H&S GM 170 Installation and maintenance instructions

Manufactured By
H&S MANUFACTURING CO.,INC.
P.O. BOX 768 [phone] FAX [phone]
MARSHFIELD, WISCONSIN 54449
GM 170 OPERAOPERA
OPERAOPERA
OPERATT
TT
TOR’SOR’S
OR’SOR’S
OR’S
MANUMANU
MANUMANU
MANUALAL
ALAL
AL AND PAND P
AND PAND P
AND PARAR
ARAR
ARTS LISTTS LIST
TS LISTTS LIST
TS LIST
Revision #5
Starting Serial #210262 HSMFG0912
WARNING
READ AND UNDERSTAND THIS MANUAL
BEFORE OPERATING THIS EQUIPMENT.
UNSAFE OPERATION OR MAINTENANCE OF
THIS EQUIPMENT CAN RESULT IN SERIOUS
INJURY OR DEATH.

CONTENTS
Warranty&Warranty Registration Card.. . . . . . . . ... . . . . . . . ... . . . . . . . . ... . . . . . . . ... . ...1-2
ManufacturersStatement.. . . . . . . ... . . . . . . . ... . . . . . . ... . . . . . . . .. . . . . . . . ... . . ....... . . . 2
DealerPre-Delivery Checklist . . .. . . . .. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .. . . . .. . . . ..... . . . . 3
DealerDelivery Checklist . . . . .. . . . . . .. . . . . . .. . . . . .. . . . . . .. . . . . . .. . . . . . .. . . . ... . . . . ... . 5
BeAlert Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Explanationof Safety Signs . . . ... . . . . . .. . . . . . . .. . . . . . .. . . . . . . .. . . . . . .. . . . . . . ....... . . . 8
Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11
Warning - Owner MustReadandUnderstand....... . . . .... . . . .... . . . .... . . ..... . . ..... ..12
BoltTorqueChart . . . ........... . . . . . . . . . . . . . . . . ........... . . . . . . . . . . . . . .. . . ..........13
Set-Up&Assembly... . . . . . . . . . ... . . . . . . . . . .... . . . . . . . . . . ... . . . . . . . . . ...... . . . . . . . . . 14
Storage . . . . . . . . . . . ........ . . . . . . . . . . . . . . . . . ........ . . . . . . . . . . . . . . . ..... . . . . . . . . . . . . 14
Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . 15
PreparingforOperation........ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .............. . . . . . . . . .16
Operation.... . . . . . . . . . . . . . ...... . . . . . . . . . . . . . ..... . . . . . . . . . . . . . . ..... . . . . . . . . ...17-25
Adjustments................ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ............26-28
Service.. . . . . . . . . . . .... . . . . . . . . . .... . . . . . . . . . .... . . . . . . . . . . .... . . . .... . . . . . . . . . .29-33
OptionalFeatures&Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . 34-35
LubricationGuide.. . . . . . . . . . . . ..... . . . . . . . . . . . . .... . . . . . . . . . . . . ..... . . . .. . . . . ....36-38
Troubleshooting Guide . . . . . . . . . . . . . . . . .............. . . . . . . . . . . . . . . . . . . . . .... . . . . . . 39-43
DecalLocation&Identification....... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ........... . . . . 44-48
Instructionsfor OrderingParts-AboutImprovements... . ... .... ... .... ... . ... ... . ... .... .. 49
ServiceNotes. . . . . . . ... . . . . . . . .. . . . . . . . ... . . . . . . ... . . . . . . . ... . . . . . . .... . . . . .. . . . 50-51
Parts... . . . . . . . . ....... . . . . . . . . . ....... . . . . . . . . . ....... . . . . . . . . . ....... . . . . . . . . . 52-102
PartsNotes . . . ..... . . ..... . . . .... . . . .... . . . ..... . . ..... . . . .... . . . ....... . . . .... .103-104
Specifications.... .. ......... .. ......... .. ....... .. ......... .. .......... ..InsideBackCover

WARRANTY
FILLOUT
ANDMAIL
IMMEDIATELY
TOMAKE
WARRANTY
EFFECTIVE
WARRANTY REGISTRATION
Date of Purchase
Purchaser Address
City State Zip
Product Model# Serial#
Dealer Address
City State Zip
Signature of Original Buyer
-1-
9/12
H&S WARRANTY
H&S Manufacturing Co., Inc. (“H&S”) warrants this product to be free from defect in material and workmanship.
Except as noted below, this warranty term is twelve (12) months from the date of delivery of the product to the original
purchaser by an authorized H&S dealer. Under this warranty , H&S will repair or replace, at its option, any covered part
which is found to be defective in material or workmanship during the applicable warranty term. In no case will the
covered repair cost of a part or parts exceed the replacement cost of that part. Warranty service must be performed by
H&S or a dealer authorized by H&S to sell and/or service the product involved, which will use only new or remanufactured
parts or components furnished by H&S. This warranty includes approved parts and labor to fix the product but does
not include, and the purchaser is responsible for, any service call and/or transportation of the product to and from
the dealer’s place of business, for any premium charged for overtime labor requested by the purchaser, and for
any service work not directly related to any defect covered under this warranty. This warranty includes only those
components of the product manufactured by H&S. Warranty for any component not manufactured by H&S including,
but not limited to, engines, batteries, tires, rims, hydraulic motors, pumps, etc. are covered by the warranty, if any,
provided separately by their respective manufacturers.
This warranty in all its parts, is extended solely to the original purchaser of the product, is terminated upon any
subsequent transfer or sale from or by the original purchaser and extends no third party benefits or rights whatsoever.
The warranty term for any product used in any commercial, custom, for hire or rental application, is limited to six (6)
months from the date of delivery of the product to the original purchaser or the first day of service, whichever comes
first, by an authorized H&S dealer.
Polybonded (polyethylene and plywood) panels utilized in H&S Manure Spreaders are warrantied, to the original
purchaser, to not wear through and the polyethylene overlay to not tear free of the plywood for the functional life of the
spreader. This specific warranty on polybonded panels includes only replacement of any defective panel part without
any allowance for labor beyond the terms of the general warranty (12 or 6 months), and is further limited to manure
spreaders used to spread normal agricultural manure.
This warranty does not include: (1) Any product that has been altered or modified in ways not approved by H&S; (2)
Depreciation or damage caused by normal wear, misuse, improper or insufficient maintenance, improper operation,
accident or failure to follow the product Operator’s Manual recommendations and product decal recommendations;
(3) Normal maintenance parts and service; (4) Repairs made with parts other than those available from H&S or
performed by anyone other than H&S or a dealer authorized by H&S to sell and/or service the product involved.
To secure warranty service the purchaser must report the product defect to a dealer authorized by H&S to sell and/
or service the product involved within the applicable warranty term together with evidence of the warranty start date and
make the product available to that dealer within a reasonable period of time.
THEREARENOWARRANTIES WHICH EXTENDBEYOND THE DESCRIPTIONON THEFACEOFTHISWARRANTY. H&S
and the companies affiliated with it makes no warranties, representations, or promises, express or implied, as to the
performance or freedom from defect of its products other than those set forth above and NO IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESSORFITNESSFORAPARTICULAR PURPOSEISMADE. INNO EVENTWILLTHE DEALER,
H&SORANYCOMPANYAFFILIATEDWITH H&SBE LIABLEFOR INCIDENTALORCONSEQUENTIAL DAMAGES.The
ONLY REMEDY the purchaser has in connection with the breach of performance of any warranty on H&S products are
those set forth above.
The selling dealer has no authority to make any representation or promise on behalf of H&S, or to modify the terms
or limitations of this warranty in any way.

IMPORTANT!
Tear on dotted line, provide the information requested on
the card. The H&S Warranty is valid “only” after this card
is received and recorded at H&S Mfg. Co. Mail at
once. No postage is required in the U.S.A.
-2-
Your new H&S Grinder-Mixer has been manufactured of the finest quality
materials and components. The performance you get from your machine is
largely dependent upon how well you read and understand this manual and
apply this knowledge. There is a right and a wrong way to do everything. Please
do not assume that you know how to operate and maintain your Grinder-Mixer
before reading this manual carefully. Keep this manual available for ready
reference.
MANUFACTURER’S STATEMENT
BUSINESS REPLY MAIL
H&S Manufacturing Co., Inc.
PO Box 768
Marshfield, WI 54449-9963
NOPOSTAGE
NECESSARY
IFMAILED
INTHE
UNITEDSTATES

DEALER PRE-DELIVERYCHECK LIST
AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS
After the 170 Grinder-Mixer hasbeencompletely set-up, check tobecertainitis in correct operating order
before delivering to the customer. The following is a list of points to inspect. Check off each item as you
have made the proper adjustments and found the item operating satisfactorily.
Grinder-Mixer was not damaged in shipment. Check for dents and loose or missing parts.
Report damage immediately to H&S Manufacturing Co., Inc.
All bolts and fasteners are tight.
Mixer has been correctly assembled according to instructions in this manual. Wheels are
properly mounted and wheel nuts are torqued to specs.
All grease fittings have been lubricated. The transmission and cyclonic reservoir are filled to
proper levels. See Lubrication Chapter of this manual for details.
No visible leaks on the hydraulic pump, motors, hoses and fittings.
Guards and shields are secure.
Screens fit properly into the mill and the mill cover closes and latches tightly.
Tires are inflated to 80 PSI (563 kpa).
Belts are properly adjusted.
Rear Drive Chain tension is properly adjusted. See Adjustment Chapter of this manual.
Discharge auger door operates smoothly.
Decals are in place and legible.
Lights and wiring functioning properly if applicable.
Connect the Mixer onto a proper horsepower 540 RPM or 1000 RPM (if applicable)
tractor and attach the PTO. Connect the scale and lights if applicable. Run the
Grinder-Mixer and make sure all components operate properly.
PTO guard turns freely.
Hydraulic system does not leak under pressure.
Electronic Scale (if provided) operates properly.
Implement and all components are functioning properly.
-3-
(Remove Dealer File Copy At Perforation)
SWINGING INTAKEAUGER (SIA) (If applicable)
Guards, shields, and attaching hardware are in place and properly secured.
SIA lifting, locking and supporting mechanisms function correctly. Counter-balance spring and
brake are properly adjusted. See Adjustments Chapter of this manual.
Transport lock mechanism engages and disengages correctly. Safety locking clip is attached
to the transport bracket.
Hydraulic motor and speed control levers operate properly during operation.
Decals are in place and legible.
Serial Number
Dealer’s Name
Signature of Pre-Delivery Inspector
ModelNumber
Inspection Date

-4-
Intentionally Left Blank

(Remove Dealer File Copy At Perforation)
DEALER DELIVERYCHECK LIST
AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS
This check list that follows is an important reminder of valuable information that should be
passed on to the customer at the time this Rake is delivered.
Check off each item as you explain it to the customer.
This delivery check list, when properly filled out and signed assures the customer that the
Pre-delivery service was satisfactorily performed.
Explain to the customer that the pre-delivery inspection was made.
Explain to the customer all the safety precautions they must take when operating
this unit.
Explain to customer that drain plugs must be installed before operating of grinder-mixer.
Explain to customer that regular lubrication is required for proper operation and long life
of machine.
Show customer the lubrication section of Owner’s Manual.
Give the customer Owner’s Manual and make sure they read and understand all operating
and service instructions.
Record Serial Number on page 49 of this Manual.
Have the customer sign a completed “Warranty Registration”, and mail it.
Date Delivered
Dealer’s Name
By
Signature of Original Buyer
-5-

-6-
Intentionally Left Blank

BE
ALERT! YOUR SAFETY IS INVOLVED.
THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS
INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST
OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS
MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.
-7-
H&S MANUFACTURING CO., INC.
SAFETY INFORMATION

-8-
RECOGNIZE SAFETY INFORMATION
This is the safety-alert symbol. When you see this symbol
on your machine or in this manual, be alert to the potential
for personal injury.
Follow recommended precautions and safe operating
practices.
UNDERSTAND SIGNAL WORDS
Asingleword - DANGER, WARNING, or CAUTION-isused
with the safety-alert symbol. DANGER identifies the most
serious hazards.
Safety signs with signal word DANGER or WARNING are
typically near specific hazards.
General precautions are listed on CAUTION safety signs.
FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages in this manual, and all safety signs on your machine. Follow all
recommended precautions and safe operating procedures.
SAFETY INFORMATION
OBSERVE MAXIMUM TRANSPORT SPEED
The maximum transport speed for this implement is 32 km/h (20 m.p.h.).
Some tractors are capable of operating at speeds that exceed the maximum
transport speed of this implement. Regardless of the maximum speed capability
of the tractor being used to tow this implement, do not exceed the implement’s
maximum transport speed.
Exceeding the implements maximum transport speed can result in:
* Loss of control of the tractor/implement combination
* Reduced or no ability to stop during braking
* Implement tire failure
* Damage to the implement structure or its components
Use additional caution and reduce speed when towing under adverse surface
conditions, when turning, and when on inclines.
Do not attempt transport if the fully loaded implement weighs more than 1.5 times
the weight of the tractor.
Keep signs in good condition. Immediately replace any missing or damaged signs.

-9-
SAFETY INFORMATION

SAFETY INFORMATION
-10-

SAFETY INFORMATION
-11-

TRACTORS:
This operators manual uses the term “Tractor” when identifying the the power source.
WARNING
TO PREVENT SERIOUS INJURY OR DEATH
Study The Above Safety Rules
ATTENTION - BE ALERT - YOUR SAFETY IS INVOLVED
BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING
INFORMATION.INADDITION,MAKESURETHATEVERYINDIVIDUALWHOOPERATESOR WORKS
WITHTHISEQUIPMENT,WHETHERFAMILYMEMBEROREMPLOYEE,ISFAMILIARWITHTHESE
SAFETYPRECAUTIONS.
H&S Mfg. Co. always takes the operator and their safety into consideration and guards exposed
moving parts for their protection. However, some areas cannot be guarded or shielded in order to assure
proper operation. In addition, the operators manual and decals on the machine itself warn you of
further danger and should be read and observed closely.
-12-
DO NOT ALLOW PERSONNEL OTHER THAN THE QUALIFIED OPERATOR NEAR THE MACHINE.
KNOW HOW TO STOP MACHINE BEFORE STARTING IT.
If the machine becomes clogged or for servicing, Stop the tractor engine, remove ignition key and allow
all mechanisms to stop. Before cleaning or working on the machine, detach the PTO shaft, and com-
pletely disengage the tractor hydraulics.
DO NOT attemptto performmaintenanceor repairwithtractorrunning, PTO and hydraulic hoses connected to
the tractor.
NEVER ALLOW RIDERS IN OR ON THE MACHINE.
DO NOT step up on machine at any time while in operation.
DO NOT allow minors to operate or be near the machine.
STAY CLEAR of discharge auger when in operation.
Keep hands, feet, and clothing away from all moving parts when the Grinder-Mixer is in operation.
Loose or floppy clothing should not be worn by the operator.
Be sure the machine is clear of people, tools, and other objects before engaging PTO.
Do not step over PTO shaft: Stay clear of PTO at all times.
NEVER start the Grinder-Mixer until all guards and safety shields are secured in place.
Never operate Grinder-Mixer with a PTO speed greater than the recommended PTO RPM.
STAY CLEAR of hydraulic lines, they may be under extreme pressure or heat.
NEVER open or plug the water drain holes with the Mixer running.

-13-

WHEELS & TIRES
The Grinder-Mixer is shipped without the rims and tires installed on the axle hubs. Install the rims and
tires, and torque the wheel nuts to 90 ft.-lbs. (124 N-m). Inflate the 12.5L x 15 - 20 ply tires to 80 PSI (563
kpa).
DRAIN PLUGS & DRAIN COVER
When the Grinder-Mixer is delivered, the drain plug on the back plate of the transfer auger will be in the
storage position. See the diagram below for the storage position. When the GM 170 is ready for delivery,
install the drain plug in the back plate of the transfer auger. Make sure that the drain plug below the
supplement hopper in the transfer auger is also installed. If the mixer is equipped with a Swinging Intake
Auger (SIA), the drain plug will also be in the storage position. Upon delivery, also install the drain plug in
the drain hole in the bottom of the SIA attachment.
IMPORTANT: Never open or plug the water drain holes with the mixer running.
SET-UP & ASSEMBLY
-14-
STORAGE
IMPORTANT: If the GM 170 is stored outside, the water drain holes must be left unplugged. Before the
mixer is going to be operated, reinstall the plugs.After a rain, check the mill, mixing tank, and augers for
water accumulation before operating the mixer. As necessary, drain the water before using the mixer.
NOTE: After water has been drained from the mixer, it is advisable to run the GM 170 while empty for a
period of time in an attempt to dry the mixer before grinding to eliminate any sticking of material and
possible plugging.
TransferAuger Drain Plug In Storage Position. SIADrain Plug In Storage Position.
Transfer
Auger
Drain
Plug

SMV BRACKET & REFLECTORS
Thegrinder-mixerisequippedwith a SMV bracket.
Redreflector strips arelocated on therear of each
side of the tank and on the SIA (if applicable).
TRANSPORTING
-15-
TRANSPORT LIGHTING
An optional highway transport lighting kit is available.

TRACTOR CONNECTIONS
PTO
Fasten the Grinder-Mixer to the tractor drawbar with a hitch pin with safety locking device, and attach the
Grinder-Mixer PTO to the tractor PTO shaft locking it into position.
1. Maintain a straight alignment between the grinder-mixer and the tractor.
2. Maintain a 15-1/2” distance between the lock on the tractor PTO and hole on grinder-mixer hitch
for a 540 RPM machine.
3. Maintain a 17” distance between the lock on the tractor PTO and hole on grinder-mixer hitch for a
1000 RPM machine.
4. Maintain a distance of 6”- 12” between the top of the tractor drawbar and the center of the tractor
PTO. An 8” distance is standard.
PREPARING FOR OPERATION
PREPARING MIXER
* Properly lubricate the grinder-mixer, checking the transmission and cyclonic reservoir oil levels, and
filling if necessary before operating the grinder-mixer.
* All drain plugs must be properly installed and secured.
* Follow the procedures outlined in the Operation Chapter of this manual for installing the mill screen.
* The tank lid and the discharge auger door must be closed and the cyclone cover must be open.
* Start the tractor, engage the PTO at idle speed and increase the rpm’s until the grinder-mixer is running
at the rated PTO speed. Begin the grinding process.
-16-
Hydraulics
TheGM170 requires a4hose hook-up; 2 hosesforthe discharge augerlift,and 2 hoses forthedischarge
auger rotation.

-17-
OPERATION
EMERGENCY SHUTDOWN
In an emergency or in case a foreign object enters the mill
inlet, stop mixer operation immediately by disengaging the
tractor PTO.
GENERAL INFORMATION
Check entire unit carefully before first operation. Tighten bolts and set screws that might have come
loose in shipping. Lubricate as explained in the Lubrication Chapter in this manual.
NOTE:These procedures must be done before grinding;
1.) Grinder mill door is closed.
2.) The collector cover is open,
3.) The tank lid is closed,
4.) The unloading auger shut-off door is closed.
Operate the mixer on level ground for uniformity of mix. Maintain a straight-line alignment between the
tractor and mixer to prolong the life of the drive line components.
Maintain the tractor rated PTO speed which produces a mill cylinder speed of 2700 RPM, to obtain the
most efficient grind. Do not exceed a cylinder speed of 3000 RPM. Before grinding, the unloading auger
shut-off door must be closed.
Add supplements after a small amount of feed has been ground, then dry granular materials.
NOTE:Do not grind feed with high moisture content. This may cause plugging. Abnormally damp crops
will not feed or mix well.
Grinding should be stopped when the feed in the windows begins to drop.
IMPORTANT: Overfilling the mixing tank will place unnecessary stress on the drive line components.
Keep the tank lid closed and properly latched so that if the tank is accidentally overfilled, the lid can pop
open and release the feed inside the tank.
The two full-length windows on the tank are calibrated with numbers representing bushels of ground
feed.
NOTE:Optional models of electronicscalesareavailableforaccurate weight measurements and rations.
Stop the tractor and disengage the mill/blower drive sheave pin after grinding. Start the tractor and allow
the mixer to continue running for several minutes to thoroughly mix the ground feed.Allow the mixer to
continue running during transport, disengaging the PTO on corners or turns.
IMPORTANT: When transporting the mixerandmixing, disengage the tractorPTObefore turning corners
to prevent damage to the PTO driveline.

OPERATION
540/1000 RPM PTO DRIVE
The H&S GM 170 grinder-mixer features a 540 drive as standard
equipment for use with tractors up to 115 hp (86 kW).
Anoptional 1000 RPM driveis available foruse with tractors upto
145 hp (109 kW).
MILL & BLOWER
Drive Sheave
Themill/blowercan be engaged ordisengagedbythe positioning
of a pin on the sheave.
Todisengage the mill/blower, grasp thepin handle, pullit forward
and rotate it onto the L-shaped bracket.
IMPORTANT: When starting the Grinder-Mixer, engage the
tractorPTOataslowidlespeed.Advance the throttleofthetractor
to the rated PTO speed.
-18-
CAPACITY
The GM 170 mixing tank capacity is 170 cubic feet or 135
bushels by volume. The tank will hold approximately 6000
lbs of ground feed consisting of average weight corn, small
grain and/or concentrates. More or less weight (per tank) is
possible,depending upon whetherthe material thatis being
ground is lighter or heavier than average. Grinding capacity
of the mill will vary due to the type of material being ground,
the moisture content of the material, the size screen used,
andthe horsepower ofthe tractor usedto operate themixer.
The mixer is designated for operation by a 50 to 115 hp (28
to 86 kW) 540 RPM tractor or by a 50 to 145 hp (38 to 109
kW) 1000 RPM tractor.
Mill & Blower Operation
Material enters the cylinder chamber through the mill inlet and is
drawn into the cylinder by a vacuum below the cylinder. The
vacuum below the cylinder is obtained by the physical location of
the blower Inlet below the cylinder.
The21”cylinderis composed of sixty-six swinging hammers which
are equally divided among three rows around the cylinder.As the
cylinder rotates at the recommended speed of 2700 RPM, the
hammersgrind the materialand force itthrough the screen.Once
throughthescreen,thegroundmaterialdropsdown to the transfer
auger and is conveyed to the mixing tank. Lightweight chaff or
dust is drawn into the blower inlet and forced by the blower up
intothecollectorwhereitisrefinedandseparated.Heavy particles
are directed back down into the transfer auger and conveyed to
the mixing tank.
