Lee & Plumpton Planar Bench User manual

No. 134 A/2257 Revision A 17/01/2020 1
www.leeandplumpton.co.uk
ASSEMBLY INSTRUCTIONS
RANGE Planar Bench
REF: 1600mm and 1800mm Wide
Read this leaet before
assembly
2 People
Required
COMPONENT PARTS
1600mm
1800mm
Item 1
Top Panel
Qty 1
Item 2
Modesty Panel
Qty 2
Item 3
Side Panel
Qty 2
Item 4
Wood Dowels
F.0431
Qty 4
Item 5
Minix Bolt Chipfast 34x11mm
F.0532
Qty 14
Item 6
F.0414
5/8” x 8g Pan Pozi BZP
Qty 32
Item 7
F.0434
Minix Alloy Cams 18mm
Qty 10
Item 8
F.0467
Minix Alloy Cams 25mm
Qty 4
Item 9
F.0551
Foot
Qty 4
Item 10
Angle Bracket
Qty 4

No. 134 A/2257 Revision A 17/01/2020 2
TOOLS REQUIRED BEFORE YOU BEGIN...
• Check you have all the tools and components required
• Keep children and animals away from small parts
• Ensure you have adequate space
• Assemble product on a at, clean surface
• Apply manual handling guidelines when building this item
• Short Pozi head screwdriver
STEP 1
STEP 2
ASSEMBLY INSTRUCTIONS
STEP 3
Lay both the Modesty
Panels(2) at on a soft
surface with the holes facing
upwards.
Ensure all holes are free of
debris.
Insert the appropriate number
of Cams (7) into the Panels.
Ensure that the arrows
moulded into the Cams are
pointing towards the edge of
the Panel (where the joining
hole is).
Attach the Angle Brackets
(10) to the Modesty Panels,
using 4 Screws (6) per
Bracket.
7
2
10
6
Lay both the Side Panels (3)
at on a soft surface with the
holes facing upwards.
Ensure all holes are free of
debris.
Insert the appropriate
number of Cams (8) and
Rapid Dowels (5) into the
Panels.
Ensure that the arrows
moulded into the Cams are
pointing towards the edge of
the Panel.
3
5
8

No. 134 A/2257 Revision A 17/01/2020 3
STEP 4
STEP 5
ASSEMBLY INSTRUCTIONS
STEP 6
Place the Side Panels (3) into
position onto the Modesty (2)
Panels.
Lock the Cams (7) with a half
turn.
Attach the Angle Brackets
(10) to the Side Panels(3),
using 4 Screws (6) per
Bracket.
3
2
3
6
10
Lay the Top Panel (1) at on
a soft surface with the holes
facing upwards.
Ensure all holes are free of
debris.
Insert the appropriate
number of Rapid dowels (5)
and wooden dowels (4) into
the Top Panel.
1
4
5

No. 134 A/2257 Revision A 17/01/2020 4
STEP 7
STEP 8
ASSEMBLY INSTRUCTIONS
CARE AND MAINTENANCE
STEP 9
Place Sides (3) and Modesty
Panels (2) into position on
the Top Panel (1).
Lock the Cams with a half
turn.
Attach the Feet (9) by
screwing them into the insert
in the Side Panels.
Clean using a damp cloth and mild detergent – do not use abrasive cleaners or bleach.
Carefully stand the bench
upright.
The bench can be levelled
by adjusting the height of the
Feet (9).
9
9
1
3
2
