HOMCOM A91-085 Installation guide

SIT UP BENCH
ASSEMBLY & INSTRUCTION MANUAL
IN231000273V01_UK_FR_ES_DE_IT
A91-085
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
*The maximum user weight is 110 Kg (242lbs).
EN

2
Main Frame Assembly
Main Frame Assembly
FrontLeg Tube
One HookFoam Unit
Foam
Front HookFootFoam Pull Handle
Rear Armrest Components
Drawstring
EXPLODED-VIEW
ASSEMBLY DRAWING
1
2
4
311
11
10
6
8
7
14
9
13
12
9
5

3
1.Main frame assembly1PCS 2.Front support tube1PCS 3.Frontleg tube 1PCS 4.Onehook foam unit 1PCS
5.Fronthook foot foam 1PCS 6.Pull handle 1PCS 7.Rear armrest components
2PCS 8. Extension spring 1PCS
9. Plumblossom knob nut
M10 2PCS
13. Hex head bolt M10 * 55 2PCS 14. Round head square
diameter bolt M10 * 75 1PCS
10.Drawstring 2PCS 11. With ring boltd10 * 55 1PCS 12. Hex bolt M10 3PCS
PARTS

4
STEP 1
Take out the front support tube assembly (2), the front leg tube assembly (3), the outer hexagon bolt M10 * 55 (14) 1 piece
the Torx knob nut M10 (9) 1 piece, the hook foot foam component (4) 1 Pieces, front hook foot foam assembly (5) 1 piece.
As shown in Figure A, align the corresponding holes to install and tighten the related screws. The completed result is the
component in Figure A
INSTALLATIONSTEPS
2
4
3
14
9
5
Picture A
A PICTURE COMPONENTS

5
STEP 2
Ia. Take out the main frame assembly (1), 3 pieces of ring bolt d10 * 55 (66) (11), 1 piece of hexagon head bolt M10 * 55 (13)
and hexagon nut M10 (12). Align with the components in Figure A as shown in Figure B, align and install the corresponding
holes, and tighten the related screws. The result is B components
Picture B
B PICTURE COMPONENTS
1
11
11
13
12

6
STEP 3
Take out the rear armrest assembly (7) 2 pieces and the assembly of B as shown in Fig. C, align and install the corresponding
holes, the result is the assembly of C
INSTALLATIONSTEPS
Picture C
C PICTURE COMPONENTS
7

7
STEP 4
Take out the handle assembly (6), tension spring assembly (8), and pull rope assembly(10) Two pieces, as shown in Figure F
align and install the corresponding holes, and the completed result is the component D. At this point, the entire product
components are completed.
Picture D
D PICTURE COMPONENTS
6
8
10

8

anc de musculation
*Le poids maximum de l'utilisateur est de 110 Kg (242lbs).
IMPORTANT - CONSERVEZ CES INFORMATIONS POUR VOTRE
CONSULTATION ULTÉRIEURE: LISEZ ATTENTIVEMENT
INSTRUCTIONS D’ASSEMBLAGE
A91-085
IN231000273V01_UK_FR_ES_DE_IT
FR

’ ’
’
’
’
’
’’’
’
ZONE CIBLE

’’
1
2
4
311
11
10
6
8
7
14
9
13
12
9
5
2

3

2
4
3
14
9
5
4

1
11
11
13
12
5

7
6

6
8
10
7

’
’
’
8

*El peso máximo del usuario no puede exceder 110 Kg (242lbs).
IMPORTANTE - CONSERVE ESTA INFORMACIÓN PARA SU
CONSULTA POSTERIOR: LEER DET ALLA DAMENTE
INSTRUCCIONES DE MONTAJE
IN231000273V01_UK_FR_ES_DE_IT
ES

Zona objetivo
