Lee & Plumpton Signature Storage Series Installation guide

1
A/1877 Revision A 29/01/2018
www.leeandplumpton.co.uk
ASSEMBLY INSTRUCTIONS
RANGE Signature Storage, Cupboard.
REF: 740mm High, 1000mm High, 1200mm High,
1600mm High, 1800mm High, 2000mm High
800mm and 1000mm Wide
Read this leaet before
assembly
2 People
Required
COMPONENT PARTS
Item 10
A.0718
Bar Handle
Qty 2
Item 11
A.0551
CU Door Lock
Qty 1
Item 12
A.0552
Cupboard Door
Bolt
Qty 2
Item 13
A.0558
Angled Striker Plate
Qty 2
Item 14
A.0559
Cupboard Lock Strike
Plate
Qty 1
Item 15
A.0592 A.0593 A.0594
Blum 100 Hinge
Qty, (See Table 1)
Item 16
D.0362
Lock Rosette
Qty 1
Item 17
F.0629
Rapid Dowel (Blue)
Qty, (See Table 1)
Item 18
F.0630
Rastex Cam
Qty, (See Table 1)
Item 19
F.0431
Wood Dowel
Qty 10
Item 20
F.0436, F.0446, F.0545,
F.0575, F.0576, F.0577
Cam Cover
Qty, (See Table 1)
Item 21
F.0404A
Kd Block Female (Brown)
Qty2
Item 22
F.0404B
Kd Block Male (Natural)
Qty 2
Item 25
F.0469
M4x28 Handle
Screw
Qty 4
Item 26
F.0470
34“x6g CSK Pozi BZP
Qty 4
Item 28
F.0442
5 8” x 4g CSK BZP
Qty 3
Item 29
F.0413
5 8” x 6g Pan BZP
Qty 4
Item 30
F.0564
Shelf Support
Qty 4
Item 31
F.0492
16mm Euro Screw
Qty 4
Item 5
STO1_643
Top Panel
Qty 1
Item 6
STO1_644
Bottom Panel
Qty 1
Item 4
STO1_592
Lintel
Qty 1
Item 2
STO1_538
LH Side Panel
Qty 1
Item 1
STO1_654
Back Panel
Qty 1
Item 3
STO1_536
RH Side Panel
Qty 1

2
A/1877 Revision A 29/01/2018
TOOLS REQUIRED BEFORE YOU BEGIN...
• Check you have all the tools and components required
• Keep children and animals away from small parts
• Ensure you have adequate space
• Assemble product on a at, clean surface
• Apply manual handling guidelines when building this item
COMPONENT PART QUANTITIES FOR UNIT SIZE VARIATIONS (TABLE 1)
• Pozi head screwdriver
• Hammer
STEP 1
ASSEMBLY INSTRUCTIONS
STEP 2
ITEM W800 x H740 mm W1000 x H740 mm W800 x H1000mm W1000 x H1000 mm W 800 x H1200 mm W1000 x H1200 mm
17 22 24 24 26 24 26
18 22 24 24 26 24 26
20 22 24 24 26 24 26
15 444444
ITEM W800 x H1600 mm W1000 x H1600 mm W800 x H1800mm W1000 x H1800 mm W 800 x H2000 mm W1000 x H2000 mm
17 26 28 26 28 26 28
18 26 28 26 28 26 28
20 26 28 26 28 26 28
15 666666
IMPORTANT
4 shelf units must be xed to the wall for stability.
18
Lay the Back (1) at on a soft
surface. Ensure all holes are free
of debris.
Insert the appropriate number of
Wooden Dowels (19) and Cams
(18).
Ensure that the arrow moulded
into the Cams are pointing
towards the edge of the panel. 19
1
Lay the Left Side (2) and Right Side
(3) at on a soft surface. Ensure all
holes are free of debris.
Insert the appropriate number of
Dowels (17) into the sides. Knock a
Male KDBlock (22) into each side.
In the Lintel (4) knock the female
KDBlocks (21).
Place both Sides into position on
the Back. Before tightening the
Cams, t the Lintel between the
Sides. Lock the Cams with a half
turn and tighten the screws in the
KD Fittings on the Lintel.
17
22
21
4
2
3

3
A/1877 Revision A 29/01/2018
ASSEMBLY INSTRUCTIONS
STEP 3
STEP 4
Insert the appropriate number of
Dowels (17) into the Top (5) and
Base (6).
Attach the Striker Plate (13) with
Screws (29) to both the Top and
Base.
Place both panels into position
on the Back and Sides. Lock the
Cams with a half turn.
5
6
17
13
29
Prepare the Left Door (7) by
attaching the Handle (10) with
Screws (25), the Hinges (15), the
Strike Plate (14)
with Screws (28).
The top and bottom Bolts (12)
with Screws (26).
Note the orientation of the Hinge
Plate that is screwed to the side
panel.
15
7
10
28
14
25
12
26

4
A/1877 Revision A 29/01/2018
STEP 5
ASSEMBLY INSTRUCTIONS
STEP 6
STEP 7
CARE AND MAINTENANCE
The Right Door (8) has a Lock (11)
inserted from behind the Door
held with Screws (28). On the front
of the Right Door, place the Lock
Rosette (16) over the Lock.
16
28
8
11
Carefully stand the cupboard
upright.
Any shelves (32) can now be tted.
Shelf Supports (30) are attached
to the Sides with Screws (31). The
Shelf has holes underneath that
locate over the pin on the Shelf
Support.
If the cupboard is 1000mm wide,
there are additional Shelf Supports
that are to be placed in holes in
the back panel to provide more
support to the Shelf.
Fit Cam Cover Caps (20) to the
Cams.
30
31
The cupboard can be levelled by
adjusting the height of the front
feet through the hole at the front of
the Base.
32
Clean using a damp cloth and mild detergent – do not use abrasive cleaners or bleach.
