Horizon Fitness PERFORMANCE SERIES PST6 User manual

PERFORMANCE
SERIES
TREADMILL USER’S GUIDE
FOR MODELS :
PST 6
PST 8

INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
3
CONGRATULATIONS and THANK YOU for your purchase of this Performance Series treadmill!
Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Performance Series
treadmill can help you attain it – adding club-quality performance to your at-home workouts, with
the ergonomics and innovative features you need to get stronger and healthier, faster. Because
we're committed to designing fitness equipment from the inside out, we use only the highest quality
components. It's a commitment we back with one of the strongest frame-to-motor warranty packages
in the industry.
You want exercise equipment that offers the most comfort, the best reliability and the highest quality
in its class.
The Horizon Performance Series delivers.
INTRODUCTION
Important Precautions
Assembly
Before You Begin
Treadmill Operation
Conditioning Guidelines
Troubleshooting & Maintenance
Limited Warranty
CONTACT INFORMATION
4
6
11
14
24
31
34
Back Panel
TABLE OF CONTENTS

INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
4
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
SAVE THESE INSTRUCTIONS
Read all instructions before using this treadmill. When using an electrical product, basic precautions
should always be followed, including the following: Read all instructions before using this treadmill. It is the
responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings
and precautions. If you have any questions after reading this manual, contact Customer Tech Support at the
number listed on the back panel of this manual.
Connect this exercise product to a properly grounded outlet only. See grounding
instructions.
GROUNDING INSTRUCTIONS
This product must be grounded. If a treadmill should malfunction or breakdown, grounding provides a path
of least resistance for electrical current to reduce the risk of electrical shock. This product is equipped with
a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with local codes and ordinances.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or serviceman if you are in doubt
as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
This product is for use on a nominal 110-volt circuit
and has a grounding plug that looks like the illustration
to the right. This product must be used on a dedicated
circuit. To determine if you are on a dedicated circuit,
shut off the power to that circuit and observe if any other
devices lose power. If so, move devices to a different
circuit. Note: There are usually multiple outlets on one
circuit. It is recommended that the treadmill be used
with a 20 amp circuit for optimal performance.
IMPORTANT PRECAUTIONS
WARNING
WARNING
3-Pole Grounded Outlet
GROUNDED
TREADMILL
POWER CORD

INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
5
At NO time should pets or children under the age of 12 be closer to the treadmill than 10 feet.
At NO time should children under the age of 12 use the treadmill.
Children over the age of 12 should not use the treadmill without adult supervision.
To reduce the risk of burns, fire, electrical shock or injury to persons:
• Never use the treadmill before securing the safety tether clip to your clothing.
• If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness
of breath, stop exercising immediately and consult your physician before continuing.
• Do not wear clothes that might catch on any part of the treadmill.
• Always wear athletic shoes while using this equipment.
• Do not jump on the treadmill.
• Keep power cord away from heated surfaces.
• Do not insert or drop any object into any opening.
• Unplug treadmill before moving or cleaning it. To clean, wipe surfaces down with soap and slightly damp
cloth only; never use solvents. (See MAINTENANCE)
• At no time should more than one person be on treadmill while in operation.
• The treadmills should not be used by persons weighing more than 375 pounds (PST6) and 400 pounds
(PST8). Failure to comply will void the warranty.
• The treadmills are intended for in-home use only. Do not use this treadmill in any commercial, rental,
school or institutional setting. Failure to comply will void the warranty.
• Do not use treadmill in any location that is not temperature controlled, such as but not limited to garages,
porches, pool rooms, bathrooms, car ports or outdoors. Failure to comply may void the warranty.
• Use the treadmill only as described in this manual.
OTHER SAFETY TIPS FOR YOUR TREADMILL
OPERATION
To reduce the risk of damaging important components on your treadmill, it is strongly
recommended that your treadmill is plugged into a dedicated 20 amp circuit, without
the use of an additional extension cord and/or power strip. Failure to comply may void
the warranty.
IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets.
It is essential that your treadmill is used only indoors, in a climate controlled room. If your treadmill has been
exposed to colder temperatures or high moisture climates, it is strongly recommended that the treadmill is
warmed up to room temperature before first time use. Failure to do so may cause premature electronic failure.
WARNING
WARNING

BEFORE
YOU BEGIN
6
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY
IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE!
During the assembly process of the treadmill there are several areas that special attention must be paid.
It is very important to follow the assembly instructions correctly and to make sure all parts are firmly
tightened. If the assembly instructions are not followed correctly, the treadmill could have frame parts that
are not tightened and will seem loose and may cause irritating noises. There should be no side-to-side play
in the console masts or any forward and back play in the console assembly or handlebars. If there is any
play in these areas, the treadmill has not been properly assembled. To prevent damage to the treadmill, the
assembly instructions must be reviewed and corrective actions should be taken.
UNPACKING
Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on
your floor. Take CAUTION when handling and transporting this unit. Never open box when it is on its side.
Once the banding straps have been removed, do not lift or transport this unit unless it is fully assembled
and in the upright folded position, with the lock latch secure. Unpack the unit where it will be used. The
enclosed treadmill is equipped with high-pressure shocks and may spring open if mishandled. Never grab
hold of any portion of the incline frame and attempt to lift or move the treadmill. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN INJURY!
Before proceeding, find your treadmill’s serial number
and model name located to the left of the on/off
power switch and power cord and enter it in the space
provided below.
ENTER YOUR SERIAL NUMBER AND
MODEL NAME IN THE BOXES BELOW:
SERIAL NUMBER:
MODEL NAME:
* Refer to the SERIAL NUMBER and MODEL NAME when calling for service.
* Also enter this serial number on your Warranty Card.
WARNING

BEFORE
YOU BEGIN ASSEMBLY
7
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
PST 8 SHOWN
READING RACK
WATER BOTTLE HOLDER
GRIP PULSE HANDRAILS
ON/OFF SWITCH
CIRCUIT BREAKER
WHEEL LOCKS
TRANSPORT WHEELS
FOOT LOCK LATCH
POWER CORD
CONSOLE
TOUCH PAD PANEL WITH BLUE BACK-LIT DISPLAY
SAFETY KEY PLACEMENT
MOTOR COVER
RUNNING BELT / RUNNING DECK
SIDE RAIL
ROLLER END CAP
CONSOLE MAST
REAR ROLLER ADJUSTMENT BOLTS
TOOLS INCLUDED
5 mm Allen Wrench/Phillips Screw Driver
8 mm Allen Wrench or 6 mm Allen Wrench
Open-end Wrench
PARTS INCLUDED
1 Safety Key
1 Console
1 Console Faceplate
2 Console Masts
If you have questions or if there are any missing parts, contact Customer Tech Support.
Contact information is located on the back panel of this manual.
For a complete exploded diagram, visit us at www.horizonfitness.com
2 Console Mast Boots
2 Handlebars
1 Power Cord
3 Hardware Packs

BEFORE
YOU BEGIN
8
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
AOpen HARDWARE BAG 1.
BConnect CONSOLE WIRES.
CSlide CONSOLE MASTS over BASE
FRAME BRACKETS.
DInsert BOLT (A) and FLAT WASHER
(B) into bottom side hole and
attach with NUT (C).
EInsert BOLT (D) and FLAT WASHER
(B) into rear hole.
FRepeat on other side.
GInsert BOLT (D) and FLAT WASHER
(B) into top side hole.
HInsert BOLT (D) into rear-most
inside hole.
IRepeat on other side.
NOTE: It is recommended that you apply grease to the threads of each bolt as you assemble your treadmill, to
prevent loosening and noise. Also, during each assembly step, ensure that ALL nuts and bolts are in place and
partially threaded in before completely tightening any ONE bolt.
PRE-ASSEMBLY
$0/40-&8*3&4
#"4&'3".&#3"$,&5
ASSEMBLY STEP 1
'-"58"4)&3#
2UZ
#0-5%
NN
2UZ
#0-5"
NN
2UZ
/65$
NN
2UZ
HARDWARE BAG 1 CONTENTS :
/65$
#0-5%
'-"58"4)&34#
#0-5"
#0-5%
#0-5%
'-"58"4)&3#
Steps A-C
Steps D-F
Steps G-I

BEFORE
YOU BEGIN ASSEMBLY
9
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
AOpen HARDWARE BAG 2.
BSlide CONSOLE MAST BOOTS
down over BASE FRAME.
CLift RUNNING DECK to upright
position.
DInsert 4 SCREWS (E) into inside
holes of CONSOLE MAST BOOTS.
EConnect CONSOLE WIRES.
FSlide CONSOLE BRACKETS into
CONSOLE MAST as shown.
GTo attach CONSOLE, insert
1FLAT WASHER (F), 1 LOCK
WASHER (G) and 1 BOLT (D) into
all 6 holes on upper CONSOLE
MASTS.
ASSEMBLY STEP 2
$0/40-&."45#005
$0/40-&."45
#"4&'3".&
36//*/(%&$,
4$3&84&
$0/40-&#3"$,&54
$0/40-&."45
#0-54%
'-"58"4)&34'
-0$,8"4)&34(
$0/40-&8*3&4
'-"58"4)&3'
NN
2UZ
-0$,8"4)&3(
NN
2UZ
#0-5%
NN
2UZ
4$3&8&
NN
2UZ
HARDWARE BAG 2 CONTENTS :

BEFORE
YOU BEGIN
10
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
AOpen HARDWARE BAG 3.
BAttach 2 CONSOLE CABLES into
the faceplate.
CAttach FACEPLATE to the
console using 3 SCREWS (H).
DSlide HANDLEBARS onto
CONSOLE as shown.
ETo attach HANDLEBARS to
CONSOLE, insert 2 LOCK
WASHERS (I) and 2 BOLTS (J)
into inside holes underneath
HANDLEBARS and insert 2 FLAT
WASHERS (K), 2 LOCK WASHERS
(L) and 2 BOLTS (M) into
outermost holes underneath
HANDLEBARS.
FRepeat for other side.
ASSEMBLY STEP 3
$0/40-&
$0/40-&."45
$0/40-&'"$&1-"5&
$0/40-&$"#-&4
4$3&84)
'-"58"4)&34,
-0$,8"4)&34-
#0-54.
-0$,8"4)&34*
#0-54+
YOU’RE FINISHED!
#0-5.
NN
2UZ
4$3&8)
NN
2UZ
-0$,8"4)&3*
NN
2UZ
-0$,8"4)&3-
NN
2UZ
'-"58"4)&3,
NN
2UZ
#0-5+
NN
2UZ
HARDWARE BAG 3 CONTENTS :

BEFORE
YOU BEGIN ASSEMBLY
11
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY ASSEMBLY
BEFORE
YOU BEGIN IMPORTANT
PRECAUTIONS
BEFORE YOU BEGIN
CONGRATULATIONS! on choosing your treadmill. You’ve taken an important step in developing and
sustaining an exercise program! Your treadmill is a tremendously effective tool for achieving your personal
fitness goals. Regular use of your treadmill can improve the quality of your life in so many ways.
HERE ARE JUST A FEW OF THE HEALTH BENEFITS OF EXERCISE:
• Weight Loss
• A Healthier Heart
• Improved Muscle Tone
• Increased Daily Energy Levels
The key to reaping these benefits is to develop an exercise habit. Your new treadmill will help you eliminate
obstacles that prevent you from exercising. Inclement weather and darkness won't interfere with your
workout when you use your treadmill in the comfort of your home. This guide provides you with basic
information for using and enjoying your new machine.
LOCATION OF THE TREADMILL
Place the treadmill on a level surface. There should be 6 feet of clearance
behind the treadmill, 3 feet on each side and one foot in front for folding
and the power cord. Do not place the treadmill in any area that will block
any vent or air openings. The treadmill should not be located in a garage,
covered patio, near water or outdoors.
DO NOT STAND ON THE BELT
While you are preparing to use the treadmill, do not stand on the belt.
Place your feet on the side rails before starting the treadmill. Start
walking on the belt only after the belt has begun to move. Never start the
treadmill at a fast running speed and attempt to jump on!
SAFETY KEY
Your treadmill will not start unless the safety key is placed in position. Attach the clip end securely to your
clothing. This safety key is designed to cut the power to the treadmill if you should fall. Check the operation
of the safety key every 2 weeks.
NEVER USE THE TREADMILL WITHOUT SECURING THE SAFETY KEY CLIP TO YOUR
CLOTHING. PULL ON THE SAFETY KEY CLIP FIRST TO MAKE SURE IT WILL NOT
COME OFF YOUR CLOTHING.
WARNING
3 feet
6 feet
3 feet
1 foot
WARNING

BEFORE
YOU BEGIN
12
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY BEFORE
YOU BEGIN
PROPER USAGE
Your treadmill is capable of reaching high speeds. Always start off using a slower speed and adjust the speed in
small increments to reach a higher speed level. Never leave the treadmill unattended while it is running. When
not in use, remove the safety key, turn the on/off switch to off and unplug the power cord. Make sure to follow
the MAINTENANCE schedule located on page 33 in this manual. Keep your body and head facing forward. Do not
attempt to turn around or look backwards while the treadmill is running. Stop your workout immediately if you
feel pain, faint, dizzy or are short of breath.
Do not operate the treadmill if the power cord or plug is damaged.
If the treadmill appears to not be working properly, do not use the treadmill.
FOLDING
Firmly grasp the back end of the treadmill. Carefully lift the end of the treadmill
deck into the upright position until the foot lock latch engages and securely
locks the deck into position. Make sure the deck is securely latched before letting
go. To unfold, firmly grasp the back end of the treadmill. Gently press down
on the foot lock latch with your foot until the lock latch disengages. Carefully
lower the deck to the ground.
MOVING
Your treadmill has 4 transport wheels built into the frame.
To move, make sure the treadmill is folded and securely
latched. To unlock wheels, push down on the top lever of all
4 wheel locks located on the corners of the base frame. Then
firmly grasp the handlebars, and slowly move the treadmill.
After moving to the desired location, push down on the
bottom lever of all 4 wheel locks.
NOTE: All 4 wheels MUST be locked before using the treadmill.
Our Treadmills are heavy, use care and additional help if necessary when moving.
Do not attempt to move or transport treadmill unless it is in the upright, folded
position with the lock latch secured. Failure to follow these instructions could
result in injury.
WARNING
WARNING
WHEEL LOCKS

BEFORE
YOU BEGIN ASSEMBLYASSEMBLY
13
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY ASSEMBLY
BEFORE
YOU BEGIN IMPORTANT
PRECAUTIONS
CENTERING THE RUNNING BELT
The running belt has been properly adjusted at the
factory before it was shipped. At times the belt can
move off-center during shipment. Before operating the
treadmill, make sure the belt is centered and remains
centered to maintain smooth operation.
CAUTION: Do not run belt faster than 1/2 mph while
centering. Keep fingers, hair and clothing away from
belt at all times.
If the running belt is too far to the right side:
With the treadmill running at 1/2 mph, turn the right
adjustment bolt clockwise 1/4 TURN at a time (using
the supplied Allen wrench). Check the belt alignment.
Allow belt to run a full cycle to gauge if more adjustment
is needed. Repeat if necessary, until the belt remains
centered during use.
If the running belt is too far to the left side:
With the treadmill running at 1/2 mph, turn the right
adjustment bolt counter-clockwise 1/4 TURN at a time
(using the supplied Allen wrench). Check the belt
alignment. Allow belt to run a full cycle to gauge if more
adjustment is needed. Repeat if necessary, until the
belt remains centered during use.
Belt is too far to the right side
Belt is too far to the left side
TENSIONING THE RUNNING BELT
The running belt has been properly adjusted at the
factory before it was shipped. At times the belt can
move off-center during shipment.
CAUTION: Running belt should NOT be moving during
tensioning. Over-tightening the running belt can
cause excessive wear on the treadmill as well as its
components. Never over-tighten the belt.
If you can feel a slipping sensation when running on the
treadmill, the running belt must be tightened. In most
cases, the belt has stretched from use, causing the
belt to slip. This is a normal and common adjustment.
To eliminate this slipping, TURN THE TREADMILL OFF
and tension BOTH THE REAR ROLLER BOLTS using the
supplied Allen wrench, turning them 1/4 TURN to the
right as shown. Turn the treadmill on and check for
slipping. Repeat if necessary, but NEVER TURN the
roller bolts more than 1/4 turn at a time. Belt is properly
tensioned when the slipping sensation is gone.

BEFORE
YOU BEGIN
14
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY TREADMILL
OPERATION
Note: There is a thin protective sheet of clear plastic on the overlay of the console and should be removed.
A) MONITOR DISPLAY: Speed, Time, Pulse, Distance, Odometer, Incline, Calories, Pace and Program Profiles
(PST6 has single large screen).
B) ADDITIONAL DISPLAY WINDOWS: Pulse, Pace, Time and Speed (PST8 only).
C) STOP: Press to pause/end your workout. Hold for 3 seconds to reset the treadmill.
D) START: Simply press to begin exercising or starts your program.
E) ENTER: Used to select Program, Level and Time. Press to change display feedback during workout,
Hold to scan.
F) ONE-TOUCH INCLINE KEYS: Used to reach desired incline more quickly.
G) ONE-TOUCH SPEED KEYS: Used to reach desired speed more quickly.
H) ONE-TOUCH PROGRAM KEYS: Choose from 10 preset programs (PST6 has 8 programs).
I) ODOMETER KEYS: Used to change Odometer settings (see page 16).
J) 1/2 KEYS: One-touch keys for increasing speed (0.5 mph increments) and incline (0.5% increments).
K) BACK-LIT INCLINE INDICATORS: Illuminate to indicate current incline.
L) BACK-LIT SPEED INDICATORS: Illuminate to indicate current speed.
M) SAFETY KEY POSITION: Enables treadmill when safety key is inserted.
N) WATER BOTTLE / CD / MP3 HOLDERS: Holds personal workout equipment.
O) READING RACK: Holds reading material (Remove sales sticker before use).
TREADMILL OPERATION
8"3/*/(
"UUBDITBGFUZLFZDMJQUP
DMPUIJOHCFGPSFTUBSUJOH5P
BWPJEJOKVSZTUBOEPOUIF
TJEFSBJMTCFGPSFTUBSUJOH
USFBENJMM3FBEBOEGPMMPX
BMMJOTUSVDUJPOTCFGPSF
PQFSBUJOH,FFQDIJMEFO
BXBZGSPNUIJTFRVJQNFOU
$"65*0/
$POTVMUBQIZTJDJBOCFGPSF
VTJOHUIJTFRVJQNFOU4UPQ
FYFSDJTJOHJGZPVGFFMQBJO
GBJOUEJ[[ZPSTIPSUPG
CSFBUI
* / $ - * / & 4 1 & & %
0/&506$)*/$-*/& 0/&506$)41&&%
0/&506$)130(3".4

)0-%50
3&4&553*1
64&3
64&3
."/6"- */5&37"-4
5)3;0/&
30--*/(
5)3;0/&3"$&
8&*()5
-044
$6450.
(0-'
$0634&
$6450.
16-4& 5*.& 41&&%1"$&
&/5&3
$)"/(&%*41-":
45"35
26*$,45"35
4501
)0-%503&4&5
 
 
 
 
 
 
 
 
 
 
 
 
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
 .1)
* / $ - * / & 4 1 & & %
&/5&3
$)"/(&%*41-":
45"35
26*$,45"35
4501
)0-%503&4&5
/ /' , -* (" #
0 )&.+ % +$

BEFORE
YOU BEGIN ASSEMBLYASSEMBLY
15
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY TREADMILL
OPERATION ASSEMBLY IMPORTANT
PRECAUTIONS
BEFORE
YOU BEGIN
SPEED • Shown as MPH. Indicates how
fast your walking or running surface
is moving.
TIME • Shown as Minutes:Seconds.
View the time remaining or the time
elapsed in your workout.
PULSE • Shown as Beats Per Minute.
Used to monitor your heart rate
(displayed when contact is made
with both pulse grips).
DISTANCE • Shown as Miles. Indicates
distance traveled during your
workout.
INCLINE • Shown as Percent. Indicates the incline of your walking or running surface.
CALORIES • Total Calories burned during your workout.
PROGRAM PROFILES • Represents the profile of the program being used (speed during speed based
programs and incline during incline based programs).
PACE • The rate of covering a mile while running or walking at your current speed. For example: If at your
current speed it will take you 10 minutes to complete a mile, the treadmill will display ‘10.0’ as your pace.
MONITOR DISPLAY
HOLD TO
RESET TRIP
USER 1
USER 2
PST8 Shown

BEFORE
YOU BEGIN
16
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY TREADMILL
OPERATION
USING THE ODOMETER FUNCTION
HEART RATE
HANDLEBARS
Place the palm of your hands directly on the grip pulse handlebars. Both hands must grip the bars for your heart
rate to register. It takes 5 consecutive heart beats (15-20 seconds) for your heart rate to register. When gripping
the pulse handlebars, do not grip tightly. Holding the grips tightly may elevate your blood pressure. Keep a loose,
cupping hold. You may experience an erratic readout if consistently holding the grip pulse handlebars. Make sure
to clean the pulse sensors to ensure proper contact can be maintained. (See page 32).
WIRELESS CHEST TRANSMITTER
(Chest strap included with PST8 only)
Prior to wearing the wireless chest transmitter on your
chest, moisten the two rubber electrodes with water. Center
the chest strap just below the breast or pectoral muscles,
directly over your sternum, with the logo facing out. NOTE:
The chest strap must be tight and properly placed to receive
an accurate and consistent readout. If the chest strap is too
loose, or positioned improperly, you may receive an erratic
or inconsistent heart rate readout. WARNING! The heart rate
function is not a medical device. Various factors may affect
the accuracy of your heart rate reading. The heart rate reading
is intended only as an exercise aid.
BACKSIDE OF CHEST TRANSMITTER
APPLY MOISTURE HERE
USER 1/USER 2: Logs User’s total accumulated distance of current workout.
- You will be prompted to select a USER during the final step in program set-up (See Page 17).
- Upon pressing either USER 1 or USER 2 and then START, the Display window will default to your current
accumulated workout’s distance.
- NOTE: If you do not select a USER and just press START, the Display window will default to program
distance. Neither USER TRIP or USER TOTAL will accumulate.
USER TRIP: Logs User’s accumulated distance since the Trip feature was last reset.
- During your workout, press the USER button once and TRIP will be displayed.
- To reset TRIP DISTANCE, hold the USER button for 3 seconds. TRIP DISTANCE will reset to 0.0.
USER TOTAL: Logs User’s total accumulated distance on the treadmill.
- During your workout, press the USER button twice and TOTAL will be displayed.
- USER TOTAL cannot be reset.
- During your workout, press the USER button 3 times to return to current program’s distance.
NOTE: A User cannot be selected once a program has started.

BEFORE
YOU BEGIN ASSEMBLYASSEMBLY
17
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY TREADMILL
OPERATION ASSEMBLY IMPORTANT
PRECAUTIONS
BEFORE
YOU BEGIN
GETTING STARTED / SELECTING AN ODOMETER FUNCTION
Check to make sure nothing is on or will hinder the movement of the treadmill.
Plug in the power cord and turn the treadmill ON.
Stand on the side rails of the treadmill.
Attach the safety key clip to part of your clothing.
Insert the safety key into the safety keyhole in the console.
You have two options to start your workout:
QUICK START UP
Simply press the START key to begin working out. OR...
SELECT A PROGRAM
Select a PROGRAM using the ONE-TOUCH PROGRAM KEYS or ARROW KEYS.
Once a PROGRAM has been chosen, press ENTER.
SELECT A LEVEL
Select a PROGRAM LEVEL using the ARROW KEYS.
Once a PROGRAM LEVEL has been chosen, press ENTER.
SET A TIME
Select a TIME using the ARROW KEYS or use the default time.
Once a TIME has been chosen, press ENTER.
SET ODOMETER (See Page 16 for details)
Select a USER using the ODOMETER KEYS.
Once a USER has been chosen, press START to begin your workout.
FINISHING YOUR WORKOUT
When your workout is complete, the MONITOR DISPLAY will flash and beep. Your workout information will
stay displayed on the console for 30 seconds and then reset.
CLEAR CURRENT SELECTION
To clear the current program selection or screen, hold the STOP button for 4-5 seconds.
SCAN VIEWING SCREENS (PST8 ONLY)
To have the display screen rotate continuously, hold the ENTER button for 4-5 seconds It will cycle between
Incline and Calories.
1)
2)
3)
4)
5)
6)
A)
B)

BEFORE
YOU BEGIN
18
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY TREADMILL
OPERATION
Motivates with different combinations of SPEED. Time-based goal with 10 difficulty levels to choose from.
ROLLING PROGRAM SEGMENTS (all segments last 30 seconds)
MPH WARM-UP 12345678
SEGMENTS ARE REPEATED UNTIL SELECTED
TIME IS REACHED
COOL-DOWN
Level 1 1.0 1.5 2.0 2.5 3.0 3.5 4.0 3.5 3.0 2.5 2.3 1.5
Level 2 1.3 1.9 2.5 3.0 3.5 4.0 4.5 4.0 3.5 3.0 2.6 1.8
Level 3 1.5 2.3 3.0 3.5 4.0 4.5 5.0 4.5 4.0 3.5 3.0 2.0
Level 4 1.8 2.6 3.5 4.0 4.5 5.0 5.5 5.0 4.5 4.0 3.4 2.3
Level 5 2.0 3.0 4.0 4.5 5.0 5.5 6.0 5.5 5.0 4.5 3.8 2.5
Level 6 2.3 3.4 4.5 5.0 5.5 6.0 6.5 6.0 5.5 5.0 4.1 2.8
Level 7 2.5 3.8 5.0 5.5 6.0 6.5 7.0 6.5 6.0 5.5 4.5 3.0
Level 8 2.8 4.1 5.5 6.0 6.5 7.0 7.5 7.0 6.5 6.0 4.9 3.3
Level 9 3.0 4.5 6.0 6.5 7.0 7.5 8.0 7.5 7.0 6.5 5.3 3.5
Level 10 3.3 4.9 6.5 7.5 7.5 8.0 8.5 8.0 7.5 7.0 5.6 3.8
(WARM-UP and COOL-DOWN last 5:00 minutes each and are included in program times)
PROGRAM: ROLLING
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
Walk or run a series of alternating SPEED levels. Time-based goal with 10 difficulty levels to choose from.
INTERVALS PROGRAM SEGMENTS
(peak segments last 30 seconds, valley segments last 90 seconds)
MPH WARM-UP 1234
SEGMENTS ARE REPEATED UNTIL SELECTED
TIME IS REACHED
COOL DOWN
Level 1 1.0 1.5 2.0 4.0 2.0 4.0 1.5 1.0
Level 2 1.0 1.5 2.0 4.5 2.0 4.5 1.5 1.0
Level 3 1.3 1.9 2.5 5.0 2.5 5.0 1.9 1.3
Level 4 1.3 1.9 2.5 5.5 2.5 5.5 1.9 1.3
Level 5 1.5 2.3 3.0 6.0 3.0 6.0 2.3 1.5
Level 6 1.5 2.3 3.0 6.5 3.0 6.5 2.3 1.5
Level 7 1.8 2.6 3.5 7.0 3.5 7.0 2.6 1.8
Level 8 1.8 2.6 3.5 7.5 3.5 7.5 2.6 1.8
Level 9 2.0 3.0 4.0 8.0 4.0 8.0 3.0 2.0
Level 10 2.0 3.0 4.0 8.5 4.0 8.5 3.0 2.0
(WARM-UP and COOL-DOWN last 5:00 minutes each and are included in program times)
PROGRAM: INTERVALS
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
PROGRAM INFORMATION
PROGRAM: MANUAL
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
Allows ‘On The Fly’ manual SPEED and INCLINE changes. Time-based goal.

BEFORE
YOU BEGIN ASSEMBLYASSEMBLY
19
INTRODUCTION
IMPORTANT
PRECAUTIONS
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY TREADMILL
OPERATION ASSEMBLY IMPORTANT
PRECAUTIONS
BEFORE
YOU BEGIN
Challenges with various combinations of hills and valleys (INCLINE & SPEED levels). Time-based goal with 10
difficulty levels to choose from.
WEIGHT LOSS PROGRAM SEGMENTS (all segments last 30 seconds)
WARM-UP 12345678
SEGMENTS ARE REPEATED UNTIL SELECTED TIME IS REACHED
COOL-DOWN
Level 1 Elevation 0.0 0.5 1.5 1.5 1.0 0.5 0.5 0.5 1.0 1.5 0.5 0.0
Speed 1.0 1.5 2.0 2.5 3.0 3.5 4.0 3.5 3.0 2.5 2.3 1.5
Level 2 Elevation 0.0 0.5 1.5 1.5 1.0 0.5 1.0 0.5 1.0 1.5 0.5 0.0
Speed 1.3 1.9 2.5 3.0 3.5 4.0 4.5 4.0 3.5 3.0 2.6 1.8
Level 3 Elevation 0.5 1.0 2.0 2.0 1.5 1.0 1.0 1.0 1.5 2.0 1.0 0.5
Speed 1.5 2.3 3.0 3.5 4.0 4.5 5.0 4.5 4.0 3.5 3.0 2.0
Level 4 Elevation 0.5 1.0 2.0 2.0 1.5 1.0 1.0 1.0 1.5 2.0 1.0 0.5
Speed 1.8 2.6 3.5 4.5 4.5 5.0 5.5 5.0 4.5 4.5 3.4 2.3
Level 5 Elevation 1.5 1.5 2.5 2.5 2.0 1.5 1.5 1.5 2.0 2.5 1.5 1.0
Speed 2.0 3.0 4.0 4.5 5.0 5.5 6.0 5.5 5.0 4.5 3.8 2.5
Level 6 Elevation 1.5 1.5 2.5 2.5 2.0 1.5 1.5 1.5 2.0 2.5 1.5 1.0
Speed 2.3 3.4 4.5 5.0 5.5 6.0 6.5 6.0 5.5 5.0 4.1 2.8
Level 7 Elevation 1.5 2.0 3.0 3.0 2.5 2.0 2.0 2.0 2.5 3.0 2.0 1.5
Speed 2.5 3.8 5.0 5.5 6.0 6.5 7.5 6.5 6.0 5.5 4.5 3.0
Level 8 Elevation 1.5 2.0 3.0 3.0 2.5 2.0 2.0 2.0 2.5 3.0 2.0 1.5
Speed 2.8 4.1 5.5 6.0 6.5 7.0 7.5 7.0 6.5 6.0 4.9 3.3
Level 9 Elevation 2.0 2.5 3.5 3.5 3.0 2.5 2.5 2.5 3.0 3.5 2.5 2.0
Speed 3.0 4.5 6.0 6.5 7.0 7.5 8.0 7.5 7.0 6.5 5.3 3.5
Level 10 Elevation 2.0 2.5 3.5 3.5 3.0 2.5 2.5 2.5 3.0 3.5 2.5 2.0
Speed 3.3 4.9 6.5 7.0 7.5 8.0 8.5 8.5 7.5 7.0 5.6 3.8
(WARM-UP and COOL-DOWN last 5:00 minutes each and are included in program times)
PROGRAM: WEIGHT LOSS
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR

BEFORE
YOU BEGIN
20
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY TREADMILL
OPERATION
Simulates various INCLINES and yardages for holes on a golf course, with 4 tee-off boxes and 9 or 18 holes to choose
from. Distance-based goal. GOLF COURSE PROGRAM SEGMENTS
HOLE
NUMBER: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 TOTAL DISTANCE
Red tee
9 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 2482
Distance 309 359 283 256 113 387 91 351 333
White tee
9 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 2875
Distance 331 427 330 295 129 466 91 369 431
Blue tee
9 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 3003
Distance 345 460 337 308 142 484 97 389 441
Black tee
9 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 3250
Distance 376 502 374 327 187 500 106 416 462
Red tee
18 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 3.5 2.5 2.0 4.0 2.5 3.0 2.0 5.0 2.0 5198
Distance 309 359 283 256 113 387 91 351 333 301 301 165 288 434 312 310 150 455
White tee
18 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 3.5 2.5 2.0 4.0 2.5 3.0 2.0 5.0 2.0 6116
Distance 331 427 330 295 129 466 97 369 431 407 339 179 368 548 349 376 166 509
Blue tee
18 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.0 1.5 3.5 2.5 2.0 4.0 2.5 3.0 2.0 5.0 2.0 6348
Distance 345 460 337 308 142 484 97 389 441 413 349 187 376 560 373 383 383 532
Black tee
18 holes
Elevation 0.0 1.0 2.0 3.0 2.5 1.0 2.0 2.5 1.5 3.5 2.5 2.0 4.0 2.5 3.0 2.0 5.0 2.0 6737
Distance 376 502 374 327 187 500 106 416 462 430 373 201 393 572 396 401 178 543
Distance = Yards
PROGRAM: GOLF COURSE
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
