LIVARNO LUX 280200 Technical specifications

LED SOLAR SPOTLIGHT
IAN 280200
LED-SOLAR-STRAHLER
Montage-, Bedienungs- und Sicherheitshinweise
LED-SOLAR-SCHIJNWERPER
Montage-, bedienings- en veiligheidsinstructies
PROJECTEUR SOLAIRE À LED
Instructions de montage, d‘utilisation et
consignes de sécurité
LED SOLAR SPOTLIGHT
Assembly, operating and safety instructions

GB/IE/NI Assembly, operating and safety instructions Page 5
FR/BE Instructions de montage, d‘utilisation et consignes de sécurité Page 21
NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 39
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 56

A
C
B
D
3
5 46
158 8
1
2
7

E
G
F
0m 2m 4m 6m 8m
2m
ca.140°
ca.8m
H
12
13
8
6
4
9
11
10

5GB/IE/NI
List of pictograms used........................................................Page 6
Introduction...................................................................................Page 6
Intended use ........................................................................................Page 7
Parts description...................................................................................Page 7
Technical Data.....................................................................................Page 8
Scope of delivery.................................................................................Page 8
General safety instructions .............................................Page 9
Safety instructions for batteries/ rechargeable batteries..................Page 10
Function.............................................................................................Page 11
Before use.......................................................................................Page 12
Charging the rechargeable batteries.................................................Page 12
Installation......................................................................................Page 13
Mounting the main unit .......................................................................Page 13
Mounting the solar cell........................................................................Page 14
Connecting the solar cell to the main unit..........................................Page 15
Start-up..............................................................................................Page 15
Setting the lighting duration................................................................Page 16
Setting the daylight level.....................................................................Page 16
Replacing the rechargeable batteries...................Page 16
Winter-time use..........................................................................Page 17
Cleaning and Care...................................................................Page 17
Troubleshooting.........................................................................Page 18
Disposal.............................................................................................Page 19
Warranty.........................................................................................Page 20

6 GB/IE/NI
List of pictograms used
Motion detector detection range approx. 8m
(weather dependant)
This product is suitable for extreme
temperature up to -21°C.
Motion detector detection angle approx. 140°
Connection cable (approx. 5m)
Splashproof (IP44)
LED solar spotlight
Introduction
We congratulate you on the purchase of your new product. You have
chosen a high quality product. The instructions for use are part of the
product. They contain important information concerning safety, use
and disposal. Before using the product, please familiarise yourself with
all of the safety information and instructions for use. Only use the
product as described and for the specified applications. If you pass

7GB/IE/NI
the product on to anyone else, please ensure that you also pass on all
the documentation with it.
Intended use
The product is intended to illuminate outdoor areas without electrical
connection, e.g. garden sheds etc. The product is intended for private
use only and is not suitable for commercial use or for use in other
applications.
Not suitable for ordinary lighting in household room
illumination.
This product is suitable for extreme temperature up to -21°C.
Parts description
1Main unit
2LED spotlight
3Motion detector
4Screw (Ø 3.6 x 30mm)
5Mounting plate
6Wall plug (Ø 6 mm)
7Cap
8Battery compartment
9Bracket (solar cell)
10 Solar cell
11 Connection cable
12 Rotary control LUX
13 Rotary control TIME

8 GB/IE/NI
Technical Data
Operating voltage: 3.7V (direct current)
Rechargeable battery: 2 x 18650/ 18650 A Li-ion 3.7V
(direct current), 1800mAh
LED: 2 x 4W (LEDs not replaceable)
Solar cell: 95 x 95mm, max. 5.5 V, max. 110 mA
Motion detector: Range: max. 8m, detection angle:
approx. 140° horizontal, approx. 90°
vertical
Degree of protection: IP44 (splash-proof)
Weight: 520g
Dimensions: approx. 19.4 x 14.5 x 10.5cm
Projected area: max. 19.4 x 14.5 cm
Mounting height: max. 2m
Scope of delivery
Check immediately after unpacking that the parts are complete and
that the product is in proper condition.
1 Main unit with pre-installed rechargeable batteries
5 Screws (Ø 3.6 x 30mm)
5 Wall plugs (Ø 6 mm)
1 Solar cell with connection cable
2 Caps
1 Instructions for assembly and use

9GB/IE/NI
General safety instructions
BEFORE USING THE PRODUCT, PLEASE FAMILIARISE YOURSELF
WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS
FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS,
PLEASE ALSO INCLUDE ALL THE DOCUMENTS!
This product may be used by children age 8 years and up, as well
as by persons with reduced physical, sensory or mental capaci
ties,
or lacking experience and/or knowle
dge, so long as they are super-
vised or instructed in the safe use of the product and understand
the associated risks. Children should not be allowed to play with
the product. Cleaning and user maintenance should not be per-
formed by children without supervision.
Never leave children unsupervised with the packaging material.
The packaging material represents a danger of suffocation.
Children frequently underestimate the dangers.
DANGER OF SUFFOCATION! Children could swallow and
choke on small included parts (e.g. screws). Keep children away
from the work area during assembly.
Do not use this product if you notice any damage!
The illuminants are not replaceable.
If the illuminants fail at the end of their lives, the entire product
must be replaced.
0.1m
FIRE HAZARD! Fit the product so that it is at least
0.1m away from the material to be illuminated. Exces-
sive heat can result in a fire.

10 GB/IE/NI
Risk Group 2
Product tested against EN62471
CAUTION. Possibly hazardous
optical radiation emitted from
this product. Do not stare at operating
lamp. May be harmful to the eye.
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries/rechargeable batteries out
of reach of children. If accidentally swallowed seek immediate
medical attention.
DANGER OF EXPLOSION! Never recharge non-
rechargeable batteries. Do not short-circuit batteries/re-
chargeable batteries and/or open them. Overheating,
fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable batteries.
Risk of batteries/rechargeable batteries leakage
Avoid extreme environmental conditions and temperatures, which
could affect batteries/rechargeable batteries, e.g. radiators/
direct sunlight.
Avoid contact with the skin, eyes and mucous membranes. In the
event of contact with battery acid, thoroughly flush the affected

11GB/IE/NI
area with plenty of clean water and seek immediate medical
attention.
WEAR PROTECTIVE GLOVES! Leaked or damaged
batteries/rechargeable batteries can cause burns on
contact with the skin. Wear suitable protective gloves at
all times if such an event occurs.
In the event of a battery leak, immediately remove it from the prod-
uct to prevent damage.
Only use the same type of batteries/rechargeable batteries. Do
not mix used and new batteries/rechargeable batteries.
Remove the batteries/rechargeable batteries if the product will not
be used for a longer period.
Risk of damage of the product
Only use the specified type of battery/rechargeable battery!
When inserting ensure the correct polarity! This is shown inside the
battery compartment!
Clean the contacts on the battery and in the battery compartment
before inserting!
Remove exhausted batteries/rechargeable batteries from the
product immediately.
Function
The solar cell 10 converts energy from sunlight into electricity. This re-
charges the rechargeable batteries inside the battery compartment 8
via the connection cable 11 .
These rechargeable batteries store the electricity fed by the solar cell.
Fully charged batteries will provide about 2 hours of light.

12 GB/IE/NI
In summer completely drained rechargeable batteries take about 2 to
4 days to fully recharge in constant sunlight. The rechargeable batter-
ies must be charged prior to initial use (see „Charging rechargeable
batteries“).
During periods of twilight or darkness, the motion detector 3registers
a change in the angle of heat radiation, triggered by people passing
by the motion detector. When the motion detector recognises a moving
person the light is switched on.
Note: The motion detector 3responds to heat radiation. When
outdoor temperatures are low, it is more sensitive to body heat than
when outdoor temperatures are warm. Be sure to regulate the sensitiv-
ity of the motion detector over the course of the year.
Note: Regularly clean the motion detector to ensure proper function-
ality (refer to „Cleaning and Care“).
Before use
Note: Before first use remove the insulation strip.
Charging the rechargeable batteries
Note:The rechargeable batteries inside the main unit 1are fully
charged at delivery. However, they may already have lost charge
during transport from the manufacturer to the retail location. Therefore
charge the rechargeable batteries prior to use. During summer, initial
charging will take at least one day in constant sunlight.
Note: In constant sunlight (depending on the season) drained re-
chargeable batteries should take two to ten days to charge.

13GB/IE/NI
Note: The built-in charging controller of the product prevents the
rechargeable batteries from overcharging.
Replace the rechargeable batteries if the light output does not improve
after charging (see „Replacing the rechargeable batteries“).
Installation
Note: Before mounting, decide where you want to mount the solar
cell 10 and the main unit 1. Please remember the connection cable
11 between the solar cell and the main unit is approx. 5 m long.
Note: The included mounting material is suitable for ordinary solid
concrete or masonry construction. Other wall substrates may require
other fastening materials. Seek specialist advice if necessary.
Note: You will need an electric drill.
CAUTION! RISK OF INJURY! Please read the operating
instructions for your drill.
CAUTION! Ensure that you do not damage any electricity cables
in the wall or ceiling.
Mounting the main unit
Please remember when selecting the location for mounting the main
unit 1:
1. Make sure the LED spotlight 2illuminate the desired area. You
can move the LED spotlight 2independently in various directions.
2. Depending on the mounting height (ideally at 2m) the motion de-
tector 3has a detection range of max. 8m with a detection an-
gle of 140° horizontally and 90° vertically.

14 GB/IE/NI
3. Be sure the motion detector is not illuminated by street lighting at
night. This can influence the effect.
Loosen the screw on the bottom of the main unit 1with a suitable
cross-head screwdriver. Remove the mounting plate 5from the
back of the product (Fig. A).
Pay attention to the rubber nipple which covers the charging socket.
Use the holes of the mounting plate 5intended for the screws to
mark the holes for drilling. Ensure that the arrow on the marking
of the mounting plate is showing vertically upward.
Now drill the mounting holes.
Insert the wall plugs 6into the drilled holes (Fig. B).
Fix the mounting plate 5using the screws 4with a suitable
cross-head screwdriver (Fig. B).
Press the caps 7onto the screws 4.
After mounting, check that the mounting plate 5is fitted securely.
Fit the main unit 1onto the mounting plate 5. Insert the 2 lugs
into the respective slots on the upper side of the mounting plate 5.
Ensure the product is correctly seated.
Secure the main unit 1with the screw on the bottom (Fig. A).
Pay attention to the rubber nipple which covers the charging
socket.
Mounting the solar cell
The solar cell 10 requires direct sunlight when possible. Ideally, the
solar cell surface will be directed to the south.

15GB/IE/NI
Use the holes of the bracket 9intended for the screws to mark
the holes for drilling (Fig. F).
Now drill the mounting holes.
Insert the wall plugs 6into the drilled holes.
Fix the bracket 9using the screws 4with a suitable cross-head
screwdriver (Fig. F).
After mounting, check that the bracket 9of the solar cell 10 is
fitted securely.
Next adjust the solar cell to face south.
Connecting the solar cell to the main unit
After mounting the two operating units (main unit 1and solar cell 10 )
run the connection cable 11 so it is not subjected to mechanical stress.
Use typical installation material such as cable clamps or conduit to fas-
ten the connection cable, to prevent damage to the insulation.
Connect the plug of the connection cable 11 with the charging
socket of the main unit 1(Fig. G).
Adjust both LED spotlights 2to your desired angle. The LED spot-
lights are independently rotatable and tiltable.
Your product is now ready for use.
Start-up
Note:
Connect the main unit 1to the solar cell 10 before using for the
first time.

16 GB/IE/NI
Setting the lighting duration
Turn the rotary control TIME 13 clockwise to increase the duration
of the illumination. The lighting duration can be adjusted within a
time window of approx. 5 seconds to 7 minutes (Fig. H).
Setting the daylight level
Turn the rotary control LUX 12 clockwise to increase the daylight
level: In the position, the motion detector 3only reacts at night
(at approx. 50lx). In the position, the motion detector also re-
sponds at daylight levels, as long as about 10,000lx are not ex-
ceeded (Fig. H).
Replacing the rechargeable batteries
Disconnect the plug of the connection cable 11 from the charging
socket of the main unit 1.
Loosen the screw on the bottom of the main unit 1(Fig. A).
Pay attention to the rubber nipple which covers the charging
socket.
Detach the main unit 1from the mounting plate 5(Fig. C).
Remove the battery compartment 8from the back of the main
unit 1(Fig. D).
Remove the exhausted rechargeable batteries from the battery
compartment 8and replace with new rechargeable batteries of
the same type (Fig. E). Be sure to insert the rechargeable batteries

17GB/IE/NI
in correct direction. The correct polarity is shown inside the battery
compartment.
Insert the battery compartment 8into the back of the main unit
1(Fig. D). Make sure that the upper lug and charging socket are
inserted into the respective supports. Do not pinch any wires.
Fit the main unit 1onto the mounting plate 5. Insert the 2 lugs
into the respective slots on the upper side of the mounting plate
5. Ensure the product is correctly seated.
Secure the main unit 1with the screw on the bottom (Fig. A).
Pay attention to the rubber nipple which covers the charging
socket.
Connect the plug of the connection cable 11 with the charging
socket of the main unit 1(Fig. G).
Winter-time use
The low amount of sunlight may reduce the light ON time at night de-
pending on the on-time. Due to the low position of the sun also verify
the solar cell 10 is out of shade throughout the day in winter and re-
move ice and snow as necessary.
If the light ON time is inadequate due to the weather, recharge or
replace the rechargeable batteries (see„Charging the rechargeable
batteries“ or „Replacing the rechargeable batteries“).
Cleaning and Care
Use a slightly dampened, lint-free cloth and mild cleaning agent to
clean.

18 GB/IE/NI
Regularly check the motion detector 3and solar cell 10 particu-
larly for dirt.
Regularly clean the motion detector and solar cell to ensure proper
functionality.
Especially keep the solar cell free of snow and ice in winter.
Troubleshooting
Problem Cause Solution
The light does
not switch on. Motion detector 3
is dirty
Clean motion detector
Batteries are drained Charge batteries (see
„Charging the rechargea-
ble batteries“)
The light flickers. Batteries are almost
drained
Charge batteries (see
„Charging the rechargea-
ble batteries“)
Battery quickly
loses its charge. The solar cell 10 is
dirty.
Clean the solar cell
Solar cell is posi-
tioned incorrectly
Reposition the solar cell
(refer to “Assembly“)
Poor weather
conditions
Refer to “Winter-time
use“
Defective batteries. Replace batteries (see
“Maintenance/
Changing batteries“)

19GB/IE/NI
Disposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities. The
Green Dot is not valid for Germany.
b
a
Observe the marking of the packaging materials for waste
separation, which are marked with abbreviations (a) and
numbers (b) with following meaning: 1–7: plastics/20–22:
paper and fibreboard/80–98: composite materials.
The product and packaging materials are recyclable,
dispose of it separately for better waste treatment. The
Triman logo is valid in France only.
Contact your local refuse disposal authority for more details
of how to dispose of your worn-out product.
To help protect the environment, please dispose of the prod-
uct properly when it has reached the end of its useful life
and not in the household waste. Information on collection
points and their opening hours can be obtained from your
local authority.
Faulty or used rechargeable batteries must be recycled in accordance
with Directive 2006/66/ EC and its amendments. Return rechargea-
ble batteries and/or the product using the recycling facilities provided.

20 GB/IE/NI
Environmental damage through incorrect
disposal of the rechargeable batteries!
Rechargeable batteries may not be disposed of with the usual domes-
tic waste. Therefore dispose of used batteries through your municipal
collection site.
Warranty
The product has been manufactured to strict quality guidelines and
meticulously examined before delivery. In the event of product defects
you have legal rights against the retailer of this product. Your legal
rights are not limited in any way by our warranty detailed below.
The warranty for this product is 3 years from the date of purchase.
Should this product show any fault in materials or manufacture within
3 years from the date of purchase, we will repair or replace it – at our
choice – free of charge to you.
The warranty period begins on the date of purchase. Please keep the
original sales receipt in a safe location. This document is required as
your proof of purchase. This warranty becomes void if the product has
been damaged, or used or maintained improperly.
The warranty applies to defects in material or manufacture. This war-
ranty does not cover product parts subject to normal wear, thus pos-
sibly considered consumables (e.g. batteries) or for damage to fragile
parts, e.g. switches, rechargeable batteries or glass parts.
