Hubbell NXP2 Series User manual

Page 1/2 Rev. 03/17/21
3483A_NXP2-RL_SPEC
© 2021 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. Specifications subject to change without notice.
701 Millennium Blvd • Greenville, SC 29607 / Tel [phone] / hubbellcontrolsolutions.com
FEATURES
• Robust mechanically latching single and double pole relays
• Electrically rated for 60,000+ operations (30,000+ cycles) at full
20a load
• Mechanically rated for 120,000+ operations (60,000+ cycles)
• Short Circuit Current Rating (SCCR) of 14,000A @ 277VAC
• Manual override switch (integral to the relay)
• At-A-Glance ON/OFF relay status indicator
• 5 year limited warranty
BROCHURE DIMENSIONAL DRAWINGS NX DESIGN & APPLICATION GUIDE
NXP2 SERIES
NX LIGHTING CONTROL PANEL RELAYS
DATE: LOCATION:
TYPE: PROJECT:
™
CATALOG #:
RELATED PRODUCTS
NX Lighting Control Panel -
NXP2 Series
NX Panel Relay Channel Barrier
CONSTRUCTION
• Relay Dimensions
• Single Pole - L:106.5mm x W:24.5mm
x H:60mm
• Double Pole – L:96mm x W:49.5mm
x H:60mm1
MOUNTING
• Mounts directly to NX Lighting Control Panel
relay mounting strap
ELECTRICAL
• Relay Operating Voltages
• Single Pole (p/n NXP2-RL-SP):
• General Use: 20A @ 300VAC
• Tungsten: 2400W @ 120VAC
• (Standard) Ballast: 20A @ 300VAC
• Electronic Ballast: 16A @ 277VAC
• Motor Starting: ½ HP @ 110-125VAC;
1.5 HP @ 220-277VAC
• Double Pole (p/n NXP2-RL-DP):
• General Use: 20A @ 480VAC
• Tungsten: 2400W @ 120VAC
OPERATING ENVIRONMENT
• Indoor use only
• 32° to 112°F (0° to 50°C)
• Relative humidity (non-condensing):
10% to 90%
CERTIFICATIONS
• UL Listed
• CSA Approved
WARRANTY
• 5 year limited
• See HCS Standard Warranty for
additional information
SPECIFICATIONS
ELECTRICAL (CONTINUED)
• Double Pole (p/n NXP2-RL-DP) (Continued):
• (Standard) Ballast: 20A @ 480VAC
• Motor Starting: ½ HP @ 110-125VAC;
1.5 HP @ 220-277VAC
• Relay Electrical Ratings
• Rated for minimum 60,000+ operations
(30,000+ cycles) at full 20A load
• Short Circuit Current Rating (SCCR) of
14,000A @ 277VAC
• Rated full-life with HID load
• Relay Mechanical Ratings
• Rated for minimum 120,000+ operations
(60,000+ cycles)
OPERATON
• Mechanically latching
• Provides at-a-glance indication of ON or OFF
relay status
• Includes manual override switch (integral to
the relay)
Notes:
1 Double pole relays occupy (2) relay spaces.
ORDERING GUIDE
Example: NXP2-RL-SP
CATALOG #
NXP2-RL –
Model Type
NXP2-RL
NX Lighting Control Panel V2 Relay SP Single Pole - General Use: 20A @ 300VAC; Tungsten: 2400W @ 120VAC; (Standard) Ballast: 20A @ 300VAC; Electronic Ballast: 16A @
277VAC; Motor Starting:
½ HP @ 110-125VAC; ½ HP @ 220-277VAC
DP Double Pole - General Use: 20A @ 480VAC; Tungsten: 2400W @ 120VAC; (Standard) Ballast: 20A @ 480VAC; Motor Starting:
½ HP @
110-125VAC; 1.5HP @ 220-277VAC
Single Pole Relay Double Pole Relay

NXP2 SERIES
NX LIGHTING CONTROL PANEL RELAYS
Page 2/2 Rev. 03/17/21
3483A_NXP2-RL_SPEC
DATE: LOCATION:
TYPE: PROJECT:
CATALOG #:
© 2021 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. Specifications subject to change without notice.
701 Millennium Blvd • Greenville, SC 29607 / Tel [phone] / hubbellcontrolsolutions.com
DIMENSIONS
4.5"
(49.5mm)
2.40"
(60mm)
3.54"
(90mm)
3.78"
(96mm)
ON
BLUE
RED
4.19"
(106.5mm)
0.96"
(24.5mm)
2.40"
(60mm)
3.54"
(90mm)
Blue
Red
ON
Double Pole RelaySingle Pole Relay
Relay Wiring Diagrams
SIMLXRL1 - Simplicity LX Single Pole Relay
SIMLXRL2 - Simplicity LX Double Pole Relay
Installation Instructions
Hubbell Building Automation, Inc.
9601 Dessau Road • Building One • Suite 100
Austin, Texas 78754
512-450-1100 • 512-450-1215 Fax
www.hubbell-automation.com
Overview
This document provides instructions for installing and connecting Single and/or Double Pole Relays in the Simplicity LX Series Lighting
Control Panel.
Contents
These instructions include information as follows:
Description
General Precautions
Installation
Precautions
• Read and understand all instructions before beginning installation.
• For installation by a qualified electrician in accordance with National and/or local Electrical Codes and the following instructions.
•RISK OF ELECTRICAL SHOCK. Turn power off at breaker panel before servicing unit. Never wire energized electrical components.
Never operate unit with door panel or relay guards removed.
•USE COPPER CONDUCTOR ONLY.
• Confirm that device ratings are suitable for application prior to installation.
• Use only approved materials and components (i.e. wire nuts, electrical box, etc.) as appropriate for installation.
•NOTICE: Do not install if any damage to product is noticed.
Installation
1. Verify that power is turned off at breaker panel before installing relay in panel.
2. Remove panel door assembly from panel enclosure.
3. Locate an open relay position (two adjacent positions for a double pole relay) in the panel and remove the relay guard cover(s).
4. Insert relay into mounting bracket noting proper orientation of input/output sides. Verify that relay is securely held in mounting bracket.
5. Connect relay input and output as shown in the wiring diagram below. Connect input to panel I/O control card using relay connector
cable. Attach red lead to red screw and blue wire to blue screw. Slide connector on to header pins of I/O control card. Connect line and
load leads to relay output.
Figure 1: Relay wiring diagrams
Load
(to lighting system)
Load, Phase 2
(to lighting system)
Load, Phase 2
(
from Circuit Breaker)
Load, Phase 1
(to lighting system)
Load, Phase 1
(to lighting system)
Blue Input Screw
Blue Lead
Red Input Screw Red Lead
Relay Connector
I/ O cont ro l
Card Head
er
(Polarized)
Blue Input Screw Blue Lead
Red Input Screw
Red Lead
Relay Connector
I/ O cont ro l
Card Head
er
(Polarized)
Line
(
from Circuit Breaker)
Single Pole Relay
Double Pole Relay
WIRING DIAGRAM
