CARE & MAINTENANCE
CaféWay™ Tables
Models ECELP, ECRDP, ECOCP & ECRCP
January 2015
■
1. Lubricate the center hinges/lock plates. Verify
urethane glide washers are in place and free
of chips, cracks or abrasion (Figure 1).
2. Inspect the storage latch for ease of motion,
Apply lubricant to the shoulder bolt and spring
(Figure 2). Note: ECRCP tables do not have a
spring on the latch.
3. As needed, lubricate the shoulder bolts at all
‘stretcher bar’ pivot points (Figures 3a and 3b).
Figure 1 Figure 2
Figure 3a Figure 3b
SEMI-ANNUAL MAINTENANCE: LUBRICATION
• Servicingoftablesmustbeperformedbyqualiedpersonnelfamiliarwiththe
tools and products being used.
• Always wear personal protective equipment such as eye goggles and gloves.
• Use an approved lubricant such as Food Grade Penetrating Oil or Food Grade
White Grease.
4. Lubricate upper pivot connections for
‘endlegs’ (Figures 4a and 4b). Note: This step
is for ECELP, ECRDP & ECOCP family tables
only.
Figure 4a - ECELP, ECRDP & ECOCP Figure 4b - ECELP, ECRDP & ECOCP

1330BellevueStreet•P.O.Box8100•GreenBay,WI54308-8100•1-800-424-2432•www.ki.com
© 2015KruegerInternational,Inc.AllRightsReserved•CodeKI-62660/KI/PDF/0115
4. Pivot tubes rotate and slide laterally as they
pass through the table aprons during normal
operation. Lubricate this location on each end
ofthepivottube(Figure5).
5.“Capped”pivottubesrequireaccessfrom
insidetheapron(Figure6).
6.Lubricatetheinnerangeoftheapronwhere
the pivot tube rotates on the apron
(Figure 7).
7. Pivot tubes need to be lubricated
 semi-annuallyonthetable(Figures8&9).
Figure 5 Figure 6
Figure 7 Figure 8
Figure 9
metal“apron”
frame
“retainer”cap
over pivot tube
11/4”
pivot tube
with1”
plastic endcap
