Hubbell ExpressLine Miniliter IV MHSY Series User manual

HubbellCanadaLP,LightingDivision
870BrockRoadSouth,Pickering,ON,L1W1Z8
Tel.(905)8391138
Formoreinformation,visitourwebsite: www.hubbellonline.com
INSTALLATIONINSTRUCTIONS
MiniliterIV
MHSYSeries
WARNING
DISCONNECTPOWERDURINGINSTALLATIONANDBEFORESERVICING.
READALLINSTRUCTIONSCOMPLETELYBEFORESTARTINGINSTALLATION
SAFETYPRECAUTIONS
Beforestartingtheinstallation,disconnectthepowerbyturningoffthe
circuitbreaker.Turningthepoweroffbyusingthelightswitchisnot
sufficienttopreventelectricalshock.
Readallwarningsandinformationoncarton(s)andproduct(s)
WARNINGS
Disconnectpowerbeforeinstallingorservicing.
Install,operateandmaintaintomeetallapplicablecodes
Protectallwiringconnectionswithapprovedinsulators
(byothers)
Selectedfixturevoltagemustmatchsupplylinevoltage.
Ensurefixtureandwiringareproperlygrounded.
MOUNTINGYOKEMODELFIXTURES(MHSY)
1.Useaminimumoftwo3/8diameterboltsorone¾dia.
Boltformounting.
2.Securelytightenallretaininghardwareafteraiming.
WIRINGYOKEMODELFIXTURES(MHSY)
1.Preparesupplycordasshowninfigure2.
Cordmustberatedformin.90°C16/3SOWA.
2.Loosentwoscrews(5)androtatecover(6)
counterclockwise.
3.Removetwoscrews(2),cordgripplate(3),
andcordgrip(4)
4.insertsupplycordthrougththecordgrip
plate(3)andcordgrip(4).
5.PulllendofcordbackthroughholdA.
6.Applystrainreliefclamlp(B)toendofcordsouterjacket.
7.Pullcordbacksothattheendofthecordsouterjacketextendsnotmore
than½insidethefixture.
8.Tightencordgripscrews(2)
9.Makewiringconnectionsbyaccessingthesupplycordandfixturewires
throughtheaccesshole(A).
CAUTION:Fixturevoltagemustmatchsupplyvoltage.
10.Ensurethatallunusedleadsareproperlyinsulated.
11.Replacecover(6)andtightenscrews(5).

HubbellCanadaLP,LightingDivision
870BrockRoadSouth,Pickering,ON,L1W1Z8
Tel.(905)8391138
Formoreinformation,visitourwebsite: www.hubbellonline.com
INSTALLATIONINSTRUCTIONS
MiniliterIV
MHSYSeries
WARNING
DISCONNECTPOWERDURINGINSTALLATIONANDBEFORESERVICING.
READALLINSTRUCTIONSCOMPLETELYBEFORESTARTINGINSTALLATION
OPTIONALPHOTOCONTROL(PBTSERIES)FIELDINSTALLATION(MHSY)
1.Removetwoscrews(5)andcover(6)
2.Drilla11/16diameterholdinthecentreofcover(6)
3.Mountthephotocontrolontheinsideofthecoveraccordingtodirections
suppliedwiththephotocontrol.
4.Replacecover(6)andtightenscrews(5).
FIXTURESNOTMARKEDIP65
A.Forupaimedfixturesuseahammeranda
Screwdrivertoknockoutthetwothin
SectionsClocatedattherearbottom
Corners.
B.Fordownaimedfixturesremovethe#10drain
Holescrew(19)locatedathefrontbottom
Centre.
FIXTURESMARKEDIP65
IfthefixtureismarkedIP65donotremove
SectionCanddonotremovethedrainhold
Screw(19)
FUSEREPLACEMENT(MHSXXXX46XFX)
1.Turnoffpowerbeforeservicing.
2.Openlensdoorandremovelamp.
3.Removethe2socketretainingscrews,socket
Andretainer.
4.Removethe4reflectorscrews,andcarefully
removethreereflectorsegments.
5.Liftbarrierifpresenttoexposefuseholder.
6.Openthefuseholder
7.Replacetheblownfusewiththesamefuse
typeandratingandclosefuseholder.
8.Replacethebarrier,reflectorsegmentsand
fourreflectorscrews.
9.Replacelampandcloselensdoor.
