idi Aspect ISR G3 User manual

Aspect ISR G3 Q-CARD
SETUP/PATIENT PREPARATION:
Moving table:
•To move table, set caster lock pedal to FLOAT or
STEER position.
•To secure table mobility, set caster lock pedal to LOCK
position.
AC Power:
1) Plug power cord into properly grounded outlet.
2) Protect cord from damage by casters or other
equipment.
Controls:
1) Emergency Stop Pushbutton disables all tabletop motion
control when engaged.
2) If tabletop motion controls fail to operate, make sure
that the Emergency Stop Pushbutton is not pushed in.
BATTERY OPERATION (DC POWER):
1) The table is FULLY functional, but motions are slower.
2) Connect to AC power for a minimum of 8 hours daily to
ensure a proper battery charge.
3) Failure to push in Emergency Stop Pushbutton when
table is not in use and not connected to AC power for
longer than 72 hours, may result in permanent damage
to the batteries.
CPR:
Return table to level, retract tabletop to minimize
overhang and lower table position to a
comfortable height to perform CPR.
CLEANING AND STORAGE:
1) Unplug power cord and wrap it around cord holder.
2) Push in Emergency Stop Pushbutton.
3) Set caster lock pedal to LOCK position.
4) Clean and disinfect table.
5)
WARNING! Read operator
manual prior to use
CONNECTION POINT FOR
HAND OR FOOT CONTROLS
CONNECT HERE
EMERGENCY
STOP
PUSHBUTTON
CASTER LOCK PEDAL
www.imagediagnostics.com
BRAKES:
The ISR G3 table braking system utilizes a passive magnetic brake;
it remains engaged in the event of a complete loss of electrical
power. Power is necessary to release brakes.
Braking force is limited by the magnet strength. Use caution when
applying pressure to the side of the table as the brakes may be
overcome if more than 70 pounds of force is applied.
To reduce potential motion during patient transfers with larger
patients, release the table brake and move the top in the direction
the patient will be pulled during loading or unloading until the table
top transverse travel limit is reached. Release the panning handle to
re-engage the lock and then transfer the paitent.
POWER
CORD
RECEPTACLE
PEDESTAL END OF TABLETOP
IMAGING END OF TABLETOP
L100-2859A 03/2018

It is recommended that the pendant
control be disconnected during critical
procedures to prevent inadvertent
operation or motion, causing patient
injury. The Motion Lockout Pushbutton
on the Panhandle Unit does not disable
the Handset Control.
Aspect ISR G3 Q-CARD
www.imagediagnostics.com
CASTER LOCK
PEDAL POSITIONS
FLOAT
(Movable in
all directions)
STEER
(Rear wheels
roll forward and
backward only)
LOCK
(Will not move in
any direction)
•PUSH IN to stop
ALL tabletop motion.
•TWIST to reset.
ELEVATE
SWITCH
TRENDELENBURG
SWITCH
(Green light to left of
switch indicates table
top is level for this
motion)
ISO-ROLL
SWITCH
(Green light to
left of switch
indicates table
top is level for
this motion)
SWITCH
LOCKOUT
PUSHBUTTON
(Amber light
indicates that
switches on pan
handle are
disabled)
PANHANDLE
KNOB/ TABLETOP
FLOAT BRAKE
(Lift underside of
Panhandle Knob to
float table top. It will
not operate if table
top is not level)
L100-2859A 03/2018
Table Top Motion
Handset Control
(Optional)
Patients must be loaded from the side of table. Tilting or instability may occur if
patient is loaded onto the pedestal end of table or the imaging end of the table.
EMERGENCY
STOP
PUSHBUTTON
(Green light to
right of Tabletop
Float Brake
indicates table top
is centered on the
base laterally)
TABLE TOP MOTION
CONTROL PANHANDLE
Elevate
Tilt up Imaging
End
(Trendelenburg)
Trendelenburg
Level Indicator
ISO-Roll
Clockwise
*ISR G3 Table
Only*
Laterally
Centered
Indicator
Lower
Tilt Down
Imaging End
(Trendelenburg)
ISO-Roll Level
Indicator
*ISR G3 Table
Only*
ISO-Roll
Counter-
Clockwise
*ISR G3 Table
Only*
