOT attempt to perform maintenance or repair with truck or tractor running and hydraulics hooked
to the power source.
DO NOT step up on machine at any time.
DO NOT get off the tractor when box is in operation. Operator position is in the tractor seat.
(Running Gear, Chassis Mount). DO NOT leave truck cab when box is in operation. (Truck Mount). DO
NOT ALLOW PERSONNEL OTHER THAN THE QUALIFIED OPERATOR NEAR THE MACHINE. DO
NOT allow minors to operate or be near the machine.
STAY CLEAR of rear of Forage Box at all times.
DO NOT clean, adjust, or lubricate the machine when any part is in operation.
BE SURE the machine is clear of people, tools, and other objects before engaging hydraulics.
NEVER start power box until all guards and safety shields are secured in place.
STAY CLEAR of hydraulic lines, they may be under extreme pressure or heat.
Loose or floppy clothing should not be worn by the operator.
CAUTION – BEWARE OF LOW ELECTRICAL WIRES.
H&S Mfg. Co. always takes the operator and his safety into consideration and guards exposed moving
parts for his protection. However, some areas cannot be guarded or shielded in order to assure proper
operation. In addition, the operators manual and decals on the machine itself warn you of further danger
and should be read and observed closely.
Study The Above Safety Rules
ATTENTION - BE ALERT - YOUR SAFETY IS INVOLVED
-7-
TRACTOR:
This Operators Manual uses the term "Tractor" when identifying the power source.

-8-
BEFORE OPERATION
Check entire unit carefully before first operation. Tighten bolts, set screws, and chains which
might have come loose in handling. Run the unloading mechanism for several minutes. This will serve
as a break-in and as a check that all parts are assembled and lubricated properly. Successful operation
will be achieved by periodic adjustments and experience of the operator. Make sure to read and
understand the main feeder apron adjustments.
Located on the front of the Wide Body
Box is a convenient hanger (Item A) for
the hydraulic hoses. When the Wide
Body Box is not being unloaded, hoses
should be securely wrapped around
this holder, with ends inserted into
Block Holder (Item B). (Running Gear
and Chassis Mount Only).
Mounting Socket For SMV Emblem (A)
Red Reflective Tape (B)
WHEN TRANSPORTING ON THE HIGHWAY
OR ROADS, PLACE SMV SIGN IN SOCKET
PROVIDED AND REGULARLY CLEAN THE
REFLECTIVE TAPE AT THE REAR OF THE
POWER BOX.
NOTE: Obey all state and local laws, concern-
ing towed equipment, on public roads.
B
A

-9-
OPERATION
After you have run the Forage Box for several minutes, checked it over thoroughly as suggested in
earlier recommendations, and have properly adjusted and lubricated it, you are ready to place your Power
Box into operation.
UNLOADING
1. Park the Forage Box on level ground whenever possible during unloading.
2. *Connect the hydraulic hoses from the Forage Box to the tractor.*
3. With operator in the truck or tractor seat, and all others well clear of Forage Box, engage the
hydraulics. NOTE: Rear unload operates in only one direction. *If tractor hydraulic system stalls,
check for obstruction, reverse the lever on the tractor or switch the hydraulic hoses at the ports on
the tractor. If stalling persists, the problem may be insufficient tractor hydraulic pressure.*
OPERATOR’S POSITION
FORAGE
BOX TRACTOR
4. During unloading, move the Power Box
forward to allow material to fall away from rear
of box.
5. When box is empty, disengage hydraulics.
6. Check rear door to make sure it is securely
latched.
NOTE: (Italics between * refers to use on Chassis or Running Gear Mount Models Only)
REAR DOOR LATCHES
Located at the bottom left, center, and right hand side of the
rear door are the door latches. These latches lock against
knurled gears on rear drive shaft to hold door closed when
loading Rear Unload Power Box. When hydraulics are acti-
vated and rear drive shaft turns, knurled gears flip latches open
to allow rear door to swing free. Upon completion of unload-
ing check rear door to insure that door latches are securely in
place for next load.
DOOR LATCHES
KNURLED GEARS

-10-
MAIN APRON ADJUSTMENT
Main feeder apron adjustment bolts are located behind the convenient access door located in the bottom
portion of front gate. Remove handle nuts (A) to open access panel and swing door downward (Chassis or
Running Gear Mount Only). On truck mount, remove 4 handle nuts and remove access panel.
All apron chains must be taken up evenly before you use the power box. Check again after the first few
loads. The Main Feeder Aprons should be at proper tension at all times. The tightener bolts are spring
loaded to help maintain proper tension on apron chains. Tighten the full threaded bolts (B) to adjust aprons.
Aprons are properly adjusted when two Cross Slats, or about three feet of chain lift off the Chain Return
Slides from the front of the box. Maintain this tension when operating the box.
PRIMARY & SECONDARY APRON DRIVE CHAINS
Check both chains regularly for wear. Tension on roller chains is
maintained by a spring loaded tightener system. This is factory set
and should not require adjustment.
A
B
(Shield Removed For Clarity)
TIGHTENER

LUBRICATION GUIDE
-11-
The operator should become familiar with all lubrication points and
establish a systematic routine to insure complete and quick lubrication
of the machine.
DRIVE CHAINS
Lubricate the drive chains with a light machine oil. Keep chains aligned with
sprockets. This will lengthen the life of the sprockets and chain. Lubricate
chains often.
GREASE ZERKS
There are multiple grease fittings on your “WIDE BODY’’ FORAGE BOX.
Grease daily during normal use and before and after storage. Use a
good grade of high quality grease.
Listed below is location and quantity of zerks.
A. (4) one on each main apron front idler sprocket.
B. (4) one on left hand, two on center, and one on right hand rear
main apron drive shaft brackets.
C. (2) one on each bearing on reduction sprocket idler shaft.
D. (2) one on each tandem pivot (chassis mount)
A (Shield Removed For Clarity) B
C

-12-
DECAL LOCATION
Your “Wide Body’’ Forage Box was manufactured with operator safety in mind. Located on the Forage
Box are various decals to aid in operation, and warn of danger or caution areas. Pay close attention
to all the decals on your Power Box.
DO NOT REMOVE ANY OF THESE DECALS. IF DECALS ARE LOST, DAMAGED, OR
IF THE POWER BOX IS REPAINTED, REPLACE DECALS. REMEMBER: DECALS ARE
FOR YOUR PROTECTION AND INFORMATION.
Listed below are the decals on your “Wide Body’’ Forage Box. These decals may be ordered individually
by part number or by ordering complete set.
ITEM PART NO.
A
B
C
D
E
F
G
H
I
J
K
L
M
54033 Made in the U.S.A.
1494C (6) Warning - Moving Parts Under
N/A Serial Number Decal
DCRED (2) Red Reflector Decal
1494A Warning - Do Not Operate
11599 Warning - Hydraulic Leaks
1494B (2) Warning - Do Not Remove Shields
DCAMB (6) Amber Reflector Decal
311 Patent Numbers
66076 (2) Grease Zerk behind shield
2495 Keep Children Away
093020 (8) Grease Zerk
32343 "H" Letter - Aluminum WB
32344 "&" Letter - Aluminum WB
32345 "S" Letter - Aluminum WB
32274 "H" Letter - Fiberglass (FRP) WB
32275 "&" Letter - Fiberglass (FRP) WB
32276 "S" Letter - Fiberglass (FRP) WB
32277 "WIDE BODY" Sign - All Models
F H
MC
B
G I
D
G
JJ
K
A
L L
LL
DESCRIPTION

DECAL LOCATION
-13-
E
INSTRUCTIONS FOR ORDERING PARTS
All service parts should be ordered through your authorized H&S Dealer. He will be able to give you faster
service if you will provide him with the following:
1. Model & Serial Number – Both are located on the left hand rear upright.
2. All reference to left or right apply to the machine as viewed from the rear.
3. Parts should not be ordered from illustration only. Please order by complete parts numbers.
4. If your dealer has to order parts - give shipping instructions:
VIA truck - large pieces (please specify local truck lines)
VIA United Parcel Service (include full address)
PLEASE RECORD NUMBERS FOR YOUR UNIT FOR QUICK REFERENCE
ABOUT IMPROVEMENTS
H&S MFG. CO. IS CONTINUALLY STRIVING TO IMPROVE ITS’ PRODUCTS.
We must therefore, reserve the right to make improvements or changes whenever it becomes practical to
do so, without incurring any obligation to make changes or additions to the equipment previously sold.
L
LLL

-14-
FIGURE 1
BOX ASSEMBLY

ITEM PART NO. PART NO. DESCRIPTION
POLY BONDED SIDES ALUMINIZED SIDES
22’ 24’ 18’ 20’ 22’
1. IFB25 IFB26 IFB128 IFB24 IFB25 Main Frame
2. PB111 “ “ “ “ Light Bracket
3. PB146 “ “ “ “ Center Floor Ridge
* IFB149 “ “ “ “ Back Center Floor Ridge
* IFB150 “ “ “ “ Front Center Floor Ridge
4. IFB27 “ “ “ “ Filler Corner
5. PB154 “ “ “ “ Front Rubber
6. PB155 “ “ “ “ Rubber Holdown
7. IFB28 “ “ “ “ Angle Bracket LH
8. IFB29 “ “ “ “ Panel Angle
9. IFB30 “ IFB45 “ “ Front Door Bottom Left
10. S199 “ “ “ “ Door Hinge LH
11. S198 “ “ “ “ LH Stake Hinge
12. IFB31 “ IFB46 “ “ Front Door Bottom Right
13. S193 “ “ “ “ Door Hinge RH
14. S194 “ “ “ “ RH Stake Hinge
15. IFB43 “ IFB32 “ “ Top Front Panel LH
16. IFB33 “ IFB88 “ “ Top Front Door Panel
17. IFB44 “ IFB34 “ “ Top Front Panel RH
18. IFB35 “ “ “ “ Angle Bracket RH
19. IFB36 “ “ “ “ Cross Front Brace
20. IFB37 “ “ “ “ Inside Deflector B
21. IFB38 “ “ “ “ Left Hood Support-Option
22. IFB39 “ “ “ “ Center Hood Support-Option
23. IFB40 “ “ “ “ Right Hood Support-Option
24. IFB41 “ “ “ “ Roof Hood-Option
25. IFB42 “ “ “ “ Top Rear Brace
26. •PB29 “ “ “ “ Hose Holder
27. IFB47 IFB84 IFB85 IFB86 IFB47 Expanded Metal Screen LH
* IFB111 IFB112 IFB113 IFB114 IFB111 Expanded Metal Screen RH
28. IFB65 IFB67 IFB69 IFB63 IFB65 LH Top Rail
29. IFB66 IFB68 IFB70 IFB64 IFB66 RH Top Rail
30. IFB115 IFB116 IFB117 IFB118 IFB115 RH Top Angle
* IFB119 IFB120 IFB121 IFB122 IFB119 LH Top Angle
* IFB152 IFB153 –– –– –– FRP Side Panel (1/side)
* IFB154 “ –– –– –– FRP Front Top Panel (1)
* IFB155 “ –– –– –– FRP Front Tailgate Panel (1)
* IFB156 “ “ “ “ FRP Inside Shelf Panel (1)
* –– –– S150 S299PB –– Aluminized Side Panels Top
* –– –– IFB75 IFB76 –– Aluminized Side Panels Bottom
* –– –– –– –– IFB157 Aluminized Side Panel Top
* –– –– –– –– IFB158 Aluminized Side Panel Bottom
* –– –– PB151 “ “ Aluminized Front Panels Top
* –– –– PB150 “ “ Aluminized Front Panels Bottom
* –– –– PB152 “ “ Aluminized Front Tailgate Panel
* PB145 IFB83 IFB81 IFB82 PB145 Poly Bonded Floor Panels
* CHM38 “ “ “ “ Plug Storage
* S522 “ “ “ “ Manual Holder
NOTE: * (Means Not Shown)
• (Indicates Use on Chassis or Running Gear Models Only)
“ (Same as Part # to Left)
–– (Part is Not Used on This Model)
-15-
FIGURE 1
BOX ASSEMBLY

FIGURE 2
REAR DOOR & DRIVE SYSTEM
-16-

ITEM PART NO. PART NO. DESCRIPTION
POLY BONDED SIDES ALUMINIZED SIDES
22’ 24’ 18’ 20’ 22’
1. S63 “ “ “ “ Idler Shaft
2. S60 “ “ “ “ Idler sprocket
3. S61 “ “ “ “ Idler shaft spacer
4. WM210 “ “ “ “ Spring-Red
5. S7 “ “ “ “ Idler Bolt 1/2 x 9-1/2”
6. PB173 IFB1 IFB62 PB220 PB173 Hydraulic Pipe
7. IFB2 “ “ “ “ Back Door Frame Work
8. IFB3 “ “ “ “ Door Hinge Pin
9. 23N67 “ “ “ “ Pipe Clamp
10. PB155 “ “ “ “ Seal Strap
11. PB154 “ “ “ “ Rubber Seal
12. PB74 “ “ “ “ Drive Shaft Panel
13. 16SV150 “ “ “ “ Hydraulic Motor
14. IFB4 “ IFB4 “ IFB4 Motor Sprocket 10Tooth #80
15. IFB5 “ “ “ “ Tightener Rod
16. 23N211 “ “ “ “ Spring
17. 23N206 “ “ “ “ Tightener Rod Holder
18. F157 “ D39 “ F157 Connector Link
19. 16SV330 “ 16SV330 “ 16SV330 Chain #80 68 Pitch
20. 45N67 “ “ “ “ Bearing W/Holder
21. IFB136 “ “ “ “ Short Idler Shaft
22. R17 “ “ “ “ Short Idler Spacer
23. IFB148 “ “ “ “
Short Idler Sprocket 52/8 Tooth #80/100
24. R57 “ “ “ “ Spacer
25. 12V77 “ 12V77 “ 12V77 Sprocket
26. IFB9 “ “ “ “ Primary Drive Spacer
27. IFB10 “ “ “ “ Short Tightener
28. IFB11 “ “ “ “ Long Tightener
29. IFB12 “ “ “ “ Tightener Axle Pivot
30. IFB13 “ “ “ “ Poly Chain Tightener Axle
31. IFB14 “ “ “ “ Chain Tightener Roller
32. IFB23 “ “ “ “ Spacer
33. IFB15 “ “ “ “ RH Drive Shaft Mount
34. S50 “ “ “ “ Bushing
35. PB175 “ “ “ “ Latch Sprocket
36. PB167 “ “ “ “ Drive Shaft
37. S37 “ “ “ “ Drive Shaft Sprockets
38. IFB16 “ IFB16 “ IFB16
Center Drive Shaft Sprocket 22 Tooth #100
39. IFB159 “ “ “ “ Connector Link #100 (Heavy)
40. IFB129 “ IFB129 “ IFB129 Chain #100 x 47 Pitch (Heavy)
41. IFB19 “ “ “ “ Center Drive Shield
42. IFB20 “ “ “ “ LH Drive Shaft Mount
43. IFB21 “ “ “ “ Elbow-90 Degrees
44. •PB185 “ “ “ “ Check Valve
45. 16SV144 “ “ “ “ Hose 1/2” x 41”
46. PB183 “ “ “ “ Center Bearing Bracket
47. PB133 “ “ “ “ Key (3) 3/8” SQ. x 4-3/8”
48. PB87 “ “ “ “ Key (2) 3/8” SQ. x 2”
49. –– –– S59 PB179 –– Complete T-Rod Apron
* PB165 IFB22 PB180 PB178 PB165 Complete 667XH Apron
50. –– –– S54 “ –– T-Rod Slat W/Att. Link
* PB177 “ –– PB177 “ 667XH Pintle Slat W/Att. Link
51. –– –– S55 “ “ T-Rod Link
* PB181 “ “ “ “ 66XH Pintle Connector Link
* PB182 “ “ “ “ 667XH Pintle Att. Link LH or RH
52. A34 “ “ “ “ Latch Washer
53. PB61 “ “ “ “ Latch Pivot
54. PB58 “ “ “ “ Latch Bracket LH
55. PB57 “ “ “ “ Latch Bracket RH
* –– –– PB161 “ “ Back Door Aluminized Panels
56. F73 “ “ “ “ Snap Ring
* IFB61 “ –– –– __ Back Door Poly Bonded Panels (2)
NOTE: * (Means Not Shown) • (Indicates Use on Chassis or Running Gear Models Only)
“ (Same as Part # to Left)
–– (Part is Not Used on This Model)
-17-
FIGURE 2
REAR DOOR & DRIVE SYSTEM

-18-
FIGURE 3
OPTIONAL BARN DOORS
