HUROM HW Series User manual

Hurom Juicer (Warranty Included)
01. Read ‘Precautions for safe use’ (Page 4) and use the appliance properly.
02. After nish reading the manual, keep it in a convenient location for future reference.
03. Do not use it abroad which has dierent power supply and voltage.
04. Any quality improvements are subject to change without notice.
HW Series
Instruction Manual

02
03
04
06
07
08
09
10
11
12
13
14
16
18
02
CONTENTS
Cautions during operation
Precautions for safe use
How to prepare ingredients / Part life cycle
Terms of parts
How to assemble
How to use
How to use control lever
How to use control lever by ingredients
When squeezing screw stops during operation
Before requesting for repair
How to Disassemble and Clean
Before requesting repair
Product Specifications / Warranty

03
03
Cautions during operation
Frozen fruit or withered ingredients that have been stored in the refrigerator for a long
time may give us less extracted amount or may even be impossible.
NOTE
We recommend you drink green vegetable juice and fruit juice immediately
after extraction rather than keeping them for long time.
You may use for crushing spice (garlic, red pepper), but not for grinding grain.
It may cause damage or failure.
Do not re-squeeze residues expelled through the pulp outlet.
Soft fruits can be re-squeezed.
Do not press the ingredients with anything except the pusher.
-It may stick to the screw and cause injury and failure.
Never insert finger, fork or spoon etc. into juice outlet during the operation.
- Inserting such as chopsticks etc. into juice outlet during operation may cause
them stuck in the spinning brush and cause damage to the parts.
Do not put in grains and fruits with hard seeds. It may cause injury and failure
of chamber, strainer and squeezing screws. The fruits with hard seeds such as
persimmon and Japanese apricot
Do not operate the switch with wet hands.
- It may cause electric shock or fire. Do not put foreign objects near the switch.
Do not operate the appliance before putting in the ingredients.
· For stalk vegetables with strong fiber such as water parsleys, celery etc.
should be cut into small size about 3~4cm before putting into the hopper chute.
· Fruits with hard seeds such as persimmon, Japanese apricot, lemon, plum, peach etc.
that are hard to chew with our teeth should be taken out before extraction.
· Do not put in sesame, coffee beans, bark of the tree, Chinese pepper, etc.
which cannot be extracted.
· Do not put in mudfish, shrimp, marsh snail and squid, etc.
· Do not put in fruits preserved in alcohol, sugar, honey, etc.
(grapes, apricot, berries, etc) and enzymes (glasswort, houseleek, etc.).
It may cause damage or failure.

04
1. You should read <Precautions for safe use>
2. You should follow <Precautions for safe use>
3. Precautions are classified as following
WARNING When violating the labeling require-
ment, it may cause serious injury or death.
WARNING When violating the labeling requirement, it may cause serious injury or death.
CAUTION When violating the labeling require-
ment, it may cause serious injury or damage to
the appliance.
04
Precautions for safe use
Do not plug in nor unplug with wet hanDs. It may cause electric shock or injury.
Do not use other than 230 - 240 V aC. It may cause electric shock, fire or abnormal performance. If the
voltage is different, it may shorten the life of the motor or cause a failure.
plug the power CorD CorreCtly anD push it tight in a wall soCket. It may cause an electric
shock or a fire.
iF the power CorD is DaMageD, it Must Be replaCeD By the ManuFaCturer’s serViCe
Center or siMilarly QualiFieD persons, in orDer to aVoiD a haZarD. If the power cord is damaged,
it may cause electric shock or fire.
neVer alter the applianCe. also, Do not DisasseMBle or repair By yourselF. Do not in-
sert Fingers, Foreign suBstanCes or oBjeCts suCh as pins into gaps or holes in the BoDy.
It may cause a fire, electric shock or failure. For any technical support, contact the authorized local Customer Care Center.
when the power CorD, wire was Broken or DaMageD or the plug-in part BeCaMe loose,
Do not operate it. It may cause electric shock, fire or injury.
Do not Moisten the BoDy or splash water on the BoDy. Be careful not to let any liquids or other
substances get into the switch on the appliance.
Do not operate the switCh with wet hanDs. It may cause an electric shock or fire.
For saFety, Must Do grounDing ConneCtion. also, Do not Do the grounDing on gas pipe,
plastiC water pipe, telephone wire, etC. It could cause electric shock, fire, malfunction or explosion. Be sure
to use the electrical outlet with ground connection.
neVer DisasseMBle the ChaMBer set During operation or insert Fingers, Foreign oB-
jeCts suCh as Forks, spoons, etC. into hopper Chute or juiCe outlet. It may cause injury, accident
or failure.
applianCes Can Be useD By persons with reDuCeD physiCal, sensory or Mental CapaBili-
ties or laCk oF experienCe anD knowleDge iF they haVe Been giVen superVision or instruC-
tion ConCerning use oF the applianCe in a saFe way anD iF they unDerstanD the haZarDs
inVolVeD. ChilDren shall not play with the applianCe. Cleaning anD user MaintenanCe
shall not Be MaDe By ChilDren. this applianCe shall not Be useD By ChilDren. keep the
applianCe anD its CorD out oF reaCh oF ChilDren.

05
CAUTION When violating the labeling requirement, it may cause serious injury or damage to the appliance.
Do not operate without loCking the hopper properly. It may cause an injury or a failure.
when DeteCting a gas leak, Do not insert the power CorD into its slot. open the winDow
to Ventilate Fully anD iMMeDiately. It may cause injury or failure.
neVer put a Finger, Fork or spoon, etC. into juiCe outlet. It may cause injury or failure.
iF rotation oF sQueeZing sCrew is stoppeD in norMal operation, press [reVerse/reV] But-
ton anD holD For 2~3 seConDs anD then aFter reVerse operation is CoMpletely stoppeD,
press [on] Button again. If such stop continues during the operation, the parts may be damaged and performance
may be deteriorated due to overheating in a motor. When the problem continues, immediately stop the appliance and contact
your local Customer Care Center.
During the operation, Do not atteMpt to MoVe the BoDy, DisasseMBle the ChaMBer set or
parts anD try to loCk theM.
It may cause an injury or a failure. If needed, switch off first and unplug the power cord.
when using the applianCe, Be CareFul For a neCktie, long neCklaCe, sCarF, etC. not to Be
entangleD into hopper Chute. It may cause injury, failure or breakage.
plaCe the applianCe on a Flat anD staBle surFaCe. It may cause injury or failure.
when plaCing ingreDients into the hopper Chute, only use the pusher proViDeD. It may cause
injury or failure.
Do not allow a seVere shoCk to the applianCe or Drop it. It may cause electric shock, fire or damage.
iF the applianCe giVes oFF an unpleasant sMell or exCessiVe heating, sMoke, stop using
iMMeDiately anD ContaCt your loCal CustoMer Care Center. When using a new appliance, it gives off
a smell and the smell disappears naturally over time.
always unplug the applianCe aFter use. always DisConneCt the applianCe FroM the sup-
ply iF it is leFt unattenDeD anD BeFore asseMBling, DisasseMBling or Cleaning. when un-
plugging the power CorD, Make sure to holD the power CorD. Pulling on the wire to unplug may cause
electric shock or fire.
Do not wash at high teMperatures oF 800C(1760F) or higher. Do not put the applianCe in a
Dishwasher, a Dryer or a MiCrowaVe etC. It may cause a failure or parts deformation.
the applianCe weighs aBout 8.6kg. when MoVing the applianCe, ensure to MoVe it holDing
grips tightly at the BoDy BottoM with Both hanDs. If attempting to hold chamber or the edge of the body,
the body falls causing an injury or failure.
05
Precautions for safe use

06
06
How to prepare ingredients
Fruits like apple, pear, kiwi, oriental melon, etc. put them with seeds and peels. However,
apple seeds contain toxicity, so it better to remove them.
Apple, pear, kiwi, oriental melon
Separate each grape from the cluster. Peel the pomegranate and use flesh only.
Pomegranate, grapes
Peel off the skin of watermelon, orange, grapefruit and cut them into right size.
Watermelon, orange, grapefruit
Fruits like mango, cherry, peach, or plum, etc. have hard seeds which are hard to swallow.
Those seeds might cause stoppage or parts damage, so they must be removed before using it.
Mango, cherry, peach
Put a handful of wheat or chives in not to be scattered.
Wheat, chives
Cut fibrous ingredients into small sized less than 3cm.
Water parsleys, angelica, celery, kale
* This is a reference about how to trim the ingredients,
so if you have allergy please choose your own proper ingredients which agrees with you.
Part life cycle
PART LIFE CYCLE(MONTH)
BASIS OF DAILY EXTRACT
(Standard ingredient : Carrot) 10kg/a day 20kg/a day Notes
·Chamber set
·Hopper
·Spinning brush
·Squeezing screw
·Silicone brush
·Juice cap packing
·Chamber packing
·Strainer
·Squeezing screw
16 Month 8 Month
16 Month 8 Month ·Cut and prepare the ingredients to insert easily.
·Do not put foreign substance.

07
09 Chamber
07
Terms of parts
Coarse Strainer 06
Pulp Container 16
08 Silicon Brush
03 Hopper
04 Squeezing Screw
09-1
Pulp Outlet
10
Control Lever
11 Juice Cap
09-2 Juice Outlet
01 Hopper Chute
05 Fine Strainer
07 Spinning Brush
13 Power Cord
12 Body
14 Small
Cleaning Brush
15 Cleaning Brush
17 Juice Container
02 Pusher
18
Safety Sensor (▲)
20
Operating Switch
19 Display

08
08
How to assemble
1
STEP
2
STEP
Press the squeezing screw into the strainer.
Check after putting in
The hoppe will not close properly when the
spinning brush is not t in completely.
Place the assembled parts from [1 STEP] into
the chamber just like the same place in the
picture.
Assemble the strainer under the groove of
spinning brush as shown in the picture.

09
3
STEP
09
How to assemble
4
STEP
Make sure the control lever is placed in
close button.The chamber set will not
t into the body if the control lever is
placed in Open position.
!Disassemble is in
reverse order of assemble.
After putting the hopper on the chamber, turn
it clockwise until it is locked completely.
①
②`

10
Put ingredients gradually in the hopper
chute and press with the pusher.
Press [ON] button.
The light on [ON] will turn on.
After extraction is completed, place the
switch in the stop position. All the lights will
be turned off except for [Power].
1
3
5
2
4
Place the lever position
before operating.
Put the control lever in [ ] position
before putting the last ingredients.
The hopper will be opened easily as long as the
residues in the strainer are released.
ON
REV
10
How to use
When using [ON] or [REV] button, make sure
that the squeezing screw stops completely.
정회전
역회전
정지상태
작동스위치 정회전
역회전
off(정지) 정지
[ON]
ON
[REV]
Reverse
Stop
ON
REV
누름
정회전
역회전
작동스위치 정회전
역회전
[ON]
ON
[REV]
Reverse
Press

11
Place the control lever in [ ] position when
putting in the last ingredients and release the residues.
The hopper will open easily when the residues in the
strainer are released.
For Simple Cleaning Mode, place the control lever in
[ ] position and release the residues.
When detaching and cleaning the chamber,
put the lever completely in [ ] position.
You can conveniently clean the chamber.
If the hopper does not open, place the lever in [ ] position and press
[REV] button for about 3~4 seconds and stop it. Repeat this process 2~3times.
Completion, Simple Cleaning Mode
Cleaning Mode
!
11
How to use control lever
How to use control lever
You can open and close the extraction packing easily.
For extracting general ingredients, placing the
control lever in [ ] position is good
enough.
However, for juicing the fruits with hard seeds,
such as grapes, rubus coreanus, and pomegranates,
place the control lever into close and switch in
[ ] position when the juice begins to
come out.
Preparation, Extraction Mode

12
12
How to use control lever by ingredients
Ingredients
Seed ingredients
Mixed with Milk
Apple, pear, melon, watermelon, Strawberry, blueberry, Orange, grapefruits, lemon,
Mango, plum, peach, cherry, persimmon, Pineapple, Wheatgrass, parsley, celery, dandelion,
Carrot, ginger, potato, beet, Tomato, paprika, broccoli, cauliflower, Cabbage, kale, spinach
(Cooked) Sweet potato, pumpkin, corn, Nuts, almonds, beans, sesame
Grapes, pomegranate, blackberry, kiwi
Banana, strawberry, blueberry, etc.
1. Start. position.
1. Start. position.
1. Start. position.
2. When extraction is almost finished,
[ ] position
2.When juice starts to come out,
[ ] position.

13
<ON>
<REV>
13
When squeezing screw stops during operation
Even after following the directions
above and still doesn’t work, please
unplug the power cord and disassemble
chamber set, and clean it. And try it
again.
Note
[REV] is the button to push back the
ingredients upward.
[REV] only works while pressing the
button, and the rotation of the squeezing
screw stops If you release the button.
Press [REV] button on the
operating switch for 3~5 sec-
onds and stop it. Repeat this
2~3times.
Press [ON] button to operate
after reverse operation com-
pletely stops.
When using [ON] or [REV] button, make
sure that the squeezing screw stops
completely.
In case of reversing during operation, press [REV] button short, then you press [REV]
button for operation.
From the feature of the product, even though you stop the operation, it doesn’t stop right away. It rotates
slowly then stops. If the rotation stops completely, you may press the button to any direction you want.
(Same as when pressing [ON] during reverse operation)
Caution when using operation button
<ON>
<REV>
<STOP>

14
How to Disassemble and Clean
01. Unplug the power cord with dry hands after
the unit has been completely stopped.
02. Remove the chamber set from the main body.
Twist the chamber cover to open and lift up the
parts in order to disassemble the unit.
03. Use a cleaning brush and wash the chamber
set under running water.
04. Open the control lever (
) and juice
cap to wash the chamber.
05. Wipe the main body with a damp towel or a
soft cloth.
06. The silicone packing can be disassembled and
washed. (Including juice cap packing, chamber
packing, silicone brush)
07. Soak in water diluted with one or two drops of
baking soda or natural bleach for dishes for about
30 minutes to sterilize and clean.
If the unit is not cleaned immediately after use, a residue
may dry and stick to the unit. This will make disassem-
bling and cleaning difficult as well as lead to perfor-
mance degradation.
Please wash the unit immediately after use. Do not wash
with hot or boiling water, an iron scrubber, abrasive
material, sink solvents, or sharp cleaning tools.
Do not put it in a dishwasher or dish dryer. After wash-
ing, thoroughly and naturally dry, and store in a clean
area.
Note

15
How to Disassemble and Clean
: Silicone
Spinning brush
Open the juice cap, hold the chamber and juice
cap with one hand, and remove the juice cap
packing with your other hand to disassemble.
Please be careful not to drop or damage the juice
cap and chamber when disassembling the unit.
To disassemble: Grab the chamber packing in
the chamber shaft with both hands, and lift up to
remove.
To assemble: Identify the upper and lower part of
the chamber packing and assemble. Stretch the
end of the packing so the surface is flat, allow it
to stick and place it all the way.
▶BE CAREFUL NOT TO APPLY TOO MUCH FORCE ON
ONE SIDE.
Juice Cap Packing
Chamber packing
Remove the silicone brush from the spinning
brush holder.
Use a cleaning brush and wash the inside and
outside of the spinning brush holder under
running water.
Please follow the recommended method to
separate the silicone brush. Otherwise, it may
cause damage of spinning brush holder and
silicone brush.
Wash the silicone brush under running water
as the same method.
2
1Silicon Brush
Spinning Brush

16
Before requesting repair
Please check the following before requesting repairs. For
requests or inquiries on A/S while using the unit, please
contact us through our customer service center (TEL)
1544-7011), or our website (http://www.hurom.co.kr).
Please check the serial number or barcode when you
request A/S or components.
03 .It does not work.
Make sure the power cord is properly plugged
in. Check if the hopper is properly engaged.
If the hopper is not properly engaged, it will
not work. Make sure the unit is assembled
according to the manual. Please refer
to the assembly guidance page. Contact
the customer service center to receive
assistance.
04. It stops during normal operation.
Was an excessive amount of ingredients or
thick ingredients inserted? Please refer to
manual P9, and try to reverse the rotation. If
the problem cannot be solved by the solution
above, please contact the customer service
center to receive assistance.
05. The squeezing screw has a mark or
a scratch.
This is a molding mark (gate) that occurs
during the manufacturing process.
It's perfectly normal, and is safe to use.
01.The main body itself will not work.
For your safety, this unit only works when it's
correctly assembled with the chamber set.
02. Please assemble according to the
safety sensor.
For your safety, this unit only works when it's
correctly assembled.
ON
REV

17
Before requesting repair
08. Juice is leaking above the main device.
Did you insert too many ingredients? If more
ingredients are inserted than can be discharged,
the packing may be pushed lightly, and juice may
leak into the gap. Do not forcibly insert a large
amount at once, but split the amount to extract
juice.
09. The hopper cannot be opened.
A lot of residue may be left inside the unit. Press
the [Extract] button to remove residue, or repeat
2-3 times by pressing the reverse button for
3-4 seconds and stopping to open the hopper.
Is a foreign substance or solid material (solid
seeds such as persimmon seeds) inside? Press
the [Reverse] button to make the residue come
up towards the inlet, and remove it. Do not
forcibly open. If the unit cannot be opened with
the recommended m ethod, please contact the
customer service center.
10. (When extracting juice) the chamber
shakes.
It may shake a little due to the power of the
motor. Large and small movements occur,
depending on the characteristics of the
ingredients (hard or chewy). This is not a defect,
since it is normally caused by the rotating
screw. Solid ingredients may seem to create
larger movements compared to moist or soft
ingredients. (E.g. Carrot/potato/radish/beet,
etc.)
07. Do not use in ways other than pressing
on the pusher in the inlet.
It may cause damage, injury, etc.
06. Do not insert too many ingredients at once.
If you insert an excessive amount of ingredients
or thick ingredients, the unit may stop.

18
1.4 m
Single-phase induction motor
250 V 5 A
8.6 kg
Width 199 mm
Length 283 mm
Height 446 mm
Product Specications
● Product Name
● Model Name
● Rated Voltage
● Rated Frequency
● Rated Power
Consumption
● RPM
Hurom Slow Juicer
HW Series
230 - 240 V
50 Hz
150 W
43 rpm
● Product name
Important: To better protect your purchase, ll out and mail this form to a local distributor where you
purchased the appliance and keep the original receipt.
This certies that the Hurom Slow juicer is covered under warranty by to be free from
defects in material construction and workmanship.
Hurom provides warranty for one (1) year for the motor, chamber, and squeezing screw(except other
parts) from the date of purchase by the original purchaser. Coverage is valid only with proof of pur-
chase from an Authorized Local Distributor. (No international warranty available)
This warranty does not apply to damages caused by accident, misuse, abuse, commercial use, alter-
ation, failure to follow operating instructions, or damage caused by parts or service unauthorized by
. Damages caused by transportation must be claimed with carrier.
disclaims all responsibilities for consequential damages from incidental losses caused
by use of this appliance.
For service and assistance with technical diculty, please contact your local customer care center.
● Manufacture’s serial number
● Supplier
● Address
● Model name
● Date of purchase
● Customer name
Warranty
● Cord Length
● Motor
● Fuse
● Weight
● Outward
Dimension
Manufacturer : | Hurom webpage : www.hurom.com

19
MEMO

www.hurom.com | Made in Korea
Copyright© All Rights Reserved by HUROM
4DC010387_V.01
