IBASE Technology SE-602-N User manual

SE-602-N User Manual
SE-602-N
User Manual

ii
SE-602-N User Manual
Revision
Release Date
V1.0
2016/01/18

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
iii
IBASE Technology Inc.
Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE ”).
Products and corporate names mentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

iv
SE-602-N User Manual
Table of Contents
Setting up your system......................................................................................... v
Care during use .................................................................................................... vi
Acknowledgments............................................................................................... vii
CHAPTER 1 INTRODUCTION ................................................................................... 1
1.1 General Description ........................................................................................ 1
1.2 System Specifications..................................................................................... 2
1.2.1 Hardware Specifications.............................................................................. 2
1.2.2 Dimensions ................................................................................................... 3
1.2.3 I/O View.......................................................................................................... 4
1.3 Exploded View of the SE-602-N Assembly.................................................... 6
1.3.1 Parts Description.......................................................................................... 6
1.4 Packing List...................................................................................................... 7
1.4.1 Optional Items module................................................................................. 7
1.5 HARDWARE INSTALLATION........................................................................... 9
1.5.1 Mounting Installation.................................................................................... 9
1.5.2 Installing the storage.................................................................................. 10
CHAPTER 2 MOTHERBOARD INTRODUCTION ........................................................11
2.1 Introduction.....................................................................................................11
2.2 Installations.................................................................................................. 133
2.2.1 Installing the Memory................................................................................. 13
2.3 Jumpers and Connectors ........................................................................... 144
CHAPTER 3 BIOS SETUP ......................................................................................177
3.1 BIOS Introduction.......................................................................................... 17
3.2 BIOS Setup................................................................................................... 177
CHAPTER 4 DRIVERS INSTALLATION ......................................................................35
4.1 Intel Chipset Software Installation Utility.................................................... 35
4.2 VGA Drivers Installation.............................................................................. 388
4.3 Realtek HD Audio Driver Installation ......................................................... 422
4.4 LAN Drivers Installation.............................................................................. 444
4.5 Intel® Management Engine Interface ........................................................ 477
4.6 Intel® USB 3.0 Drivers............................................................................... 5050
Appendix .............................................................................................................54
A. I/O Port Address Map...................................................................................... 54
B. Interrupt Request Lines (IRQ)...................................................................... 555
C. Watchdog Timer Configuration ................................................................... 566
D. MBD602 MCU ISP Specification .................................................................. 569

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
v
IBASE Technology Inc.
Safety Information
Your SE-602-N is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between -40˚C and
75˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -50°C (-58°F) OR ABOVE 85°
C (185°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.

vi
SE-602-N User Manual
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
Equipment Location
This equipment can only be accessed by SERVICE PERSONNEL or by USERS who
have been instructed about the reasons for the restrictions applied to the location.
Access is through the use of a TOOL or lock and key, or other means of security, and
is controlled by the authority responsible for the location.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
vii
IBASE Technology Inc.
Acknowledgments
AMI is a registered trademark of AMI Software International, Inc.
AMD and ATI are registered trademarks of AMD Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective
owners.

1
SE-602-N User Manual
CHAPTER 1 INTRODUCTION
1.1 General Description
The “Signature Book™” SE-602-N is a professional fanless digital signage
system powered by 5th Gen. Intel®CoreTM i7/i5 ULT Processors with Intel®HD
graphics engine integrated. Featuring a wide-operating temperature range from -40°C
to 75°C and 7V to 36V wide-range DC input, the SE-602-N is built specifically for
harsh environments in-vehicle applications. The integrated dual DVI-I interface
supports either a DVI-D or VGA display and has built-in EDID emulation function(**).
Additionally, SE-602-N has two dual-channel DDR3L-1600 sockets to provide up to
16GB of memory, dual Gigabit Ethernet, a SIM card slot and an extended temp SSD
drive for fast system boot and low heat emissions. It also comes with IntelAMT for the
remote control and power management for power on/off scheduling and power
resume functions. The ruggedized design player comes with a chassis that provides
passive cooling for better system reliability and quiet operation.
SE-602-N overview
** The integrated dual DVI-I interface supports either a DVI-D or VGA display and has built-in
EDID emulation function. To use the EDID function, turn off the power first. Then, connect the
new display port. After you turn on the power, SE-602-N will detect new EDID data.

2
SE-602-N User Manual
1.2 System Specifications
1.2.1 Hardware Specifications
Model Name
SE-602-N
System Mainboard
MBD602
CPU
5th Generation Intel® Core™ i7-5650U ULT 2.2GHz
5th Generation Intel® Core™ i5-5350U ULT 1.8GHz
Memory
2x DDR3L-1600 SO-DIMM Max. 16GB
I/O Interface
2x DVI-I with EDID emulation function
2x USB 2.0
2x USB 3.0
2x RJ45 for Gigabit LAN
1x RJ45 for RS-232 serial port
2x Microjack audio connectors for Mic-in / Line-out
Power / HDD LED, 1x Power on/off button
1x 4 pin 7-36V DC terminal block
1x clear EDID switch
Storage
1x 2.5” HDD/SSD
1x mSATA
1x NGFF M key 22 x 80mm (2280)
Expansion Slots
1x Mini PCI-E(x1) slot for Wi-Fi/ Bluetooth/ TV Tuner/ 3G /
LTE Wireless options
1x SIM card slot
2x M2(NGFF) slots for Solid State Storage Devices (SSD)/
Wi-Fi/ Bluetooth/ 3G/LTE/ TV tuner options
Power Supply
7V-36V DC-in
Construction
Aluminum + SGCC
Mounting
Standard system bracket
Dimensions
280mm(W) x 216mm(D) x 46mm(H)
10.7”(W) x 8.6”(D) x 1.8”(H)
Operating
Temperature
-40°C~ 75°C (-40°F~166°F)
Storage
Temperature
-50°~ 85°C (-58°F~185°F)
Relative Humidity
5~90% @ 45°C, (non-condensing)
Vibration
mSATA: 5 grms / 5~500Hz / random operation
RoHS
Available
Certification
CE, FCC, CCC, UL & e24 Mark
‧ This specification is subject to change without prior notice.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
3
IBASE Technology Inc.
1.2.2 Dimensions

4
SE-602-N User Manual
1.2.3 I/O View
SE-602-N front side
SE-602-N rear side

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
5
IBASE Technology Inc.
**Based on the design of SE-602-N, the use of DVI port has certain limitations. In
order to have an image on the screen, the “ odd number ” port should be plugged
in first. If the “ even number ” port is plugged in first, then there will be no image
on the screen. This procedure also applies when using the two ports at the same
time in order to have image on the screens. The only requirement is to always
plugged in first the “ odd number ” port.
**In order to erase the EDID data, the system needs to be powered off and the DVI
connector has to be removed. Afterwards, press and hold the EDID button while
power is introduced for five (5) seconds; then, release the EDID button.

6
SE-602-N User Manual
1.3 Exploded View of the SE-602-N Assembly
1.3.1 Parts Description
Part No.
Description
Part No.
Description
1
MBD602 motherboard
2
SE-602-N_perimeter
3
SE-602-N_rear cover
4
SE-602-N_front cover
5
SCREW-B30
6
SCREW-B30-B
7
NUTBOSS-S6
8
SE-602-N_heat sink
9
SE-602-N_ic heat sink_2
10
SE-602-N_hdd bracket
11
SE-602-N_HDD tray
12
SE-602-N_HDD cover
bracket
13
SATA_25HDD
14
SE-602-N_CPU Heat Sink
15
SE-602-N_ic heat sink_4

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
7
IBASE Technology Inc.
1.4 Packing List
Item No.
Description
Qty
1
Driver CD
1
1.4.1 Optional Items module
WiFi Solution
Description
WiFi module
Wireless Card;Mini PCI 802.11 A/B/G/N WT [WPEA-252NI] RoHS
(A008WIRELESS00840P)
WIFI CABLE KIT-6
Internal cable / Antenna / Bracket / Screws Kit
(SC2WIFI----A10600P)
3G Solution
Description
3G
Wireless; 3.75G UMTS/HSPA [ZU202] RoHS (A008WIRELESS00520P)
3G+GPS
Wireless; 3.75G UMTS/HSPA & GPS Module
[ZU200] RoHS (A008WIRELESS00510P)
WW-350U
Wireless; 3.75G UMTS/HSPA [NAVISYS WW-350U] RoHS
(A008WIRELESS00530P)
Cable
Cable; SMA IPX Cable For 3G 30CM [RF11030A] RoHS
(A012INTENAL010000P)
Antenna
3G [ANT0921Q2P] RoHS (A055ANT0921Q2P000P)
COM Port Cable
Description
EXT-311
Cable; EXT-311 2-HD 10C 150CM; DSUB-9F => RJ45-10M RoHS
(C501EXT3110A12000P)
EXT-312
Cable; EXT-312 2-HD 10C 150CM; DSUB-9M => RJ45-10M RoHS
(C501EXT3120A12000P)
Power adapter/cable
Description
150W power adapter
P/S;ADAPTER 150W 12V 4PIN W/LOCK [FSP150-AHAN2] RoHS
(A005PS150W0313000P)
4 pin external power
cable
CABLE;EXT-532 2-HD 30CM MINI-DIN 4-pin => EC350VM 04P+SW
RoHS (C501EXT5320302000P)

8
SE-602-N User Manual
** Power adapter connection
[Important] If you shutoff the electric switch, DO NOT push the power button of the
external power cable at the same time. Otherwise, it will send a wrong signal.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
9
IBASE Technology Inc.
1.5 HARDWARE INSTALLATION
1.5.1 Mounting Installation
1. Please install SE-602-N to the desired location using 6 screws, as shown in the
picture.

10
SE-602-N User Manual
1.5.2 Installing the storage
1. Remove the two screws on the HDD cover and draw it out.
2. Install the HDD/SSD to the HDD bracket with 4 screws.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
11
IBASE Technology Inc.
CHAPTER 2 MOTHERBOARD INTRODUCTION
2.1 Introduction
MBD602 Jumpers and Connectors

12
SE-602-N User Manual
IMBD602 Board Dimensions
