시방서
DESIGN SPECIFICATION
R&D2본부 디자인팀 자재명(자재번호 / 파일명 / 버전) : 작성일 :
󾖴󻸛󼓣󼛷
󾖴󼓧󻼳󻄳󻾇
󾖴󼜯󻛇
󾖴󽄇󼓣󼜯
󾖴󼖋󻩧
󾖴󽐳󺥯󺩤
󾖼󾖴󼓿󼔛󾖴󻸛󼌀
󾖼󾖴󺮟󼔛󾖴󼌧󼌣
󾖼󾖴󼖋󼔀󾖴󻥾󾖴󻾇󼖄󼓫󼓿
󾖼󾖴󻾇󼖄󻸛󽋜
󾖴󻦋󼙫󼐘󾖴󼓧󻼳󾖴󼁋󾖴󽊳󽓷󾖴󻩧󾖴󽄇󼓣󼜯󾖸󼁋󻦘󻺋󾖹󾖴󻸜󼖋󾖴󽐳󾖴󼜳󽋸󽋇󻺧󼐃󾖼󾖴 본 파일은 시방과 인쇄파일을 포함합니다. 유관의 부서와 업체의 견적 / 사양 / 발주 인쇄 진행 / 품질검사 외에는 사용을 금합니다.
인쇄물 시방서 개정 : 19' 11
강영진 4DC010894 사용설명서 통합 H310A Series 영문_V.01 2022. 01. 28
150 x 220 mm
표지- 1도 인쇄
내지- 1도 인쇄
M 메트지 100g
12페이지
중철
없음
영어
1. 2022.01.28-V.01
1. 해당없음

English
Manuale di istruzioni (solo per uso domestico / garanzia non inclusa) | Manuale di istruzioni | Serie H310A
TM

02
outlet.
Do not forcibly bend, tie, damage, or pull the power
cord. Do not place it near a high temperature or a
heat, such as a gas cooktop, and do not place any
heavy objects on top of it, wedge it into a narrow
space, or alter it.
Do not ever modify it. Do not attempt to dismantle
or repair it yourself.
Do not insert foreign objects, such as a finger or
iron pin, into any cracks or holes in the product body.
Failure to follow this instruction may result in fire,
electric shock, injury, or malfunction. For after-sales
service and product maintenance, contact the HUROM
Customer Center.
When the power plug is damaged, do not repair
or dismantle it on your own. Take the product to the
after-sales service center or store.
Do not get wet or splash water over the product
body. Make sure that no water or foreign material
enters the product's power switch.
Do not operate the power dial with wet hands.
For your safety, always ground your power outlet.
Also, do not ground it to gas pipes, plastic water pipes,
or telephone lines. Make sure that you use a grounded
outlet.
Never attempt to dismantle any parts of the
chamber set, or put foreign objects, such as a
finger or spoon, into the inlet or juice outlet during
operation.
Do not use it within reach of children. Children
should be carefully supervised so that they do not
use this device or play with it. There is risk of injury or
damage if children accidentally hit and knock it down.
Do not use the juicer by yourself if you are not
used to handling it. Anyone with physical or mental
conditions, or users who lack experience and
knowledge, should not use it without a supervisor
present.
Do not use the product while wearing or holding any
items with magnetic force (e.g., magnetic bracelets,
etc.). Placing magnetic objects around the product
may lead to malfunctions.
Caution Failure to comply with the label
instructions may result in serious injury or death.
Do not operate it unless the product body and
chamber set are securely connected.
If there is a gas leak, etc., then do not touch the
power cord. Open the windows and thoroughly
ventilate the area.
If the screw stops rotating during operation, turn
the dial to the [REV] direction for 3 to 5 seconds to
activate the reverse operation. Then, turn the dial
again to the [ON] direction. If the screw is continuous-
ly in the stopped state, it may overheat the motor and
cause damage to parts and impairment of functions. If
Warning Failure to comply with the label
instructions may result in serious injury or death.
Do not plug in or pull out the power cord with wet
hands.
Use the right voltage only as specified on the
warranty card and the product specifications. Failure
to follow this instruction may result in electric shock,
fire, or performance impairment. Connecting to a
different voltage may shorten the motor's lifespan or
cause a malfunction.
Securely plug the power cord all the way into an
Instruction Manual [Home use only / Warranty not included]  | H310A Seires
You should read <Safety Precautions>.
You must follow <Safety Precautions>.
Precautions are classified as follows.
1. Precautions for Safe Use
Read "Safety Precautions" (p. 2-3) and use the
appliance properly.
After reading the manual, keep it in a convenient
location for future reference.
This appliance is for domestic use (Korea) only. Do
not use it in countries that have a different power
supply and voltage.
Any quality improvements are subject to change
without notice.
Before Reading Manual
01
02
03
04
01
02
03
CONTENTS
P. 0 2
P. 0 3
P. 0 4
P. 0 6
P. 0 7
P. 0 8
P. 0 9
P.10
P.11
1. Precautions for Safe Use
2. Cautions during Operation
3. Power Dial
4. Precautions before Juicing
5. How to Assemble
6. Assembly and Disassembly of
Silicone
7. How to Operate
8. When the Screw Stops during
Operation
9. How to Disassemble and Clean
10. Before Requesting Repair

03
English
the problem continues, stop the product and contact
the HUROM Customer Center.
Do not move the product body, or disassemble or
assemble the chamber set or parts, while it is in
operation. sure to stop it, unplug the power cord
before you move, disassemble or connect it.
Pay attention while using the product to prevent
articles you may be wearing, such as a necktie, long
necklace, scarf, etc., from being pulled into the inlet.
Place this product on a flat, even surface to use it.
Do not use the product for more than 15 minutes
continuously at a time. Doing so may overheat the
motor and cause it to malfunction. For continuous
operation, completely stop operation, take a break for
at least 5 minutes, and then use it again.
Do not subject the product to extreme shock or
dropping.
If it produces unusual sounds, excessive heat, or
smoke, then stop using it immediately and contact
the Customer Center. The new product odor will
naturally go away over time.
Unplug the power cord from the outlet when it is
not in use. Also, be sure to unplug the power cord by
holding the plug head.
Do not clean it at 80 °C or a higher temperature.
Do not put it in a dishwasher, dryer, microwave,
etc. Failure to follow this instruction may cause
malfunction or deformation of its parts.
The appliance weighs approximately 3.6 kg. When
you move it, make sure that you securely hold the
product body with both hands. If you move it by just
holding the chamber or its side, then the product body
may fall, causing damage or malfunction.
This appliance is for household use only. Do not
use it for commercial purposes. Do not attempt to
extract juice from a large amount of ingredients at
once. Doing so may damage the parts. If you wish
to use it for commercial purposes, then contact the
Customer Center.
Please read the instructions for preparing
ingredients thoroughly before putting them in.
- Poorly prepared ingredients may hinder the
extraction process and/or cause damage to the
product.
Ingredients that require extra care
- When using soft ingredients alone, such as bananas,
ripened kiwis, or tomatoes, the juice may pool inside
the chamber and not be extracted properly. Please
add other ingredients that are not overly soft.
- For walnuts, peanuts, almonds, sunflower seeds,
pine nuts, beans, etc., insert only a small amount
or use them with other ingredients after steeping in
2. Cautions during Operation
water.
- When extracting only the ingredients with long and
thin stalks such as water parsley, they may not be
extracted properly. Please chop the ingredients into
1cm-long pieces before inserting them.
Ingredients that can't be juiced
- Do not use the ingredients that can't be juiced, such
as sesame seeds, coffee beans, Chinese peppers, tree
bark, pine needles, etc. Do not put in mudfish, eel,
shrimp, marsh snails, squid, etc.
- Do not use fruits soaked in alcohol, honey, or sugar
(e.g., grapes, raspberries, mulberries) and herbal
ingredients (e.g., glasswort, rock pine enzymes).
- Do not use any ingredients that can't be juiced, such
as silverberries, aloe, cactus, quince, yams, kudzu
root, sugar cane, acorns, and dandelions.
- Do not use boiled ingredients (e.g. boiled potatoes,
boiled sweet potatoes).
- Do not use frozen ice made up of just water.
We recommend that you consume the juice
immediately, if possible, and don't refrigerate it for
a long period of time.
Do not use this product for grinding grain. Failure
to follow this instruction may cause malfunction or
damage to the product.
Do not attempt to extract juice from pulp that is
already juiced.
Do not let it run idly before putting in any
ingredients.
Do not overload ingredients into the hopper above
the guided limit mark.
Do not use it for more than 15 minutes continuously.
- Doing so may overheat the motor and cause it to
malfunction. However, when using continuously, stop
once and use breaks of at least 5 minutes in duration.
Do not insert a chopstick or spoon into the juice/
pulp outlet while it is in operation.
Do not operate the power dial with wet hands.
- Failure to follow this instruction may cause electric
shock, short circuiting, or fire. Do not get foreign
substances on or near the power dial.
Use it with the juice cap open.
- The juice can flow backwards into the hopper if the
juice cap is closed while juicing.
Do not use it when the top of the product body is wet
from extracted juice or water.
Note
1. Juicing withered ingredients or frozen fruits that
have been stored for a long time in the refrigerator
might only produce a small amount of juice or none
at all.
2. If it is not cleaned immediately after use, then
it will be harder to disassemble parts and clean off
any dry pulp inside. It may also cause performance
impairment, so clean it immediately after use.

04
REV ON
OFF
REV ON
OFF
REV ON
OFF
Turn the dial to the left or right
for operation.
※When you prepare juicing ingredients,
make sure to choose your own proper
ingredients if you have any food
allergies.
※Please refer to the recipe book for how
to use the product and tips for different
ingredients.
※Juicing ingredients should be cut
small enough for the hopper. When you
want juicing to be faster or to produce
more juice, chop up the ingredients a
bit smaller. For every 1 kg extraction,
repeat the "disassemble and clean after
juicing" cycle.
※Do not overload ingredients into the
hopper above the guided limit mark.
※Extraction of soft fruits may cause
pooling in the chamber.
※Extraction of fibrous fruits and
vegetables may cause thick juice
extraction.
※Inputting the following ingredients may
cause product damage or breakdown.
- Unjuiceable ingredients such as sesame
seeds, coffee beans, Chinese pepper,
tree bark, pine needles, etc. Mudfish, eel,
shrimp, marsh snails, squid, etc.
- Fruits soaked in alcohol, honey, or sugar
(e.g., grapes, raspberries, mulberries)
and herbal ingredients (e.g., glasswort,
rock pine enzymes)
- Any ingredients that are unjuiceable
in nature such as autumn olives, aloe,
cactus, quince, bananas, yams, kudzu
root, sugar cane, acorns, dandelions, etc.
- Boiled ingredients such as boiled potatoes
and boiled sweet potatoes
- Frozen ice made of water
※Do not use it for grinding grain.
※Please refer to <Precautions during
Operation>.
4. Precautions before Juicing
3. Power Dial
[ OFF ] : Stop - Used to stop the
product's operation
[ ] : Reverse rotation -
Used when the operation halts
while in use due to material
overload ※It only works when
the dial is being turned, and it
stops when the dial is released.
[ ] : Operation - Used to
start the product for juicing

05
English
4. Precautions before Juicing
Root vegetables
Carrots, beets, ginger, sweet potatoes, potatoes, garlic,
etc.
Wash dirt and debris off the ingredients under running
water. Peel the outer skins of fibrous ingredients such as
ginger, and cut long ingredients into sticks for juicing.
Leaf/stem vegetables
Celery, kale, cabbage, etc.
Cut the ingredients into 3-cm or shorter pieces for juicing.
Since leaf stalk vegetables are rough and fibrous, they are
not easily squeezed, and they can get caught in the screw.
When extracting only the ingredients with long and thin
stalks such as water parsley, they may not be extracted
properly. Please chop the ingredients into 1cm-long
pieces before inserting them.
Citrus fruits
Grapefruits, oranges, lemons, etc.
Prepare the ingredients by peeling and cutting them
into smaller pieces to fit in the hopper inlet. Remove
all the hard, unchewable seeds or pits before
insertion.
Fruits with thick peel
Pineapples, dragon fruit, melons, watermelons,
pomegranates, etc.
Prepare the ingredients by peeling and cutting them
into smaller pieces to fit in the hopper inlet. Remove
the seeds that are hard to chew before insertion.
Fruits with hard seeds
Grapes, apples, peaches, persimmons, plums,
cherries, pears, Korean melons, etc.
For ingredients containing seeds that are hard to
chew or large pits such as those in peaches, use flesh
only after removing the seeds or pits. Hard seeds
cause it to halt while in use and may damage its
components. Remove the apple seeds, if possible,
since they can be toxic when ground. For grapes,
pluck each grape from the bunch after cleaning them
thoroughly. Do not use the ingredients that are overly
soft on their own. Instead, put them in with other
fruits and vegetables.
4-1. Multi-screw
•󾖴 
As some ingredients need extra care in
trimming, please refer to the preparation
guide below.
•󾖴 
If you are juicing in large quantities
or multiple times, then finely trim the
ingredients and repeat the "disassemble
and clean after juicing" process.
•󾖴 
For even faster processing, cut ingredients
into smaller pieces.
Fruits with soft, juicy texture
Single extraction (berries, cherry tomatoes,
pineapples, etc.)
※After cleansing, cut the ingredients into
small pieces for the hopper inlet. Remove stalk
ends from the fruit and vegetables.
Mixed extraction (strawberries, kiwi,
bananas, tomatoes, mangoes, etc.)
※For dry and viscous ingredients, mix with
other ingredients for juicing. Remove the peel
and stalk ends, and seeds if there are any.

06
Assemble the bottom of the multi-screw (④) with the top of the multi-screw (③) as shown in the
figure.
Press down the multi-screw set assembled in the chamber.
Align the hopper [ ] assembly guide mark (①-4) with the chamber [ ] assembly guide mark
(④-2) to connect.
Turn the assembled hopper clockwise until its guide mark is aligned with the chamber assembly
guide mark [ ].
If the internal components are not assembled correctly, then the hopper won't close.
Check that the discharge cover and the loop (④-4) of the chamber are properly fastened.
1. Close the discharge cover and fasten it with the loop.
2. If the packing is not in place or the lever is not fastened properly, juice may leak or the lever may
open during extraction.
Place the well-assembled chamber set onto the product body (⑤).
Assemble the chamber set and connect it to the product body.
01
02
03
04
05
06
5. How to Assemble
01 ⑤
02 03
④-2
①-4
06
0504
④-4
⑤

07
English



01
02
03
(The juicer may leak if the product is not assembled
properly.)
Hold the silicone ring and pull it out smoothly.
After cleaning, plug the silicone ring upright into the
slot by fixing one end into place first.
Insert the rest and press down firmly
Extraction Packing
Seal Packing
After cleaning, firmly insert with the round side outward
and the grid hollow facing upward.
Assemble the packings as shown in the figure.
Juice Cap Packing
Hopper Packing
01
02
03
Grab onto one side and pull out.
After cleaning, check the top and bottom direction of
the packing and insert it upward as if you hook it on
the bottom of the multi-screw.
After checking the direction, press the rest of the
packing down without any folded part.
Screw Packing
6. Assembly and Disassembly of Silicone
01
02
01
02

08
7. How to Operate
Note
Juice container is not provided
separately.
04
08
07
05 06
01 0302
REV ON
OFF
REV ON
OFF

09
English
01 Open the hopper cover.
①Pull the lever of the hopper cover to open it.
02 Add the juicing ingredients below the limit
mark of the hopper.
①Use soft ingredients by mixing them with
others.
※Overloading the product with ingredients may
damage the product.
03 Close the hopper cover and keep the juice cap
open.
①Before pressing the extraction button, put a
cup in place first.
②The juice can flow backwards into the hopper
if the juice cap is closed. If the juice does not
come out even after opening the juice cap, then
open the hopper cover and remove the content.
04 Turn the power dial [ON] to start operation.
①The "click" sound when the product is operating
is the sound of the chamber set and the motor
binding together.
※Operation stops when the hopper cover is open.
05 During extraction, ingredients may get
stuck on the interior wall of the hopper or
cutting blades.
①Turn the dial to the [REV] direction for 3 to 5
seconds to activate the reverse operation. Then,
turn the dial again to the [ON] direction.※If the
movement of ingredients is not smooth, open
the hopper cover and organize the ingredients.
06 Let it operate for another minute or so after
the last ingredient goes down through the
hopper.
①It takes some time for the last piece to be juiced
as it slowly squeezes the ingredients.
②If the remaining pulp is removed by additionally
running the machine after extraction, then it
should be quite easy to remove the hopper and
wash the parts.
07 Once the juicing and pulp removal are done,
stop the product by turning the power dial.
①Even when it is stopped by the power switch,
the operation may stop after 3 seconds.
08 Pour any juice left by tilting the chamber set
forward.
①For thick juice like tomato juice, it is likely to
pool in the chamber set.
8. When the Screw Stops during
Operation
01 For 2 to 3 times, repeat the process
of maintaining the state in which the
power dial is turned to the [REV] direction
(counterclockwise) for 3 to 5 seconds and
then releasing the dial. The reverse rotation
is a function that returns and lifts the
ingredients upward. It only works when the
dial is being turned, and the screw rotation
stops when the dial is released.
02 󾖴󾖴󾖴󾖴󾖴󾖴
󾖴󾖴󾖺󾖴󾖴󾖴󾖴
󾖴󾖴󾖴󾗁󾗂󾖴󾖴󾖸󾖹󾖴󾖴
󾖴󾖴󾖴󾖼
Note
If it does not work even after following the
above steps, unplug the power cord from the
outlet, remove the chamber set, wash it, and
use it again.
The motor will continue to spin after the
machine is turned off but it will slow down
and come to a complete halt.
01
02
REV ON
OFF
REV ON
OFF

10
After the product stops operating completely,
unplug the power cord with your dry hands. The
motor is still slowing down after the appliance
is turned off so wait about 3 seconds before
separating the chamber set.
Separate the chamber set from the product body.
Turn the hopper open and pull off the parts in
order to disassemble them.
Wash the parts with a cleaning brush under
running water.
Wash the chamber by opening the discharge cover
and the juice cap.
Wipe the product body with a damp towel or soft
cloth.
For silicon packings, remove and wash them after
use.
- Residue may remain stuck
(hopper packing, juice cap packing, extraction
packing, seal packing, screw packing).
You can sterilize the parts by soaking them in
warm water diluted with baking soda, citric acid or
vinegar.
※Failure to clean the product immediately after use can
cause its stainless steel parts and other parts to corrode or
become discolored due to salt and pulp from the ingredients.
Contaminants may dry out and get stuck inside, making it
difficult to disassemble or clean it, as well as adversely affect
its performance. Be sure to clean and air dry it completely
after use and store it in a clean place. For long-term storage,
clean it with the cleaning brush first. Do not clean it with
boiling water or subject it to high temperatures. Do not use
abrasive cleaning products or tools like kitchen sink cleaners
or a stainless-steel sponge. Do not put it in a dishwasher or
dish dryer.
※
01
02
03
04
05
06
9. How to Disassemble and Clean

11
Check thefollowingbeforeasking for repair. For follow-up serviceandanyinquiry
you may have while using the product, please contact our Customer Center, or
homepage at http://www.globalhurom.com Check the manufacturer’s number
or the number under the barcode when requesting for follow-up service or parts.
10. Before Requesting
Repair
01. When the appliance starts
operation, it will make a "click"
sound.
02. It won't operate with only the
product body.
03. Assemble it, making sure to
align it with the safety sensor.
04. It does not work.
05. It suddenly stops during
operation.
06. There are cracks on the screw
or scratch marks on the top part of
the screw.
07. Juice leaks through the pulp
outlet right when the ingredients
are put in the ingredients.
08. Juice flows back into the hopper.
09. Juice leaks between the hopper
and the chamber, or between the
chamber and the product body.
10. The hopper does not open.
11. The chamber is vibrating (during
juicing).
12. Pulp is discharged even when
the discharge cover is closed.
13. An unusual noise is heard while
juicing.
This is the sound when the motor and the screw are connected. This is not a malfunction.
Check if the chamber set and body are properly assembled.
Please turn off the power before assembling or disassembling the product.
Check if they are assembled in accordance with the guide mark.
Please turn off the power before assembling or disassembling the product.
Check if the power cord is properly plugged in.
The machine may not work after prolonged use (15 minutes or longer).
It will resume normal operation once the product body (motor) cools down.
Check if the hopper fits properly. If the hopper is connected incorrectly, the product will not
operate properly. It will only operate when the lock symbol on the chamber is perfectly aligned
with the hopper's assembly guide mark. Check if the product is assembled in accordance with the
assembly guide. Refer to Page 6 of this manual for assembly.
Is the hopper overloaded with juicing ingredients, or are the ingredients too big? Refer to Page 9
of this manual and activate reverse rotation.
Curve lines are created in addition to the straight mold marks left on the top and sides of the
screw in the process of marking molding. They are normal parts, and they do not affect the
operation.
A little juice may come out of the pulp outlet, depending on the ingredient being inserted.
This is not a product defect but the result of the characteristics of the ingredient. The leakage
will stop once the product starts running. If the leakage persists, contact the Customer Center.
Did you perform extraction with the juice cap closed? Extraction with the juice cap closed may
cause the juice to flow backward into the hopper. If the juice is not properly discharged even after
opening the juice cap again, open the hopper cover and empty out the inside.
Is the hopper packing or chamber packing assembled correctly?
Juice will leak if the hopper packing or chamber packing has been assembled upside-down or
incompletely. Check if the packing has been assembled correctly.
There may be excessive pulp remaining inside. Turn the product [ON] to discharge the remaining
pulp, or, for 2 to 3 times, repeat the process of doing a reverse rotation for about 10 seconds and
stopping it. Then, the hopper will open without any issue.
Were foreign or solid substances put in (hard seeds such as persimmon seeds)?
If there are foreign or solid substances, then attempting to operate it in reverse may further
damage the components. In this case, contact the Customer Center and request for after-sales
service.
The product may wobble slightly due to the force and motion of the product body's motor. It may
produce small and large vibrations depending on the ingredient's characteristics (hard or tough).
This is not a malfunction but a normal phenomenon caused by the rotating screw. The product
may seem to vibrate more when juicing hard ingredients than when juicing soft and watery
ingredients (e.g., carrots, potatoes, radishes, beets, kohlrabi, etc.).
Even if the lever is closed, pulp will be discharged naturally. Depending on the ingredients used,
there may be a difference in the amount and speed of pulp discharge.
It is a natural sound when the ingredients are being crushed. If the ingredients are hard or tough
like apples, carrots, cabbage, celery and beets, the noise may be louder than when juicing softer
ingredients.
English

4DC010894_V.01
MADE IN KOREA | www.globalhurom.com
Copyright© All Rights Reserved by HUROM
TM
