IBASE Technology SI-626 User manual

SI-626
Digital Signage Player
User’s Manual
Version 1.1
(Nov. 2018)

ii
SI-626 User Manual
Copyright
©2018 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from misuse or
inability to use the product or the information contained herein, and for any infringements of
rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

SI-626 User Manual
iii
Compliance
The product described in this manual complies with all applicable European Union
(CE) directives if it has a CE marking. For systems to remain CE compliant, only CE-
compliant parts may be used. Maintaining CE compliance also requires proper cable
and cabling techniques.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product complies with the current RoHS directives restricting the
use of the following substances in concentrations not to exceed 0.1%
by weight (1000 ppm) except for cadmium, limited to 0.01% by weight
(100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
SI-626 User Manual
Important Safety Information
Carefully read the following safety information before using this device.
Setting up your system:
•Put the device horizontally on a stable and solid surface.
•Do not use this product near water or any heated source.
•Leave plenty of space around the device and do not block the ventilation
openings. Never drop or insert any objects of any kind into the openings.
•Use this product in environments with ambient temperatures between 0˚C and
45˚C.
Care during use:
•Do not place heavy objects on the top of the device.
•Make sure to connect the correct voltage to the device. Failure to supply the
correct voltage could damage the unit.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure the total ampere rating of all devices
plugged into the extension cord does not cord’s ampere rating.
•Do not spill water or any other liquids on your device.
•Always unplug the power cord from the wall outlet before cleaning the device.
•Only use neutral cleaning agents to clean the device.
•Vacuum dust and particles from the vents by using a computer vacuum cleaner.
Product Disassembly
Do not try to repair, disassemble, or make modifications to the device. Doing so will
void the warranty and may result in damage to the product or personal injury.
CAUTION
There is a danger of explosion if the lithium-ion battery is replaced with an incorrect
battery. Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries by observing local regulations.

SI-626 User Manual
v
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for 3rd-party parts that are not
manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices,
power adaptor, display panel and touch screen.
＊PRODUCTS, HOWEVER, THAT FAIL DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you encounter any technical problems and require assistance from your
distributor or sales representative, please prepare and send the following
information:
•Product model name
•Product serial number
•Detailed description of the problem
•Error messages in text or screenshots if any
•The arrangement of the peripherals
•Software used (such as OS and application software)
3. If repair service is required, please download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/.
Fill out the form and contact your distributor or sales representative.

vi
SI-626 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
CAUTION .......................................................................................................iv
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................3
1.4 Optional Accessories ..............................................................................3
1.5 Specifications..........................................................................................4
1.6 I/O View..................................................................................................6
1.7 Dimensions.............................................................................................7
Chapter 2 Hardware Installation & Motherboard Information ..............8
2.1 Installations.............................................................................................9
2.1.1 Memory Installation / Replacement...........................................9
2.1.2 Mini-PCIe & M.2 Cards Installation.........................................10
2.1.3 WiFi / 3G / 4G Antenna Installation.........................................10
2.1.4 HDMI Cable Holder Installation...............................................11
2.1.5 Mounting Installation...............................................................12
2.1.6 Pin Assignment for Power Input Connector ............................13
2.1.7 Pin Assignment for COM1 & COM2 Serial Ports.....................13
2.2 Setting the Jumpers..............................................................................15
2.2.1 How to Set Jumpers ...............................................................15
2.3 Jumper & Connector Locations on Motherboard...................................16
2.4 22Jumper & Connectors Quick Reference............................................17
2.4.1 Clearing CMOS Data (JP2).....................................................18
2.4.2 DC Power Input (CN17)..........................................................18
2.4.3 CPU Fan Power Connector (J1, J2, J3) ...............................19
2.4.4 USB 2.0 Ports Header (J7)...................................................19
2.4.5 System Function Connector (J18)........................................20
2.4.6 Digital I/O Connector (J17)...................................................20
2.4.7 Battery Connector (JBAT1)..................................................21

SI-626 User Manual
vii
Chapter 3 Driver Installation .................................................................22
3.1 Introduction...........................................................................................23
3.2 Intel®Chipset Software Installation Utility..............................................23
3.3 Intel®Graphics Driver Installation..........................................................25
3.4 HD Audio Driver Installation..................................................................27
3.5 LAN Driver Installation ..........................................................................28
3.6 Intel®Management Engine Components Drivers Installation.................29
Chapter 4 BIOS Setup............................................................................30
4.1 Introduction...........................................................................................31
4.2 BIOS Setup...........................................................................................31
4.3 Main Settings........................................................................................32
4.4 Advanced Settings................................................................................32
4.4.1 CPU Configuration..................................................................33
4.4.2 Power & Performance.............................................................34
4.4.3 PCH-FW Configuration...........................................................35
4.4.4 ACPI Settings.........................................................................35
4.4.5 iSmart Controller.....................................................................36
4.4.6 F81846 Super IO Configuration..............................................37
4.4.7 Hardware Monitor...................................................................38
4.4.8 Network Stack Configuration ..................................................39
4.4.9 CSM Configuration.................................................................40
4.4.10 NVMe Configuration ...............................................................41
4.5 Chipset Settings....................................................................................42
4.5.1 System Agent Configuration...................................................42
4.5.2 PCH-IO Configuration.............................................................43
4.6 Security Settings...................................................................................44
4.7 Boot Settings.........................................................................................45
4.8 Save & Exit Settings..............................................................................46
Appendix ......................................................................................................47
A. AMD Eyefinity Multiple Displays Configuration......................................48
A.1 Setting Up AMD Eyefinity Using Quick Setup .........................48
A.2 Customizing AMD Eyefinity Using Try Advanced Setup..........52
A.3 Video Wall Layouts Applicable to SI-626 ................................58
B. I/O Port Address Map............................................................................60
C. Interrupt Request Lines (IRQ)...............................................................63
D. Watchdog Timer Configuration..............................................................64

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Specifications
•Optional Accessories
•Overview
•Dimensions

2
SI-626 User Manual
1.1 Introduction
The SI-626 is powered by Intel®7th / 6th Generation mobile processors. It
supports three display outputs for HDMI high definition video playback and
iSmart energy-saving features such as power on/off scheduling and power
resume function. The device operates in environments with temperatures
ranging from 0°C to 45°C.
1.2 Features
•Slim and segregated ventilation design
•iSmart - for EuP/ErP power saving, auto-scheduling and power
resumption
•6 x HDMI1.4b with independent audio output
•Built-in hardware EDID emulation function
•7th / 6th Generation Intel®Core™mobile processor
•2 x DDR4-2133 SO-DIMM, dual channel, Max. 32 GB
•Flexible VW display configuration setting
•1 x Mini PCIe (full-size) for Wi-Fi, Bluetooth, 4G LTE or capture card
options
•1 x M.2 E2230 for Wi-Fi, Bluetooth, 4G LTE options
•1 x M.2 M2280 for storage
•2 x RS232 serial ports

General Information
SI-626 User Manual
3
1
1.3 Packing List
If you buy a barebone SI-626, your product package should include the items
listed below. If any of the items below is missing, contact the distributor or the
dealer from whom you have purchased the product.
Drivers and this user manual are downloadable from our website.
•SI-626 Digital Signage Player x 1
•Power Adaptor x 1
•Power Cord x 1
•HDMI Cable Holder x 1
•Screws with Washer for HDMI Cable Holder (M3 x 6 mm) x 2
1.4 Optional Accessories
IBASE provides optional accessories as listed below. Please contact us or
your dealer if you would like to order any item(s).
•VESA Kit
Including:
Mounting Bracket x 1
Round Head Screw (M6 x 35 mm) x 4
Pan Head Screw (M4 x 8 mm) x 4

4
SI-626 User Manual
1.5 Specifications
Product
SI-626
System
Mainboard
MBD626
Operating
System
•Windows 10 Enterprise (64-bit)
•Windows 7 (64-bit),
•Linux Ubuntu (64-bit)
CPU
Intel®7th / 6th Gen. Core™ mobile processor
Chipset
Intel®HM170 / QM170
Memory
2 x DDR4 SO-DIMM 2133 MHz, dual channel, expandable to
32GB
Graphics
AMD Radeon™ E8860 Graphics
Network
2 x Realtek RTL8111G GbE LAN
Super I/O
Fintek F81846AD
Storage
1 x 2.5” SATA SSD / HDD
Power
Requirement
12V DC-in
Power Supply
150W power adaptor
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
iSmart
Yes
Chassis
Aluminum and SGCC, black & white
Mounting
VESA mount 75 x 75 mm / 100 x 100 mm
Wall mount/TV Mount 200 x 100 mm
Dimensions
(W x H x D)
290 x 29.9 x 222 mm (11.41” x 1.17”x 8.74”)
Net Weight
2.1 kg (4.63 lb)
Compliance
CE, FCC class B, cULus & CCC
I/O Ports
HDMI
6 x HDMI 1.4 with hardware EDID emulation
LAN
2 x GbE RJ45 LAN port
Serial
•2 x RJ50 for RS-232 serial port
USB
4 x USB 3.0
Audio Jack
•1 x Line-Out
•1 x Mic-In
Power Jack
1 x DC-In power jack

General Information
SI-626 User Manual
5
1
SIM
1 x SIM card socket (on board)
Expansion
•1 x M.2 E2230 for WiFi / BT / 4G LTE options
•1 x M.2 M2280 for storage
•1 x full size Mini-PCIe (x1) for WiFi / BT / TV tuner / 4G LTE
options
Environment
Temperature
•Operating: 0°C ~ 45°C (32°F ~ 113°F)
•Storage: -20°C ~ 80°C (-4°F ~ 176°F)
Relative
Humidity
5 ~ 90% at 45°C (non-condensing)
Vibration
SSD: 5 grms / 5 ~ 500 Hz, random operation
All specifications are subject to change without prior notice.
Note: The product performance relies on the system functioning as a whole. The
level of CPU/APU/GPU processor, the interaction among the processor and
the memory and storage bandwidth, or the functionality of the digital signage
application software may affect the product performance.

6
SI-626 User Manual
1.6 I/O View
No.
Name
No.
Name
1
DC Power Input
7
Power Button
2
HDMI Ports
8
LED Indicator for Power
3
EDID Button*
9
LAN Port
4
USB 3.0 Ports
10
COM1 RS-232/422/485 Port
5
Audio Jacks
(From left to right: Line-Out,
Mic-In)
11
COM2 RS-232 Port
6
LED Indicator for HDD
*Be sure to press the EDID Button to acquire or change the EDID data when
the connected display/monitor cannot be recognized, or the displayed image
does not fit the screen.

General Information
SI-626 User Manual
7
1
1.7 Dimensions
Unit: mm

8
Chapter 2
Hardware Installation &
Motherboard Information
This section contains general information about:
•Installations
•Jumper and connectors

Motherboard Information
SI-626 User Manual
9
2
2.1 Installations
Before installing any card or module into the device, remove the 10 screws
shown in the picture below to remove the cover.
2.1.1 Memory Installation / Replacement
To install or replace modules, locate the memory slot on the board and
perform the following steps:
1. Align the key of the memory module with that on the memory slot and
insert the module slantwise.
2. Gently push the module in an upright position until the clips of the slot
close to hold the module in place when the module touches the bottom of
the slot.
To remove a module, use your fingers to press the clips outwards until the
module pops up. Grab the module gently and pull it out of the slot.

10
SI-626 User Manual
2.1.2 Mini-PCIe & M.2 Cards Installation
1. Align the mini-PCIe card’s bus connector with the mini-PCIe slot, and
insert the card slantwise.
(Insert M.2 cards by using the same method.)
2. Push the mini PCIe card downwards as shown in the picture, and fix it with
a screw.
(Fix M.2 cards by using the same method.)
Mini PCIe:
M.2:
2.1.3 WiFi / 3G / 4G Antenna Installation
Insert the WiFi / 3G / 4G antenna extension cable through the antenna hole of
the front I/O cover and fasten the antenna as shown below. Then apply
adhesive around the hex nut behind the front I/O cover to prevent the
extension cable from falling off if the cable becomes loose.
1. Fasten the hex nut and the washer. Then
install the antenna.
2. Apply adhesive around here.
Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC).

Motherboard Information
SI-626 User Manual
11
2
2.1.4 HDMI Cable Holder Installation
An HDMI cable holder comes with the product package. After you have
plugged the HDMI cables, you can use the holder to prevent the cables from
coming loose. Align the holder to the HDMI ports and secure it with the
supplied two round-head screws with washer as shown below.

12
SI-626 User Manual
2.1.5 Mounting Installation
Note: Mounting plate is optional and purchasable from IBASE.
Requirements
Before mounting the system, ensure that you have enough room for the power
adaptor and signal cable routing, and have good ventilation for the power
adaptor. The method of mounting must be able to support weight of the device
plus the weight of the suspending cables attached to the system.
The device with the optional mounting plate is shown as the figure below.
Prepare at least 4 screws (M3) to install the device on the wall.
•VESA 75 x 75 mm
•VESA 100 x 100mm
•Wall Mount / TV Mount: 200 x 100 mm

Motherboard Information
SI-626 User Manual
13
2
2.1.6 Pin Assignment for Power Input Connector
Pin
Signal
Pin
Signal
1
Ground
3
+12V
2
Ground
4
+12V
2.1.7 Pin Assignment for COM1 & COM2 Serial Ports
➔
(RJ50 connector)
COM1 RS-232/422/485 port:
Pin
Signal Name
RS-232
RS-422
RS-485
1
DSR
NC
NC
2
Ground
Ground
Ground
3
Ground
Ground
Ground
4
TX
RX+
NC
5
RX
TX+
DATA+
6
DCD
TX-
DATA-
7
DTR
RX-
NC
8
CTS
NC
NC
9
RTS
NC
NC
10
RI
NC
NC
4 3
2 1
101
