Leuze GS63B/6.3-S8 User manual

Leuze electronic GmbH + Co. KG In der Braike 1 D-73277 Owen Tel. [phone]
[email protected] • www.leuze.com
We reserve the right to make changes ? DS_IGS63B_en_50128041-01.fm
Optical fork photoelectric sensor with 3mm
fork width and 60mm fork depth for exact
detection of labels on base material
High switching frequency and short
response time guarantee very good
repeatability
Slimline-design (reduced fork height) for
installation in a groove directly at the
dispensing edge
ALC function (Auto Level Control):
highest function reserve through
autonomous online optimization of the
switching threshold ((I)GS63B/….3…)
Storage of up to 30 teach values in the
sensor
Warning output for indicating teach or
function errors (IGS63B…)
Easy adjustment via lockable teach button
or teach input
3mm
Accessories:
(available separately)
Clamp BT-GS6X.DT
(Part no. 50128583)
Mounting device BT-GS6X.L
(Part No. 50112215)
Mounting device BT-GS6X.H
(Part no. 50123869)
Dimensioned drawing
ALabel center position
DD1: horizontal connector, D2: vertical connector, D3: cable
EMounted mounting device BT-GS6X.L (see mechanical accessories)
FMounted mounting device BT-GS6X.H (see mechanical accessories)
GIndicator diodes
HTeach button or potentiometer
Electrical connection
/
/
/
/
Cable, 5-wire, IGS 63B only
Connector, 4-pin
/
/
/
Connector, 5-pin
(n. c.: for device version with potentiometer)
(I)GS 63B Fork photoelectric sensor
(I)GS 63B… - 02
en 2020/08/19 50128041-01

(I)GS 63B… - 02 2020/08/19
Technical data
Physical data
Mouth width 3mm
Mouth depth 60mm
Label width 2mm
Label gap 2mm
Light source 940nm (infrared light)
Switching frequency Max. 10kHz
Conveyor speed during teach-in 20m/min (0.3m/s)
Typ. response time 50μs
Repeatability See diagrams
Readiness delay 300ms acc. to IEC 60947-5-2
Electrical data
Operating voltage UB 1)
1) For UL applications: for use in class 2 circuits according to NEC only
10 … 30VDC (incl. residual ripple)
Residual ripple 15% of UB
Open-circuit current 30mA
Switching output 2) …/6
Switching signal in the label gap
2) The push-pull switching outputs must not be connected in parallel
1 push-pull switching output
Pin 4: PNP gap signal, NPN label signal
…/66
Switching signal in the label gap
2 push-pull switching outputs,
Pin 4: PNP gap signal, NPN label signal
Pin 2: PNP label signal, NPN gap signal
…/6D
Switching signal on the label
1 push-pull switching output
Pin 4: PNP label signal, NPN gap signal
…/66D
Switching signal on the label
2 push-pull switching outputs,
Pin 4: PNP label signal, NPN gap signal
Pin 2: PNP gap signal, NPN label signal
Warning output IGS 63B only… 1 push-pull switching output
Pin 4: active low (normal operation high, event case low)
Switching output function Gap signal/label signal adjustable
Signal voltage high/low (UB-2V)/2V
Output current 100mA
Capacitive load 0.2FF 3)
3) Max. permissible input capacitance of a consumer connected to the switching output that can be switched without
activation of short-circuit-current limiting.
Indicators
Green LED Ready
Yellow LED Switching signal in the label gap
Red LED Teaching error / function error
Mechanical data
Housing base Diecast zinc; chemically nickel-plated surface (silver)
Upper part of housing PC plastic, red RAL 3000
Optics PC plastic
Weight 55g with connector, 100g with cable
Connection type M8 connector, 4-pin, metal or
Cable 2m (cross section 5 x 0.2mm²)
Environmental data
Ambient temp. (operation/storage) -20°C … +60°C/-30°C … +70°C
Protective circuit 4)
4) 1=polarity reversal protection, 2=short circuit protection for all outputs
1, 2
VDE protection class III
Degree of protection IP 67 with mounted connector
Standards applied IEC 60947-5-2
Certifications UL 508, C22.2 No.14-13 1) 5)
5) These proximity switches shall be used with UL Listed Cable assemblies rated 30V, 0.5A min,
in the field installation, or equivalent (categories: CYJV/CYJV7 or PVVA/PVVA7).
Additional functions
Teach-in input
Active/Not active 8V/2V
Activation/disable delay 0.2ms
Input resistance Typ. 10k
Marking on the
sensor
Align the label tape
according to the sensor’s
marker "Label center
position".
Diagrams
0
±5
±10
±15
±20
±25
±30
±35
±40
±45
±50
0 50 100 150 200
Conveyor speed [m/min]
Repeatability [µm]
Repeatability as a function of the
conveyor speed
Notes
Intended use:
The fork photoelectric sensor is
an optoelectronic sensor for
contactless detection of non-
transparent labels on any given
base material. Depending on
the setting, a switching signal
occurs in the gap (gap signal)
between two successive labels
or on the label (label signal).
Observe intended use!
This product is not a safety
sensor and is not intended
as personnel protection.
The product may only be put
into operation by competent
persons.
Only use the product in ac-
cordance with its intended
use.
(I)GS 63B

Leuze electronic GmbH + Co. KG In der Braike 1 D-73277 Owen Tel. [phone] (I)GS 63B… - 02
[email protected] • www.leuze.com
Order guide
The sensors listed here are preferred types; current information at www.leuze.com.
Part number code
ALC (Auto Level Control) function ((I)GS63B/….3…)
In each teach event, the current signal values in the sensor are digitally determined, resulting in the optimum switching threshold being
calculated for maximum function reserve. All values are permanently saved, retaining their validity as long as the dynamic parameters of
the system remain unchanged and the material is not changed.
Signal changes can result each time the roll is changed, even with labels that are apparently the same. This is caused, for example, by
material variations (transmission factor, homogeneity …) or changes of the dynamic system parameters (e.g. tape tension, middle position
of the labels, jitter, etc.) that can have a negative affect on the function reserve of the sensor.
With the ALC function, the sensor now automatically corrects the switching threshold in such a way that the maximum function reserve is
always available during operation - the sensor works absolutely reliably and free of errors.
The teach event only needs to be repeated if the sensor does not switch following a change of material.
Designation Part no. Comment
Without warning output GS63B/6.3-S8 50128004
GS63B/6D.3-S8 50128008
GS63B/6.3-S8V 50128005
GS63B/6D.3-S8V 50128009
GS63B/66.3-S8 50143910 2 antivalent switching outputs
GS63B/6.3,200-S8 50129248
With warning output IGS63B/6.3 50128013
IGS63B/6.3,200-S12 50128014
IGS63B/6D.3,200-S12 50128015
SET IGS63B/6D.3,200-S12 50128016 Included with BT-GS6X.L
SET IGS63B/6D.3BTH,200-S12 50128017 Mounted with BT-GS6X.H
Potentiometer GS63B/6 50128001
GS63B/6,200-S12 50128002
GS63B/6.01,200-S12 50128003 Mounted with BT-GS6X.L
GS63B/6-S8 50128011
GS63B/6-S8V 50128012
GS63B/6D 50128006
GS63B/6D-S8 50128010
GS63B/6D,200-S12 50128007
GS63B/6D,200-S8 50131604
IGS 63B/6D.3-S8V
Warning function
ISensor has warning output
Operating principle
GS Fork sensor, optical
Series
63B High quality series with metal housing, B generation
Output function
/6 Push-pull output: PNP signal in the label gap, NPN signal on the label
/66 2 push-pull outputs:
Pin 4: PNP signal in the label gap, NPN signal on the label
Pin 2: PNP signal on the label, NPN signal in the label gap
/6D Push-pull output: PNP signal on the label, NPN signal in the label gap
/66D 2 push-pull outputs:
Pin 4: PNP signal on the label, NPN signal in the label gap
Pin 2: PNP signal in the label gap, NPN signal on the label
Setting
N/A Potentiometer adjustment
.3 Teach button on the device
Electrical connection
N/A Device with cable, standard length 2000mm, cable outlet at 45°
-S8 M8 connector, 4-pin, horizontal plug outlet
-S8V M8 connector, 4-pin, vertical plug outlet
,200-S12 200mm cable with M12 connector, 5-pin, cable outlet at 45°
,200-S8 200mm cable with M8 connector, 4-pin, cable outlet at 45°
(I)GS 63B Fork photoelectric sensor

(I)GS 63B… - 02 2020/08/19
Sensor adjustment via potentiometer for GS 63B
Note: A removable operating button is plugged on the potentiometer in ex works. The setting of the fork
photoelectric sensor can thereby be performed manually and without the need for a tool. If this is not
desired, the operating button can be pulled off – a screwdriver is then necessary for making adjustments.
The following description applies to a fork photoelectric sensor with switching signal in the label gap
(GS 63B/6…). For device versions with switching signal on the label (GS 63B/6D…), the LED indicators
are inverted.
Preparation: Remove one or more labels from the base material and advance this blank area into the sen-
sor.
- If the yellow OUT LED does not switch on when the blank area is encountered, increase the sensi-
tivity by turning the potentiometer clockwise until the yellow OUT LED switches on.
- Starting from this setting, turn the potentiometer clockwise another approx. one half turn.
- Now advance the label tape so that a label is in the sensor.
- If set correctly, the yellow OUT LED must now switch off. Reduce the sensitivity by turning counter-
clockwise if the LED remains on.
- Finished: if set correctly, the LED changes between gap and label.
Short instructions for sensor adjustment via teach button for
(I)GS 63B (teach-in)
Top view of sensor
with operating
button plugged.
≥2 s
≥7 s
≥12 s
Standard function
Normal operation after switch-on
ON LED - green = ready
OUT LED - yellow = switching output
WARN LED - red = warning output
Teach-in "Sensitive" (level 2)
For slightly transparent/translucent labels
Either static or dynamic (as described here)
Green ON LED and yellow OUT LED
flash alternately 3 x per sec.
Move several labels through the sensor
Briefly press the button again to end the teach event
WARN LED - red is off if teach is error-free
= function lockable through constant application of UB on the teach input (devices with teach input only)
Setting switching behavior (Level 3)
Setting the switching output:
signal in the gap/signal on the label
ON LED - green flashes 3 x per sec.,
release button, green ON LED continues to flash.
OUT LED - yellow: on=signal in the gap
off=signal on the label
Pressing the button briefly once more terminates the setting
with the currently indicated switching behavior
Teach-in "Standard" (level 1)
Recommended - optimum for very many labels
Either static or dynamic (as described here)
ON LED - green and OUT LED - yellow
flash simultaneously 3 x per sec.
Move several labels through the sensor
Briefly press the button again to end the teach event
WARN LED - red is off if teach is error-free
(I)GS 63B

Leuze electronic GmbH + Co. KG In der Braike 1 D-73277 Owen Tel. [phone] (I)GS 63B… - 02
[email protected] • www.leuze.com
Standard function for (I)GS 63B
During operation the sensor is always in this function. The sensor detects label gaps with high precision and
speed. This is indicated by the yellow LED and the switching output.
Indicators:
Operation:
The teach button must be pressed for at least 2 seconds to operate the device. The button can be electrically disabled to prevent acci-
dental operation.
Sensor adjustment (teach-in) via teach button for (I)GS 63B
For optimum adaptation to various labels, the fork photoelectric sensor features two different sensitivities. The standard sensitivity
(2 … 7s) functions with very many labels and is always the first choice.
Only in the event of faulty switching on the label, e.g., with slightly transparent (translucent) or strongly inhomogeneous label materials,
is teaching on level 2 "Sensitive" (7 … 12s) recommended.
The teach-in can always be performed dynamically while label tape is passing through or, if the label tape cannot be transported, statically.
Preparation for dynamic teach-in:
Insert label tape into the sensor.
Preparation for static teach-in:
Remove one or more labels from the base material and advance this blank area into the sensor
Press the teach button until green and yellow LEDs flash simultaneously.
Release teach button.
During the teach event, the switching output is frozen in the most recently valid state prior to teaching.
Dynamic teach-in:
Advance the label tape at a maximum speed of 20m/min through the sensor so that at least 3 … 7 labels pass through the
sensor.
Static teach-in:
Blank area remains at the same position in the sensor.
Press the button briefly once more to terminate the teach event, the sensor goes into standard mode.
If the teach event is faulty (e.g. transmission with insufficiently thick base material), the red LED illuminates, the green and yellow LEDs
flash rapidly and the warning output is activated. For error acknowledgment, briefly press the teach button and repeat the teach event. If
the fault cannot be rectified, the label material cannot be detected with the (I)GS 63B.
Adjusting the switching behavior of the switching output
(signal in the label gap/on the label)
Press teach button until only the green LED flashes with 3 Hz.
Release the teach button - the green LED continues to flash, the yellow LED alternates slowly between ON and OFF.
Yellow LED ON = output switches in the label gap
Yellow LED OFF = output switches on the label.
If the button is pressed again while the LED is ON, the device switches in the label gap. For control purposes, the switching
behavior is displayed as long as the button is pressed. If the output is to switch on the label, the button must be pressed while
the LED is OFF.
Ready.
ON LED - green Constantly ON when operating voltage is applied.
OUT LED - yellow Indicates the switching signal. LED is ON if the sensor detects label gaps.
The display is independent of the output setting.
WARN LED - red Is OFF if operation is error-free. If the "Control limit reached" message appears or if the last
teach event was faulty, the red LED illuminates.
(I)GS 63B Fork photoelectric sensor

(I)GS 63B… - 02 2020/08/19
Sensor adjustment (teach-in) via teach input for (I)GS 63B
The following description applies to PNP switching logic!
The device setting is stored in a fail-safe way. A reconfiguration following power failure or switch-off is thus not required.
Line teach while label tape is passing through
Preparation: Insert the label tape in the correct position in the sensor (align the middle of the tape to the sensor marking).
The red LED illuminates and the warning output is activated if a teaching error occurs (e.g. the label cannot be reliably detected due to
insufficient signals).
Regardless of the state, the green LED is on when the teach event is terminated, the yellow LED indicates the current switching state.
Line teach if the label tape cannot be advanced (static teach)
Preparation: Remove one or more labels from the base material and place this blank area in the sensor. The label tape must now not be
advanced further.
The process is identical to the line teach with moving label tape.
Adjusting the switching behavior of the switching output – light/dark switching
UTeach Not connected Internal pull-down resistor pulls the
input down to zero
Teach button can be operated;
all functions adjustable
UTeach low 2V Low level Teach button can be operated;
all functions adjustable
UTeach high 8V High level Teach button disabled;
button has no function
UTeach > 2V … < 8V Not permitted
Pulse only
necessary if
a low-level
was applied
previously
Activation of the teach-in:
Action starts with the falling
edge:
tTeach = 1100 … 1900ms
The rising edge starts the teach event. The green
and yellow LEDs flash alternately 3x per second as
long as the signal is high.
Advance the label tape so that several label gaps
pass the sensor, thereby allowing the teach values
to be determined.
The teach event is concluded with the
falling edge.
50ms after the falling edge, the sensor
returns to normal operation.
The teach button is enabled again after
max. 3 s
Pulse only
necessary if
a low-level
was applied
previously
Activation of the teach
switching output:
Action starts with the falling
edge:
tTeach = 2100 … 3000ms
Switching output switches in the label gap
(20 … 900ms)
Switching output switches on the label
(1100 … 2000ms)
The teach event is concluded with the
falling edge.
50ms after the falling edge, the sensor
returns to normal operation.
The teach button is enabled again after
max. 3 s
t
20 ms … ∞1100 … 1900ms 50 ms … ∞50 ms
Button disabled
Button enabled
Button disabled
Button enabled after 3s
t
2100 … 3000ms 20 … 900ms 1100 … 2000ms20 ms … ∞
Button disabled
Button enabled
Button disabled
Button enabled after 3s
(I)GS 63B

Leuze electronic GmbH + Co. KG In der Braike 1 D-73277 Owen Tel. [phone] (I)GS 63B… - 02
[email protected] • www.leuze.com
Storing teach values in the sensor
It is possible to store or retrieve up to 30 different teach values. In this way, various label materials can be processed without the operator
needing to perform a teach event. If this function is desired, static interlocking of the teach button is recommended so that no operation
of the device can occur.
The event starts with the execution of the line teach (see description on page 6). The teach value ascertained in this way remains in sensor
memory and is then stored in one of 30 possible storage places using the process described in the following.
Flow chart: First perform line teach, then store teach value.
Storing teach values
Reading out teach values
Locking the teach button via the teach input
(I)GS 63B
A static high signal on the teach input locks the teach button on the device so that
no manual operation is possible (e.g. protection against erroneous operation or
manipulation).
If the teach input is not connected or if there is a static low signal, the button is
unlocked and can be operated freely.
Notices for integrating the sensor in a control concept
If the sensor is taught externally via a control, it may be necessary to receive acknowledgment from the sensor with respect to its current
teach state. Use the following chart for this purpose:
Pulse only
necessary
if a low-
level was
applied
previously
Activation - store current
teach value:
Action starts with the falling
edge:
tTeach = 580 … 620ms
Select storage place:
The pulse length determines the stor-
age place for the current teach value:
n=1,2,3 … 30
Example: t for storage place 3:
140ms … 160ms
The selection of
the storage place
is concluded with
the rising edge.
50ms after the
rising edge, the
sensor returns to
normal opera-
tion.
Pulse only
necessary
if a low-
level was
applied
previously
Action - read out teach val-
ue:
Action starts with the falling
edge:
tTeach = 780 … 820ms
Load
teach val-
ue
Select storage place:
The pulse length determines the stor-
age place from which the teach value
is loaded:
n=1,2,3 … 30
Example: t for storage place 7:
340ms … 360ms
The selection of
the storage place
is concluded with
the rising edge.
50ms after the
rising edge, the
sensor returns to
normal opera-
tion.
Operating mode Reaction from sensor
Dispensing mode Dynamic output signal: alternates between gap and label
Teach Static output signal: the state prior to teaching is frozen
Teach OK Output signal is dynamic again—warning output not active
Teach faulty Output signal is dynamic again—warning output active; repeat teach event if necessary
t
580 … 620ms 50ms(n x 50ms) -10ms
…
(n x 50ms) +10ms
20 ms … ∞ 20 … 100ms
Button disabled
Button enabled
Button disabled
Button enabled after 3s
t
780 … 820ms 50ms20 … 100ms (n x 50ms) -10ms
…
(n x 50ms) +10ms
20 ms … ∞
Button disabled
Button enabled
Button disabled
Button enabled after 3s
(I)GS 63B Fork photoelectric sensor

(I)GS 63B… - 02 2020/08/19
Mechanical accessories
Flat mounting device – for mounting compatibility with GS 06 fork photoelectric sensors
High mounting device – for uniform tape height with (I)GSU 14 ultrasonic fork sensors
Clamp – for installation in a groove directly at the dispensing edge
Maintenance information
The (I)GS 63B fork photoelectric sensor is largely maintenance free. Depending on the environmental conditions and the used materials,
it may be necessary from time to time to clean the transparent parts in the lower and upper fork of the fork photoelectric sensor. We rec-
ommend using a soft, moist cloth for this purpose. To protect the surface, cleaning agents containing solvents should not be used for
transparent parts.
Environmental durability
The used materials feature very good resistance to weak acids and bases as well as to UV exposure. Contact with organic solvents is
possible only to a limited extent and only for short times. Resistance to chemicals should be examined on a case by case basis.
Mounting device BT-GS6X.L (part no. 50114381),
flat design, especially for mounting compatibility with
our GS 06 fork photoelectric sensors.
Mounting device BT-GS6X.H (part no. 50123869),
high design, especially if it is desired that the tape
pass through at a uniform height between our
(I)GSU 14 and the GS 63B.
The BT-GS6X.DT clamp (part no. 50128583) is re-
quired for fastening the sensor at an arbitrary posi-
tion in a groove. Connect clamp to sensor as shown
and secure at the desired position by uniformly
screwing in the stud screws.
BT-
GS6X.DT
Sensor System-side
mounting plate
with groove
BT-GS6X.DT
Sensor
System-side
mounting plate
with groove
(I)GS 63B
