Hioki BT3563A User manual

BT3563A
Instruction Manual
BATTERY HiTESTER
EN
Jan. 2021 Revised edition 9
BT3562A981-09 21-01H
Be sure to read this manual before using the instrument. p.3
When using the instrument for the
rst time Troubleshooting
Names and Functions of Parts p.11 Maintenance and Service p.189
Measurement Preparations p.19 Error Display p.191
BT3562A
BT3561A
BT3563
BT3563-01
BT3562
BT3562-01
HIOKI BT3562A981-09

HIOKI BT3562A981-09

Contents
i
Contents
Introduction.................................................................................1
Verifying Package Contents .......................................................2
Safety Information ......................................................................3
Operating Precautions............................................................... 5
Chapter 1
Overview ___________________________________ 9
1.1 Product Overview ................................................................9
1.2 Features ............................................................................10
1.3 Names and Functions of Parts ..........................................11
1.4 Menu Display Sequence (SHIFT ENTER) .....................16
1.5 Measurement Flowchart ...................................................17
Chapter 2
Measurement Preparations___________________ 19
2.1 Preparation Flowchart .......................................................19
2.2 Connecting the Power Cord.............................................. 20
2.3 Connecting the Optional Test Leads................................. 21
2.4 Turning the Power On and Off ..........................................22
2.5 Selecting the Line Frequency ...........................................24
Chapter 3
Measurement ______________________________ 25
3.1 Pre-Operation Inspection ..................................................25
3.2 Basic Measurement Example ...........................................26
Preparations ........................................................................26
Instrument Settings ............................................................. 27
Zero-Adjustment ..................................................................28
Measurement ......................................................................29
3.3 Selecting Measurement Mode ..........................................30
3.4 Setting Measurement Range ............................................31
Resistance measurement range .........................................31
Voltage measurement range ...............................................32
Auto-Ranging ......................................................................33
3.5 Setting Sampling Rate ......................................................34
3.6 Zero-Adjust Function .........................................................35
Wiring Method for Zero-Adjustment .................................... 35
Executing Zero-Adjustment................................................. 35
3.7 Displaying Measurement Results .....................................38
4
5
6
7
8
9
10
11
12
Appendix Index
10
BT3562A981-09
HIOKI BT3562A981-09

Contents
ii
Measurement Fault Detection ............................................ 39
Overflow Display ................................................................. 40
Chapter 4
Applied Measurement _______________________41
4.1 Comparator Function ........................................................ 42
Comparator Setting Example 1
(Upper and Lower Threshold Judgment) ............................ 43
Comparator Setting Example 2
(Reference Value and Tolerance Judgment) ...................... 47
Comparator Judgment Beeper Setting ............................... 52
Comparator Execution Mode Setting .................................. 52
Comparator Threshold Method Selection ........................... 53
Upper and Lower Thresholds Setting
(by Reference Value and Tolerance) .................................. 54
Configuring the Absolute Value Judgment Function
(Voltage) ............................................................................. 55
Enabling and Disabling the Comparator Function .............. 56
Comparator Judgment Results ........................................... 57
Switching Between Measurement Value and Comparator
Setting Displays .................................................................. 58
4.2 Trigger Function ................................................................ 59
Trigger Source Settings ...................................................... 59
Trigger Delay Settings ........................................................ 60
4.3 Measurement Current Pulse Output Function ..................61
4.4 Averaging Function ........................................................... 63
4.5 Statistical Calculation Functions ....................................... 64
4.6 Memory Function .............................................................. 68
4.7 Key-Lock Function ............................................................ 70
4.8 Panel Save Function ......................................................... 71
4.9 Panel Load Function ......................................................... 72
4.10 Self-Calibration ................................................................. 73
4.11 Measurement Value Output Function ............................... 74
4.12 Key Beeper Setting ........................................................... 75
4.13 Reset Function .................................................................. 76
Chapter 5
External Control (EXT I/O) ____________________79
5.1 Overview........................................................................... 79
5.2 Signal Descriptions ........................................................... 80
Pinout ................................................................................. 80
Input Signals ....................................................................... 81
Output Signals .................................................................... 82
ERR Output ........................................................................ 83
Instrument Settings ............................................................. 84
HIOKI BT3562A981-09

Contents
iii
5.3 Timing Chart .....................................................................85
5.4 Internal Circuitry ................................................................87
5.5 External Control Q&A ........................................................90
Chapter 6
Printing ___________________________________ 91
6.1 Connecting the Printer ......................................................91
Connecting the PRINTER to the Instrument .......................92
6.2 Selecting the Interface ......................................................93
6.3 Printing ..............................................................................94
Chapter 7
Analog Output _____________________________ 97
7.1 Connecting Analog Output ................................................97
7.2 Analog Output Specifications ............................................98
Chapter 8
RS-232C/GP-IB/LAN Interfaces________________ 99
8.1 Overview and Features .....................................................99
8.2 Specifications ..................................................................100
RS-232C Specification.......................................................100
LAN Specifications ............................................................100
GP-IB Specifications (Model BT3562-01 only) ..................101
8.3 Selecting the Connections and Protocol ........................102
Attaching the Connector ....................................................102
Selecting the Interface ......................................................105
Setting LAN communications ............................................106
8.4 Communication Methods ................................................108
Message Format ...............................................................108
Output Queue and Input Buffer .........................................112
Status Byte Register .........................................................113
Event Registers .................................................................115
Initialization Items ..............................................................118
Local Function....................................................................118
8.5 Message List ...................................................................119
Standard Commands ........................................................119
Device-Specific Commands ..............................................121
8.6 Message Reference ........................................................126
Standard Commands ........................................................127
Device-Specific Commands ..............................................131
Measurement Value Formats ............................................159
Command Compatibility with the
Model 3560 AC m HiTESTER......................................... 160
HIOKI BT3562A981-09

Contents
iv
8.7 Basic Data Importing Methods ........................................ 165
8.8 Sample Programs ........................................................... 166
To be prepared in Visual Basic® 5.0/6.0 ........................... 166
To be prepared in Visual Basic® 2005 .............................. 176
Creation Procedure(Visual Basic® 2005) ......................... 176
Sample Programs(Visual Basic® 2005) ............................ 178
Chapter 9
Specifications _____________________________181
9.1 Basic Specifications ........................................................ 181
9.2 Accuracy ......................................................................... 186
9.3 General Specifications .................................................... 188
Chapter 10
Maintenance and Service ___________________189
10.1 Troubleshooting .............................................................. 189
10.2 Cleaning .......................................................................... 191
10.3 Error Display ................................................................... 191
Chapter 11
License Information ________________________193
Appendix ________________________________ A 1
Appendix 1 Precautions for Making Custom Test Leads ...............A 1
Appendix 2 AC Four-terminal Method............................................A 4
Appendix 3 Measurement values when using four-terminal
measurement (Differences in measurement
values due to measurement leads used) ....................A 5
Appendix 4 Synchronous Detection System ..................................A 6
Appendix 5 Configuration and Extension of the Test Leads ..........A 7
Appendix 6 Effect of Eddy Currents ...............................................A 8
Appendix 7 Calibration Procedure..................................................A 9
Appendix 8 Zero Adjustment........................................................A 10
Appendix 9 Test Lead Options.....................................................A 15
Appendix 10Rack Mounting ..........................................................A 17
Appendix 11Dimensional Diagram................................................A 19
Index ________________________________ Index i
HIOKI BT3562A981-09

Introduction
1
Thank you for purchasing the HIOKI “Model BT3561A, BT3562A, BT3562, BT3562-01, BT3563A,
BT3563, and BT3563-01 BATTERY HiTESTER. ” To obtain maximum performance from the instru-
ment, please read this manual first, and keep it handy for future reference.
Please review the separate “Operating Precautions” before using the instrument.
This manual uses the following conventions:
The Model BT3561A, BT3562A, BT3562, BT3562-01, BT3563A, BT3563, and BT3563-01 are referred to as
"the instrument."
Unless otherwise noted, the Model BT3562, BT3562-01, and BT3562A are referred to collectively as "Model
BT3562," while the Model BT3563, BT3563-01, and BT3563A are referred to collectively as "Model BT3563."
Trademarks
Microsoft, Windows, Visual Studio, Visual Basic, Edge, and Visual C# are either registered trademarks or
trademarks of Microsoft Corporation in the United States and other countries.
Introduction
HIOKI BT3562A981-09

Verifying Package Contents
2
When you receive the instrument, inspect it carefully to ensure that no damage occurred during
shipping. In particular, check the accessories, panel switches, and connectors. If damage is evident,
or if it fails to operate according to the specifications, contact your dealer or Hioki representative.
Use the original packing materials when transporting the instrument, if possible.
Options The following options are available for the instrument. Contact your authorized
Hioki distributor or reseller when ordering.
The options are subject to change. Visit our website for updated information.
 Model L2107 CLIP TYPE LEAD (60 VDC or less)
 Model 9453 FOUR TERMINAL LEAD (60 VDC or less)
 Model 9467 LARGE CLIP TYPE LEAD (50 VDC or less)
 Model 9770 PIN TYPE LEAD (60 VDC or less)
 Model 9771 PIN TYPE LEAD (60 VDC or less)
 Model L2100 PIN TYPE LEAD (1000 VDC or less)
 Model L2110 PIN TYPE LEAD (1000 VDC or less)
 Model Z5038 0 ADJ BOARD (for model L2100 and L2110)
 Model 9637 RS-232C CABLE (9-pin to 9-pin/cross cable)
 Model 9638 RS-232C CABLE (9-pin to 25-pin/cross cable)
 Model 9151-02 GP-IB CONNECTOR CABLE (2 m)
 Model 9642 LAN CABLE
Verifying Package Contents
Confirm that these contents are provided. (One each)
 Model BT3561A BATTERY HiTESTER
Model BT3562 BATTERY HiTESTER
Model BT3562-01 (GP-IB version) BATTERY HiTESTER
Model BT3562A (LAN version) BATTERY HiTESTER
Model BT3563 BATTERY HiTESTER
Model BT3563-01 (GP-IB version) BATTERY HiTESTER
Model BT3563A (LAN version) BATTERY HiTESTER
 Instruction Manual
 Power Cord
 Operating Precautions (0990A903)
HIOKI BT3562A981-09

Safety Information
3
This manual contains information and warnings essential for safe operation of
the instrument and for maintaining it in safe operating condition. Before using it,
be sure to carefully read the following safety precautions.
The following symbols in this manual indicate the relative importance of cautions
and warnings.
Symbols for Various Standards
Other Symbols
Safety Information
This instrument is designed to comply with IEC 61010 Safety Standards, and
has been thoroughly tested for safety prior to shipment. However, mishandling
during use could result in injury or death, as well as damage to the instrument.
Be certain that you understand the instructions and precautions in the manual
before use. We disclaim any responsibility for accidents or injuries not resulting
directly from instrument defects.
In the manual, the symbol indicates particularly important information
that the user should read before using the instrument.
The symbol printed on the instrument indicates that the user should
refer to a corresponding topic in the manual (marked with the symbol)
before using the relevant function.
Indicates a grounding terminal.
Indicates DC (Direct Current).
Indicates the ON side of the power switch.
Indicates the OFF side of the power switch.
Indicates that incorrect operation presents an extreme hazard that
could result in serious injury or death to the user.
Indicates that incorrect operation presents a significant hazard that
could result in serious injury or death to the user.
Indicates that incorrect operation presents a possibility of injury to
the user or damage to the instrument.
Indicates advisory items related to performance or correct opera-
tion of the instrument.
This symbol indicates that the product conforms to regulations set out by
the EU Directive.
Indicates a prohibited action.
(p. ) Indicates the location of reference information.
Indicates quick references for operation and remedies for troubleshoot-
ing.
*Indicates that descriptive information is provided below.
HIOKI BT3562A981-09

Safety Information
4
Screen display The screen of this instrument displays characters in the following manner.
Measurement categories
To ensure safe operation of measurement instruments, IEC 61010 establishes
safety standards for various electrical environments, categorized as CAT II to
CAT IV, and called measurement categories.
Using a measurement instrument in an environment designated with a higher-
numbered category than that for which the instrument is rated could result in a
severe accident, and must be carefully avoided.
Use of a measurement instrument that is not CAT-rated in CAT II to CAT IV
measurement applications could result in a severe accident, and must be care-
fully avoided.
Accuracy
Hioki expresses accuracy as error limit values specified in terms of
percentages relative to reading and full scale, and digits.
CAT II Primary electrical circuits in equipment connected to an AC electrical outlet
by a power cord (portable tools, household appliances, etc.)
CAT II covers directly measuring electrical outlet receptacles.
CAT III Primary electrical circuits of heavy equipment (fixed installations) connect-
ed directly to the distribution panel, and feeders from the distribution panel
to outlets.
CAT IV The circuit from the service drop to the service entrance, and to the power
meter and primary overcurrent protection device (distribution panel).
Full scale
(Maximum displayable value)
Refers to the maximum displayable value of each measurement range.
The instrument has measurement ranges whose values are equal to the max-
imum displayable values. The limit values of full-scale errors are expressed in
percent of full scale (% of full scale, % f.s.).
Reading (Displayed value)
Refers to the displayed value of the measuring instrument.
The limit values of reading errors are expressed in percent of reading (% of
reading, % rdg).
Digits (Resolution)
Refers to the smallest change in the indication on the digital measuring instru-
ment, i.e., the numeral one in the rightmost place. The limit values of digit
errors are expressed in terms of digits (dgt).
HIOKI BT3562A981-09

Operating Precautions
5
Follow these precautions to ensure safe operation and to obtain the full benefits
of the various functions.
Use of the instrument should confirm not only to itsspecifications, but also to the
specifications of all accessories, options, and other equipment in use.
Operating temperature and humidity:
0 to 40°C (32 ± 104°F), 80%RH or less (non-condensating)
Temperature and humidity range for guaranteed accuracy:
23 ± 5°C (73 ± 9°F), 80% RH or less (non-condensating)
Installation Precautions
• The instrument should be operated only with the bottom downwards.
• Do not place the instrument on an unstable or slanted surface.
Operating Precautions
Instrument Installation and Operating Environment
Avoid the following locations that could cause an accident or damage to the
instrument.
Exposed to direct sun-
light
Exposed to high tem-
perature
In the presence of cor-
rosive or explosive gas-
es
Exposed to water, oil,
other chemicals, or
solvents
Exposed to high hu-
midity or condensa-
tion
Exposed to strong elec-
tromagnetic fields
Near electromagnetic
radiators
Exposed to high lev-
els of particulate dust
Subject to vibration
To avoid electric shock, do not remove the instrument's case. The internal com-
ponents of the instrument carry high voltages and may become very hot during
operation.
Avoid using near electrically noisy devices, as the noise may impinge upon the
test object and cause unreliable measurements.
The instrument can be used with the stand. (p.15)
It can also be rack-mounted. Appendix (p. A17)
50 mm or more 10 mm or more
Rear
50 mm or more
HIOKI BT3562A981-09

Operating Precautions
6
Before using the instrument the first time, verify that it operates normally to
ensure that the no damage occurred during storage or shipping. If you find any
damage, contact your dealer or Hioki representative.
Preliminary Checks
Before using the instrument, make sure that the insulation on the power cord
and test leads is undamaged and that no bare conductors are improperly
exposed. Using the instrument in such conditions could cause an electric
shock, so contact your dealer or Hioki representative for replacements.
Measurement Precautions
• To avoid electrical shock, be careful to avoid shorting live lines with the test
leads.
• Do not use the instrument to measure circuits that exceed its ratings or spec-
ifications. Damage to the instrument or overheating can cause anelectric
shock.
• The maximum input voltage and maximum rated voltage are shown in the
following table.
• Never connect a battery cell or module to a motor or other load while it is
being measured. Doing so may result in a surge voltage, which may damage
the instrument or cause injury.
See:"9.1 Basic Specifications" (p.181)
Model Maximum input voltage Maximum rated voltage
to earth
BT3561A ± 60 V DC ± 60 V DC
BT3562
BT3562-02
± 60 V DC ± 70 V DC
BT3562A ± 100 V DC ± 100 V DC
BT3563 ± 300 V DC ± 300 V DC
• To prevent electrical shock, verify the ratings of the measurement leads
before measurement and exercise care not to measure voltages that exceed
those ratings.
• Do not touch the metallic tip of probes after measuring high-voltage batter-
ies. Doing so may result in electrical shock since internal instrument compo-
nents could retain a charge under those conditions. (Internal discharge time:
Approx. 20 sec.)
• To avoid short-circuit accidents, connect the probe's banana terminals to the
instrument before connecting the probes to the battery.
HIOKI BT3562A981-09

Operating Precautions
7
• Use only the specified test leads and cables. Using a non-specified cable may
result in incorrect measurements due to poor connection or other reasons.
• To ensure certified measurement accuracy, allow at least 30 minutes warm-
up. After warm-up, be sure to execute self-calibration.
See "4.10 Self-Calibration" (p.73).
• The input circuitry includes a protective fuse. Measurement is not possible
when the fuse is blown.
• This instrument internally stores (backs up) all settings (except memory func-
tion and measurement values), such as measurement range, comparator
settings and etc., but only when no operation is performed for a certain time.
Therefore, to preserve settings, do not turn the power off for a short time
(about five seconds) after changing a setting. However, measurement set-
tings made through the RS-232C, LAN, or GP-IB interface and measurement
settings loaded by LOAD signals of the EXT I/O connector are not memo-
rized.
• Select an appropriate measurement range when measuring batteries. Using
a low range such as 3 m to measure a button cell or other battery that has
high internal resistance may result in an open-terminal voltage (approx. 4
V), causing the battery to be charged.
Before Connecting and Powering On
• Before turning the instrument on, make sure the supply voltage matches that
indicated on the its power connector. Connection to an improper supply volt-
age may damage the instrument and present an electrical hazard.
• To avoid electrical accidents and to maintain the safety specifications of this
instrument, connect the power cord provided only to a 3-contact (two-con-
ductor + ground) outlet.
To suppress noise, the instrument needs to be set to match the frequency of
the power source. Before operating, set the instrument to the frequency of your
commercial power. If the supply frequency is not set properly, measurements
will be unstable.
See "2.5 Selecting the Line Frequency" (p.24).
Make sure the power is turned off before connecting or disconnecting the
power cord.
Handling the Instrument
• To avoid damage to the instrument, protect it from physical shock when
transporting and handling. Be especially careful to avoid physical shock from
dropping.
• Do not apply heavy downward pressure with the stand extended. The stand
could be damaged.
This instrument may cause interference if used in residential areas. Such use
must be avoided unless the user takes special measures to reduce electro-
magnetic emissions to prevent interference to the reception of radio and televi-
sion broadcasts.
HIOKI BT3562A981-09

Operating Precautions
8
Handling the Test Leads and Cables
• To avoid breaking the test leads and cables, do not bend or pull them.
• Avoid stepping on or pinching cables, which could damage the cable insula-
tion.
• To avoid equipment failure, do not disconnect the communications cable
while communications are in progress.
• Use a common ground for both the instrument and the computer. Using dif-
ferent ground circuits will result in a potential difference between the instru-
ment's ground and the computer's ground. If the communications cable is
connected while such a potential difference exists, it may result in equipment
malfunction or failure.
• Before connecting or disconnecting any the communications cable, always
turn off the instrument and the computer. Failure to do so could result in
equipment malfunction or damage.
• After connecting the communications cable, tighten the screws on the con-
nector securely. Failure to secure the connector could result in equipment
malfunction or damage.
HIOKI BT3562A981-09

1.1 Product Overview
9
1
Chapter 1 Overview
The Model BT3561A, BT3562 and BT3563 Battery Hitester measure battery
internal resistance using a four-terminal, 1-kHz AC method, while simultaneously
measuring DC voltage (electromotive force [emf]). The high-precision, fast mea-
surement performance and extensive interface capabilities make these models
ideal for incorporating into battery testing production lines.
Overview Chapter 1
1.1 Product Overview
HIOKI BT3562A981-09

1.2 Features
10
The four-terminal AC method measures resistance and DC voltage simultane-
ously, so battery internal resistance and emf are measured and judged at once.
Resistance measurement resolution of 1  or 0.1  and voltage measure-
ment resolution of 10 V. The voltage measurement accuracy of ±0.01% of
reading is achieved.
Simultaneous resistance and voltage measurements can be performed as fast
as once every 20 ms.
(Response time of approx. 10 ms + sampling time of approx. 8 ms)
The Model BT3563 supports measurement of high-voltage batteries of up to 300 V.
(the Model BT3561A, BT3562, and BT3562-01 supports measurement of up to
60 V) (the Model BT3562A supports measurement of up to 100 V)
Resistance and voltage measurement values are judged in three categories (Hi,
IN and Lo), with results clearly displayed. A comparator judgment beeper also
provides distinct sounds to indicate pass/fail judgments and to facilitate correct
recognition of judgment results.
Maximum, minimum and average measurement values, standard deviation, pro-
cess capability indices and other values can be automatically calculated for
applications such as production management. Calculation results can also be
applied as comparator setting values.
The instrument includes a Memory function and storage capacity for up to 400
pairs of measurement values. When making many sequential measurements at
high speed and sending the measured values to a PC after each measurement,
the time to switch test objects can become unsatisfactorily long. The Memory
function can avoid the slow-down by sending stored measurements in batches
during idle times.
EXT I/O and RS-232C interfaces are equipped as standard, supporting transfer
rates up to 38,400 bps.
• Model BT3562-01 and BT3563-01 also supports GP-IB and analog output.
• Model BT3561A, BT3562A, and BT3563A also supports LAN and analog out-
put.
Connect the printer to print measurement values and statistical calculation
results.
1.2 Features
Simultaneously Measures Battery Internal Resistance and Volt-
age
High-Precision Measurements
High-Speed Measurements
High-voltage measurement
Comparator Functions
Statistical Calculation Functions
Measurement Value Memory Function
EXT I/O Interface
Printing Measurement Values and Statistical Results
HIOKI BT3562A981-09

1.3 Names and Functions of Parts
11
1
Chapter 1 Overview
1.3 Names and Functions of Parts
Front Panel
POWER Switch
Turns the instrument on and off (Standby).
Turns the power on and off (standby).
Off (standby) On (cancel standby)
On (press and hold for 1 second) Off (standby)
(The main power switch is located on the back of the instrument.)
Input Terminals (INPUT)
Connect the optional test leads.
See "2.3 Connecting the Optional Test Leads" (p.21)
Operating Keys
(p.13)
Sub Display
(p.12)
SOURCE-H
SOURCE-L
SENSE-H
SENSE-L
Main Display
(p.12)
See "2.4 Turning the Power On and Off" (p.22)
HIOKI BT3562A981-09

1.3 Names and Functions of Parts
12
Lit when measuring
voltage.
Indicates percentage
units during relative
value comparator op-
eration.
Shows measured
value or setting item.
Main Display
(Upper row)
AUTO Lit when measuring with Auto-Ranging.
EX.FAST, FAST, MED, SLOW
The selected Sampling Rate is lit.
0 ADJ Lit when measuring in a range for
which Zero-Adjustment has been per-
formed.
MEM Lit when the Memory function is en-
abled.
EXT TRIG Lit when the External Trigger function
is enabled.
(Lower row)
VLit when the V (Resistance and
Voltage measurement) mode is se-
lected.
STAT Lit when the Statistical Calculation
function is enabled.
AVG Lit when measuring with the Averag-
ing setting enabled.
LOCK Lit when the keys are locked.
REMOTE Lit during communications.
The current measurement mode is indicated while measuring, and the setting item is displayed while
making settings.
Shows Comparator Decision Result.
Hi Indicates that the measured value is
above the upper threshold.
IN
Indicates that the measured value is be-
tween the upper and lower thresholds.
Lo Indicates that the measured value is be-
low the lower threshold.
Units of displayed measurement
VUnit of voltage
Unit of resistance (lit when the 3
 to 3000  range is selected)
mUnit of resistance (lit when the 3
m300 m range is select-
ed)
Indicates Voltage mea-
surement mode
Indicates percentage
units during relative value
comparator operation
While measuring, indi-
cates the Comparator
function is enabled.
HIGH, LOW Indicates that absolute value comparator operation is enabled
(while measuring), and also when setting.
REF, % Indicates that relative value comparator operation is enabled
(while measuring), and also when setting.
VIndicates voltage measurement units.
Upper and lower thresholds and other settings are displayed (when set).
Sub Display
HIOKI BT3562A981-09

1.3 Names and Functions of Parts
13
1
Chapter 1 Overview
Operating Keys
To use a function marked on a
key, just press the key.
To use a function printed un-
der a key (blue letter), press
the SHIFT key first (and con-
firm the SHIFT lamp is lit),
and then the key.
SHIFT Lamp
Use numeric key-
pads to enter nu-
merical values.
(Numerical values
can be used with
the RANGE key.)
[ ]: Enabled after pressing the SHIFT key (SHIFT lamp lit).
Operating
Key
Description
V/ / V Selects Measurement mode.
(Resistance and voltage measure-
ment, Resistance measurement or
Voltage measurement)
[0 ADJ] Executes Zero-Adjustment.
LOAD Loads a saved measurement configu-
ration (Panel settings).
[SAVE] Saves the current measurement con-
figuration (Panel settings).
TRIG Executes a Manual Trigger event.
[INT/EXT] Selects internal/external triggering.
VIEW Switches the view mode of the V
mode.
STAT Displays and sets Statistical Calcula-
tion results.
[DELAY] Sets the Trigger Delay.
SMPL Selects the Sampling Rate.
[AVG] Activates Averaging function settings.
COMP Switches the Comparator function on
and off.
[SET] Activates Comparator function setting.
LOCAL Cancels remote control (RMT) and re-
enables key operations.
Operating
Key
Description
PRINT
Sends measurement values and statis-
tical calculation results to the printer.
AUTO Switches between Auto and Manual
range selection.
[LOCK]
Switches the Key-Lock function on and
off.
ENTER Applies settings.
[MENU] Selects various operating functions
and settings.
RANGE Up/Down:
Changes setting value or numerical
value, and sets the resistance mea-
surement range.
Left/Right:
Moves the setting item or digit.
[V RANGE]Up/Down:
Sets voltage measurement range.
SHIFT • Enables the functions of the operat-
ing keys marked in blue.
The lamp is lit when the SHIFT
state is active.
• Cancels settings in various setting
displays. (Returns to the Measure-
ment display without applying set-
tings.) However, this does not apply
to Menu display. However, from a
menu item display, changed set-
tings are not canceled, but
accepted as the display returns to
measurement display (except after
Zero-Adjustment clear or resetting).
HIOKI BT3562A981-09

1.3 Names and Functions of Parts
14
* The illustration shows the Model BT3563A Battery Hitester (LAN version).
Rear Panel
1
2
45
* The illustration shows the Model BT3563-01 Battery Hitester (GP-IB version).
1
2
3
78
6
3
HIOKI BT3562A981-09
