Kongskilde 800 Series User manual

2































$/5",%2/,,%2
!33%-",9 


 





 



3).',%2/,,%2
!33%-",9 








Shaftless Roller Assembly

Fig. Part no. Description
3
1 603 150 707 Mounting Bracket Weldment
2 603 150 700 Short Arm Weldment
3 603 150 701 Long Arm Weldment
4 600 366 005 1/2" Locknut
5 600 356 115 Bolt 3/8" x 1 1/2"
6 600 356 137 Bolt 1/2" x 3 1/2"
7 600 356 105 Bolt 1/2" x 4"
8 600 373 072 Bolt 5/8" x 5" Full Thread
9 600 381 020 Flatwasher 5/8"
10 600 366 004 Locknut 3/8"
11 600 365 014 Hex Nut 5/8" - 11 UNC, Plated
12 600 373 061 U-Bolt 1/2" x 2" x 3 1/4"
13 603 150 017 Roller Tension Spring
14 603 150 018 Spring Insert
15 603 150 712 Wear Bushing
16 603 150 191 Frame Mount Plate
17 603 150 195 32" Frame
603 150 196 47" Frame (Shown)
603 150 197 55" Frame
603 150 198 63" Frame
603 150 199 71" Frame
18 603 151 280 32" L. H. Roller Assembly- Shaftless
603 151 278 47" L. H. Roller Assembly - Shaftless (Shown)
603 151 282 55" L. H. Roller Assembly - Shaftless
603 151 284 63" L. H. Roller Assembly - Shaftless
603 151 286 71" L. H. Roller Assembly - Shaftless
19 603 151 281 32" R. H. Roller Assembly - Shaftless
603 151 279 47" R. H. Roller Assembly - Shaftless (Shown)
603 151 283 55" R. H. Roller Assembly - Shaftless
603 151 285 63" R. H. Roller Assembly - Shaftless
603 151 287 71" R. H. Roller Assembly - Shaftless
20 603 151 270 Right Roller Harrow Bearing Arm
21 603 151 262 Left Roller Harrow Bearing Arm
22 600 451 006 Harrow Bearing 1-1/8" Square (FD209)
23 603 151 241 Right Roller Bearing Arm Sheild
24 603 151 240 Left Roller Bearing Arm Shield
25 600 383 013 Roll Pin 3/8" X 2-1/2"
26 600 361 034 Carriage Bolt 1/2" X 1-1/4"
Spare part list / 800SS/RR Double Rota Harrows - 800S/R Single Front Roller. Date: 12/2013

800 Series Cultivator Specifications
4' Frame
7' Frame
15' Frame
Tine Extension Kit
8" Add On Frame
16" Add On Frame
No. Tines 4" Spacing
Working Width 4" Spacing
No. Tines 6" Spacing
Working Width 6" Spacing
32" R.H. Roller
47" R.H. Roller
55" R.H. Roller
63" R.H. Roller
71" R.H. Roller
32" L.H. Roller
47" L.H. Roller
55" L.H. Roller
63" L.H. Roller
71" L.H. Roller
Hanger Assembly
Harrow Working Width
804-03 Cultivator 1 13 4' 2" 9 4' 2" 1 1 2 4' 7" 804-11 Cultivator 1 4 15 4' 10" 10 4' 8" 1 1 2 5' 3"
805 Cultivator 1 2 17 5' 6" 11 5' 2" 1 1 2 6' 2" 806 Cultivator 1 4 2 19 6' 2" 13 6' 2" 1 1 1 1 4 6' 7" 807 Cultivator 1 21 6' 10" 15 7' 1" 2 2 4 8' 2" 808 Cultivator 1 2 23 7' 6" 17 8' 2" 1 1 1 1 4 8' 7" 810 Cultivator 1 2 29 9' 6" 19 9' 2" 2 2 4 10' 10"
811 Cultivator 1 2 2 31 10' 2" 21 10' 5" 1 1 1 1 4 11' 2" 812 Cultivator 1 4 37 12' 2" 25 12' 2" 1 2 1 2 6 13' 6" 813 Cultivator 1 2 4 39 12' 10" 27 13' 2" 1 2 1 2 6 14' 8" 815 Cultivator 1 45 14' 10" 30 15' 2" 2 1 2 1 6 16' 9" 816 Cultivator 1 2 47 15' 6" 33 16' 2" 1 2 1 2 6 17' 6" 818 Cultivator 1 2 53 17' 6" 35 17' 2" 4 4 8 18' 8"
819 Cultivator 1 2 2 55 18' 2" 37 18' 6" 2 2 2 2 8 19' 3" 820 Cultivator 1 4 61 20' 2" 41 20' 2" 3 1 3 1 8 22' 3" 821 Cultivato
r
1 2 4 63 20' 10" 43 21' 2" 2 2 2 2 8 22' 9"
