HOMCOM A91-192 Installation guide

ASSEMBLY & INSTRUCTION MANUAL
INadd045_UK
A91-192
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

A:Base
B: Cap
C: Spring cover
D: Ball
E: Spring assembly
F: Socket head cap screw
G: Steel pipe
H: Bolt
I: Steel pipe
J: washer
K: Pump
M: Steel pipe sleeve
N: Suction cup
WARNING:
Before using the Free Standing Bag you are urged to contact a physician to be
sure that your hands, wrists, elbows, shoulders and back are suitably condi-
tioned withstand the rigors of punching this equipment.
it is recommended that you use well-padded Bag Gloves together with hand
wraps. They provide a degree of protection but it not warranted that this will
avoid any injury.
When using this equipment be sure that you are in good physical condition and
under expert supervision. Before each and every use be sure the equipment is
in good condition and properly fastened.
Use of any sports equipment subjects the used to a degree of risk. Users of this
equipment must assume all risk of injury.
PART LIST
EN
X1
A+B
N
X6
X1
E+C
X1
I+H+G
X1
D
X1
K
X1
J
X4
F
-2-

SETP:
1. Install (N) at the bottom of (A)
2. Open the Cap(B)on the Base(A)and fill
with water（Figure A) or and (Figure B)and
close with Cap(B)
3. Tighten Cover (C) onto Spring (E).
Attach spring (E) to the top of the Base (A)
with four Screw (F) and tighten
4. Loosen Knob(H) and slide inner Tube (I)
into Outer Tube (G) and tighten Knob (H) .
Slide tube assembly into spring assembly.
5. Pump up the ball(D) by using the pump
(K) provided. maximum air pressure of 4
LBS
6. Put the washer (J) on the top of( I) and
lock it with the ball(D)
7. Use Knob (H) to adjust tube assembly
height as desirec
EN
K
Pump
J
D
N
washer
