HUROM HV Series User manual
HV Series
Precautions for safe use Terms for Parts
How to use Cautions during
operation
How to trim the
ingredients! / Use by
strainer types
Before Requesting for
Repair
When squeezing screw
stops during operation /
Caution when using
operation button
Before Requesting for
Repair
02 04
08 09
How to assemble
06
12
16
13
20
How to use control
lever[by mode / by
ingredients (Juicing)]
10
How to Clean
14
Hurom Juicer Household Use (Warranty Included)
1. Read ‘Precautions for safe use’ (Page 2) and use the appliance properly.
2. After finish reading the manual, keep it in a convenient location for future reference.
3. Do not use it abroad which has different power supply and voltage.
4. Any quality improvements are subject to change without notice.
02
Precautions for safe use
1. You should read <Precautions for safe use>.
2. You should follow <Precautions for safe use>.
3. Precautions are classified as following.
Warning When violating the labeling requirement, it may cause serious injury or death.
DO NOT PLUG OR UNPLUG WITH WET HANDS. It may cause electric shock or injury.
DO NOT USE OTHER THAN 230V - 240V AC. It may cause electric shock, fire or product failure.
If the voltage is different, it may shorten the life of the motor or cause a failure.
PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL SOCKET.
It may cause an electric shock or a fire.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER OF
ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
If the power cord is damaged, it may cause electric shock or fire.
NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR REPAIR THE PRODUCT
BY YOURSELF. DO NOT INSERT FINGERS, FOREIGN SUBSTANCES OR OBJECTS SUCH AS
PINS INTO GAPS OR HOLES IN THE BODY. It may cause a fire, electric shock or product failure. For any
technical support, contact the authorized local Customer Service Center.
WHEN THE POWER CORD, WIRE IS BROKEN OR DAMAGED, OR THE PLUG-IN PART
BECOME LOOSE, DO NOT OPERATE IT. It may cause electric shock, fire or injury.
DO NOT MOISTEN BODY OR SPLASH WATER ON THE BASE.
Be careful not to let any liquids or other substances get into the switch of the appliance.
DO NOT OPERATE THE SWITCH WITH WET HANDS. It may cause an electric shock or fire.
FOR SAFETY, MUST DO GROUNDING CONNECTION. ALSO, DO NOT DO THE GROUNDING
ON GAS PIPE, PLASTIC WATER PIPE, TELEPHONE WIRE, ETC.
It could cause electric shock, fire, malfunction or explosion. Be sure to use the electrical outlet with ground connection.
NEVER DISASSEMBLE THE CHAMBER SET DURING OPERATION OR INSERT FINGERS,
FOREIGN OBJECTS SUCH AS FORKS, SPOONS, ETC. INTO HOPPER CHUTE OR JUICE
OUTLET. It may cause injury, accident or product failure.
APPLIANCES CAN BE USED BY PERSONS WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE IN A SAFE
WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY
WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY
CHILDREN. THIS APPLIANCE SHALL NOT BE USED BY CHILDREN. KEEP THE APPLIANCE
AND ITS CORD AWAY FROM CHILDREN.
03
Caution When violating the labeling requirement, it may cause serious injury or damage to the appliance.
DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY. It may cause an injury or a failure.
WHEN A GAS LEAK IS DETECTED, DO NOT INSERT THE POWER CORD INTO ITS SLOT.
OPEN THE WINDOW IMMEDIATELY FOR AIR VENTILATION. It may cause injury or failure.
NEVER PUT A FINGER, FORK OR SPOON, ETC. INTO JUICE OUTLET. It may cause injury or failure.
IF SQUEEZING SCREW ROTATION IS STOPPED DURING NORMAL OPERATION, PRESS
[REV] BUTTON AND HOLD FOR 3~5 SECONDS AND AFTER REVERSE OPERATION IS
COMPLETELY STOPPED, PRESS [ON] BUTTON AGAIN. If stopping continues during the operation, the
parts may be damaged and performance may be deteriorated due to overheating in a motor. When the problem continues,
stop the appliance immediately and contact the local Customer Service Center.
DURING THE OPERATION, DO NOT ATTEMPT TO MOVE THE BASE, DISASSEMBLE THE
CHAMBER SET OR PARTS AND TRY TO LOCK THEM. It may cause an injury or a failure. If any act of event
needed, switch off first and unplug the power cord.
WHEN USING THE APPLIANCE, BE CAREFUL WITH A NECKTIE, LONG NECKLACE, SCARF,
ETC. TO NOT BE ENTANGLED INTO HOPPER CHUTE. It may cause injury, failure or breakage.
PLACE THE APPLIANCE ON A FLAT AND STABLE SURFACE. It may cause injury or failure.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME.
It may cause a motor failure due to overheating. Cool it down sufficiently about 5 minutes and operate it again.
WHEN PLACING INGREDIENTS INTO THE HOPPER CHUTE, USE ONLY THE PUSHER
PROVIDED. It may cause injury or failure.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE OR DROP IT. It may cause electric shock,
fire or damage.
IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL, EXCESSIVE HEATING, OR
SMOKE, STOP USING IMMEDIATELY AND CONTACT THE LOCAL CUSTOMER SERVICE
CENTER. When using a new appliance, it gives off a smell and the smell disappears naturally over time.
ALWAYS UNPLUG THE APPLIANCE AFTER USE. ALWAYS DISCONNECT THE
APPLIANCE FROM THE SUPPLY IF IT IS LEFT UNATTENDED AND BEFORE ASSEMBLING,
DISASSEMBLING OR CLEANING. WHEN UNPLUGGING THE POWER CORD, MAKE SURE TO
HOLD THE POWER CORD. Pulling the wire to unplug may cause electric shock or fire.
DO NOT WASH AT HIGH TEMPERATURES OF 800C(1760F) OR HIGHER. DO NOT PUT THE
APPLIANCE IN A DISHWASHER, DRYER OR A MICROWAVE ETC. It may cause a failure or parts
deformation.
THE APPLIANCE WEIGHS ABOUT 5.1kg. WHEN MOVING THE APPLIANCE, ENSURE TO
MOVE IT HOLDING GRIPS TIGHTLY AT THE BOTTOM OF BODY WITH BOTH HANDS. By
attempting to hold chamber or the edge of the body, the body may fall causing an injury or failure.
04
Pulp Outlet
Control Lever
Juice Cap
Juice Outlet
Chamber packing
Juice cap packing
Silicone Brush
Brush holder
Screw axis
Terms for Parts
02. Hopper
01. Pusher
03. Squeezing Screw
04. Fine Strainer 05. Coarse Strainer
07. Chamber
06. Spinning Brush
Hopper Chute
Safety Sensor ( )
05
Shaft
Body bump
*Chamber Rack can't
be separated after
assembling.
10. Pulp Container
09. Juice Container
12. Small Cleaning Brush
11. Cleaning Brush
08. Body
13. Chamber Rack
How to use
Operating
Switch
Power Cord
Safety Sensor ( )
06
How to assemble
1 2 3
Spinning
brush
groove
Spinning
brush
grooves
* If the strainer is not placed below the
groove, the hopper will not be locked.
Squeezing
screw
wings
Assemble the strainer under
the groove of spinning brush
just like from the picture.
Put the assembled part in
proper place by moving left
and right in the chamber just
like the picture no.1.
Assemble the squeezing
screw like the picture.
If they are not completely
assembled, the chamber set will not
be closed.
Put the auger by turning it to fit in
the spinning brush grooves.
!
07
54
123
2
1
3
The chamber set will not fit in to the base if
the lever is placed in position.
Please assemble according to the safety sensor.
The appliance will not work if the chamber set isn’t
assembled well even though it is on the body.
Assemble the bottom of the chamber to
bump of the body.
After putting the hopper on
the chamber, turn it clockwise
until it is locked completely.
Mount the chamber set on the
body.
Make sure the lever is placed in
position.
Assemble the squeezing
screw like the picture.
Put the auger by turning it to fit in
the spinning brush grooves.
08
How to use
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
누름
정회전
역회전
작동스위치 정회전
역회전
ON
REV
ON
REV
[ON]
On
[REV]
Reverse
Press
Stop
[ON]
On
[REV]
Reverse
NOTE
When using [ON] or [REV] buon, make sure that the squeezing screw is completely
stopped.
Press [ON] buon to start.
Place the control lever into CLOSE
() position before operating.
Place the control lever in half-open ( )
pung the last ingredients.
The hopper will be opened easily as long as the
residues in the strainer are released.
Stop the machine slowly after press the button for
safety and product performance.
Do not press the ingredients with anything except the
pusher provided.
Please put the ingredients as 3~4cm sizes.
When you extract over 400ml at once, please open
the control lever every 400ml to emit the pulp.
For your safety, this appliance only works when
it's correctly assembled with chamber set.
The chamber will not be assembled with body if the
control lever is not into CLOSE( ) position.
1
3
5
2
4
Put ingredients gradually in the hopper
chute and press with the pusher.
After extraction is completed, place the
switch in the [REV] position.
09
Cautions during operation
Withered ingredients because of refrigerated for long term may make small amount of juice or
impossible to make juice. If the unit is not cleaned immediately after use, a residue may dry and
stick to the unit. This will make assembling and cleaning difficult as well as lead to performance
degradation.
Ingredients which needs cauon.
It may cause damage or failure.
- Fruits with hard seeds such as persimmon, Japanese apricot, lemon, plum, peach etc. that are hard to
We recommend you to drink green vegetable juice and fruit juice immediately aer extracon
rather than keeping them for long me.
Do not use for grinding grains.
Do not re-squeeze residues expelled through the pulp outlet.
Do not operate the appliance before pung in the ingredients.
Do not use the appliance for more than 30 minutes connuously.
Never insert nger, fork or spoon etc. into juice outlet during the operaon.
spinning brush and cause damage to the parts.
Do not press the ingredients with anything except the pusher.
Do not operate the switch with wet hands.
When you extract over 400ml at once, please open the control lever every 400ml to emit the pulp.
NOTE
10
The control lever is between the juice cap and pulp outlet.
The control lever has various functions and can help to extract juice by characteristic of ingredients except extract function.
Cleaning Mode
Preparation/Extraction mode
How to use control lever by mode
NOTE
Completion, Simple Cleaning Mode
when putting in the last ingredients and release
residues in the strainer are released.
For general ingredients, the extraction rate is good
pulp.
rubus coreanus, and pomegranates, place the control
When detaching and cleaning the chamber, place the
When it is hard to open the hopper after the operation:
Place the control lever into half-closed ( ) position and press Reverse button for
about 3~4 seconds. Repeat this for 2~3 times and the hopper will be open easily.
11
1
1
2
2
How to use control lever by ingredients (Juicing)
Ingredients
Seed ingredients
Mixed with Milk
Apple, pear, melon, watermelon, strawberry, blueberry, orange, grapefruits,
lemon, mango, plum, peach, cherry, persimmon, pineapple, wheat-grass,
parsley, celery, dandelion, carrot, ginger, potato, beet, tomato, paprika, broccoli,
cauliflower, cabbage, kale, spinach, Cooked sweet potato and pumpkin, Cone.
1. Start as position. 2. When extraction is almost finished, place the
control lever into, Half-Opened position
Grapes, pomegranate, blackberry, kiwi
1. Start as position.
Banana, strawberry and blueberry, etc.
1. Start as position.
12
Use by strainer types
Fruits like apple, pear, kiwi, oriental melon, etc. put them with seeds and peels.
However, apple seeds contain toxicity, so it is better to remove them.
Separate each grape from the cluster. Peel the pomegranate and use flesh only.
Peel off the skin of watermelon, orange, grapefruit and cut them into right size.
Fruits like mango, cherry, peach, or plum, etc. have hard seeds which are hard to
swallow. Those seeds might cause stoppage or parts damage, so they must be
removed before using it.
Put a handful of wheat or chives in not to be scattered.
Cut fibrous ingredients into small sized less than 3cm.
* This is a reference about how to trim the ingredients,
so if you have allergy please choose your own proper ingredients.
* Please refer to the recipe book for the product usage of each ingredient.
Apple, pear, kiwi,
oriental melon
Watermelon, orange,
grapefruit
Mango, cherry,
peach
Wheat, chives
Water parsleys,
angelica, celery, kale
Pomegranate,
grapes
How to trim the ingredients!
For juicing
Fine strainer has tiny and fine holes good to make clean juice.
Fine Strainer
Coarse strainer has larger holes so is good to make thick juice
with flesh in it.
It is to make juice with so fruits and thick juice like banana, strawberry, and
also useful for smoothie, lae, or soup.
Coarse Strainer
13
开关操作法
Caution when using operation button
NOTE
NOTE
1
2
Even aer following the direcons above and sll
doesn’t work, please unplug the power cord and
disassemble chamber set, and clean it. And try it
again.
[REV] is the buon to push back the ingredients
upward.
[REV] only works while pressing the buon, and
the rotaon of the squeezing screw stops If you
release the buon.
Press [REV] buon on the operang
switchfor about 2~3 seconds and stop it.
Repeat this 2~3 mes.
Press [ON] buon to operate aer reverse
operaon is completely stopped.
When using [ON] or [REV] buon, make sure that
the squeezing screw stops completely.
In case of reversing during operaon, press [REV] buon shortly to stop the
appliance, then you press [REV] buon for operaon.
From the feature of the product, even though you stop the operaon, it doesn’t stop right away.
It rotates slowly then stops. If the rotaon stops completely, you may press the buon to any
direcon you want.
<ON>
<ON>
<REV>
<REV>
<STOP>
When squeezing screw stops during operation
14
1.
2.
3.
4.
5.
6.
7.
Unplug the power cord with dry hands after
the unit has been completely stopped.
Remove the chamber set from the main body.
Twist the hopper to open and lift up the parts
in order to disassemble the unit.
Use a cleaning brush and wash the chamber
set under running water.
Open the control lever ( ) and juice
cap to wash the chamber
Wipe the main body with a damp towel or a
soft cloth.
The silicone packing can be disassembled and
washed. (Including juice cap packing, chamber
packing, silicone brush)
Soak in water diluted with one or two drops
of baking soda or natural bleach for dishes for
about 30 minutes to sterilize and clean.
How to Clean
※When you clean the chamber set, wash the
residue inside of the chamber rst. And then
disassemble the chamber packing and wash it
under running water.
1.
2.
If the chamber is not cleaned immediately aer use, a residue may dry and sck to the
unit. This will make disassembling and cleaning dicult as well as lead to performance
degradaon. Please wash the chamber set immediately aer use.
Do not wash with hot or boiling water, an iron scrubber, abrasive material, sink solvents, or
sharp cleaning tools. Do not put it in a dishwasher or dish dryer. Aer washing, thoroughly
and naturally dry, and store in a clean area.
NOTE
Clean the parts
15
※When you clean the chamber set, wash the
residue inside of the chamber rst. And then
disassemble the chamber packing and wash it
under running water.
Remove the silicone brush from the pinning
brush holder.
Use a cleaning brush and wash the inside
and outside of the spinning brush holder
under running water.
Please follow the recommended method to
separate the silicone brush. Otherwise, it may
cause damage of spinning brush holder and
silicone brush.
Wash the silicone brush under running water as
the same method.
1
2
Spinning Brush
Open the juice cap, hold the chamber and juice
cap with one hand, and remove the juice cap
packing with your other hand to disassemble.
Please be careful not to drop or damage the juice
cap and chamber when disassembling the unit.
Pinch the chamber packing with two ngers and
twist to separate.
Please assemble the upper and lower parts
correctly. (Refer to chamber packing image on the
le.)
Juice Cap Packing
Chamber Packing
16
ON
REV
number or bar code available.
03. The Appliance does not work.
Make sure that the power cord is properly plugged in.
Check if the hopper is assembled properly.
Check if the appliance is assembled according to the direcons in the manual.
04. The appliance stops during normal operaon.
Have you inserted heavy loads or large pieces of ingredients into the appliance?
Refer to page 13 of the manual and follow the guideline for using [REV
05. The hopper does not open.
There might be a lot of residues inside.
[ONREV
Have you placed any foreign substances or solid objects (hard seed such as persimmon seed) in
the juicer?
Press [
01. The main body itself will not work.
02. Please assemble according to the
safety sensor.
Before Requesting for Repair
17
08. Juice leaks over the body.
Have you inserted a lot of ingredients into the hopper chute?
09. There are ne lines or scratch marks around the squeezing screw.
This is a normal product and there is no problem for use.
10. The Chamber shakes when squeezing.
Slight shaking may be caused by the motor.
-
11. Chamber set does not t into the body.
If the control lever is in
assembling the chamber set, make sure that the control lever is in position.
07. Do not use in ways other than press-
ing on the pusher in the inlet.
06. Do not insert too many ingredients
at once.
-
18
MEMO
19
MEMO
Product name
Supplier
Date of purchase
Address
Model name
Manufacture’s serial number
Customer name
4DC010000_V.00
Warranty
to be
-
with carrier.
-
-
-
vice center.
Product Specifications
Product Name
Model Name
Rated Voltage
Rated Frequency
Rated Power
Consumpon
RPM
Hurom Slow Juicer
HV Series
43 rpm
Cord Length
Motor
Fuse
Weight
Outward
Dimension
Rated
Operang Hour
1.4 m
motor
5.1 kg
Width 227 mm
Table of contents
Other HUROM Juicer manuals
HUROM
HUROM HU-100 Ultem User manual
HUROM
HUROM H-AA Series User manual
HUROM
HUROM HG series User manual
HUROM
HUROM HH series User manual
HUROM
HUROM H-AA Series User manual
HUROM
HUROM HN Series User manual
HUROM
HUROM HH-SBB11 User manual
HUROM
HUROM HH series User manual
HUROM
HUROM HU-100 Ultem User manual
HUROM
HUROM HP Series User manual
HUROM
HUROM H-AF User manual
HUROM
HUROM HG Elite User manual
HUROM
HUROM H320N Series User manual
HUROM
HUROM HQ Series User manual
HUROM
HUROM CJ-B01BSS User manual
HUROM
HUROM HG Elite User manual
HUROM
HUROM HH series User manual
HUROM
HUROM H-200 Series User manual
HUROM
HUROM HP Series User manual
HUROM
HUROM HU-100 Ultem User manual
