LSIS XBF-AD04A User manual

Right choice for ultimate yield
LSIS strives to maximize customers' profit in gratitude of choosing us for your partner.
Programmable Logic Controller
XGB Analog
User’s Manual
 Read this manual carefully before
installing,
wiring, operating, servicing
or inspecting this equipment.

Keep this manual within easy reach
for quick reference.
XGT Series
www.lsis.com
XBF-AD04A
XBF-AD08A
XBF-DV04A
XBF-DC04A
XBF-RD04A
XBF-TC04S
XBF-AH04A
XBO-AD02A
XBO-DA02A
XBO-AH02A
XBO-RD01A
XBO-TC02A
Analog
input
Analog
output
Temperature input
Analog
input/output
Analog
input option board
Analog
output option board
Analog
input/output option board
Temperature input
option board
Built
-in PID

Safety Instructions
Before using the product …
For your safety and effective operation, please read the safety instructions
thoroughly before using the product.
►Safety Instructions should always be observed in order to prevent accident
or risk with the safe and proper use the product.
►Instructions are divided into “Warning” and “Caution”, and the meaning of
the terms is as follows.
This symbol indicates the possibility of serious injury
or death if some applicable instruction is violated
This symbol indicates the possibility of severe or
slight injury, and property damages if some
applicable instruction is violated
Moreover, even classified events under its caution category may develop into
serious accidents relying on situations. Therefore we strongly advise users to
observe all precautions properly just like warnings.
►The marks displayed on the product and in the user’s manual have the
following meanings.
Be careful! Danger may be expected.
Be careful! Electric shock may occur.
►The user’s manual even after read shall be kept available and accessible to
any user of the product.
Warning
Caution

Safety Instructions
Safety Instructions for design process
Please install a protection circuit on the exterior of PLC so that the
whole system may operate safely regardless of failures from
external power or PLC. Any abnormal output or operation from PLC
may cause serious problems to safety in whole system.
- Install protection units on the exterior of PLC like an interlock circuit
that deals with opposite operations such as
emergency stop,
protection circuit, and forward/reverse rotation or install an interlock
circuit that deals with high/low limit under its position controls.
- If any system error (watch-dog timer error, module installation error,
etc.) is detected during CPU operation in PLC, all output signals are
designed to be turned off and stopped for safety. However, there
are cases when output signals remain active due to device failures
in Relay and TR which can’t be detected
. Thus, you are
recommended to install an addition circuit to monitor
the output
status for those critical outputs which may cause significant
problems.
Never overload more than rated current of output module nor
allow to have a short circuit. Over current for a long period time may
cause a fire .
Never let the external power of the output circuit to be on earlier
than PLC power, which may cause accidents from abnormal output or
operation.
Please install interlock circuits in the sequence program for safe
operations in the system when exchange data with PLC or modify
operation modes using a computer or other external equipments
Read specific instructions thoroughly when conducting control
operations with PLC.
Warning

Safety Instructions
Safety Instructions for design process
Safety Instructions on installation process
I/O signal or communication line shall be wired at least 100mm
away from a high-voltage cable or power line.Fail to follow this
instruction may cause malfunctions from noise
Caution
Use PLC only in the environment specified in PLC manual or
general standard of data sheet. If not, electric shock, fire, abnormal
operation of the product may be caused.
Before install or remove the module, be sure PLC power is off. If
not, electric shock or damage on the product may be caused.
Be sure that every module is securely attached after adding a
module or an extension connector.
If the product is installed
loosely or incorrectly, abnormal operation, error or dropping may be
caused.
In addition, contact failures under poor cable installation will
be causing malfunctions as well.
Be sure that screws get tighten securely under vibrating
environments.
Fail to do so will put the product under direct
vibrations which will cause electric shock, fire and abnormal
operation.
Do not come in contact with conducting parts in each module,
which may cause electric shock, malfunctions or abnormal operation.
Caution

Safety Instructions
Safety Instructions for wiring process
Prior to wiring works, make sure that every power is turned off. If
not, electric shock or damage on the product may be caused.
After wir
ing process is done, make sure that terminal covers are
installed properly before its use.Fail to install the cover may cause
electric shocks.
Warning
Check rated voltages and terminal arrangements in each product
prior to its wiring process.
Applying incorrect voltages other than
rated voltages and misarrangement among terminals may cause fire
or malfunctions.
Secure terminal screws tightly applying with specified torque.If
the screws get loose, short circuit, fire or abnormal operation may be
caused. Securing screws too tightly will cause damages to the module
or malfunctions, short circuit, and dropping.
*
Be sure to earth to the ground using Class 3 wires for PE
terminals which is exclusively used for PLC. If the terminals not
grounded correctly, abnormal operation or electric shock
may be
caused.
Don’t let any foreign materials such as wiring waste inside the
module while wiring, which may cause fire, damage on the product
or abnormal operation.
Make sure that pressed terminals
get tighten following the
specified torque. External connector type shall be pressed or
soldered using proper equipments.
Caution

Safety Instructions
Safety Instructions for test-operation and
maintenance
Don’t touch the terminal when powered. Electric shock or abnormal
operation may occur.
Prior to cleaning or tightening the
terminal screws, let all the
external power off including PLC power.
If not, electric shock or
abnormal operation may occur.
Don’t let the battery recharged, disassembled, heated, short or
soldered. Heat, explosion or ignition may cause injuries or fire.
Warning
Do not make modifications or disassemble each module.Fire,
electric shock or abnormal operation may occur.
Prior to installing or disassemb
ling the module, let all the
external power off including PLC power. If not, electric shock or
abnormal operation may occur.
Keep any wireless equipment such as walkie-talkie or cell phones
at least 30cm away from PLC
. If not, abnormal operation may be
caused.
When making a modification on programs or using run to modify
functions under PLC operations,
read and comprehend all
contents in the manual fully. Mismanagement will cause damages to
products and accidents.

Avoid any physical impact to the battery and prevent it from
dropping as well. Damages to battery may cause leakage from its
fluid. When battery was dropped or exposed under strong impact,
never reuse the battery again. Moreover skilled workers are needed
when exchanging batteries.
Caution

Safety Instructions
Safety Instructions for waste disposal

Product or battery waste shall be processed as industrial waste.
The waste may discharge toxic materials or explode itself.
Caution

Revision History
Version Data Important change Page
V 1.0 2007. 7
1. Adding contents
(1) Setting Sequence before operation
(2) Accuracy calculation example
2. Changing contents
(1) Wiring examples
(2) Configuration and Function of Internal
Memory
(3) Example Program
2-1,3-1,4-1
2-9,3-7
2-13,3-9,4-9
2-28,3-18,4-20
2-33,3-23,4-24,5-37
V 1.1 2008. 1
1. Adding model
(1) Thermocouple input module
(XBF-TC04S)
2. Adding contents
(1) Thermo electromotive force and
compensating cable
(2) Performance Specification
(3) Dimension
3. Changing chapter number
(1) CH.6 PID Function
(2) Appendix 3. Dimension
5-1 ~ 5-54
Appendix 2
1-5
APP.3-3
CH 5 →CH6
App.2 --> App.3
V1.2
2008.4
1. Adding XGB compact ‘H’ type
All over
V1.3
2009.2
1. Adding contents about XGB IEC type
All over
V1.4 2009.7 1. Adding model
(1) Analog combo module (XBF-AH04A)
2. Adding/changing contents
(1) Adding contents at chapter 1
(2) Adding dimension
6-1 ~ 6-48
1-1,1-6,1-7
Appendix3-3
V1.5 2009.12 1. Adding new model
(1) Analog input module (XBF-AD08A)
2. Contents added/modified
(1) Contents added
(2) Name changed
Analog input module Analog input
module (4-channel)
(3) CH.7 PID moved to CH8
(4) Dimension added
(5) XGB Compact type ‘S’ type added
7-1 ~ 7-40
1-1, 1-3
2-1 ~ 2-42
CH7 →CH8
Appendix 3-3
All over

Version Data Important change Page
V1.6
2011.2 1. Adding new model
(1) Analog Input Option Board
(XBO-AD02A)
(2) Analog Output Option Board
(XBO-DA02A)
(3) Analog IO Option Board
(XBO-AH02A)
(4) RTD Input Option Board
(XBO-RD01A)
(5) Thermocouple Input Option Board
(XBO-TC02A)
(6) Thermocouple Voltage Input
(XBF-TC04B)
2. Contents added/modified
(1) CH.8 PID moved to CH13
8-1 ~ 8-35
9-1 ~ 9-35
10-1 ~ 10-44
11-1 ~ 11-27
12-1 ~ 12-35
5-1 ~ 5-60
CH8 →CH13
V1.7 2012.8 1. Adding new model
(1) XBF-AD04C
(2) XBF-DV04C/DC04C
2. Changing contents
(1) CH.13 PID moved to CH15
13-1 ~ 13-47
14-1 ~ 14-41
CH13
→
CH1
V1.8 2014.1 1. Adding Analog/Temp option board IEC
Memory Area
(1) XBO-AD02A/DA02A/AH02A
(2) XBO-RD01A/TC02A
8-26,9-22,10-32
11-20,12-24
V1.9 2014.3 1. Revision of content error
(1) XBF-DC04C Current Resolution
14-3
V2.0
2015.7 1. Domain name changed 2. General specifications changed by reason
of changed IEC Specifications.
2-2,3-2,4-2,5-2,6-2
7-2,8-2,9-2,10-2,11-2
12-2,13-2,14-2
※The number of User’s manual is indicated right part of the back cover.
ⓒLSIS Co., Ltd.2007All Rights Reserved.

About User’s Manual
About User’s Manual
Thank you for purchasing PLC of LSIS Co., Ltd.
Before use, make sure to carefully read and understand the User’s Manual about the functions,
performances, installation and programming of the product you purchased in order for correct use and
importantly, let the end user and maintenance administrator to be provided with the User’s Manual.
The User’s Manual describes the product. If necessary, you may refer to the following description and order
accordingly. In addition, you may connect our website(http://www.lsis.com/) and download the information as
a PDF file.
Relevant User’s Manuals
Title Description No. of User’s
Manual
XG5000 user’s
manual
It describes how to use XG5000 software about online functions
such as programming, printing, monitoring
and debugging by
using XGB series products.
10310000512
XG5000 user’s
manual (for
XGI/XGR/XEC)
It describes how to use XG5000 software about online functions
such as programming, printing, monitoring and
debugging by
using XGB (IEC language)
10310000834
XGK/XGB
Instructions &
Programming
It is the user’s manual for programming to explain how to use
commands that are used PLC system with XGB CPU. 10310000510
XGI/XGR/XEC
Instructions &
Programming
It is the user’s manual for programming to explain how to use
commands that are used in XGB (IEC language) 10310000833
XGB hardware It describes power, IO, extension
specification and system
configuration, built-in high speed counter of XGB main unit.
10310000693
XGB hardware (IEC) It describes power, IO, extension
specification and system
configuration, built-in high speed counter of XGB (IEC) main unit.
10310000983
XGB Analog
user’s manual
It describes how to use the specification of analog input/analog
output/temperature input module, system configuration and built-in
PID control for XGB basic unit.
10310000920
XGB Position
User’s manual
It describes how to use the specification of analog input/analog
output/temperature input module, system configuration and built-in
PID control for XGB basic unit.
10310000927
XGB Cnet I/F
It is the user’s manual about XGB Cnet I/F that describes built-in
communication function and external Cnet I/F module of XGB
basic unit
10310000816
XGB FEnet I/F
It describes how to use XGB FEnet I/F module.
10310000873
XBC Standard /
Economic Type
Main Unit
It describes power, I/O, extension
specification and system
configuration, built-
in high speed counter of XGB standard /
economic type main unit.
10310001091

About User’s Manual
Title Description No. of User’s
Manual
XGB High speed
counter User’s
Manual
It is the user’s manual for High speed counter extension module of
XGB basic unit to explain High speed counter extension module
function of XGB basic unit.
10310001242
XGB Fast Ethernet
I/F It describes how to use XGB FEnet I/F module.
10310000873
XGB CANopen I/F It describes how to use the CANopen that is kind of opened type
network.
10310001245

◎Table of Contents ◎
Chapter 1 General .........................................................................................1-1~1-17
1.1 Analog Product List.........................................................................................................................1-1
1.2 Specification of Analog Module.......................................................................................................1-3
Chapter 2 Analog Input Module (XBF-AD04A)............................................2-1~2-43
2.1 Setting Sequence before Operation................................................................................................2-1
2.2 Specifications ................................................................................................................................2-2
2.3 Name of part and function .............................................................................................................2-4
2.4 Characteristic of I/O conversion ....................................................................................................2-5
2.5 Conversion Characteristic according to Input Range ....................................................................2-6
2.6 Accuracy ........................................................................................................................................2-9
2.7 Functions of Analog Input Module ...............................................................................................2-10
2.8 Wiring ..........................................................................................................................................2-13
2.9 Operation Parameter Setting ......................................................................................................2-17
2.10 Special Module Monitoring Functions .......................................................................................2-19
2.11 Register U devices ....................................................................................................................2-24
2.12 Configuration and Function of Internal Memory ........................................................................2-28
2.13 Example Program ......................................................................................................................2-34
2.14 Troubleshooting .........................................................................................................................2-40
Chapter 3 Analog Onput Module (XBF-DV04A / XBF-DC04A / XBF-DC04B)........3-1~3-29
3.1 Setting Sequence before Operation ..............................................................................................3-1
3.2 Specification ..................................................................................................................................3-2
3.3 Designations and Functions ..........................................................................................................3-4
3.4 Characteristic of I/O Conversion ...................................................................................................3-5
3.5 Characteristic of Input/Output .......................................................................................................3-6
3.6 Accuracy ........................................................................................................................................3-7
3.7 Functions of Analog Output Module ..............................................................................................3-8
3.8 Wiring ............................................................................................................................................3-9
3.9 Operation Parameter Setting ......................................................................................................3-10
3.10 Special Module Monitoring Function .........................................................................................3-12
3.11 Register U devices ....................................................................................................................3-15
3.12 Internal memory ........................................................................................................................3-19
3.13 Example Program ......................................................................................................................3-25
3.14 Troubleshooting .........................................................................................................................3-27

Chapter 4 RTD Input Module (XBF-RD04A / XBF-RD01A)..........................4-1~4-30..4-1
4.1 Setting Sequence before Operation ..............................................................................................4-1
4.2 Specification ..................................................................................................................................4-2
4.3 Part Names and Functions ............................................................................................................4-4
4.4 Temperature Conversion Characteristic .......................................................................................4-5
4.5 Conversion Speed .........................................................................................................................4-6
4.6 Accuracy .........................................................................................................................................4-6
4.7 Temperature Display .....................................................................................................................4-6
4.8 Scaling Function ............................................................................................................................4-7
4.9 Disconnection Detection Function .................................................................................................4-8
4.10 Wiring ..........................................................................................................................................4-9
4.11 Filtering Function .......................................................................................................................4-11
4.12 Operation Parameter Setting ......................................................................................................4-12
4.13 Special Module Monitoring ........................................................................................................4-15
4.14 Register U devices ....................................................................................................................4-18
4.15 Configuration and Function of Internal Memory ........................................................................4-21
4.16 Example Program ......................................................................................................................4-25
4.17 Trouble Shooting .......................................................................................................................4-28
Chapter 5 Thermocouple Input Module (XBF-TC04S / XBF-TC04B) .........5-1~5-60
5.1 General............................................................................................................................................5-1
5.2 Specification....................................................................................................................................5-4
5.3 Function ........................................................................................................................................5-14
5.4 Installation and Wiring...................................................................................................................5-19
5.5 Operation Setting and Monitor ....................................................................................................5-22
5.6 Configuration and Function of Internal Memory ..........................................................................5-36
5.7 Example Program ........................................................................................................................5-51
5.8 Troubleshooting ...........................................................................................................................5-56
Chapter 6 Analog I/O Module (XBF-AH04A)................................................6-1~6-48..6-1
6.1 Pre-operation Setting Procedure ....................................................................................................6-1
6.2 Specification....................................................................................................................................6-2
6.3 Major Components..........................................................................................................................6-5
6.4 Conversion Characteristics by I/O Range.......................................................................................6-6
6.5 Precision .......................................................................................................................................6-10
6.6 Functions of Analog I/O Module....................................................................................................6-12
6.7 Wiring............................................................................................................................................6-18

6.8 Operation Parameter Setting ......................................................................................................6-22
6.9 Special Module Monitor Function..................................................................................................6-24
6.10 Auto-registration of U-Device (Special Module Variable) ...........................................................6-28
6.11 Constitution and Function of Internal Memory............................................................................6-33
6.12 Example Program .......................................................................................................................6-40
6.13 Troubleshooting ..........................................................................................................................6-46
Chapter 7 Analog Input Module (XBF-AD08A)............................................7-1~7-39
7.1 Setting Sequence before Operation................................................................................................7-1
7.2 Specifications ................................................................................................................................7-2
7.3 Name of part and function .............................................................................................................7-4
7.4 Characteristic of I/O conversion ....................................................................................................7-5
7.5 Accuracy ........................................................................................................................................7-7
7.6 Functions of Analog Input Module .................................................................................................7-8
7.7 Wiring ..........................................................................................................................................7-13
7.8 Operation Parameter Setting ......................................................................................................7-16
7.9 Special Module Monitoring Functions .........................................................................................7-19
7.10 Register U devices ....................................................................................................................7-23
7.11 Configuration and Function of Internal Memory ........................................................................7-28
7.12 Example Program ......................................................................................................................7-35
7.13 Troubleshooting .........................................................................................................................7-37
Chapter 8 Analog Input Option Board (XBO-AD02A).................................8-1~8-35
8.1 Setting Sequence before Operation................................................................................................8-1
8.2 Specifications ................................................................................................................................8-2
8.3 Name of part and function .............................................................................................................8-4
8.4 Characteristic of I/O conversion ....................................................................................................8-5
8.5 Accuracy ........................................................................................................................................8-7
8.6 Functions of Analog Input Option Board .......................................................................................8-8
8.7 Wiring ..........................................................................................................................................8-11
8.8 Operation Parameter Setting ......................................................................................................8-13
8.9 Special Module Monitoring Functions .........................................................................................8-16
8.10 Register U devices ....................................................................................................................8-20
8.11 Configuration and Function of Internal Memory ........................................................................8-25
8.12 Example Program ......................................................................................................................8-33
8.13 Troubleshooting .........................................................................................................................8-35

Chapter 9 Analog Output Option Board (XBO-DA02A)..............................9-1~9-31
9.1 Setting Sequence before Operation................................................................................................9-1
9.2 Specifications ................................................................................................................................9-2
9.3 Name of part and function .............................................................................................................9-4
9.4 Characteristic of I/O conversion ....................................................................................................9-5
9.5 Accuracy ........................................................................................................................................9-7
9.6 Functions of Analog Output Option Board ....................................................................................9-8
9.7 Wiring ..........................................................................................................................................9-10
9.8 Operation Parameter Setting ......................................................................................................9-11
9.9 Special Module Monitoring Functions .........................................................................................9-13
9.10 Register U devices ....................................................................................................................9-16
9.11 Internal memory..........................................................................................................................9-21
9.12 Example Program ......................................................................................................................9-29
9.13 Troubleshooting .........................................................................................................................9-31
Chapter 10 Analog I/O Option Board (XBO-AH02A)...............................10-1~10-44
10.1 Setting Sequence before Operation............................................................................................10-1
10.2 Specifications ............................................................................................................................10-2
10.3 Name of part and function .........................................................................................................10-5
10.4 Characteristic of I/O conversion ................................................................................................10-6
10.5 Accuracy ..................................................................................................................................10-10
10.6 Functions of Analog Output Option Board ..............................................................................10-12
10.7 Wiring ......................................................................................................................................10-16
10.8 Operation Parameter Setting ..................................................................................................10-20
10.9 Special Module Monitoring Functions .....................................................................................10-22
10.10 Register U devices ................................................................................................................10-26
10.11 Configuration and Function of Internal Memory......................................................................10-31
10.12 Example Program ..................................................................................................................10-41
10.13 Troubleshooting .....................................................................................................................10-43
Chapter 11 RTD Input Option Board (XBO-RD01A)................................11-1~11-27
11.1 Setting Sequence before Operation............................................................................................11-1
11.2 Specifications ............................................................................................................................11-2
11.3 Name of part and function .........................................................................................................11-4
11.4 Temperature Conversion Characteristic.....................................................................................11-5
11.5 Conversion Speed.......................................................................................................................11-6
11.6 Accuracy ....................................................................................................................................11-6

11.7 Temperature Display...................................................................................................................11-6
11.8 Disconnection Detection Function .............................................................................................11-7
11.9 Wiring ........................................................................................................................................11-8
11.10 Average Function ..................................................................................................................11-10
11.11 Operation Parameter Setting ................................................................................................11-11
11.12 Special Module Monitoring Functions ...................................................................................11-14
11.13 Register U devices ................................................................................................................11-17
11.14 Configuration and Function of Internal Memory......................................................................11-20
11.15 Example Program ..................................................................................................................11-25
11.16 Troubleshooting .....................................................................................................................11-27
Chapter 12 Thermocouple Input Option Module (XBF-TC02A) .............12-1~12-35
12.1 Setting Sequence before Operation............................................................................................12-1
12.2 Specifications ............................................................................................................................12-2
12.3 Name of Part and Function .......................................................................................................12-4
12.4 Characteristic of Thermocouple Temperature Conversion.........................................................12-5
12.5 Accuracy ....................................................................................................................................12-6
12.6 Conversion Speed.......................................................................................................................12-7
12.7 Function ......................................................................................................................................12-8
12.8 Installation and Wiring...............................................................................................................12-10
12.9 Operation Setting and Monitor ..................................................................................................12-12
12.10 Configuration and Function of Internal Memory......................................................................12-24
12.11 Example Program ..................................................................................................................12-31
12.12 Troubleshooting .....................................................................................................................12-34
Chapter 13 Analog Input Module (XBF-AD04C)......................................13-1~13-47
13.1 Setting Sequence before Operation............................................................................................13-1
13.2 Specifications ............................................................................................................................13-2
13.3 Name of each Part and Functions ..............................................................................................13-5
13.4 Characteristic of I/O Conversion.................................................................................................13-6
13.5 Accuracy .....................................................................................................................................13-8
13.6 Functions of Analog Input Module ..............................................................................................13-9
13.7 Installation and Separation of Module.......................................................................................13-16
13.8 Operation Parameter Setting ....................................................................................................13-22
13.9 Special Module Monitoring Functions.......................................................................................13-25
13.10 Register U Devices .................................................................................................................13-29
13.11 Configuration and Function of Internal Memory......................................................................13-36
13.12 Example Program ...................................................................................................................13-43

13.13 Breakdown Test......................................................................................................................13-45
Chapter 14 Analog Output Module (XBF-DV04C/XBF-DC04C)..............14-1~14-41
14.1 Setting Sequence before Operation............................................................................................14-1
14.2 Specifications..............................................................................................................................14-2
14.3 Name of each Part and Functions ..............................................................................................14-5
14.4 Conversion Characteristic of each Output Range ......................................................................14-6
14.5 Accuracy .....................................................................................................................................14-9
14.6 Functions of Analog Output Module..........................................................................................14-10
14.7 Installation and Wiring...............................................................................................................14-14
14.8 Operation Parameter Setting ....................................................................................................14-18
14.9 Special Module Monitoring Functions.......................................................................................14-21
14.10 Register U Devices .................................................................................................................14-24
14.11 Internal Memory......................................................................................................................14-28
14.12 Example Program ...................................................................................................................14-36
14.13 Breakdown Test......................................................................................................................14-39
Chapter 15 PID Function (Built-in function)............................................15-1~15-55
15.1 General ......................................................................................................................................15-1
15.2 PID Control ................................................................................................................................15-3
15.3 PID Instructions ..........................................................................................................................15-27
15.4 PID Auto-tuning .......................................................................................................................15-33
15.5 Example Programs ..................................................................................................................15-42
15.6 Error/Warning Codes ...............................................................................................................15-54
Appendix.........................................................................................................App.1-3
Appendix 1 Standard Resistor of Pt RTD .................................................................................... App.1-1
Appendix 2 Thermo Electromotive Force and Compensating Cable .......................................... App.2-1
Appendix 3 Dimension..................................................................................................................App.3-1

Chapter 1 General
1 - 1
Chapter 1 General
Here describes about analog module and built-in PID function of XGB series.
1.1 Analog Product List
Classification
Name
No. of
channel
Range
Resolution
Characteristic
Voltage/
Current input
XBF-AD04A
4
0 ~ 10V
2.5 ㎷
1.Range selection by external switch and
parameter setting
2. External DC24V used
0 ~ 20 ㎃
4㎃~20㎃
5.0 ㎂
XBF-AD04C
4
1 ~ 5V
0.250㎷
1.Range selection by external switch and
parameter setting
2 Function of. Filter, Average,
Detection disconnection, Alarm,
Retaining Valid conversion value
3. External DC24V used
0 ~ 5V
0.3125㎷
0 ~ 10V
0.625㎷
±10V
1.250㎷
4 ~ 20㎃
1.0㎂
0 ~ 20㎃
1.25㎂
XBF-AD08A
8
4~20㎃
0~20㎃
5.0 ㎂
1.Range selection by external switch and
parameter setting
2. Filter function, average function
3. External DC24V used
1~5V
0~5V
1.25 ㎷
0~10V
2.5 ㎷
Voltage output
XBF-DV04A
4
0 ~ 10V
2.5 ㎷
1. External DC24V used
2. Designates output in case of Error and
CPU STOP
3. Interpolation function (Linear, S-type)
XBF-DV04C
4
1 ~ 5V
0.250㎷
0 ~ 5V
0.3125㎷
0 ~ 10V
0.625㎷
±10V
1.250㎷
Current output
XBF-DC04A
4
0 ~ 20㎃
4㎃~20㎃
5.0 ㎂
1. External DC24V used
2. Designates output in case of Error and
CPU STOP
XBF-DC04B
4
0 ~ 1.2㎃
0.3㎂
XBF-DC04C
4
4~20㎃
1.0㎂
1. 1. External DC24V used
2. Designates output in case of Error and
CPU STOP
3. Interpolation Function(Linear, S-type)
4. Detection disconnection
0 ~ 20㎃
1.25㎂
RTD input
XBF-RD04A
4
PT100
JPT100
0.1℃
1. External DC24V used
2. Filter function
XBF-RD01A
1
Thermocouple
Input module
XBF-TC04S
4
K / J / T / R
Note1)
1. External DC24V used
2. Filter function, average function
XBF-TC04B
Note1) for more detail on thermocouple input module resolution, refer to Ch.5.2.6 accuracy/resolution.

XGB Analog edition manual
1 - 2
Classification
Name
No. of
channel
Range
Resolution
Characteristic
Analog combo
(voltage/current
I/O)
XBF-AH04A
2(Input)
2(Output)
4~20㎃
0~20㎃
5.0 ㎂
1.Range selection by external switch
and parameter setting
2.Filter function, averaging function
3.Specifies output when error or CPU
STOP
4. Uses external DC24V
1~5V
0~5V
1.25 ㎷
0~10V
2.5 ㎷
Analog Input
Option Board
XBO-AD02A
2
4~20㎃
6.25 ㎂
1. Parameter setting
2. Filter function, average function
3. Internal VDD 5V
0~20㎃
5.0 ㎂
Analog Output
Option Board
XBO-DA02A
2
0~10V
2.5 ㎷
Analog IO
Option Board
XBO-AH02A
1(Input)
4~20㎃
6.25 ㎂
1. Parameter setting
2. Filter function, average function
3. Internal VDD 5V
0~20㎃
5.0 ㎂
1(Output)
0~10V
2.5 ㎷
RTD Input
Option Board
XBO-RD01A
1
PT100
JPT100
0.1℃
1. Internal VDD 5V
2. Filter function, average function
Thermocouple
Input Option
Board
XBO-TC02A
2
K / J
Note2)
1. Internal VDD 5V
2. Filter function, average function
Note2) for more detail on Thermocouple Input Option Board resolution, refer to Ch.12.5 accuracy

Chapter 1 General
1 - 3
Here describes about specification of analog module of XGB series.
1.2.1 Analog input
Item
XBF-AD04A
Analog input
range
Type
Voltage
Current
Range
DC 0 ~ 10V
(Input resistance: 1 MΩ min.)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Input resistance: 250 Ω)
Digital output
Type
12 bit binary data
Range
Unsigned
value
0 ~ 4000
Signed value
-2000 ~ 2000
Precise value
0 ~ 1000
400 ~ 2000/0 ~ 2000
Percentile
value
0 ~ 1000
Max. resolution
2.5㎷(1/4000)
5㎂(1/4000)
Accuracy
± 0.5% or less
Max. conversion speed
1.5ms/channel
Absolute max. input
DC ±15V
DC +25㎃
No. of output channel
4 channels
Insulation method
Photo-coupler insulation between input terminal and PLC power
(No insulation between channels)
Connection Terminal
11 point terminal block
I/O points occupied
Fixed type: 64 points
Max. number of equipment
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Consumption
current
Inner (DC 5V)
120㎃
External (DC 24V)
62㎃
Weight
64g
Additional function
Filter-processing, average-processing (time, count)
1.2 Specification of Analog Module
