Kaabo Mantis User manual

Kaabo Mantis Electric
Scooter
User Manual
Read this manual carefully
BEFORE operating your scooter!

2
Congratulations on your new Mantis electric scooter! And
thank you for purchasing it at urban360.es or at one of
our retail partners.
Follow us on Instagram and
tag us to be featured on our page!
@urban360es

3
BEFORE YOU START
It is important to read through, understand, and adhere to all instructions
and safety warnings before charging and operating this scooter.
Upon receiving and opening your box, please inspect the contents for signs
of damage or loose screws from transport. If something doesn’t feel right,
please take a few pictures and contact your place of purchase immediately.
Your scooter comes with a 180-day limited warranty against manufacturing
defects. In case of any issues beyond this time frame we will still help you
out but may decide to charge a fee for spare parts or repairs.
If you have purchased your scooter from a dealer other than
fluidfreeride.com, please contact them first in case of any issues. If you still
need help or you have purchased directly from fluidfreeride.com, please
feel free to contact us with any questions or concerns.
Make sure you understand and adhere to local rules and regulations for
riding electric scooters. Riding an electric scooter comes with inherent risks
and hazards. To minimize risk of falling or being injured, make sure you
understand how to safely operate and control this scooter.
Always use good judgement, common sense and protective gear.

4
TABLE OF CONTENTS
BEFORE YOU START 3
TABLE OF CONTENTS 4
GENERAL SAFETY WARNINGS 5
MANTIS OVERVIEW 6
What’s in the Box 6
Technical Specifications 6
Key Components 7
CHARGING AND BATTERY SAFETY 8
Charging the Mantis 8
Battery Maintenance 8
Battery Disposal 9
Charging Warnings and Battery Safety Warnings 9
OPERATIONS 11
Assembling the Mantis 11
Folding your Scooter 12
Your First Ride 12
Braking Correctly 13
Mechanical Disc Brake Check –Mantis 17.5Ah 13
Hydraulic Disc Brake Check –Mantis PRO 24.5Ah 13
DISPLAY & KEY SETTINGS 14
Driving Mode Selection 14
Display Settings –Mantis 17.5Ah 14
Display Settings –Mantis PRO 24.5Ah 16
SCOOTER MAINTENANCE & TRANSPORT 19
DECLARATION OF CONFORMITY 20

5
GENERAL SAFETY WARNINGS
Always wear a helmet and protective safety equipment.
Wear closed shoes without heels and ensure your laces are tied.
Do not ride with more than one rider or exceed the weight limit of
120kg/265lbs in any other way.
Only use your scooter in line with its intended purpose.
Check your scooter for any loose parts or screws, flat tires, signs of
damage or excessive wear before every ride. Stop operation
immediately and contact your place of purchase if something does not
feel right.
Start riding slowly to familiarize yourself with the behavior of your
scooter. Start in first gear and slowly try out the brakes. Always slow
down when riding over bumps or on rough road conditions.
Keep the scooter away from children. It is not a toy. 16+ riders only.
Do not use your electric scooter in heavy rain, on surfaces covered by
more than ½ inch of water. Do not submerge the scooter in liquid or let
any liquid near the battery or electrical components.
Do not lend your scooter to anybody unfamiliar with its operation.
Ensure any new riders are familiar with these instructions and are
wearing proper safety gear.
Once riding in public space, you are subject to the risks faced by all
traffic participants just like when you're riding a bike.
oOther traffic participants may not obey traffic regulations or ride
carelessly.
oThe faster you ride your scooter, the longer it will take you to stop.
oThe scooter may slip on slippery surfaces leading to subsequent
injuries to the rider. Pay special attention crossing train tracks and
when it is wet.
oAlways use caution, adapt your speed to road/traffic conditions and
keep distance from other traffic participants.
oWatch out for pedestrians. Do not use your scooter in any way that
could harm pedestrians. Slow down when you are passing them to
avoid accidents.
You must follow all local traffic rules and regulations.

6
MANTIS OVERVIEW
What’s in the Box
Mantis Electric Scooter
(with detached handle bar)
Technical Specifications
Configuration
Mantis 17.5Ah
Mantis PRO 24.5Ah
Motor
2x 1000W brushless (Dual Motor)
Battery
60V 17.5Ah
FST Li-Ion
16S 7P (2,500 mAh /
3.75V cells)
60V 24.5Ah
LG Li-Ion
16S 7P (3,500 mAh / 3.75V
cells)
Top speed (by gear)
Gear 3: 40 mph –65 km/h
Gear 2: 28 mph –45 km/h
Gear 1: 19 mph –30 km/h
Range (eco mode)
40 mi –64 km
50 mi –80 km
Range (normal mode)
30 mi –48 km
40 mi –64 km
Brakes
Front and rear disk
brake + electric
(regenerative) braking
Front and rear hydraulic
disk brake + electric
(regenerative) braking
Suspension
Front and rear spring shock absorber
Tire Size
10” x 2.5” (pneumatic)
Weight –Scooter
61 lb –28 kg
66 lb –30 kg
Weight –Rider limit
265 lb –120 kg
Charger input/output
110-240V / 2A
Dimensions –Opened
48.6 x 22.6 x 49.9 inch / 123.5 x 57.5 x 126.7 cm
Dimensions –Folded
18.7 x 8.3 x 13.2 inch / 47.4 x 21 x 33.5 cm
2.0A UL certified charger
Manual Set of tools

7
Key Components

8
CHARGING AND BATTERY SAFETY
Charging the Mantis
1. Turn your scooter off
2. Locate the charging port
3. Open the charging port cover
4. Connect the charger to the scooter
5. Connect the charger to the wall power outlet
The LED on the charger will turn red while charging and turn green when
the scooter is ready for use. Remove the charger and cover the plug.
Charging time with the included 2A charger is ca. 7-9 hours for the Mantis
17.5 Ah version, and 10-12 hours for the Mantis PRO 24.5Ah version.
Battery Maintenance
We recommend to charge your scooter after every use. This is not
required.
A lithium-ion battery is a consumable device. Please replace with a
new battery once capacity drops below 50% of what you experienced
initially. Contact your place of purchase for a replacement.
Make sure the battery is charged and that the scooter is turned off
before storing your scooter for extended periods at a time.
Store your scooter in a dry and cool place. Do not keep it outdoors or
in outdoor sheds for extended periods of time as excessive cold, heat,
sunlight, rain, or other environmental conditions may impact safe
operation and reduce the scooter’s lifespan.
Charge your battery at minimum every 3 months to prevent it from
running completely empty. Once the battery runs completely empty
due to slow discharge while in storage, it may have to be replaced.
Batteries perform poorly at low temperatures. For instance, if the
temperature is around 0°F (-18°C), battery capacity reduces by 50%.
Capacity will restore to normal when temperatures rise.
Battery life and riding ranges will vary depending on usage, climate,
conditions, rider weight, and/or riding style, proper care and
maintenance.

9
Battery Disposal
Do not dispose of your battery by way of landfilling, incineration or
household trash.
We recommend disposing through a local recycling program suitable
for lithium-ion batteries. Contact your local waste management service
for more information.
Mishandling of used batteries may do tremendous harm to the
environment. You must abide by local laws and regulations to properly
dispose of used batteries.
Charging Warnings and Battery Safety Warnings
Use caution when using outlets to prevent electric shock.
Do not leave the charger plugged in for extended period of times (>24
hours).
Only charge your scooter in a safe, clean, and dry environment. Keep
the charger and scooter away from inflammable materials as they may
get hot.
Only use the original battery packs and the original charger supplied
with your electric scooter. Contact your place of purchase if you need
a replacement. Use of other models or brands may not be safe.
Do not touch any part of the USB charging prongs and keep them away
from metal objects to prevent short circuit which may result in battery
damage or physical injuries and death.
Do not place the battery in direct contact with heat or near high
temperatures. Do not expose the battery to direct sunlight. Do not
leave the scooter in a car where the battery might get hot.
Do not pierce the battery with sharp objects. Do not subject it to
impact or force.
Stop charging if the battery fails to recharge within the approximate
charging time. This will prevent the battery from overheating,
rupturing, or igniting.
Do not charge the battery in temperatures below 32°F (0°C) or above
104°F (40°C) as this can hamper performance, result in breaking,
overheating, rupturing, or igniting and could cause personal injury or
property damage.

10
Do not charge your scooter if the charging port on the scooter is
damaged or wet. Do not charge if there is excessive heat, odor or
leakage coming from the battery or it looks abnormal in any way.
If the battery leaks and you accidentally get in touch with the liquid,
rinse thoroughly with water and then seek medical care.
Never attempt to disassemble, modify, perform repairs or
maintenance on the battery. You run the risk of damaging the
protective and safety components that prevent incidents, personal
injury or property damage. Professionals only!
Mishandling or misuse of the battery can result in lower performance,
shorter lifespan, rupturing, igniting, or other incidents and could
increase the risk of serious personal injury.
Do not discharge the battery using any other product than the scooter
it comes with. Doing so could result in damage to the other product or
the battery and reduced lifespan. The battery could overheat, rupture,
or ignite and cause personal injury or property damage.

11
OPERATIONS
Assembling the Mantis
Carefully open the box and take the scooter out with both hands. Do not
pull the steering bar out by itself as it is attached to the rest via the
cablework. Also pay attention not to lose the metal plaque with the fluid
logo which you will need to screw on to secure the steering bar to the
scooter.
1. Place the scooter on the floor and secure it by pulling out the kickstand
2. Lift the handle post into a
vertical position. Pay attention
as the steering bar is not yet
fixed to the handle post but
only loosely connected via the
cablework.
3. Slide the locking ring
downwards. This prevents the
handle post from moving out of
its vertical position.
Close the two quick release
buckles around the locking ring
and ensure the buckles are tight. Before every ride, make sure the
buckles are locked tightly around the locking ring.
4. Place the steering bar onto
the handle post and screw the
metal plaque (with fluid logo)
onto it with the four screws
provided. For the most
comfortable riding position, we
recommend you place the
handlebar in the most upward position when tightening the screws.

12
Folding your Scooter
1. Loosen the quick release
buckles and slide the
locking ring upwards.
2. Fold the handle post
downwards until it touches
the scooter’s deck and
attach it to the hook in the
rear of the board. This will
lock the handle post in
folded position and enable
you to carry your scooter
with one hand while folded.
Your First Ride
Before using your scooter, make sure to visually inspect it for any signs of
damage or loose parts/screws. Every scooter is individually tested before
shipping from the factory, but we recognize that it has travelled far and in
rare cases, it can get damaged during transport. If something does not feel
right, reach out to your place of purchase.
Also pull the brake levers and ensure there is sufficient tension on the
brakes BEFORE your first and any subsequent ride.
Ensure you have sufficient run way ahead of you. Do not use the
scooter indoors.
Put both of your hands on the handle bar.
Step with one foot on the scooter, kick it lightly with your other foot
to bring it slightly in motion.
Step with your second foot onto the board, hold on tight and pull the
accelerator. Do prepare for strong acceleration and start slowly.

13
Braking Correctly
The Mantis scooter has dual front and rear disc brakes.
For braking, use the rear brake first for decelerating (the left braking lever
on the handle bar) before engaging the front brake (the right lever) to
come to a full stop.
When travelling at higher speeds, exercise caution when braking as the
brakes are sensitive. This is especially true for the front brake as you risk
falling over the handle bar if your center of gravity is too high while
performing a hard stop with the front brake alone.
Mechanical Disc Brake Check –Mantis 17.5Ah
Pull the brake lever and ensure there is sufficient tension on the disc brake
before riding. Check frequently to ensure brakes are working properly.
In case there is not sufficient tension on the brake, you can tighten it a
little with the barrel adjuster (the plastic turning bolt at the end of the
brake cable, just before it enters the caliper):
-To increase brake tension, turn the barrel adjuster backwards so
that the caliper arm moves closer to the barrel adjuster.
-Don’t forget to tighten the nut afterwards so that the barrel
adjuster stays safely in place.
If this does not do the trick or you have any doubts or concerns, please
contact a local bike shop for help or reach out to your place of purchase.
Hydraulic Disc Brake Check –Mantis PRO 24.5Ah
Pull the brake lever and ensure there is sufficient tension on the disc brake
before riding. Check integrity of hydraulic systems frequently (no leakage
of oil) to ensure brakes are working properly.

14
DISPLAY & KEY SETTINGS
Driving Mode Selection
Located underneath the main display on the right side of
the handle bar you can find two switches to configure
driving modes:
The ECO/TURBO switch regulates the power of your scooter. By pressing
down the button, ECO mode is activated which will reduce torque and top
speed to maximize range. When the button is not pressed, TURBO mode is
activated and there is no restriction of power.
The SINGLE/DUAL switch toggles single or dual motor drive. By pressing
down the button DUAL motor drive is activated. When the button is not
pressed, SINGLE (rear) motor drive is activated.
For Maximum range, select ECO mode and SINGLE motor drive. For
maximum power and speed, select TURBO mode and DUAL motor drive.
Display Settings –Mantis 17.5Ah
The Mantis scooter is equipped with the following display:
Gear change. To change the gear (1=slow, 2=medium, 3=fast), while the
scooter is powered ON, press the POWER button to enter gear setting
mode. Press MODE to switch between gears. To return to operating mode
either press POWER or wait for 2 seconds.
1. Speedometer. Shows the speed at which you are travelling.
2. Battery Indicator. Charge your scooter frequently, do not let it run out
of battery. As a rough guideline, charge at or below 2 bars.
3. Power Button.To turn the scooter on or off press button for 2 seconds.
4. Accelerator. Pull to accelerate. The stronger you pull, the faster it
accelerates. The scooter is delivered in “Non-Zero Start” setting (Kick-

15
And-Go is ON), i.e. the accelerator only works if the scooter is already
in motion.
5. Mode Button. Press to select various display options:
MODE
COMMENT
TIME
Time since powering on the scooter.
TRIP
Distance travelled since powering on the scooter.
ODO
Total distance travelled.
VOL
Current battery voltage.
CH2:00
Charging mode. Time (2 hours) scooter stays ON (overrides auto-
switch off) so you can use display’s USB port to charge e.g. your phone.
Detailed P-settings mode. To access P-settings to make various advanced
changes, press POWER [3] and MODE [5] simultaneously for 2 seconds.
Cycle through the P-settings using the MODE button. To select a P-setting
in order to make changes press the POWER button. Change the value (up
or down) using the MODE (Up) and POWER (Down) buttons. To return to
the P-settings menu after changing a value, wait 2 seconds. To return to
operating mode, wait a further 2 seconds. Only
P-SETTINGS
P0
Tire diameter (10 = 10 inch). Do not change.
P1
Controller shut-down voltage. Default set to 52V (minimum is 48V –we
recommend 52V to preserve battery life).
P2
Motor magnetic pole setting. Default is 40. Do not change.
P3
Speed signal selection. Default is 0. Do not change.
P4
Distance / speed unit. 0=km, 1=miles
P5
Start setting. 1=non-zero start (Kick-and-Go), accelerator won’t work if scooter
not in motion; 0=immediate start (CAUTION while using this!)
P6
Cruise control. 0=cruise control OFF, 1=cruise control ON.
P7
Initial acceleration. 0=strong, 1=soft.
P8
Electric (regenerative) braking (E-ABS). 0=E-ABS off, 1=E-ABS on
P9
Speed limit as % of top speed, i.e. 100=no speed limit.
PA
Clear total distance travelled (ODO).
PB
Scooter auto-turn off time in minutes.
PC
Display brightness (1=low, 3=high)

16
Cruise Control. Cruise control allows you to maintain your driving speed
automatically without continuing to hold down the accelerator. In order to
enter Cruise Control, activate it first in the P-settings [P6].
While driving, keep the accelerator steady for a few seconds until Cruise
Control kicks in and scooter travels at constant speed without driver
holding down the accelerator. When you activate the brakes Cruise Control
will be cancelled. CAUTION: Ride in a position where you can immediately
access the brake to cancel Cruise Control if necessary.
Display Settings –Mantis PRO 24.5Ah
The Mantis PRO scooter is equipped with the following LCD display:
1. Speedometer. Shows the speed at which you are travelling.
2. Battery Indicator. Charge your scooter frequently, do not let it run out
of battery. As a rough guideline, charge at or below 2 bars.
3. Gear. Shows the selected gear.
4. Gear selector. Press to set gear (1=slow, 2=medium, 3=fast).
5. Power Button.To turn the scooter on or off press button for 2 seconds.
6. Accelerator. Pull to accelerate. The stronger you pull, the faster it
accelerates. The scooter is delivered in “Non-Zero Start” setting (Kick-
And-Go is ON), i.e. the accelerator only works if the scooter is already
in motion.

17
7. Mode Button. Press to select various display options:
MODE
COMMENT
TIME
Time since powering on the scooter.
TRIP
Distance travelled since powering on the scooter.
ODO
Total distance travelled.
VOL
Current voltage.
CHA
Number of times battery has been charged (inaccurate as only full
discharges are counted)
Detailed P-settings mode. To access P-settings to make various advanced
changes, press MODE [7] for 2-3 seconds.
Cycle through the P-settings using the MODE button [7]. In order to change
a P-setting press GEAR button [4]. To return to operating mode, wait a few
seconds.
P-SETTINGS
P0
Tire diameter (10 = 10 inch). Do not change.
P1
System voltage. Default 60V. Do not change.
P2
Motor magnetic pole setting. Default 15. Do not change.
P3
Speed signal selection. Default is 0. Do not change.
P4
Distance / speed unit. 0=km, 1=miles
P5
Start setting. 1=non-zero start (Kick-and-Go), accelerator won’t work if scooter
not in motion; 0=immediate start (CAUTION while using this!)
P6
Cruise control. 0=cruise control OFF, 1=cruise control ON. Advanced riders
only.
P7
Initial acceleration. 0=strong power, 5=least power.
P8
Speed limit as % of top speed, i.e. 100=no speed limit.
P9
Motor torque. 1=50% of max. torque, 2=75% of max. torque, 3=max. torque
PA
Electric (regenerative) braking strength (E-ABS). 0=None, 1=Weak, 2=Medium,
3=strong.
PB
Display brightness (0=off, 5=highest illumination)
PC
Scooter auto-turn off time in minutes (1-30 minutes).
PD
ABS (anti-lock braking system) setting. 0=ABS off, 1=ABS on (as in a car, the
brake engages and disengages rapidly to prevent the wheel from blocking)
WARNING: Due to increased vibration and force and on scooter components
when using ABS, do frequently check that all bolts are properly fastened.

18
Cruise Control. Cruise control allows you to maintain your driving speed
automatically without continuing to hold down the accelerator. In order to
enter Cruise Control, activate it first in the P-settings [P6].
While driving, keep the accelerator steady for 3-5 seconds until Cruise
Control kicks in and scooter travels at constant speed without driver
holding down the accelerator. When you activate the brakes, Cruise
Control will be cancelled. CAUTION: Ride in a position where you can
immediately access the brake to cancel Cruise Control if necessary.

19
SCOOTER MAINTENANCE & TRANSPORT
Never perform maintenance on this product while the unit is powered
on or charging. Always power off before performing maintenance. Do
not attempt to perform repairs or modify the scooter but contact your
place of purchase or refer to a professional repair facility.
Clean stains on your scooter’s body with a damp cloth. Do not use
alcohol, gasoline, kerosene or other corrosive and volatile chemicals. Do
not wash with high pressure cleaners. Make sure the scooter is turned
off and unplugged during cleaning and ensure no moisture enters the
charging port.
When transporting your scooter, please take into account that it
contains lithium-ion batteries that are considered a hazardous material.
Always exercise caution and follow applicable rules and regulations
when transporting your scooter. It is very likely that you will not be
allowed to take your scooter including battery on a plane.

20
DECLARATION OF CONFORMITY
This product complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This product may not cause harmful interference, and (2) this product
must accept any interference received, including interference that may
cause undesired operation.
FCC RELATED INFORMATION:
This product has been tested and found to comply with the limits for a
Class B digital product, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This product generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be determined by
turning the product off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the product and receiver.
Connect the product into an outlet on a circuit different from that to
which the receiver is connected.
Consult your place of purchase or an experienced radio/TV technician
for assistance.
NOTE: INFORMATION, SPECIFICATIONS, WARNINGS AND ALL OTHER
DETAILS INCLUDED IN THIS MANUAL ARE SUBJECT TO CHANGE AT ANY
TIME, WITHOUT PRIOR WRITTEN NOTICE.
