Lee & Plumpton Satellite MP Cant Bracket Pack User manual

A
Satellite MP Cant Bracket Pack
Feature A
MP
Desk
Cantilever leg frame
Fittings supplied
Part A
Screw 4.5x25
Quantity=2
Part B
1/4 washer
Quantity=2
Part C
Z bracket
Quantity=2
Assembly instruction leaflet no.40
Tools required
Pozi head screw driver
Allen key (4mm)
Assembly steps
1. Remove the 70mm chipfast bolts (parts D x2) that connect the top of the desk to the cantilever leg frame.
2. Use the 70mm chipfast bolts (parts D x2) to fix parts C (x2) to the desk (use the small hole on the brackets).
3. Stand the MP up, rest it on the brackets in the position you would like it fixed.
4. Fix the brackets (part C) to the MP using parts A (x2) and parts B (x2). (An electric screw driver may be required).
N.B. Larger meeting points (1600/1200) require 2 bracket packs (4 Brackets), fixed across 2 desks.
A
B
A
B
C
C
70mm chipfast bolts
Fitting reference
Part D
70mm chipfast bolt
D
D

A
Satellite MP Slab Bracket Pack
Tools required
Pozi head screw driver
Allen keys (4mm and 5mm)
Fittings supplied
Part A
Screw 4.5x25
Quantity=2
Part B
1/4 washer
Quantity=2
Part C
Slab bracket
Quantity=2
Feature A
Assembly steps
1. Position parts C (x2) so they sit flush with the edges of the slabs and are pushed firmly against the top of the desk, as
shown in feature B, (round hole against slab). Mark through the round holes onto the slabs where the through holes
should be. (These should be 21.5mm down from the top of the slab and 15mm in from the edges).
2. Drill the 10mm through holes in the positions previously stated, apply a packing piece to the opposite face when drilling
to prevent damage.
3. Use parts D (x2) and parts E (x2) to fix the brackets via the round holes to the slabs.
4. Stand the MP up, rest it on the brackets in the position you would like it fixed.
5. Fix the brackets (part C) to the MP using parts A (x2) and parts B (x2). (An electric screw driver may be required).
N.B. Larger meeting points (1600/1200) require 2 bracket packs (4 Brackets), fixed across 2 desks.
Part D
Bolt 25x6
Quantity=2
Part E
Sleeve nut
Quantity=2
Feature B
(Fixed position)
Brackets fixed as close to the
edge of the slabs as possible.
10mm hole to
be drilled for bolt
10mm hole to
be drilled for bolt
MP
Slab
Desk
Assembly instruction leaflet no.40
C
D
B
A
E
