Hubbell Compass CU2SO User manual

WARNING – This product contains chemicals known to the State of California to cause cancer, birth
defects and/or other reproductive harm. Thoroughly wash hands after installing, handling, cleaning,
or otherwise touching this product.
Hubbell Lighting, Inc. Life Safety Products • www.compasslightingproducts.com
Copyright© Hubbell Lighting, Inc., All Rights Reserved • Specications subject to change without notice. • Printed in U.S.A.
COM604082_INST_SHT 01/18
LED Emergency Light
CU2SO
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following.
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. Rated for temperature range of 10°C-40°C (50°F - 104°F) and suitable for use in an
application that is designated as a damp location area as dened by NED Article 100,
Location, Damp.
2. Used Indoors
3. Equipment should be mounted in locations and at heights (Max: 8ft) where it will not be
subject to tampering by unauthorized personnel.
4. Do not mount near gas or electric heaters.
5. The use of accessory equipment is not recommended by the manufacturer and may cause
an unsafe condition.
6. Do not use this equipment for anything other than its intended use.
7. Servicing of this equipment should be performed by qualied personnel.
8. Disconnect AC power before servicing.
INSTALLER:
•SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
•SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
IMPORTANT
The battery in this unit may not be fully charged. After electricity is connected to the unit,
let battery charge up to 24 hours. Then the normal operation of this unit should take
effect. To check press the “TEST” button and the lights on the unit should turn ON
RECYCLING INFORMATION
All steel, aluminum and thermoplastic
parts are recyclable. All cartons contain
recycled materials.
Please recycle responsibly.

INSTALLATION
WIRING DIAGRAM
Warning:
Unused wires must be capped
using enclosed wire nuts.
Fig. A
READY
RED
TEST
Fig. D Fig. E Fig. F Fig. G
Fig. B Fig. C
J-Box Mounting
1. Open the Base plate and lead out a wire after getting through the hole on the Base plate. Fix the
Base plate on J-Box with screws.
2. Then connect to AC power (Fig.D).
3. Connect to the battery with connectors (Fig.E).
4. Install the housing to Base plate, turn on the AC power and press the “TEST” button check light
(Fig.F).
Conduit Mounting
1. Use tool to pry the hold position on both sides of the transparent lid to remove it. (Fig. A)
2. Press holding bottoms to take the unit out of the base plate. (Fig. B&C)
3. Secure Base Plate to wall surface. Route wires through hole in conduit ange and make conduit
connection. Use exible conduit only. (Fig.D)
4. Connect battery only after continuous AC power is being supplied to the unit (Fig. E).
5. Place the unit back to the base plate and add the transparent lid on, make sure both unit and
transparent lid are xed.
6. Align snaps and push housing directly onto the Base Plate (Fig. G). Apply continuous AC power
and press “TEST” button to check light.
OPERATION
1. During an electrical power failure, the lamps on the unit will automatically come ON for a
minimum of 90 minutes.
2. To test this unit, let it charge correctly with AC power supply for a minimum of 24 hours after its
rst installation and then depress the “TEST” switch, the emergency lamps will illuminate. When
the switch is released, the lamps will turn OFF.
BATTERY
Topa 3.6V/900MAH
JYH 3.6V/1000MAH
100~300 VOLT
NEUTRAL
NOTE: UNUSED LEAD
MUST BE CAPPED WITH
ENCLOSED WIRE NUT
WHITE
CHARGER
BOARD
+
LAMPLAMP
BLACK
RED
BLACK
BLACK
RED
RED
