Hubbell Laredo LMC User manual

WARNING!LUMINAIRES require high current and voltage. HID LAMPS used in luminaires generate intense light and high
temperatures. HID LAMPS may emit UV and IR radiation. LAMPS may contain MERCURY (Hg), LEAD (Pb) and other potentially
dangerous and/or toxic materials. If lamp is marked it contains mercury and is subject to disposal laws. See www.lamprecycle.org.
HID LAMPS may rupture unexpectedly.
WARNING! Fixtures must be grounded and installed in accordance with the National Electrical Code and all local codes. Failure to
do so may increase the RISK OF PERSONAL INJURY, PROPERTY DAMAGE, FIRE AND DEATH. Install and use so lamp and control
gear burnouts do not cause a hazard and use only in environments for which the product is specifically marked.
WARNING! This product contains chemicals known to the State of California to cause cancer, birth defects, and/or other reproductive
harm. Thoroughly wash hands after installing, handling, cleaning, or otherwise touching this product.
CAUTION!Follow ALL luminaire and lamp manufacturer's recommendations, product markings, instructions, restrictions and
warnings regarding lumninaire and lamp operation, burning position, cycling and lamp replacement. Luminaire label shows electrical,
environmental and lamp requirements. STOP USING WHEN LAMP FAILS. Continued operation will result in control gear damage and
possible nuisance smoke.
All electrical work must be done by a qualified electrician.
Turn off electric power to all affected circuits and allow to cool before servicing.
A regularly scheduled maintenance program should be established to retain optimum light output and reduce heat retention. Dusting
with a soft, clean, dry cloth is normally sufficient for the reflector. Any accumulation of dust or dirt should be removed regularly from both
sides of the lens during relamping. Use only a mild soapy solution, DO NOT use alkaline or acid cleaners on reflector surfaces.
Carefully read these instructions before installing product. If you do not understand these instructions, before starting any work, contact
your Hubbell Lighting distributor or [e-mail] or [phone]
Give instructions to facility owner/manager for future reference.
93029166 - LAREDO LMC LED INSTALLATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Hg
701 Millennium Boulevard Greenville, SC 29607 [phone] www.hubbelloutdoor.com
STEP I
MOUNTING PREPARATION
CAUTION: FIXTURE WEIGHS ABOUT 15 POUNDS
• Using mounting bracket (A) as a template, align slots in
bracket with mounting holes in junction box (B) on the
wall.
Mark hole locations (4) 4.5” square. (See Fig.1)
• Drill wall for the hardware appropriate for the type wall.
Use 1/4 diameter bolt (supplied by others) and attach
bracket to wall.
• Pull the supply wires (C) from junction box (B).
• Apply caulking sealant (supplied by others) around the
top and two sides of the bracket where it meets the wall.
4.500
4.500
B
A
C
1
CAULKING
FIG. 1
NOTE: DO NOT OPEN FIXTURE. FIXTURE HAS BEEN DESIGNED WITH EASY TO INSTALL
MOUNTING BRACKETS.
TOOLS REQUIRED: FLAT BLADE SCREWDRIVER OR 5/16” NUT DRIVER, DRILL, ANY
ADDITIONAL TOOLS NEEDED FOR APPROPRIATE WALL FASTENERS
PARTS REQUIRED: (SUPPLIED BY OTHERS) SILICONE CAULK, TEFLON TAPE, 1/4”
WALL ANCHORS AND FASTENERS APPROPRIATE FOR WALL CONSTRUCTION TYPE

INSTALLATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
701 Millennium Boulevard Greenville, SC 29607 [phone] www.hubbelloutdoor.com
REMOVE HUB PORTS
AND ADD TEFLON TAPE
STEP II
FIXTURE PREPARATION
(See Fig. 2)
• Remove hub ports at (D), (E), and (F).
• Apply Teflon tape (supplied by others) to hub ports and
re-install.
STEP I
V
FIXTURE MOUNTING
(See Fig.
4
)
• Hold fixture at a slight angle, slide over mounting plate and
rotate downward to capture plate.
• Tighten screw (G) securely.
• Check to ensure secure mount.
• Energize product.
Step
III
WIRING
(See Fig. 3)
• POWER MUST BE OFF.
(WIRING MUST BE PERFORMED BY
A QUALIFIED ELECTRICIAN)
• Wire service leads to fixture power leads according to local
and National Electric Codes.
• Luminaire is equipped with a universal voltage driver capa
ble of
120V-277V input.
• For direct wire connections, connect ground wire to green
wire. Connect
black to black and white to neutral then push
connections back inside J-box (B).
2
DE
F
B
A
C
FIG. 2
FIG. 3
FIG. 4
G
NOTE: DO NOT OPEN FIXTURE. FIXTURE HAS BEEN DESIGNED WITH EASY TO INSTALL
MOUNTING BRACKETS.
