KI WorkZone Series Installation instructions

Required
Tools
Disassembly Instructions
Material Type:
Warning: This drawing format requires special non-standard fonts!!
Make sure the appropriate font files are installed!!!
TT Humanst 521 BT Light
O HelveticaLTStd-Cond
O HelveticaLTStd-LightCond
Workzone® Basic Worksurfaces
Page 1 of 2Rev. 0©2013 Krueger International, Inc. All Rights Reserved · P0033-0082
A .Steel B. Wood / Particle Board C. Plastic
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
Procedure:
1. Pry off the plastic covers from the sides of each leg and pull
out the plastic grommets from the worksurface.
2. Remove the screws holding the legs and modesty panel to the
worksurface and remove the worksurface.
3. Remove the screws holding the modesty panel to the legs and
remove the panel from the legs.
(continued on next page)
General Notes:
1. Disassembly time: 10-15 minutes
2. This procedure assumes basic familiarity with hand tools and
furniture terminology: no specialized training is required
3. All materials removed and disassembled shall be sorted and
segregated with like materials and disposed of or recycled
according to recycling availability or waste acceptance
4. For items to be recycled, refer to KI's End of Life Recycling
Matrix and KI's End of Life Recovery Options Matrix, available
at www.ki.com
All fasteners not explicitly
tagged or shown are
Material Type A: Steel
SCALE 0.040
Safety Glasses
Tin Snips
Power Drill
Channel Lock Pliers
Rubber Mallet
Claw Hammer
Cold Chisel
Gloves
Pliers
Pry Bar
Putty Knife
Scissors
Utility Knife
Wood_Chisel
Flat Screwdriver
#2 Philips Screwdriver
T15 Torx Screwdriver
1-1/2" Socket Wrench
B
A
C
C
C
C
C
C

Required
Tools
Disassembly Instructions
Material Type:
Warning: This drawing format requires special non-standard fonts!!
Make sure the appropriate font files are installed!!!
TT Humanst 521 BT Light
O HelveticaLTStd-Cond
O HelveticaLTStd-LightCond
Workzone® Basic Worksurfaces
Page 2 of 2Rev. 0©2013 Krueger International, Inc. All Rights Reserved · P0033-0082
A .Steel B. Wood / Particle Board C. Plastic D. Zinc Alloy
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
Procedure (continued):
4. Pry out the square metal end caps from the top tube of each
leg assembly.
5. Unscrew the glides from the bottom tube of each leg
assembly.
6. Drill out the threaded rivet nuts that the glides were screwed
into and pry out the metal end caps from the ends of the tube.
SCALE 0.100
Safety Glasses Power Drill
Gloves Pry Bar Flat Screwdriver
#2 Philips Screwdriver
A
A
A
C
C
D
D
