FIREBOX PANEL KITS
INSTALLATION INSTRUCTIONS FOR INSTALLING FIREBOX PANEL KITS. FOR USE
WITH RAVENNA™, DRI3030TEN, DRI3030TENC AND SDVI40 GAS FIREPLACE INSERTS
775266M
Rev. A, 12/2013
HEARTH PRODUCTS
KITS AND ACCESSORIES
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE
KIT CONTENTS (See Figure 1)
Please ensure that all these parts are in the packaging.
1 ea. Rear Brick Panel (A),
1 ea. Left Brick Panel (B),
1 ea. Right Brick Panel (C),
2 ea. Retaining Brackets (D)
1 ea. Instruction Sheet
NOTE: Zen Garden, Tan Brick, Red Brick, all ship with the retaining
brackets in the kit. Architectural Stone panels use the bracket that ships
pre-installed on the unit.
CAUTION: The firebox panels are required for your appliance
to function correctly and safely.
Check the contents of the kits upon receipt and check for any damaged
or missing parts. If there is hidden damage, notify your freight company
or IHP dealer immediately.
INSTALLATION INSTRUCTIONS
If logs are not installed according to the log installation instructions,
flame impingement and improper combustion could occur and result in
soot and/or excessive production of carbon monoxide (CO), a colorless,
odorless, toxic gas.
The size and position of the log set is critical to achieve a safe, reliable
and attractive flame pattern. Any attempt to use a different log set in the
fireplace will void the warranty and will result in incomplete combustion,
sooting and poor flame quality.
Step 1. Remove the glass door per instructions in the installation and
operation manual.
Step 2. Remove the log rack (2 screws) and install the rear log on the
retainer. See Figures 1 and 2.
Step 3. Remove brick retainer bracket and install rear panel. Reinstall
the log rack with the rear log. IMPORTANT!!! SCREWS PASS
THROUGH THE LOG RACK AND THE BURNER PAN.
TOOLS NEEDED
5/32” Allen Wrench Or T-Handle Wrench
GENERAL INFORMATION
All of these parts may scratch and bend, great care should be used
in handling them.
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
Figure 1 - Log Rack Screws
Firebox Panel Kits
Cat. No. Model Description
H7979 RDV-BRK-STD Tan Brick
H7981 RDV-BRK-ARCHSTONE Architectural Stone
H7980 RDV-BRK-RED Red Brick
H8453 RDV-ZG Zen Garden
Tan Brick Red Brick
Zen Garden Architectural Stone
A
B
C
D
fire-parts.com

Printed in U.S.A. © 2011 IHP LLC
P/N 775266M REV. A 12/2013
IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor
for fireplace code information.
Innovative Hearth Products
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
Figure 2
Log Rack Rear Log
Step 5. Zen Garden, Tan Brick, Or Red Brick Panel Kits ONLY - Using
a 5/32” allen wrench or t handle remove the screws holding the
brick panel brackets on each side of the firebox. Keep those
screws as you will use them when them for the new brackets.
The new brackets are included with the brick panel set. Use the
screws that were removed to attach these new brackets with the
wrench or t handle.
Step 6. Install a light layer of glowing embers (rockwool) directly over
the ports.
- A light layer will give a more constant rear flame.
- A heavy layer will give more glow, but will need to
be adjusted after light up.
Step 7. Install front logs on retainer slots.
Step 8. Place volcanic stone around the perimeter of the glowing embers
(rockwool). IMPORTANT!!! Do not cover the ports with
volcanic stone.
Step 9. Place top log on pin.
Figure 4
Figure 5 Front Logs
Figure 3 Side Firebox Panels
Retaining Brackets
Top Log
Ports
Figure 6
Step 4. Install the side firebox panels by sliding them into place. See
Figure 3.
Step 10. Light the burner per instructions on the lighting label (in control
compartment) or in the installation and operation manual.
Step 11. If necessary, adjust the burner air shutter per instructions in the
installation and operation manual.
Step 12. Volcanic stone adjustment - To achieve optimumflame aesthetics:
If one or two flames are substantially taller than the others, turn
the flame off – open door and slightly move volcanic stone with
a screwdriver or other tool.
