IBASE Technology IOPS-302 User manual

IOPS-302
Open Pluggable Specification
Digital Signage Player
User’s Manual
Version 1.0
(May 2018)

ii
IOPS-302 User Manual
Copyright
©2018 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from misuse or
inability to use the product or the information contained herein, and for any infringements of
rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IOPS-302 User Manual
iii
Compliance
The product described in this manual complies with all applicable European Union
(CE) directives if it has a CE marking. For systems to remain CE compliant, only CE-
compliant parts may be used. Maintaining CE compliance also requires proper cable
and cabling techniques.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product complies with the current RoHS directives restricting the
use of the following substances in concentrations not to exceed 0.1%
by weight (1000 ppm) except for cadmium, limited to 0.01% by weight
(100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
IOPS-302 User Manual
Important Safety Information
Carefully read the following safety information before using this device.
Setting up your system:
•Put the device horizontally on a stable and solid surface.
•Do not use this product near water or any heated source.
•Leave plenty of space around the device and do not block the ventilation
openings. Never drop or insert any objects of any kind into the openings.
•Use this product in environments with ambient temperatures between 0˚C and
45˚C.
Care during use:
•Do not place heavy objects on the top of the device.
•Make sure to connect the correct voltage to the device. Failure to supply the
correct voltage could damage the unit.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure the total ampere rating of all devices
plugged into the extension cord does not cord’s ampere rating.
•Do not spill water or any other liquids on your device.
•Always unplug the power cord from the wall outlet before cleaning the device.
•Only use neutral cleaning agents to clean the device.
•Vacuum dust and particles from the vents by using a computer vacuum cleaner.
Product Disassembly
Do not try to repair, disassemble, or make modifications to the device. Doing so will
void the warranty and may result in damage to the product or personal injury.
CAUTION
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries by observing local regulations.

IOPS-302 User Manual
v
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for 3rd-party parts that are not
manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices,
power adaptor, display panel and touch screen.
＊PRODUCTS, HOWEVER, THAT FAIL DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you encounter any technical problems and require assistance from your
distributor or sales representative, please prepare and send the following
information:
•Product model name
•Product serial number
•Detailed description of the problem
•Error messages in text or screenshots if any
•The arrangement of the peripherals
•Software used (such as OS and application software)
3. If repair service is required, please download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/.
Fill out the form and contact your distributor or sales representative.

vi
IOPS-302 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
CAUTION .......................................................................................................iv
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................2
1.4 Optional Accessories ..............................................................................2
1.5 Specifications..........................................................................................3
1.6 Overview.................................................................................................4
1.7 Dimensions.............................................................................................5
Chapter 2 Hardware Configuration.........................................................6
2.1 Installations.............................................................................................7
2.1.1 Memory Module Installation......................................................7
2.1.2 M.2 Cards Installation...............................................................8
2.1.3 WiFi / 3G / 4G Antenna Installation...........................................8
2.2 Pin Assignment for COM RS-232 Port ....................................................9
2.3 Setting the Jumpers..............................................................................10
2.3.1 How to Set Jumpers ...............................................................10
2.4 Jumper & Connector Locations on Motherboard...................................11
2.5 Jumper & Connectors Quick Reference................................................13
2.5.1 ATX & AT Mode Selection (JP1)..........................................14
2.5.2 Clearing CMOS Data (JP2)..................................................14
2.5.3 System Fan Power Connector (SYS_FAN1)........................15
Chapter 3 Driver Installation .................................................................16
3.1 Introduction...........................................................................................17
3.2 AMD Merlin Falcon Graphics Driver Installation....................................17
3.3 HD Audio Driver Installation..................................................................18
3.4 LAN Driver Installation ..........................................................................19

IOPS-302 User Manual
vii
Chapter 4 BIOS Setup............................................................................20
4.1 Introduction...........................................................................................21
4.2 BIOS Setup...........................................................................................21
4.3 Main Settings........................................................................................22
4.4 Advanced Settings................................................................................23
4.4.1 ACPI Settings.........................................................................23
4.4.2 IDE Configuration...................................................................24
4.4.3 F81846 Super IO Configuration..............................................24
4.4.4 Hardware Monitor...................................................................27
4.4.5 CPU Configuration..................................................................28
4.4.6 CSM Configuration.................................................................29
4.4.7 USB Configuration..................................................................30
4.5 Chipset Settings....................................................................................31
4.5.1 SB SATA Configuration..........................................................31
4.5.2 North Bridge...........................................................................32
4.6 Security Settings...................................................................................33
4.7 Boot Settings.........................................................................................34
4.8 Save & Exit Settings..............................................................................35
Appendix ......................................................................................................36
A. I/O Port Address Map............................................................................37
B. Interrupt Request Lines (IRQ)...............................................................40
C. Watchdog Timer Configuration..............................................................41

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Specifications
•Optional Accessories
•Overview
•Dimensions

2
IOPS-302 User Manual
1.1 Introduction
The IOPS-302 is a slot-in digital signage player compliant with OPS (Open
Pluggable Specification). It is powered by AMD 3rd Generation R & G series
processors, supports HDMI high definition video playback, and provides
outstanding performance. It is fully compatible with large format OPS displays
and monitors and allows cableless deployment and easy maintenance.
1.2 Features
•Supports 3rd Gen. AMD Embedded R & G series APU.
•1 or 2 x DDR4-2133 SO-DIMM, expandable to 32GB
•HDMI display output and audio jacks for line-out and Mic-in
•1 x RJ45 for GbE LAN, 1 x RJ50 for RS-232 serial COM port
•2 x USB 3.0 ports, 2 x USB 2.0 ports
•1 x M.2 E2230 for Wi-Fi or Bluetooth options
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
have purchased the product. Drivers and this user manual are downloadable
from our website.
•IOPS-302 OPS Digital Signage Player
1.4 Optional Accessories
IBASE provides optional accessories as listed below. Please contact us or
your dealer if you would like to order any item(s).
•IOPS-DK1-SYS docking kit with two screws
•Power adaptor & power cord

General Information
IOPS-302 User Manual
3
1
1.5 Specifications
Product
IOPS-302 / IOPS-302-N224
System
Mainboard
OPS302
Operating
System
•Windows 10 IoT Enterprise (64-bit)
•Windows 10 (64-bit), 8.1 (64-bit) & 7 (32-bit / 64-bit)
•Windows Embedded Standard 8 (32-bit / 64-bit) &
Windows 7 (32-bit / 64-bit)
•Linux Open Source (64-bit)
CPU
AMD R & G -Series 28 nm QC / DC APU
FP4 BGA package, 37 x 29 mm, 0.8 mm pitch
Chipset
AMD integrated SoC
Memory
IOPS-302: 2 x DDR4-2133 SO-DIMM, dual channel, Max. 32GB
IOPS-302-N224: 1 x DDR4-2133 SO-DIMM, single channel, Max.
16GB
Graphics
Next-gen. AMD Radeon™HD GPU integrated
Network
Controller
Realtek RTL8111G Gigabit LAN controller
Super I/O
Fintek F81846AD
Storage
1 x M.2 M2280 slot for SATA SSD
Power
Requirement
12V ~ 19V DC-in (Intel®OPS standard)
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
Chassis
SGCC, black & gray
Mounting
OPS standard bracket
Dimensions
(W x H x D)
200 x 30 x 119 mm (7.87” x 1.18” x 4.69”)
Net Weight
0.9 kg (1.98 lb)
Compliance
CE, FCC class B
I/O Ports
HDMI
1 x HDMI 1.4b
LAN
1 x GbE RJ45 LAN port
Serial
1 x RJ50 for COM1 RS-232 port
USB
•2 x USB 3.0
•2 x USB 2.0

4
IOPS-302 User Manual
Audio Jack
•1 x Line-Out
•1 x Mic-In
Expansion
1 x M.2 E2230 for WiFi or BT options
Environment
Temperature
•Operating: 0 ~ 45 °C (32 ~ 113 °F)
•Storage: -20 ~ 80 °C (-4 ~ 176 °F)
Relative
Humidity
5 ~ 90% at 45°C (non-condensing)
Vibration
SSD: 5 grms / 5~500Hz / random operation
All specifications are subject to change without prior notice.
1.6 Overview
No.
Name
No.
Name
1
Screw Holes
(for the optional docking kit)
6
RJ50 COM RS-232 Port
2
HDMI Port
7
Audio Jacks
(From left to right: Line-Out, Mic-In)
3
GbE LAN Port
8
Antenna Holes
4
USB 3.0
9
Power Button
5
USB 2.0
10
LED Indicators
(From left to right: for power, for HDD)

General Information
IOPS-302 User Manual
5
1
1.7 Dimensions
Unit: mm

6
Chapter 2
Hardware Configuration
This section contains general information about:
•Installations
•Jumper and connectors

Hardware Configuration
IOPS-302 User Manual
7
2
2.1 Installations
Before installing any card or module into the device, remove the screws
shown in the picture below to pull out the cover.
2.1.1 Memory Module Installation
To install or replace the memory modules, locate the memory slot on the
board and perform the following steps:
1. Align the key of the memory module with that on the memory slot and
insert the module slantwise.
2. Gently push the module in an upright position until the clips of the slot
close to hold the module in place when the module touches the bottom of
the slot.
To remove a module, use your fingers to press the clips outwards until the
module pops up. Grab the module gently and pull it out of the slot.

8
IOPS-302 User Manual
2.1.2 M.2 Cards Installation
1. Align the bus connector of the M.2 card with that of the M.2 slot, and insert
the card slantwise.
2. Push the M.2 card downwards as shown in the picture below, and fix it
with a screw.
2.1.3 WiFi / 3G / 4G Antenna Installation
Insert the WiFi / 3G / 4G antenna extension cable through the antenna hole of
the front I/O cover and fasten the antenna as shown below. Then apply
adhesive around the hex nut behind the front I/O cover to prevent the
extension cable from falling off if the cable becomes loose.
1. Fasten the hex nut and the washer. Then
install the antenna.
2. Apply adhesive around here.
Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC).

Hardware Configuration
IOPS-302 User Manual
9
2
2.2 Pin Assignment for COM RS-232 Port
(RJ50 connector)
Pin
Signal Name
Pin
Signal Name
1
DSR (Data set ready)
6
DCD (Data carrier detect)
2
Ground
7
DTR (Data terminal ready)
3
Ground
8
CTS (Clear to send)
4
TX (Transmit)
9
RTS (Request to send)
5
RX (Receive)
10
RI (Ring indicator)
101

10
IOPS-302 User Manual
2.3 Setting the Jumpers
Configure your device by using jumpers to enable the features that you need
based on your applications. Contact your supplier if you have doubts about
the best configuration for your use.
2.3.1 How to Set Jumpers
Jumpers are short-length conductors consisting of several metal pins with a
base mounted on the circuit board. Jumper caps are placed (or removed) on
the pins to enable or disable functions or features. If a jumper has 3 pins, you
can connect Pin 1 with Pin 2 or Pin 2 with Pin 3 by shorting the jumper.
A 3-pin jumper
A jumper cap
Refer to the illustration below to set jumpers.
Pin closed
Oblique view
Illustration in the manual
Open
1-2
2-3
When two pins of a jumper are encased in a jumper cap, this jumper is
closed, i.e. turned On.
When a jumper cap is removed from two jumper pins, this jumper is open, i.e.
turned Off.
Pin# 1 23
1 2 3
1 2 3
1 2 3

Hardware Configuration
IOPS-302 User Manual
11
2
2.4 Jumper & Connector Locations on Motherboard
Motherboard: OPS302
OPS302 –top view

12
IOPS-302 User Manual
OPS302 –bottom view

Hardware Configuration
IOPS-302 User Manual
13
2
2.5 Jumper & Connectors Quick Reference
Jumper:
Function
Connector Name
Page
ATX & AT Mode Selection
JP1
14
Clearing CMOS Data
JP2
14
Connectors:
Function
Connector Name
Page
System Fan Connector
SYS_FAN1
15
Power Button
SW1
--
OPS Connector
CN1
--
HDMI Port
CN2
--
GbE LAN Port
CN3
--
Dual USB 3.0 Port
CN4
--
Dual USB 2.0 Port
CN5
--
COM RS-232 Port [1]
CN6
--
Audio Jack
CN7, CN8
--
DDR4 Memory Slot
J3, J6
--
M.2 E2230 Slot
J2
--
M.2 M2280 Slot
J7
--
LED Indicator
LED1 (for power),
LED2 (for HDD)
--
Battery Socket
BAT1
--
Factory Use Only
J1, J4, J5
--
[1]: Refer to 2.2 Pin Assignment for COM RS-232 Port.
