Lee & Plumpton Atmosphere Conference Round Column Base User manual

Assembly instruction leaflet no. 63a
Atmosphere Conference Round
- Column Base Assembly
Part A
Column Base
Quantity = 1
Part B
Bolts
Quantity = 8
Tools required
Allen Key (4mm)
Part A
Part B
Parts Supplied
Assembly steps
1. Assemble the column base using
the instructions provided in the
column pack.
2. Place top upside down on a soft
clean surface.
3. Align the column base (part A) to
the holes on the underside of the
top.
4. Fix the column base to the top
using the eight bolts (parts B) as
shown.
5. Stand the product onto the base,
taking extra care as the column
base weighs aproximatly 23kg.

Assembly instruction leaflet no. 63b
Atmosphere Conference Round
- Round Leg Assembly
Part A
10mm bolts
Quantity = 4
Part B
Leg plates
Quantity = 4
Part C
Screws
Quantity = 20
Part D
Legs
Quantity = 4
Tools required
Pozi head screw driver
Assembly steps
1. Place top upside down on a soft clean
surface.
2. Position the bolts (parts A) in the
underside of the leg plates (parts B) as
shown.
3. Align the leg plates (parts B) to the
holes on the underside of the top.
4. Fix the leg plates to the top using the
screws (parts C) as shown.
5. Screw the legs (parts D) on to the leg
plates.
6. Stand the product onto the legs.
Part A
Part B
Part C
Part D
Parts supplied
