Chapter 1 Overview
Description
DS-PEA series of active panic alarm station supports dual network ports. It provides200W high-
definition camera, center call, strobe light work schedule, two-way audio, remote/local open
electric lock, external network camera to increase field of view and other functions. The device
supports video call with the center, and linkage with the surrounding cameras and external lamp,
sound box, etc. It helps to realize alarm aid in emergency.
The device is mainly used in classrooms, corridors, laboratories, dormitories, offices, hospital
wards, etc.
Key Features
●Supports network adaptive, video and audio adaptive, and low video and audio delay in the case
of network packet loss
●Two-way audio with center
●Video collection and all-day monitoring with 2 MP HD IR camera
●Supports accessing one channel of network camera
●Supports H.264/H.265
●Supports G.711U, G726, OPUS, and AAC
●Supports video storage
●Built-in omnidirectional microphone to realize 2 m two-way audio distance, 10 m listening
distance
●Multiple network protocols including SIP, Private SIP, ISUP, and RTSP
●3.5 mm standard audio interface for external active speaker
●Supports anti-breaking with full-band high-quality speaker and pickup
●Optional wireless communication module to meet different network environments
●Supports dual network ports

Panic Alarm Station Configuration Guide
2
Chapter 2 Activation
In order to protect personal security and privacy and improve the network security level, you
should activate the device the first time you connect the device to a network.
2.1 Activate via SADP
SADP is a tool to detect, activate and modify the IP address of the device over the LAN.
Before You Start
●Get the SADP software from the supplied disk or the official website
http://www.hikvision.com/en/, and install the SADP according to the prompts.
●The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to activate a device and modify its IP address. For batch activation
and IP addresses modification, refer to User Manual of SADP for details.
Steps
1. Run the SADP software and search the online devices.
2. Find and select your device in online device list.
3. Input new password (admin password) and confirm the password.
Caution
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case letters, lower case
letters, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your product.
4. Click Activate to start activation.

Panic Alarm Station Configuration Guide
3
Figure 2-1 Activate via SADP
Status of the device becomes Active after successful activation.
5. Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to activate your IP address modification.
2.2 Activate Device via Client Software
Before You Start
●Get the iVMS-4200 client software from the supplied disk or the official website
http://www.hikvision.com/en/. Install the software by following the prompts.
●Get the Guarding Vision client software from the supplied disk. Install the software by following
the prompts.
●The device and the PC that runs the software should be in the same subnet.
Steps
1. Run the client software.
2. Enter Device Management → Device in the Maintenance and Management list.
3. Click Online Device.
4. Check the device status from the online device list, and select an inactive device.
5. Click Activate.
6. Create and confirm the admin password of the device.

Panic Alarm Station Configuration Guide
4
Caution
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case letters, lower case
letters, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your product.
7. Click OK to start activation.
Device status will change to Active after successful activation.
8. Edit IP address of the device.
1) Select a device and click on the online device list.
2) Change the device IP address to the same subnet with your computer.
3) Enter the admin password of the device and click OK to complete modification.
9. Optional: Check the device on the online device list and click Add to add the device to the
device list.

Panic Alarm Station Configuration Guide
5
Chapter 3 Remote Settings
In the client software, go to Control Panel → Device Mnagement, click and select the device in the
Device for Management, and click Remote Configuration to go to Remote Configuration page.
Note
●The device should be activated the first time it is used to log in and use properly. See Activation
to activate the device.
●You need to add the device to the client software before configure it. See Add Device to the
Client Software.
●Get the client software from the technical support, and install the software according to the
prompts.
3.1 Device Management
3.1.1 Add Device to the Client Software
Before You Start
Activate the device and ensure that the device is on the same subnet as the PC.
Figure 3-1 Client Software Main Page
In the client software, go to Device Management → Device on the Maintenance and
Management list. You can add devices to client software by several methods on the device

Panic Alarm Station Configuration Guide
6
management page. The following describes how to add devices through IP/Domain Name. For
more information, see iVMS-4200 Client Software User Manual.
Steps
1. On the Device page, click Add.
2. Select IP/Domain as the adding mode, edit the device information, including Name, Address,
Port, User Name, and Password.
3. Check Import to Group.
4. Click Add to add the device.
3.1.2 Edit Network Parameters
Edit the device network parameters so that the device IP address is in the same subnet as the
computer IP address.
You can edit the network parameters through the SADP software, or the client software. The SADP
software is taken as an example for explanation.
Steps
1. Run the SADP software, check the activated device, and edit the IP Address, Subnet Mask,
Gateway and other parameters in the Modify Network Parameters list on the right.
Note
If check Enable DHCP, the device can automatically obtain network parameters.
2. Enter the activation password, click Modify, and the prompt Modify parameters is successful
indicate that the settings take effect.
3.2 Network Configuration
3.2.1 Basic Settings
Configure network mode, IP address, NIC and NIC type, subnet mask, gateway, MAC address, MTU
settings, and port No. for device.
Before You Start
Make sure the cable of the device is connected.

Panic Alarm Station Configuration Guide
7
Steps
Note
The network mode is multiple networks mode, you can set the basic network parameters for
NIC 1 and NIC 2.
1. On the Remote Configuration page, go to Network → General.
Figure 3-2 Network Basic Settings Page
2. Select the NIC and the NIC type.
3. Set the network address.
–Automatically obtain the network address
Check Auto-obtain, the device automatically obtains the network address (IPv4 Address,
Subnet Mask (IPv4), Default Gateway (IPv4)) through DHCP.
Note
NIC 1 and NIC 2 are independent of DHCP.
–Manually set the network address
According to the actual network environment, manually set the network address IPv4
Address, Subnet Mask (IPv4), Default Gateway (IPv4).
4. Set the MTU(Byte), Device Port, HTTP port, RTSP port, and Default NIC for the device.
MTU(Byte)
Maximum transmission unit, which refers to the maximum packet size passed by TCP/UDP
protocol network transmission. The default is 1500.

Panic Alarm Station Configuration Guide
8
Device Port
The default device port number is 8000.
HTTP port
The default port number is 80, and it can be changed to any port No. which is not occupied.
RTSP port
The default port number is 554 and it can be changed to any port No. ranges from 1 to 65535.
Default NIC
The default NIC is NIC 1 and it can be set to NIC 1 or NIC 2.
5. Click Save to save the settings.
3.2.2 Set DNS
When the device accesses the network through the domain name, you need to configure the
correct and available DNS server IP address.
The device supports 2 DNS address.
On the Remote Configuration page, go to Network → DNS, set the DNS server IP address and click
Save to save the settings.
Figure 3-3 DNS Setting Page
3.2.3 Set NAT
Enable the UPnP function, and you don't need to configure the port mapping for each port, and
the device is connected to the Wide Area Network via the router.
Steps
Note
Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among
networking equipment, software and other hardware devices. The UPnP protocol allows devices
to connect seamlessly and to simplify the implementation of networks in the home and
corporate environments.
1. On the Remote Configuration page, go to Network → NAT.

Panic Alarm Station Configuration Guide
9
Figure 3-4 NAT Setting Page
2. Check Enable UPnP, and set Mapping Types as Manual or Auto.
–Set Mapping Types as Auto
The Ports are read-only, and the external ports are set by the router automatically.
–Set Mapping Types as Manual
You can edit the external port on your demand. And then you should enable UPnP function
on the router.
Caution
Please do not arbitrarily edit the default port number. If there is a port conflict and you need
to edit the port number, please modify the port number as follows.
HTTP Port
By default, the value of the HTTP port No. is 80.
Server Port
By default, the value of the Server port No. is 8000. If the value is changed, you need to
enter the server port number on the login page when you log in the device by client
software.
RTSP Port
Real-time transport protocol port, please make sure that the port you modified is available.
By default, the value of the RTSP port No. is 554.
3. Click Save to save the settings.

Panic Alarm Station Configuration Guide
10
3.2.4 Set Alarm Center
Configure the alarm center. When an alarm is triggered, the alarm information can be uploaded to
the configured alarm center.
Steps
1. On the Remote Configuration page, go to Network → Network Center Configure.
Figure 3-5 Alarm Center Configuration
2. Select a NIC.
Note
The device supports two wired networks and one wireless network. Each network supports
uploading alarm information to one alarm center.
3. Check Enable Upload Center to enable the alarm center, and set the upload center parameters.
Notify Surveillance Center
Each NIC supports only one upload center, and the default is Net Center 1.
Server Type
The address type of the upload center server. You can set Server Type as IP4/IP6 or Domain
Name.
IP Address/Server Domain Name
Enter the server IP address or server domain name according to the server type you set.
Port
The port number of the upload center. The HIK protocol defaults to 7200; the NAL2300
protocol needs to be set to 4001.
Protocol Type
The default is HIK. Can be set to HIK or NAL2300.

Panic Alarm Station Configuration Guide
11
User Name
Supports numbers and letters. The HIK protocol can be set to a length ranging from 6 to 9
digits; the NAL2300 protocol can be set to a length of 6 digits.
Note
If you set the protocol type as HIK, you do not need to edit the user name.
4. Click Save.
3.2.5 Set SIP
After the SIP server address is set, the device actively registers to the SIP server, and devices under
the same SIP server address can communicate with each other.
Steps
1. On the Remote Configuration page, go to Network → SIP Settings.
Note
The SIP parameters need to be configured will vary as the selected intercom protocol type. For
intercom protocol settings, please see 3.2.11Set Intercom Parameters.
Figure 3-6 SIP Setting Page (Private Protocol)
Figure 3-7 SIP Setting Page (SIP Protocol)
Login Status
Display the status of the device registers to the SIP server.
2. Select the Server Address Type as IP Address or Domain Name.
3. According to the selected address type, enter the IP address or domain name of the SIP server.
4. Set the Port and the Local Listening Port.

Panic Alarm Station Configuration Guide
12
Port
The SIP server port. By default, the private SIP port is 5065 and the standard SIP port is 5060.
The available server port number should be between 1024 and 65535.
Local Listening Port
The local port of the device SIP function. By default, the local listening port is 5060. The
available port number should be between 1024 and 65535.
5. Configure the SIP parameters according to the selected intercom protocol.
–If configuring the SIP parameters based on Private Protocol, please set the Device Serial No.,
Display Name, Local Listening Port Register Period (min) and Network Mode.
If configuring the SIP parameters based on SIP Protocol, please enter the User Name, Password
and Called User.
Device Serial No.
Device ID is the unique identification of the device, facilitating the communication between
the devices.
Display Name
You can enter the position information of the device for easy management.
Register Period (min)
The interval that the device continuously registers to the SIP server, the register period
ranges from 1 to 30 (min).
Network Mode
Select the Network Mode as Wired Network 1, Wired Network 2 or Wireless Network.
Note
When you select a wired network, the wired network is used regardless of whether the wired
network is normal; when you select a wireless network, only the wireless network is used.
User Name
The user name which the device registers to the SIP server.
Password
The password which the device registers to the SIP server.
Called User
The user name of the user which the device calls.
6. Click Save.
3.2.6 Data Limit
Enable the data limit for the 3G/4G wireless network. Once the data traffic exceeds the set
threshold, the data traffic excess alarm is uploaded to the platform and the user will receive a
