Open-Q™ 410 Development Kit based on the
Qualcomm® Snapdragon™ 410 processor (APQ8016)
Quick Start Guide
Your use of this document is subject to and governed by those terms and conditions in the Intrinsyc Purchase and Software License Agreement for the based on the Open-Q™ 410 Development Kit based on the Qualcomm® Snapdragon™ 410 processor, which you or the legal entity you repre-
sent, as the case may be, accepted and agreed to when purchasing an Open-Q™ 410 Development Kit based on the Qualcomm® Snapdragon™ 410 processor from Intrinsyc Technologies Corporation (“Agreement”). You may use this document, which shall be considered part of the defined term
“Documentation” for purposes of the Agreement, solely in support of your permitted use of the Open-Q™ 410 Development Kit based on the Qualcomm® Snapdragon™ 410 processor under the Agreement. Distribution of this document is strictly prohibited without the express written
permission of Intrinsyc Technologies Corporation and its respective licensors, which they can withhold, condition or delay in its sole discretion.
Intrinsyc is a trademark of Intrinsyc Technologies Corporation, registered in Canada and other countries. Qualcomm and Snapdragon are trademarks of Qualcomm Incorporated, registered in the United States and other countries.
Package Contents 123456
24
1. 12V DC Jack
2. Headset
3. Line in
4. HDMI out on HDMI
adaptor board
5. USB client micro B
6. 2 x USB host
7. USB host switch
8. Debug UART
9. UART LED
10. Micro SD slot *
11. Sensor and IoT
expansion connector
12. Boot sengs
13. Volume down buon
14. Volume up buon
15. Power buon
16. Power and user de-
ned LEDs
17. Camera module con-
nector (CSI1) 2-lane
18. Camera module con-
nector (CSI0) 4-lane
19. WLAN/BT antenna
20. Speaker out
21. Digital audio expan-
sion connector *
22. Earpiece audio out
23. 8GB eMMC/1GB
LDDR3 RAM combo
24. Snapdragon APQ8016
processor
25. WLAN/BT antenna
connector (U.FL)
26. GPS antenna
connector (U.FL)
27. WLAN WCN3620
and WGR7640 GPS *
28. Open-Q 410 SOM
* on boom side
1. Open-Q™ 410 SOM with APQ8016 and 1GB LPDDR3 RAM
2. Carrier board 13 x 13 cm
3. AC Power Adapter
4. HDMI cable
5. 5MP camera
6. 4.46” FWVGA MIPI DSI LCD/Touch (oponal)
23 14 15 1317
7
8
11
9
21
18
10
19
16
22
20
12
25 26
27
28

Open-Q™ 410 Development Kit based on the
Qualcomm® Snapdragon™ 410 processor (APQ8016)
Quick Start Guide
Specifications are subject to change - Open-Q 410 QSG Rev. 1.2
Support
For more information or assistance make sure to visit the Open-Q 410 FAQ page:
http://www.intrinsyc.com/snapdragon-support/faq
You can also contact us at [email protected]m
Should you require additional technical support for your Development Kit you can
easily purchase a block of technical support hours from the Intrinsyc store:
http://shop.intrinsyc.com/collections/product-development-kits
Thank you for purchasing the Open-Q 410 Development Kit
The Intrinsyc team
Setup
1. Remove the development kit board carefully from the anti static bag
2. Connect the HDMI cable from the development kit to your display
3. Connect the Power Adapter; press the power button (PWR)
for 5 seconds, the board will boot automatically
4. Documentation and software
To access the documentation (schematics, user guides, datasheets,
programming guides, tech notes…), platform BSP software and much more,
please register at: http://support.intrinsyc.com
