HUROM HP Series User manual

01
How to trim the
ingredients
How to use When Squeezing
Screw stops during
operation
Before requesting for
repair
Terms for parts
05
Precautions for safe
use
02
How to assemble
06
Cautions during
operation
04
Disassemble and
cleaning
08
09 10
Juice Cap
11
12 14
Product
Specifications /
Warranty
15
HP Series
TM
Hurom Juicer Household Use (Warranty Included)
1. Read ‘Precauons for safe use’ (Page 2) and use the appliance properly.
2. Aer nish reading the manual, keep it in a convenient locaon for future reference.
3. Do not use it abroad which has dierent power supply and voltage.
4. Any quality improvements are subject to change without noce.

02 03
Caution When violating the labeling requirement, it may cause serious injury or damage to the appliance.
WHEN A GAS LEAK IS DETECTED, DO NOT INSERT THE POWER CORD INTO ITS
SLOT. OPEN THE WINDOW IMMEDIATELY FOR AIR VENTILATION.
It may cause injury or failure.
NEVER PUT A FINGER, FORK OR SPOON, ETC. INTO JUICE OUTLET. It may cause injury or
failure.
IF SQUEEZING SCREW ROTATION IS STOPPED DURING NORMAL OPERATION, PRESS
[REV] BUTTON AND HOLD FOR 3~5 SECONDS AND AFTER REVERSE OPERATION IS
COMPLETELY STOPPED, PRESS [ON] BUTTON AGAIN.
If stopping continues during the operation,
the parts may be damaged and performance may be deteriorated due to overheating in a motor. When the problem
continues, stop the appliance immediately and contact the local Customer Service Center.
DURING THE OPERATION, DO NOT ATTEMPT TO MOVE THE BASE, DISASSEMBLE
THE CHAMBER SET OR PARTS AND TRY TO LOCK THEM.
It may cause an injury or a failure. If any
act of event needed, switch off first and unplug the power cord.
WHEN USING THE APPLIANCE, BE CAREFUL WITH A NECKTIE, LONG NECKLACE,
SCARF, ETC. TO NOT BE BE ENTANGLED INTO HOPPER CHUTE.
It may cause injury, failure or
breakage.
PLACE THE APPLIANCE ON A FLAT AND STABLE SURFACE. It may cause injury or failure.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME.
It may cause a motor failure due to overheating. Cool it down sufficiently about 5 minutes and operate it again.
WHEN PLACING INGREDIENTS INTO THE HOPPER CHUTE, USE ONLY THE PUSHER
PROVIDED.
It may cause injury or failure.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE OR DROP IT. It may cause electric
shock, fire or damage.
IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL, EXCESSIVE HEATING, OR
SMOKE, STOP USING IMMEDIATELY AND CONTACT THE LOCAL CUSTOMER SERVICE
CENTER. When using a new appliance, it gives off a smell and the smell disappears naturally over time.
ALWAYS UNPLUG THE APPLIANCE AFTER USE. ALWAYS DISCONNECT THE
APPLIANCE FROM THE SUPPLY IF IT IS LEFT UNATTENDED AND BEFORE
ASSEMBLING, DISASSEMBLING OR CLEANING. WHEN UNPLUGGING THE POWER
CORD, MAKE SURE TO HOLD THE POWER CORD. Pulling the wire to unplug may cause electric
shock or fire.
DO NOT WASH AT HIGH TEMPERATURES OF 800C(1760F) OR HIGHER. DO NOT PUT
THE APPLIANCE IN A DISHWASHER, DRYER OR A MICROWAVE ETC.
It may cause a failure
or parts deformation.
THE APPLIANCE WEIGHS ABOUT 4.3kg (9.5lb). WHEN MOVING THE APPLIANCE,
ENSURE TO MOVE IT HOLDING GRIPS TIGHTLY AT THE BOTTOM OF BODY WITH BOTH
HANDS.
By attempting to hold chamber or the edge of the body, the body may fall causing an injury or failure.
DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY. It may cause an injury or a
failure.
1. You should read <Precautions for safe use>
2. You should follow <Precautions for safe use>
3. Precautions are classified as following.
Warning When violating the labeling requirement, it may cause serious injury or death.
DO NOT PLUG OR UNPLUG WITH WET HANDS. It may cause electric shock or injury.
DO NOT USE OTHER THAN 230 - 240V AC. It may cause electric shock, fire or product failure.
If the voltage is different, it may shorten the life of the motor or cause a failure.
PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL SOCKET.
It may cause an electric shock or a fire.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER
OF ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
If the power cord is damaged, it may cause electric shock or fire.
NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR REPAIR THE
PRODUCT BY YOURSELF. DO NOT INSERT FINGERS, FOREIGN SUBSTANCES OR
OBJECTS SUCH AS PINS INTO GAPS OR HOLES IN THE BODY. It may cause a fire, electric
shock or product failure. For any technical support, contact the authorized local Customer Service Center.
WHEN THE POWER CORD, WIRE IS BROKEN OR DAMAGED, OR THE PLUG-IN PART
BECOME LOOSE, DO NOT OPERATE IT.
It may cause electric shock, fire or injury.
DO NOT MOISTEN BODY OR SPLASH WATER ON THE BASE.
Be careful not to let any liquids or other substances get into the switch of the appliance.
DO NOT OPERATE THE SWITCH WITH WET HANDS. It may cause an electric shock or fire.
FOR SAFETY, MUST DO GROUNDING CONNECTION. ALSO, DO NOT DO THE
GROUNDING ON GAS PIPE, PLASTIC WATER PIPE, TELEPHONE WIRE, ETC.
It could cause electric shock, fire, malfunction or explosion. Be sure to use the electrical outlet with ground connection.
NEVER DISASSEMBLE THE CHAMBER SET DURING OPERATION OR INSERT
FINGERS, FOREIGN OBJECTS SUCH AS FORKS, SPOONS, ETC. INTO HOPPER CHUTE
OR JUICE OUTLET. It may cause injury, accident or product failure.
APPLIANCES CAN BE USED BY PERSONS WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE
IN A SAFE WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED. CHILDREN
SHALL NOT PLAY WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE
SHALL NOT BE MADE BY CHILDREN. THIS APPLIANCE SHALL NOT BE USED BY
CHILDREN. KEEP THE APPLIANCE AND ITS CORD AWAY FROM CHILDREN.
Precautions for safe use

04 05
3 Strainer
4 Spinning Brush
Frozen fruit or withered ingredients that have been stored in the refrigerator for a long
me may give us less extracted amount or may even be impossible.
Ingredients which needs cauon
- Fruits with hard seeds such as persimmon, Japanese apricot, lemon, plum, peach etc. that are hard to
chew with our teeth should be taken out before extracon.
- For stalk vegetables with strong ber such as water parsleys, celery etc. should be cut into small size
about 3~4cm before pung into the hopper chute.
- Do not put in sesame, coee beans, bark of the tree, Chinese pepper, etc. which cannot be extracted.
- Do not put in fruits preserved in alcohol, sugar, honey, etc. (grapes, apricot, berries, etc) and enzymes
(glasswort, houseleek, etc.). It may cause damage or failure.
We recommend you to drink green vegetable juice and fruit juice immediately aer extracon
rather than keeping them for long me.
You may use for crushing spice (garlic, red pepper), but not for grinding grain.
It may cause damage or failure.
Do not re-squeeze residues expelled through the pulp outlet.
So fruits can be re-squeezed.
Do not operate the appliance before pung in the ingredients.
Do not use the appliance for more than 30 minutes connuously.
- It may cause a failure due to overheang of the motor.
When using connuously, stop it and give it 5 minutes of interval and then you may use it again.
Never insert nger, fork or spoon etc. into juice outlet during the operaon.
- Inserng such as chopscks etc. into Juice outlet during operaon may cause them to stuck into the
spinning brush and cause damage to the parts.
Do not press the ingredients with anything except the pusher.
- It may be stuck in the screw and cause injury and failure.
Do not operate the switch with wet hands.
- It may cause electric shock or re. Do not put foreign objects near the switch.
When you extract over 300ml at once, please open the control lever every 300ml to emit the pulp.
- The hopper can’t be opened or it may cause damage when the pressure in the chamber increases.
Cautions during operation
Note
Terms for parts
1 Hopper 7 Pusher
Power Cord
Locking Sensor ( )
Chamber
assembling point
Operating switch
<REAR>
2 Squeezing Screw
8 Pulp Container
9 Juice Container
10 Cleaning Brush
11 Small Cleaning Brush
Hopper Chute
Locking
Sensor ( )
Screw axis
silicone brush
Juice Outlet
Chamber
packing
Juice cap packing
5 Chamber
Pulp Outlet
Brush holder
Juice Cap
Locking
Sensor ( )
Operating
switch
6 Body
Body bump
Motor spin

06 07
How to assemble
After putting the hopper on
the chamber, turn it clockwise
until it is locked completely.
Mount the chamber set on the
body.
54
Assemble the strainer under
the groove of spinning brush
just like from the picture.
Put the assembled part in
proper place by moving left
and right in the chamber just
like the picture no.1.
Assemble the squeezing
screw like the picture.
If they are not completely
assembled, the chamber set will not
be closed.
Put the auger by turning it to fit in
the spinning brush grooves.
Align the mark on the back of the
body to the mark on the chamber
set for correct assembly.
123
Spinning
brush
groove
Spinning
brush
grooves
* If the strainer is not placed below the
groove, the hopper will not be locked.
Squeezing
screw
wings
<REAR>
<REAR>

08 09
How to use
*Do not press the ingredients with anything
except the pusher provided. Please put the
ingredients as 3~4cm sizes.
*When you use the icecream strainer, the juice
can be out through outlet and it is normal
operaon.
*When you extract over 300ml at once, please
open the control lever every 300ml to emit the
pulp.
*For your safety, this unit only works when it’s
correctly assembled with the chamber set.
Put ingredients gradually in the hopper
chute and press with the pusher.
Press [ON] buon to start.
After extraction is completed, place the
switch in stop position to stop.
2
3
1
When using [ON] or [REV] buon, make sure that the
auger stops completely.
누름
정회전
역회전
작동스위치 정회전
역회전
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
Stop
[ON]
On
[REV]
Reverse
[ON]
On
[REV]
Reverse
Press
Disassemble and cleaning
1.
2.
If the unit is not cleaned immediately after use, a residue
may dry and stick to the unit. This will make disassembling
and cleaning difficult as well as lead to performance
degradation.
Do not wash with hot or boiling water, an iron scrubber,
abra sive material, sink solvents, or sharp cleaning tools.
Do not put it in a dishwasher or dish dryer. After washing,
thoroughly and naturally dry, and store in a clean area.
NOTE
1.
2.
3.
4.
5.
6.
Unplug the power cord with dry hands after the unit
has been completely stopped.
Remove the chamber set from the main body.
Twist the chamber cover to open and lift up the parts
in order to disassemble the unit.
Use a cleaning brush and wash the chamber set
under running water.
Wipe the main body with a damp towel or a soft
cloth.
The silicone packing can be disassembled and
washed. (Including juice cap packing, chamber
packing, silicone brush)
Soak in water diluted with one or two drops of
baking soda or natural bleach for dishes for about 30
minutes to sterilize and clean.
Cleaning for parts
Open the juice cap, hold the chamber and juice
cap with one hand, and remove the juice cap pack-
ing with your other hand to disassemble.
Please be careful not to drop or damage the juice
cap and chamber when disassembling the unit.
Grab the chamber packing in the chamber sha
with both hands, and li up to remove.
Idenfy the upper and lower part of the chamber
packing and assemble.
(Refer to image)
Juice Cap Packing Chamber Packing

10 11
Even aer following the direcons above and
sll doesn’t work, please unplug the power
cord and disassemble chamber set, and clean
it. And try it again.
1
2
Note
[REV] is the buon to push back the
ingredients upward.
[REV] only works while pressing the buon,
and the rotaon of the squeezing screw stops
If you release the buon.
Press [REV] buon on the operang
switchfor about 3~5 seconds and
stop it. Repeat this 2~3mes.
Press [ON] buon to operate aer
reverse operaon is completely
stopped.
When using [ON] or [REV] buon, make sure
that the squeezing screw stops completely.
<REV>
<ON>
In case of reversing during operaon, press [REV] buon short, then press [REV] buon
for operaon.
With the feature of the product, even though you stop the operaon, it doesn’t stop right away. It rotates
slowly then stops. If the rotaon stops completely, you may press the buon to any direcon you want.
(Same as when pressing [ON] during reverse operaon)
<ON>
<REV>
<STOP>
Juice Cap
This is the cap of juice outlet from the chamber. If you close the juice cap and ll up the juice in the
chamber, you can easily make mixed fruit juice or vegetable juice with various ingredients.
Close the juice cap and press [ON] button to
start.
When juice starts filling up the bowl, you
can mix beans, boiled sweet potato, banana,
nuts etc. and liquid such as milk, etc. as well
as vegetables and fruits
Open the juice cap to pour as much as you
need and you can close it without any drops.
It is the pulp stopper made of silicone at the boom of the chamber. Make sure to close the extracon
seal always as shown below before use. For cleaning, open the extracon seal and start washing.
CLOSED
Extracon Seal
Juice Cap
Juice Cap
Juice Cap Seal
1
3
2
Juice Cap
Extraction Seal
Caution when using operation button
When the squeezing screw stops during the operation
NOTE

12 13
3. The Appliance does not work.
Make sure that the power cord is properly plugged in.
Check if the hopper is assembled properly.
If the hopper has not been locked into place, the appliance will not operate for safety reasons.
Check if the appliance is assembled according to the direcons in the manual.
Refer to instrucons for assembly in the manual or consult with your Customer Service Center for
addional assistance.
4. The appliance stops during normal operaon.
Have you in heavy loads or large pieces of ingredients into the appliance?
Refer to page 11 of the manual and follow the guideline for using [REV] buon.
If the issue is not resolved aer following the above process, please contact your local Customer
Service Center.
5. There are ne lines or scratch marks around the squeezing screw.
These are molding marks resulng from the normal manufacturing process.
This is a normal product and there is no problem for use.
1. The main body itself will not work.
For your safety, this unit only works when it’s
correctly assembled with the chamber set.
2. Please assemble according to the safety
sensor.
For your safety, this unit only works when it's
correctly assembled.
8. Juice leaks over the body.
Have you inserted a lot of ingredients into the hopper chute?
If you insert a large amount of ingredients compared to the pulp outlet, the packing is slightly pushed
away, so the juice leaks out of the gap. Do not put too much ingredients by force and just put gradually
for extracon.
9. The hopper does not open.
There might be a lot of residues inside.
Put the lever in half-closed posion, and press [ON] buon to release residues. Press [REV] buon for
3~5 seconds and stop it. Repeat this process 2~3mes.
Have you placed any foreign substances or solid objects (hard seed such as persimmon seed) in
the juicer?
Press [REV] buon and push the ingredients back up toward the hopper chute.
Do not aempt to open by force. Please contact your local Customer Service Center for assistance.
10. The Chamber shakes when squeezing.
Slight shaking may be caused by the motor.
Depending on the texture of the ingredient, there may be slight to more pronounced shaking of
This is a normal phenomenon as auger rotates and it is not a malfuncon. Hard ingredients
(e.g carrot, potato, radish, beet, etc.) may cause more shaking than so ingredients.
7. Do not use in ways other than pressing
on the pusher in the inlet.
It may cause damage, injury, etc.
6. Do not insert too many ingredients at
once.
If you insert an excessive amount of ingredients
or thick ingredients, the unit may stop.
Please check the details below before contacting Technical
Support for repair.
If you need addional informaon, please contact your local Customer Service Center or visit www.hurom.com.
When applying for aer-sales service, please have the manufacturer’s serial number or bar code available.

14 15
Product name
Supplier
Date of purchase
Address
Model name
Manufacture’s serial number
Customer name
Product Specifications
How to trim the ingredients!
Warranty
Important: For beer protecon of your purchase, ll out and mail this form to a local distributor
where you purchased the appliance and keep the original receipt.
This ceres that the Hurom Slow juicer is covered under warranty by to be free
from defects in material construcon and workmanship.
Hurom provides warranty for ten (10) years for the motor and two (2) years for other parts from
the date of purchase by the original purchaser. Coverage is valid only with proof of purchase from
an Authorized Local Distributor. (No internaonal warranty available)
This warranty does not apply to damages caused by accident, misuse, abuse, commercial
use, alteraon, failure to follow operang instrucons, or damage caused by parts or service
unauthorized by . Damages caused by transportaon must be claimed with carrier.
disclaims all responsibilies for consequenal damages from incidental losses
caused by use of this appliance.
For service and assistance with technical diculty, please contact our local customer service
center.
Manufacturer :
Hurom webpage : www.hurom.com
Product Name
Model Name
Rated Voltage
Rated Frequency
Rated Power
Consumpon
RPM
Hurom Slow Juicer
HP Series
230-240 V
50 Hz
150 W
43 rpm
Cord Length
Motor
Fuse
Weight
Outward
Dimension
Rated
Operang Hour
1.4 m
Single-phase inducon
motor
250 V 5 A
4.3 kg (9.5 lb)
Width 192 mm
Length 176 mm
Height 398 mm
Less than 30 minutes
* This is a reference about how to trim the ingredients,
so if you have allergy please choose your own proper ingredients which agrees with you.
* Please refer to the recipe book for the product usage of each ingredient.
Apple, pear, kiwi, oriental melon
- Juice fruits like apple, pear, kiwi, oriental melon, etc. put them with seeds and peels. However, apple
seeds contain toxicity, so it beer to remove them.
Pomegranate, grapes
- Separate each grape from the cluster. Peel the pomegranate and use esh only.
Watermelon, orange, grapefruit
- Peel o the skin of watermelon, orange, grapefruit and cut them into right size.
Mango, cherry, peach
- Fruits like mango, cherry, peach, or plum, etc. have hard seeds which are hard to swallow.
Those seeds might cause stoppage or parts damage, so they must be removed before using it.
Wheat, chives
- Put a handful of wheat or chives in not to be scaered.
Water parsleys, angelica, celery, kale
- Cut brous ingredients into small sized less than 3 cm.

4DC010435_V.01
www.hurom.com / Made in korea
Copyright© All Rights Reserved by HUROM
TM
