Kemper 460plus User manual

460plusStalkBuster™Rotary
HarvestingUnit
*OMKM128769*
OPERATOR'SMANUAL
460plusStalkBuster™Rotary
HarvestingUnit
OMKM128769ISSUEE1(ENGLISH)
MaschinenfabrikKemperGmbH&Co.KG
EuropeanEditions
PRINTEDINU.S.A.

Introduction
KM00321,0000A73-19-12MAY20-1/1
Foreword
READTHISOPERATOR'SMANUALcarefullytolearn
howtooperateandserviceyourmachinecorrectly.Failure
todosocouldresultinpersonalinjuryorequipment
damage.Thisrotaryharvestingunitmaybeinstalledand
operatedonaforageharvesteronly.Theusermustbe
entitledtodriveaforageharvesteronpublicroads.This
manualandsafetysignsonyourmachineareavailablein
otherlanguages.Toorder,seeyourKEMPERdealer.
THISMANUALSHOULDBECONSIDEREDapermanent
partofyourmachineandmustremainwiththemachine
whenyousellit.
MEASUREMENTSINTHISMANUALaregiveninmetric
units.ThecustomaryU.S.unitequivalentsarealso
quoted.Onlyusecomponentsandboltsthatfit.Metric
andinchfastenersmayrequireaspecificmetricorinch
wrench.
RIGHT-HANDANDLEFT-HANDsidesaredetermined
byfacinginthedirectiontheimplementwilltravelwhen
goingforward.
THETERM"TRANSPORT"referstoarotaryharvesting
unitmountedonaforageharvesterandtransportedfrom
AtoBontheforageharvester.
THETERM"HAULAGE"referstoarotaryharvestingunit
loadedonaflatbedcarrierandtransportedfromAtoB
ontheflatbedcarrier.
LOADINGANDHAULAGEofthisrotaryharvestingunit
mustbeperformedonlybypersonsfamiliarwithhowthe
loadissecured,andwhocanprovideevidenceofthis.
WRITEPRODUCTIDENTIFICATIONNUMBERS(P .I.N.)
intheSpecificationorIdentificationNumberssection.
Recordallnumbersexactly.Intheeventoftheft,these
numbersmayprovevitalintracingyourproperty.Your
KEMPERdealerneedsthesenumberswhenyouorder
parts.Filetheidentificationnumbersinasecureplace
awayfrommachine.
BEFOREDELIVERINGTHISMACHINE,yourdealer
performedapredeliveryinspection.
INTENDEDUSE:THISROTARYHARVESTINGUNIT
maybeusedONLYforharvesting:
•thick-stemmed,flexibletypesofplantsuchascorn,
elephantgrassorbamboo
•thin-stemmedtypesofplantsuchasgraincrop,mustard
Useinanyotherwayisconsideredascontrarytothe
intendeduse.Themanufactureracceptsnoliabilityfor
damageorinjuryresultingfromthismisuse,andthese
risksmustbebornesolelybytheuser.
THISROTARYHARVESTINGUNITMUSTNOTbe
usedtomanuallytransfermaterialsofanysortandisnot
suitableforthetransferandchoppingof:
•woodyplantswithadiametergreaterthan1mm
•woodintendedforchipping
•animalfeedsuchasbeets
•metallicobjects
•materialsthatincludestones
Compliancewithandstrictadherencetotheconditions
ofoperation,serviceandrepairasspecifiedbythe
manufactureralsoconstituteessentialelementsforthe
INTENDEDUSE.
THISROTARYHARVESTINGUNITMUSTbeserviced
andrepairedONLYbyindustrialmechanics,fittersor
personswithcomparablequalifications.Theelectrical
systemmustberepairedonlybyelectricians.Theaccident
preventionregulations,allothergenerallyrecognized
regulationsonsafetyandoccupationalmedicineandthe
roadtrafficregulationsmustbeobservedatalltimes.It
isnotpermittedtoalterthemachinetoacceptmaterials
otherthanthosepermittedinitsintendeduse.Any
arbitrarymodificationscarriedoutonthisrotaryharvesting
unitwillrelievethemanufacturerofallliabilityforany
resultingdamageorinjury.
THISROTARYHARVESTINGUNITMUSTNOTbe
operatedintheUnitedStatesandCanada.
061721
PN=2
