Maha Msd series User manual

Fehler! Verwenden Sie die Registerkarte 'Start', um Name dem Text zuzuweisen, der hier angezeigt werden soll.Fehler! Verwenden Sie

die Registerkarte 'Start', um Name dem Text zuzuweisen, der hier angezeigt werden soll.Fehler! Verwenden Sie die Registerkarte

'Start', um Name dem Text zuzuweisen, der hier angezeigt werden soll.

MSD 3000

Shock Tester

Original Operating Instructions

BA031701-en

Pos: 1 /-----Fo rmat-----/MANUE LLER UMBRUCH Seitenumbruch@ 0\mod_1134403577687_0.do cx @ 1277@ @ 1

BA031701-en

Pos: 2 /-----Fo rmat-----/Inhaltsve rzeichnis- 3 Ebenen @ 5\mod_116886744 1046_75.do cx @ 729 20 @ @ 1

Contents

Safety ....................................................................................................................3

1.1 Introduction..............................................................................................................3

1.2 Symbols...................................................................................................................3

1.3 Intended Use ...........................................................................................................3

1.4 Safety Instructions....................................................................................................3

1.5 What to Do in the Event of an Accident ....................................................................4

Specifications.........................................................................................................5

Operation...............................................................................................................7

3.1 Important Information...............................................................................................7

3.2 Button Assignment...................................................................................................7

3.3 Test Procedure ........................................................................................................8

3.4 Limit Values..............................................................................................................9

3.4.1 Interpretation of Results ...........................................................................................9

3.4.2 Setting the Limit Values ............................................................................................9

3.5 Redisplay of Measurements ...................................................................................10

3.6 Additional Functions...............................................................................................11

3.6.1 Noise Detection......................................................................................................11

3.6.2 Weighing Mode......................................................................................................13

3.7 Operation with IW/MBT LON Brake Testers............................................................14

Maintenance ........................................................................................................16

4.1 Annual Inspection...................................................................................................16

4.2 Maintenance by the Operator .................................................................................16

4.3 Troubleshooting .....................................................................................................16

4.4 Spare Parts............................................................................................................17

Dismantling..........................................................................................................17

Contents of the Declaration of Conformity............................................................. 17

Company Information...........................................................................................18

Pos: 3 /-----Fo rmat-----/MANUE LLER UMBRUCH Seitenumbruch@ 0\mod_1134403577687_0.do cx @ 1277@ @ 1

BA031701-en

Pos: 4/Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1/S/Überschrift1: Sicherheit @ 6\mod_117448239 9906_75.docx @ 76962 @ 1 @ 1

Safety

Pos: 5 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/E/Überschrift 1.1: Einführung @ 6\mod_1174482219 062_75.docx @ 7679 3@ 2 @ 1

1.1

Introduction

Pos: 6 /TechnischeDokumentation/Alle Geräte/Inhalte/Sicherheit/Inhalt: Einführung Sicherheit_12pt @ 25\mod_ 1324455248318_75.docx @ 1138886 @ @ 1

Thoroughly read this manual before operating the equipment and comply with the

instructions. Always display the manual in a conspicuous location.

Personal injury and property damage incurred due to non-compliance with these

safety instructions are not covered by the product liability regulations.

Pos: 7/Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1.1/S/Überschrift1.1: Symbole @ 6\mod_ 1174482270875_75.do cx @ 76865 @ 2@ 1

1.2

Symbols

Pos: 8 /Technische Dokumentation/Alle Geräte/Inhalte/Sicherheit/Inhalt: Symbole Sicherheit_12pt @ 25\mod_132445665089 7_75.docx @ 1139046 @ @ 1

Important safety instructions. Failure to comply with instructions could result in

personal injury or property damage.

Important information.

Pos:9 /Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1.1/B/Überschrift1.1: BestimmungsgemäßerGebrauch @ 6\mod_1176734022203_ 75.docx @ 88746 @ 2@ 1

1.3

Intended Use

Pos: 10 /Technische Dokumentation/Fahrwerksprüftechnik/- Arch iv -/0001 Achsdämpfungs-Prüfstände Alle/Inhalte/Inhalt: Bestimmungsgemäßer Gebrauch Achsdämpfung_12pt @ 29\mod_ 1343905380125_75.doc x@ 163829 0@ @ 1

This equipment is to be used exclusively for the testing of shock absorbers and

suspension systems of motor vehicles. Observe the rated axle load.

The equipment shall not be modified without the express written consent of the

manufacturer. In case of non-compliance the declaration of conformity becomes

void.

Pos: 11 /TechnischeDokumentation/Alle Geräte/Inhalte/Sicherheit/Inhalt: Bestimmungswidriger Gebrauchallg_12pt @ 25\mod_13244550159 38_75.doc x @ 1138843 @ @ 1

Any use other than described is inappropriate.

Pos: 12 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/S/Überschrift 1.1: Sicherheitsvorschriften @ 8\mod_1204545 563175_75.do cx @ 155576 @ 2 @ 1

1.4

Safety Instructions

Pos: 13 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 S icherheitsvo rschriften_12p t @ 29\mod_13439060169 62_75.docx @ 1638344 @ @ 1

•The tester may not be installed in hazardous locations or moist rooms such as

a car wash.

•The tester may only be used for its intended purpose and within its stated per-

formance limits.

•The tester may only be operated by trained personnel.

•Keep the tester and the working area clean.

•The tester must be turned off when not in use.

•No persons are allowed in the danger zone of the tester. Plates in motion are

potentially dangerous!

•Running vehicle engines represent a potential danger of poisoning. The own-

er/operator is responsible for providing sufficient air ventilation.

•Service work may be done by authorized service technicians only.

BA031701-en

•Work on the electrical equipment may be done by certified electricians only.

•Turn off and padlock the main switch before doing any repair, maintenance or

setup work.

Pos: 14 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften1.1/V/Überschrift1.1: Verhalten bei Unfällen@ 19\mod_1267177 245337_75.doc x@ 79 4600 @ 2 @ 1

1.5

What to Do in the Event of an Accident

Pos: 15 /Technische Dokumentation/Alle Geräte/Inhalte/Sicherheit/Inhalt: Verhalten bei Unfällen_12pt @ 34\mod_1381128863 435_75.do cx @ 1837175 @ @ 1

•The injured person is to be removed from the danger area. Find out where

dressing and bandages are kept. Seek first-aid.

•Provide first-aid (stop bleeding, immobilise injured limbs), report the accident

and seal off the accident site.

•Immediately report any accident to your supervisor. Make sure a record is kept

of every occasion first-aid is provided, e.g. in an accident book.

•Remain calm and answer any questions that may arise.

Pos: 16 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 17 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1/T/Überschrift 1: Technische Daten @ 6\mod_1174482473078_ 75.docx @ 76986 @ 1 @ 1

Specifications

Pos: 18 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 TD (Text)_12pt @ 29\mod_1343976500918_ 75.docx @ 1638393 @ @ 1

Track width (min….max.) mm

880…2200

Exciter swing mm

6.5

Exciter frequency Hz

2…10

Measuring range (max.) displacement mm

approx. 70

Indicating accuracy of full scale value %

Axle load, testable kg

2200

Axle load, traversable kg

2500 (standard) / 13000 (option)

Supply voltage V

1 x 230

Frequency Hz

50/60

Fuse protection A

Motor power kW

2 x 1.1

Total weight kg

approx. 650

Tester dimensions (L x W x H) mm

2320 x 800 x 280

Shipping dimensions (L x W x H) mm

2400 x 1000 x 700

Pos: 19 /Technische Dokumentation/AlleGe räte/Inhalte/Info!/Inhalt:Info - Technische Änderungen vorbehalten_12pt @ 26\mod_1324463311 106_75.d ocx @ 1140069 @ @ 1

Specifications are subject to change without notice.

Pos: 20 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 TD (Bild) @ 9\mod_ 1212668484827_0.doc x @ 216725 @ @ 1

BA031701-en

Pos: 21 /-----Fo rmat-----/MANUELLER UMBRUCH Se itenumbruch @ 0\mod_1134403577687_ 0.docx @ 1277 @ @ 1

BA031701-en

Pos: 22 /Technische Dokumentation/AlleGe räte/Überschriften/Überschriften1/B/Überschrift 1: Bedienung @ 6\mod_1174482271 218_75.do cx @ 76877 @ 1@ 1

Operation

Pos: 23 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/W/Überschrift 1.1: Wichtige Hinweise @ 6\mod_1182863869 546_75.docx @ 97710 @ 2 @ 1

3.1

Important Information

Pos: 24 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 I nfo - Bedienung_12p t @ 29\mod_1343977259 726_75.docx @ 1638437 @ @ 1

•Operation of this tester is supported by the EUROSYSTEM Software ≥V 7.10.

•The tester shows its highest measuring accuracy at a limit value of

D = 0.1 ± 0.01.

•Fully functional shock absorbers have a somewhat higher deviation

(D = 0.25 ± 0.03) due to their relatively small amplitude.

•If a vehicle is tested several times in a row, the shock absorber fluid heats up

and gets less viscous. This may also affect the shock absorber performance.

•During the test place the gear lever in idle/neutral position, do not press the

clutch pedal and do not apply the service brakes or the parking brake.

•The tester measures the

complete

axle damping rate,

not

the condition of the

shock absorbers.

•The manufacturer is not liable for damage or costs incurred due to faulty evalu-

ation of shock absorbers.

Pos: 25 /Technische Dokumentation/AlleGe räte/Überschriften/Überschriften1.1/B/Überschrift 1.1: Buttonbelegung @ 8\mod_1207572622 335_75.docx @ 181922 @ 2 @ 1

3.2

Button Assignment

Pos: 26 /Technische Dokumentation/Bremsprüftechnik/MBT-SERIES/E10101 EUROSYSTEM Standard/ BA/Inhalt: E101 B uttonbelegu ng@ 26\mod_1326789578845_75. docx @ 1508153@ @ 1

Button

Key

Assignment

F2 Previous page

F3 Next page

F4 Start page (Main menu)

Page ↑One level up

Page ↓One level down

F1 Start help

F12 Start printout

BA031701-en

Button

Key

Assignment

Esc Exit page

Pos: 27 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/P/Überschrift 1.1: Prüfablauf @ 8\mod_ 1200574029101_75.docx @ 140824 @ 2 @ 1

3.3

Test Procedure

Pos: 28 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 P rüfablauf_12pt @ 29\mod_1343978360334_75.d ocx @ 1638525 @ @ 1

1 Drive the vehicle onto the test plates

with the front axle.

The wheels must be positioned

straight in the center of the test

plates and must not be blocked by

an engaged gear or brake.

The tester is activated automatically

once the load on both test plates ex-

ceeds 100kg.

The tester conducts a controlled

measurement from 10…5 Hz. Both

sides are measured simultaneously.

At completion of the measurement

the tester switches off automatically.

The damping rate D is determined

and displayed on the screen.

2 Drive the vehicle onto the test plates

with the rear axle.

The test is repeated in the same way

as for the front axle.

Use <F5> to display the amplitudes ei-

ther in separate diagrams or one on top

of the other in the same diagram.

Pos: 29 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 30 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/G/Überschrift 1.1: Grenzwerte @ 9\mod_121420913479 7_75.docx @ 226224 @ 2@ 1

3.4

Limit Values

Pos: 31 /Technische Dokumentation/AlleGe räte/Überschriften/Überschriften1.1.1/E/Überschrift 1.1.1: Ergebnisbewertung @ 10\mod_122121249 3584_75.doc x@ 242770 @ 3 @ 1

3.4.1

Interpretation of Results

Pos: 32 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/ BA/Inhalt: 0317 E rgebnisbewe rtung_12pt @ 29\mod_ 1343978658177_75.do cx @ 1638569 @ @ 1

1st Measurement

D ≥ 0.13

and

∆D ≤ 29%

0.1 <D< 0.13

and/or

29% < ∆D ≤40%

D ≤ 0.1

and/or

∆D > 40%

Display green yellow red

2nd Measurement

(automatic, single

wheel)



D > 0.1

and

∆D ≤40%

D ≤ 0.1

and/or

∆D > 40%

D > 0.1

and

∆D ≤40%

D ≤ 0.1

and/or

∆D > 40%

Interpretation OK OK Defective OK Defective

Pos: 33 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 I nfo - Dämpfungsgrad Neu-FZG_12pt @ 29\mod_ 1343978782485_75.docx @ 1638613 @ @ 1

Reference value for new vehicles: D = 0.2…0.3

Pos: 34 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1.1/G/Überschrift 1.1.1: Grenzwerte einstellen @ 9\mod_121421399 4282_75.docx @ 226326 @ 3@ 1

3.4.2

Setting the Limit Values

Pos: 35 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 M SD 3000/BA/Inha lt: 0317 Grenzwe rte_12pt @ 29\mod_13439 78855960_75.doc x@ 1638657 @ @ 1

1 From the main menu, switch to the

third level using <Dn>.

2 <F5> System.

3 <2> Settings.

4 <M> Devices Limit values.

The following limit values can be set:

•D defective

•D ok

•Difference D defective

•Difference D ok

Pos: 36 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 37 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/W/Überschrift1.1: Wiederanzeigenvon Messungen@ 9\mod_12130877 83895_75.doc x@ 21719 1 @ 2 @ 1

3.5

Redisplay of Measurements

Pos: 38 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 Wi ederanzeigen_ 12pt @ 29\mod_13439 79450195_75.docx @ 1638701 @ @ 1

1 In the main menu: Menu item <1>

Select vehicle.

2 Mark desired entry and load data

using <F8>.

3 <3> Review measurement values.

4 <M> External equipment.

5 <G> Shock tester.

6 Use <F2> and <F3> to switch be-

tween front and rear axle.

7 Use <F12> to start the printout.

Pos: 39 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 40 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/Z/Überschrift 1.1: Zusätzliche Funktionen @ 9\mod_1213099140290_ 75.docx @ 217293 @ 2 @ 1

3.6

Additional Functions

Pos: 41 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1.1/G /Überschrift 1. 1.1: Ge räuschsuche @ 9 \mod_1213099237088_75. docx @ 217316 @ 3@ 1

3.6.1

Noise Detection

Pos: 42 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 I nfo - Geräuschsuchefreischalten_12pt@ 26\mod_13268029 79229_75.do cx @ 1510511 @ @ 1

The Noise Detection option can be activated via software.

Pos: 43 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 G eräuschsuche a uswählen_12pt @ 26\mod_ 1326803114164_75.do cx@ 1510555 @ @ 1

Selecting Noise Detection

1 From the main menu, switch to the

second level using <Dn>.

2 <F8> Shock absorber.

3 <1> Noise detection.

1 In the main menu, select <7> Test

procedure.

2 <K> Shock tester Noise detection.

Pos: 44 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 G eräuschsuche Mot oren Ein_12pt @ 26\mod_1326803216371_75.d ocx@ 1510669 @ @ 1

Starting the Motors

•Use <F6> or <F7> to start the left- or

right-side motor respectively.

•Use <F5> to switch off both motors.

Pos: 45 /-----Fo rmat-----/ MANUELLER UMBRUCH Se itenumbruch@ 0\mod_ 1134403577687_0.d ocx @ 1277 @ @ 1

BA031701-en

Pos: 46 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 G eräuschsuche F requenz_12pt @ 26\mod_1326803 283152_75.do cx @ 1510713 @ @ 1

Changing the Frequency

•Use <F9> or <F11> to reduce or in-

crease the frequency of the test

plates.

•Use <F10> to determine

one particu-

lar

side to be changed.

Pos: 47 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 G eräuschsuche P unkte_12pt @ 26\mod_13268033389 98_75.docx @ 1510757 @ @ 1

Storing Noise Points

•After setting the frequency the noise

point can be stored using <F8>.

A list with all noise points already

stored appears on the display.

Pos: 48 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 G eräuschsuche A uto-Aus_12pt @ 26\mod_1326803 402239_75.do cx @ 1510801 @ @ 1

Automatic Shutdown

•After a preset operating time, the

tester switches off automatically to

prevent the motors from overheating.

This screen appears for confirmation.

Pos: 49 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 50 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 Geräuschsuche Variablen_12pt @ 29\mod_1343979718657_ 75.docx @ 1638745 @ @ 1

Setting the Installation Variables

Accessing the Installation Variables requires a hardlock.

1 From the main menu, switch to the

third level using <Dn>.

2 <F5> System.

3 <1> LON Service.

4 <F> Installation variables.

The following Noise Detection variables

can be set:

•181 Max. operating time of motors [s]

•182 Min. frequency of test plates [Hz]

•183 Max. frequency of test plates [Hz]

•184 Starting frequency [Hz]

Pos: 51/TechnischeDokumentation/AlleGeräte/Überschriften/Überschriften1.1.1/W/Überschrift1.1.1: Wiege-Modus @ 9\mod_1213099 278854_75.docx @ 217339 @ 3@ 1

3.6.2

Weighing Mode

Pos: 52 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 Wi ege-Modus_12pt @ 26\mo d_1326872330707_75.d ocx @ 1511063 @ @ 1

1 From the main menu, switch to the

second level using <Dn>.

2 <F8> Shock absorber.

3 <2> Shock tester mode.

4 <F9> Weigh only, confirm with <F2>.

The left-side, right-side and overall

axle weights are displayed.

Pos: 53 /Technische Dokumentation/AlleGe räte/Überschriften/Überschriften1.1/B/Überschrift 1.1: Bedienung mit IW/MBT LON-Bremsprüfständen @ 25\mod_1313566583 634_75.docx @ 10309 49 @ 2 @ 1

BA031701-en

3.7

Operation with IW/MBT LON Brake Testers

Pos: 54 /Technische Dokumentation/Bremsprüftechnik/MBT-SERIES/022301 MBTL ON/BA/Inhalt: 0223 Be dienung MSD 3000 (Bilde r)@ 21\mod _1277367161654_0.doc x@ 860633 @ @ 1

Pos: 55 /Technische Dokumentation/Bremsprüftechnik/MBT-SERIES/022301 MBTL ON/BA/Inhalt: 0223 Be dienung MSD 3000 (Text) @ 27\mod_ 1327402629870_75.docx @ 1515105 @ @ 1

Test

1 Drive onto the MSD (A). Weight measurement (B)!

2 Both sides start up simultaneously (C).

3 After measurement completion the pointers move to test value 0 to 0.3 D. If the

test value is above 0.3, the pointers move slightly above 0.3 D.

•The display changes between the unit (D) and the difference (E) in % until the

tester is exited. The differential value is based on the left and right measurement

value.

•If the measurement value of a wheel is under 0.13 D, or if the difference is

> 29%, then an additional single wheel measurement is done of each wheel.

The display flashes during the single wheel measurement (C).

4 Measurement values are automatically stored without remote control.

With 2 additional AN5-Displays the wheel weight is displayed during the meas-

urement procedure, and the measurement value 0…0.3 is displayed after com-

pleted measurement.

B C

D E

BA031701-en

Printing and Re-display of the Measurement Values

(Re-display of the measurement values is

not

possible with the RECO remote

control.)

•The print program is started with F7. Enter Program 1 and confirm with star key

(*). Printout follows.

•Re-display of the shock absorber with Shift + Axle number + key F10.

If AN5 displays are present, press the F10 key again to switch to the wheel

weight.

•Re-display of the side-slip tester with Shift + Axle number + key F9 if available.

•New vehicle (NEW) with pound key # and star key * (Delete all measurement

values).

Pos: 56 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 57 /Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1/I/Überschrift1: Instandhaltung@ 28\mod_1332159812536_ 75.docx @ 1565908 @ 1 @1

Maintenance

Pos: 58 /Technische Dokumentation/Alle Geräte/Inhalte/Sicherheit/Inhalt: GEFAHR - Hauptschalter aus bei Instandhaltung_12pt @ 54\mo d_1534925207098_75. docx @ 30819 71 @ @ 1

DANGER

Risk of death or severe personal injury by electric shock

Before doing any maintenance work, turn off the main switch and protect it

against tampering.

Pos: 59 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/J/Überschrift 1.1: Jährliche Überprüfung @ 28\mod_1332230089 694_75.docx @ 1566204 @ 2 @ 1

4.1

Annual Inspection

Pos: 60 /Technische Dokumentation/AlleGe räte/Inhalte/Info!/Inhalt:Info - Jährliche Überp rüfung_12pt @ 25\mod_ 1324460481075_75.d ocx @ 1139 412 @ @ 1

•The maintenance interval prescribed by the manufacturer is

12 (twelve) months

This maintenance interval refers to normal workshop usage. If the equipment is

used more frequently or under severe operating conditions (e.g. outdoors), the

interval must be reduced accordingly.

•Maintenance work shall be done only by authorized and trained service techni-

cians provided by the manufacturer, licensed dealers or service partners.

•In case of non-compliance the manufacturer's warranty becomes void.

Pos: 61 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften 1.1/I/Überschrift 1.1: Instandhaltung durch de n Betreiber @ 28\mod_ 1332231100716_75.do cx @ 1566248 @ 2 @ 1

4.2

Maintenance by the Operator

Pos: 62 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 I nstandhaltung _12pt @ 29\mod_13439 80312686_75.doc x @ 1638789 @ @ 1

Perform the following maintenance work every 200 operating hours or once

annually:

•Clean and lubricate the tester.

•Check the fastening screws for tight fit.

•Visually check for: •correct screening of LON network

•functionality of oscillating plate

•corrosion

•damaged cables

•safe PE connection

Pos: 63 /Technische Dokumentation/Alle Geräte/Überschriften/Überschriften1.1/F/Überschrift1.1: Fehlerbehebung@ 8\mod_120671464674 8_75.docx @ 179620 @ 2@ 1

4.3

Troubleshooting

Pos: 64 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 F ehlerbehebung_ 12pt @ 29\mod_13439 80407332_75.docx @ 1638833 @ @ 1

Error Diagnosis Remedy

Tester does not start up. Tester was already occu-

pied when switched on.

Main switch off, remove

vehicle, main switch on.

Pos: 65 /-----Fo rmat-----/ MANUELLER UMBRUCH Se itenumbruch@ 0\mod_ 1134403577687_0.d ocx @ 1277 @ @ 1

BA031701-en

Pos: 66/Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1.1/E/Überschrift1.1:Ersatzteile @ 18\mod_1255596847002_ 75.docx @ 474414 @ 2@ 1

4.4

Spare Parts

Pos: 67 /Technische Dokumentation/Alle Geräte/Inhalte/Inhalt: Ersatzteile - AlleG eräte_12pt@ 26\mod_1324468768120_ 75.docx @ 1141219 @ @ 1

To ensure safe and reliable operation, only use original spare parts supplied by the

equipment manufacturer.

Pos: 68 /Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1/D/Überschrift1: Demontage @ 19\mod_1266336822863_75. docx @ 742452 @ 1@ 1

Dismantling

Pos: 69 /Technische Dokumentation/Alle Geräte/Inhalte/Inhalt: Demontage - Alle Geräte_12pt@ 26\mod_13244660782 29_75.docx @ 1140857 @ @ 1

Decommissioning and dismantling of the equipment may be done only by

specially authorized and trained personnel provided by the manufacturer, licensed

dealers or service partners.

Pos: 70/Technische Dokumentation/AlleGeräte/Überschriften/Überschriften1/I/Überschrift 1: I nhalt der Konformitätserklärung @ 22\mod_ 1292856748432_75.do cx @9 58616 @ 1 @ 1

Contents of the Declaration of Conformity

Pos: 71 /Technische Dokumentation/Alle Geräte/Inhalte/Inhalt: Inhalt der Konformitätserklärung allg_12pt @ 26\mo d_1324468436145_75.do cx@ 1141120 @ @ 1

MAHA Maschinenbau Haldenwang GmbH & Co. KG

herewith declares as a manufacturer its sole responsibility to ensure that the

product named hereafter meets the safety and health regulations both in design

and construction required by the EC directives stated below.

This declaration becomes void if any change is made to the product that was not

discussed and approved by named company beforehand.

Pos: 72 /Technische Dokumentation/Fahrwerksprüftechnik/MSD-SERIES/031701 MSD 3000/BA/Inhalt: 0317 I nhalt der Ko nformitätserklä rung_12pt @ 55\mod_15474674 82996_75.do cx @ 3111679 @ @ 1

Model:

MSD 3000

Designation:

Shock Tester; Rated Axle Load 2500 kg

Directives:

2006/42/EC; 2014/30/EU

Standards:

EN 12100-1/-2; EN 60204-1, EN 61000-6-3, EN 61000-6-2

Pos: 73 /-----Fo rmat-----/MA NUELLER UMBRUCH Seitenumbruch @ 0\mod_113440357768 7_0.docx @ 1277 @ @ 1

BA031701-en

Pos: 74 /Techn ische Dokumentation/Alle Geräte/Überschriften/Überschriften 1/F/Überschrift 1: Firmen-Information @ 7\mod_1187338 625828_75.docx @ 104047 @ 1 @ 1
