KI Altus Task Seating Installation instructions

Required
Tools
Disassembly Instructions
Material Type:
Warning: This drawing format requires special non-standard fonts!!
Make sure the appropriate font files are installed!!!
TT Humanst 521 BT Light
O HelveticaLTStd-Cond
O HelveticaLTStd-LightCond
Altus™ and Allude™ Task Seating
Page 1 of 2Rev. 0©2013 Krueger International, Inc. All Rights Reserved · P0033-0088
A . Steel B. Plastic C. Foam D. Aluminum
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
Procedure:
1. Invert the chair and undo the Velcro holding the seat
cushion to the seat pan. Pull up on the cushion to remove
the cushion.
2. Invert the chair and gently tap on the bottom of the steel
height adjustment cylinder while lifting the star base.
WARNING: CONTENTS UNDER PRESSURE!
REMOVE WITH CATUTION.
General Notes:
1. Disassembly time: 10-15 minutes
2. This procedure assumes basic familiarity with hand tools and
furniture terminology: no specialized training is required
3. All materials removed and disassembled shall be sorted and
segregated with like materials and disposed of or recycled
according to recycling availability or waste acceptance
4. For items to be recycled, refer to KI's End of Life Recycling
Matrix and KI's End of Life Recovery Options Matrix, available
at www.ki.com
All fasteners not explicitly tagged
are Material Type A: Steel
Image Not Available
All fasteners not explicitly tagged
are Material Type A: Steel
SCALE 0.050
Gloves Safety Glasses
Pry Bar
Philips Screwdriver
Putty Knife
Hex Socket Wrench
Rubber Mallet
Flat Screwdriver
Channel Lock Pliers
Allen Wrench
B
B
C
BD
A

Required
Tools
Disassembly Instructions
Material Type:
Warning: This drawing format requires special non-standard fonts!!
Make sure the appropriate font files are installed!!!
TT Humanst 521 BT Light
O HelveticaLTStd-Cond
O HelveticaLTStd-LightCond
Altus™ and Allude™ Task Seating
Page 2 of 2Rev. 0©2013 Krueger International, Inc. All Rights Reserved · P0033-0088
A . Steel B. Plastic C. Foam D. Aluminum
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
All fasteners not explicitly tagged
are Material Type A: Steel
General Notes:
1. Disassembly time: 10-15 minutes
2. This procedure assumes basic familiarity with hand tools and
furniture terminology: no specialized training is required
3. All materials removed and disassembled shall be sorted and
segregated with like materials and disposed of or recycled
according to recycling availability or waste acceptance
4. For items to be recycled, refer to KI's End of Life Recycling
Matrix and KI's End of Life Recovery Options Matrix, available
at www.ki.com
Procedure:
3. Remove the screws holding the seat back and seat pan
onto the mechanism frame.
4. Pry off the plastic control knob and handles from the base
support mechanism.
Gloves Safety Glasses Pry Bar Rubber Mallet
B
D
Allen Wrench Philips Screwdriver
B
B
A
D
A
C
