Lee & Plumpton Spire Rectangular User manual

No. 116 A/1885 Revision A 15/08/2018 1
www.leeandplumpton.co.uk
ASSEMBLY INSTRUCTIONS
RANGE Spire Tables, Single Frame.
REF: Rectangular: 1800 x 800mm, 2000 x 800mm,
2000 x 1000mm
Square: 1200 x 1200mm, 1400 x 1400mm
Circular: 1200mm Dia, 1400mm Dia, 1600mm Dia
Oval: 2000 x 1200mm, 2200 x 1200mm,
2400 x 1200mm
Read this leaet before
assembly
2 People
Required
COMPONENT PARTS
Item 2
Curved Spire Leg
Qty, (See Table 1)
M/0794, M/0795, M/0796
Item 3
Rail
Qty, (See Table 1)
M/0807
Item 4
Expander Nut Plate
Qty, (See Table 1)
A/1164
Item 5
Grub Screw M8x35mm
Qty, (See Table 1)
F/0627
Item 6
Pin M10 for Leveller
Qty, (See Table 1)
A/1162
Item 7
Base of Leveller
Qty, (See Table 1)
A/1163
Item 8
Chipfast Bolt
Qty, (See Table 1)
F/0486

No. 116 A/1885 Revision A 15/08/2018 2
TOOLS REQUIRED BEFORE YOU BEGIN...
• Check you have all the tools and components required
• Keep children and animals away from small parts
• Ensure you have adequate space
• Assemble product on a at, clean surface
• Apply manual handling guidelines when building this item
COMPONENT PART QUANTITIES FOR UNIT SIZE VARIATIONS (TABLE 1)
• Pozi head screwdriver
• 4mm Allen key
STEP 1
ASSEMBLY INSTRUCTIONS
ITEM W1800 x
D 800mm
W2000 x
D800mm
W 2000 x
D1000mm
Top 1087 1088 1089
2Leg 444
3Rail 1 222
3Rail 2 222
4Expander Nut Plate 888
5Grub Screw 16 16 16
6 Pin For Leveller 444
7 Leveller Foot 444
8Chipfast Bolt 10 12 12
Rectangular
ITEM W1200 x
D 1200mm
W1200 x
D1200mm
Top 1076 1077
2Leg 4 4
3Rail 1 4 4
3Rail 2 0 0
4Expander Nut Plate 8 8
5Grub Screw 16 16
6 Pin For Leveller 4 4
7 Leveller Foot 4 4
8Chipfast Bolt 8 8
Square
ITEM 1200mm Dia 1400mm Dia 1600mm Dia
Top 1078 1079 1080
2Leg 4 4 4
3Rail 1 4 4 4
3Rail 2 0 0 0
4Expander Nut Plate 8 8 8
5Grub Screw 16 16 16
6 Pin For Leveller 4 4 4
7 Leveller Foot 4 4 4
8Chipfast Bolt 8 8 8
Circular
ITEM W 2000 x
D1200mm
W2200 x
D1200mm
W2400 x
D1200mm
Top 1081 1082 1083
2Leg 4 4 4
3Rail 1 222
3Rail 2 2 2 2
4Expander Nut Plate 8 8 8
5Grub Screw 16 16 16
6 Pin For Leveller 444
7 Leveller Foot 4 4 4
8Chipfast Bolt 10 12 12
Oval
Attach the “foot” (7) to all Legs (2)
using Pin (6).
At the top of the Leg t the
Expander Nut Plates (4).
4
2
7
6
7
2

No. 116 A/1885 Revision A 15/08/2018 3
STEP 2
ASSEMBLY INSTRUCTIONS
STEP 4
STEP 3
CARE AND MAINTENANCE
Slide the Rails (3) over the
brackets on the Legs.
Ensure that the holes at the ends
of the Rails are at the top of the
Rails.
Depending on the SPIRE model
that you are building, the Rails
may differ in length.
Insert the Grub Screws (5) to hold
the Rails to the Legs.
Do not fully tighten yet.
3
3
5
8
Fix the Top to the frame using
Screws (8).
Build the frame as shown, a large
U shape with 3 Rails and two Legs
and a small Ushape with one
Rail and two Legs. Slide the two
partially built frames together.
When fully tted, tighten up the
Grub Screws.
Clean using a damp cloth and mild detergent – do not use abrasive cleaners or bleach.
