IBASE Technology SI-18 Series User manual

SI-18 Series
User Manual
2011 November V2

2
Copyright © 2011 IBASE Technology INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE”).
Products and corporate names mentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

3
Table of Contents
Safety Information ................................................................................................ 5
Acknowledgments................................................................................................. 6
Accessories ........................................................................................................... 8
Components.......................................................................................................... 9
I/O View ...................................................................................................................... 9
Specification ........................................................................................................10
Mounting SI-18 to the Wall ..................................................................................11
Wall mounting requirements ...................................................................................... 11
Selecting the location ................................................................................................. 12
Exploded view of the SI-18 assembly ....................................................................13
Parts description ........................................................................................................ 13
Installation ..........................................................................................................14
Installing WLAN antenna (Optional)............................................................................ 14
Installing the memory ................................................................................................ 18
Setting Jumper ........................................................................................................... 19
Pin Definition ............................................................................................................. 20
BIOS Setup ...........................................................................................................21
BIOS Introduction....................................................................................................... 21
BIOS Setup ................................................................................................................. 21
Main BIOS Setup ........................................................................................................ 22
Advanced Settings ...................................................................................................... 24
Chipset Settings.......................................................................................................... 35
Boot Settings.............................................................................................................. 41
Security Settings......................................................................................................... 42
Save & Exit Settings.................................................................................................... 43
Driver Installation ................................................................................................45
AMD A55E Chipset Family Graphic Driver Installation.................................................. 46

4
Realtek High Definition Audio Driver Installation......................................................... 50
Realtek LAN Controller Drivers Installation.................................................................. 52
Appendix .............................................................................................................54

5
Safety Information
Your SI-18 is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions.
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between 0˚C and
45˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE
THESTORAGE TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE
80°C (176°F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.

6
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
The warranty does not apply to the products that have been disassembled by users

7
Acknowledgments
AMI is a registered trademark of AMI Software International, Inc.
AMD and ATI are registered trademarks of AMD Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective owners.

8
Accessories
a. Power Cord x 1
b. Driver CD x 1
c. Power Brick x 1

9
Components
I/O View
Refer to the diagram below to identify the components on this side of the system.
DVI
The Digital Visual Interface (DVI) port supports a high quality VGA-compatible
device such as a monitor or projector to allow viewing on a larger external
display.
LAN
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection
to a local network.
COM
Communication or serial port is compatible with RS-232 interface without RI (ring
indicator) signal.
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting
as additional plug-in sites or hubs.
AUDIO
The stereo audio jack (3.5mm) is used to connect the system’s audio out signal to
amplified speakers or headphones.
DC-IN
The supplied power adapter converts AC power to DC power for use with this
jack. Power supplied through this jack supplies power to the system. To prevent
damage to the system, always use the supplied power adapter.

10
Specification
System Mainboard
EB-900
Construction
SGCC 1.0t
Chassis Color
Black / White
Storage
2.5” 80GB SATA HDD x 1
Mounting
Wall mount
Dimensions
125.5(W) x 36(H) x 125.5(D)mm
(4.94” x 1.41” x 4.94”)
Power Supply
60W DC adapter
Operating Temperature
0°C ~ 45°C (32°F ~ 113°F)
Storage Temperature
-20°C ~ 80°C
Relative Humidity
5~90% @45°C (non-condensing)
Vibration
HDD: 0.25 Grms/5~500Hz random operation
Shock
HDD: 15 Grms peak acceleration (11 msec duration)
RoHS
Available
‧ This specification is subject to change without prior notice.

11
Mounting SI-18 to the Wall
You can install SI-18 on plastic (LCD monitor), wood, drywall surface over studs, or
a solid concrete or metal plane directly. Ensure the installer uses at least four M3
length 6mm screws to secure the system on wall. Six M3 length 6mm screws are
recommended to secure the system on wall.
Fasteners are not included with the unit, and must be supplied by the installer. The
types of fasteners required are dependent on the type of wall construction. Choose
fasteners that are rated either ”Medium Duty“ or ”Heavy Duty.“ To assure proper
fastener selection and installation, follow the fastener manufacturer’s
recommendations.
Wall mounting requirements
Note: Before mounting the system on wall, ensure that you are following all
applicable building and electric codes.
When mounting, ensure that you have enough room for power and signal cable
routing. And have good ventilation for power adapter. The method of mounting must
be able to support weight of the SI-18 plus the suspend weight of all the cables to
be attached to the system. Use the following methods for mounting your system:

12
Mounting to hollow walls
Method 1: Wood surface –A minimum wood thickness –38mm (1.5in.) by
25.4 cm (10in.) –of high, construction –grade wood is recommended.
Note: This method provides the most reliable attachment of the unit with
little risk that the unit will come loose or require ongoing maintenance.
Method 2: Drywall walls - Drywall over wood studs is acceptable.
Mounting to a solid concrete or brick wall - Mounts on a flat smooth surface.
Selecting the location
Plan the mounting location thoroughly. Locations such as walkway areas, hallways,
and crowded areas are not recommended. Mount the unit to a flat, sturdy,
structurally sound column or wall surface.
The best mounting surface is a standard countertop, cabinet, table, or other
structure that is minimally the width and length of the unit. This recommendation
reduces the risk that someone may accidentally walk into and damage the device.
Local laws governing the safety of individuals might require this type of
consideration.

13
Exploded view of the SI-18 assembly
Parts description
Part NO.
Description
Part NO.
Description
1
HDD
2
HDD bracket
3
EB900
4
FAN Set
5
FAN bracket
6
Heatsink
7
FAN Dock
8
Bottom Chassis / Mounting
9
Chassis Body –I/O
10
Chassis Body
11
Top cover

14
Installation
Installing WLAN antenna (Optional)
SI-18 reserved one SMA connector hole for WLAN (wireless LAN) antenna
connection on I/O side. It means you can only use one antenna solution WLAN card.
For 802.11n solution, you can only have up to 150Mbit/s performance. You can have
WLAN feature by purchase WLAN set from your sales representative. And follow
below procedure to install the WLAN feature by yourself.
Before you start to install WLAN antenna and card please:
- Complete remove DC power source from SI-18.
- Please ensure you have good ESD protection environment and if possible please
wear ESD protection equipment and have well grounding connection.
1. Upside-down SI-18 and let bottom side face to you.
2. Remove all M3 screw of bottom chassis (12 pieces) with properly screw driver
from point A.
3. Rotating SI-18 to let bottom side face to your body.
4. Using screw driver to pinch out the knock-out metal-plate of SMAantenna hole
from point B. To avoid the metal fall in system, please pinch out the metal-cover
with same direction as the figure below.
A
A
A
A

15
5. Hold WLAN antenna SMAhead carefully and through the hole on I/O wall.
Beware the direction of SMA head with the hole, there only has one direction can
pass through the antenna hole. And there has one washer shall be put on head
before through into the hole, point C.
6. Fit on antenna washer then hex nut on SMAconnector and use hex socket driver
or plier to tie the nut to ensure the SMA connector secure on I/O wall.
B
C

16
7. Install your WLAN card on mini-PCIe connector and use the screw provided by
WLAN card to secure WLAN card in position on point D.
8. Wiring the IPX connector on WLAN card and manage your internal antenna
D
D

17
cable routing.
9. Screw bottom chassis back to system with 8 screws where disassembled by
procedure 2 in above.

18
Installing the memory
The motherboard supports two DDR3 memory socket for a maximum total memory of
4GB in DDR3 memory type.
Installing and Removing Memory Module (CN1)
To install the DDR3 modules, locate the memory slot on the board and perform the
following steps:
1. Hold the DDR3 module so that the key of the DDR3 module align with those on
the memory slot.
2. Gently push the DDR3 module in SOCKET position until the clips of the slot
close to hold the DDR3 module in place when the DDR3 module touches the
bottom of the slot.
3. To remove the DDR3 module, press the clips with both hands.

19
Setting Jumper
Jumpers are used on the motherboard to select various settings and features
according to your needs and applications. Contact your supplier if you have doubts
about the best configuration for your needs. The following lists the connectors and
their respective functions.
Jumper Locations
JP1: Clear CMOS Setting
JP1
Setting
Normal
Clear CMOS

20
JP2: LCD Panel Power Selection
JP2
LCD Panel Power
3.3V
5V
JP6: COM1 RS232 +5V/+12V Power Setting
JP6
Setting
Function
Pin 1-2
Short/Closed
+12V
Pin 3-4
Short/Closed
Normal
Pin 5-6
Short/Closed
+5V
Pin Definition
