Iron Age Office KNIGHT RECEPTION User manual

KNIGHT RECEPTION
DESK L-SHAPE
Assembly Instructions
Thank you for your purchase!
Iron Age Office furniture is uniquely and individually
fabricated. For this reason, your furniture is pre-assembled
and labeled before shipping. Labels are marked on the
underside of the furniture. The furniture is then
deconstructed prior to shipping. Pieces that uniquely
correspond can typically be found on the same pallet.
Assembly is best completed by keeping the pieces that
correspond together. Clear your work area of anything that
could scratch furniture surfaces. If possible, cover your
work area with a clean, soft blanket. Carefully flip
any wooden tops over and inspect the bottomsides
for markings. Match legs, flat brackets, etc.
to the appropriate labels.
If you need further assistance of any kind,
please contact:
Iron Age Office Operations Manager
Henry Dover
678-725-1473 (c)
[e-mail]

HARDWARE
Screws are shown actual size. You may receive extra hardware with your unit.
14-10 LAG BOLTS #3 Square Drive
Tools Required
1
T2 SIDE TRANSACTION TOP
MAIN TOP
M1 MKS MAIN KNIGHT SHELL
T1 MAIN TRANSACTION TOP
SKS
TS2
SIDE KNIGHT SHELL
SIDE TRANSACTION SCREEN
MAIN TRANSACTION SCREEN
3/8-16 x 3/8 BOLTS 7/32 Hex Drive
11
PARTS
Depending on your transaction counter configuration, you may receive more or less parts than shown below.
TS1
AB ANGLE
BRACKET
EKS
R1
A
RKS
M1
MKS
SKS
TS2
T2
TS1
T2
END KNIGHT SHELL
EKS
RETURN KNIGHT SHELL
RKS
R1 RETURN TOP
SPLICE PLATE
A

AA
ASSEMBLY
STEP 1
Align main and side shells.
STEP 2
Align return shell to main shell and secure
with 3/8-16x3/8 bolts and angle brackets like step 1.
STEP 3
Align end shell to return shell and secure
with 3/8-16x3/8 bolts and angle brackets like step 1.
AB
11 Secure main shell to side shell with
angle bracket and (2) 3/8-16x3/8 bolts
using a 7/32 hex drive at the top and bottom of joint.
MKS
SKS
RKS
MKS
EKS
RKS

AC
AD
AE
AF
ASSEMBLY
STEP 4
Align main top to assembled shell.
STEP 5
Align return top to assembled shell and secure with
lag bolts like step 4.
STEP 6
Align transaction screen to main
top.
Secure transaction screen to main top
with lag bolts using a #3 square drive.
1
TS2
*Depending on your transaction counter configuration you may have
additional transaction screens to secure to main top.
M1
1Secure main top to assembled shell
with lag bolts using a #3 square drive.
R1
Secure main top and return top together with
a splice plate at connection and lag bolts.
A
1
TS2
M1

AG
ASSEMBLY
STEP 7
Align main transaction screen to main top and
side transaction screen. Secure with lag bolts
like step 6.
CARE INSTRUCTIONS
To care for either wooden or metal surfaces of
Iron Age Office products,
gently wipe with a soft cloth dampened with water and a
mild dishwashing liquid.
Once satisfied, dry with a soft cloth.
TS1 TS2
M1
*Depending on your transaction counter configuration you may have
additional transaction screens to secure to tops.
STEP 8
Align transaction tops to transaction screens.
T1
T2
Secure transaction tops to transaction screens
with lag bolts using a #3 square drive.
1
STEP 8
Enjoy your desk!
