FDML
Multi blade fire damper
Technical Documentation
Installation, Commissioning, Operation, Maintenance and Service Manual
TPM 130/17
Version 2023-10-31

Fire damper - FDMLPage 2 Version 2023-10-31
TPM 130/17
These technical specifications state a row of manufactured sizes and models of fire dampers FDML
It is valid for production, designing, ordering, delivery, maintenance and operation.
CONTENT
I. GENERAL.....................................................................................................................................................................................3
Description..............................................................................................................................................................................3
II. DESIGN.......................................................................................................................................................................................4
Design with manual control....................................................................................................................................................4
III. DIMENSIONS...........................................................................................................................................................................11
Technical parameters............................................................................................................................................................12
IV. INSTALLATION........................................................................................................................................................................16
Placement and installation...................................................................................................................................................16
Statement of installations.....................................................................................................................................................17
In solid wall construction...................................................................................................................................................18
In gypsum wall construction..............................................................................................................................................20
In solid ceiling construction...............................................................................................................................................22
Examples of installation situations....................................................................................................................................23
Examples of fixing FDML....................................................................................................................................................24
Example of duct connection..............................................................................................................................................27
V. TECHNICAL DATA.....................................................................................................................................................................28
Pressure loss.........................................................................................................................................................................28
VI. MATERIAL, FINISHING.............................................................................................................................................................30
VII. TRANSPORTATION, STORAGE AND WARRANTY....................................................................................................................30
Logistic terms........................................................................................................................................................................30
Warranty...............................................................................................................................................................................31
VIII. ASSEMBLY, ATTENDANCE AND MAINTENANCE....................................................................................................................31
Commissioning and revisions................................................................................................................................................32
IX. ORDERING INFORMATIONS....................................................................................................................................................33
Ordering key.........................................................................................................................................................................33
Data label..............................................................................................................................................................................33

Page 3Version 2023-10-31 Fire damper - FDML
TPM 130/17
I. GENERAL
Working conditions
■Exact damper function is provided under the following conditions:
■maximum air velocity 12 m/s
■maximum pressure difference 1500 Pa
■Even distribution of air flow in complete damper cross section area
■Damper operating characteristics are independent on airflow direction through the damper. The damper can be installed
with blade axis vertically or horizontally, temperature sensor (BAT) must always be in damper upper part.
■Dampers are suitable for systems without abrasive, chemical and adhesive particles.
■Dampers are designed for macroclimatic areas with mild climate according to EN IEC 60 721-3-3 ed.2., class 3K22.
(Environment 3K22 is typically protected place with regulated temperature).
■Temperature in the place of installation is permitted to range from -30°C to +50°C.
■Optical smoke detector ORS 142K with socket 143A is intended for environments protected from weathering of categories
3K5/3Z1/3Z8/3B1/3C2/3S1/3M2 within temperature scope -25°C to +70°C, max. relative humidity 95% at 40°C, without
condensing, icing and ice formation according to EN 60 721-3-3 amend.A2.
■If the damper is used for self-ventilation it must be equipped with cover grilles from both sides.
Description
Fire dampers are shutters in ducts of air-conditioning devices
that prevent the spread of fire and combustion products from
one fire segment to the other one. FDML multi blade fire
dampers are in motorised design only with actuator and they
have the following two main applications:
For use as a fire shutter without following air duct with cover
grilles for closing ventilation openings in fire separating walls,
constructions, elevator and other shafts, cable and other
ducts, preventing the spread of heat and combustion
products.
For use as a multi blade fire damper with following air duct on
both sides (without cover grilles) or with duct on one side
(with one cover grille), preventing the spread of heat and
combustion products through this duct system.
Damper blades automatically closes air duct using a spring
return actuator. The return spring of the actuator is actuated
when a thermoelectric activation device BAT is activated,
when a test button on BAT is pressed or when power supply
of the actuator is interrupted.
After closing blades, the damper is sealed with silicon against
smoke penetration. On request by customer, the damper can
be supplied silicon-free. In the closed position, the damper is
also sealed with material which increases its volume due to
increasing temperature and air proofs the air duct.
Damper characteristics
■CE certified acc. to EN 15650
■Tested in accordance with EN 1366-2
■Classified acc. to EN 13501-3+A1
■Fire resistance EI 90 S, E 120 S
■Leakage acc. to EN 1751, through the casing class B and
through the damper blades class 3
■Cycling tests in class C10000 acc. to EN 15650
■Corrosion resistant acc. to EN 15650
■Certificate of constancy of performance No. 1391-CPR-2020/0130/O1
■Declaration of Perfomance No. PM/FDML/01/23/1
■Hygienic assessment of fire dampers - Report No. 1.6/pos/19/19b

Fire damper - FDMLPage 4 Version 2023-10-31
TPM 130/17
■Fire dampers are equipped with Belimo spring return
actuators with thermoelectric activation device BAT. The
spring return actuator types are BFL, BFN or BF depending
on the damper size. (Further mentioned as „actuator“).
■After being connected to power supply 230V or AC/DC
24V, the actuator rotates the damper blades to the
operating position "OPEN" and at the same time
prestretches its return spring. When the actuator is power
supplied, the damper blades are in the position "OPEN"
and the return spring is prestretched. Time needed for full
opening of the damper blades from the position "CLOSED"
to the position "OPEN" is maximum 120 sec.
■If the actuator power supply is interrupted (due to loss of
supply voltage, or pressing a test button on the
thermoelectric activation device BAT), the actuator
rotates the damper blades to the breakdown position
"CLOSED". The time of closing the damper blades from the
position "OPEN" to the position "CLOSED" takes maximum
20 sec.
■In case that the power supply is restored again (the blades
can be in any position), the actuator starts to rotate the
damper blades back to the position "OPEN".
■A thermoelectric activation device BAT, which contains
two thermal fuses Tf1 and Tf2, is an integral part of the
actuator.
■These fuses are activated when temperature +72°C has
been reached (the fuse Tf1 due to temperature outside
the duct and the fuse Tf2 due to temperature inside the
duct). The thermoelectric activation device can also be
equipped with a Tf2 thermal fuse type ZBAT 95/120/140
(must be specified in the order). In this case, the activation
temperature inside the duct is +95°C, +120°C or +140°C
(depending on the type).
■After the thermal fuse Tf1 or Tf2 has been activated, the
power supply is permanently and irreversibly interrupted
and the actuator, by means of the pre-stretched spring,
rotate the damper blades into the breakdown position
"CLOSED".
■Signalisation of damper blades position "OPEN" and
"CLOSE" is provided by two microswitches.
Design .40 and .50
Spring return actuator
Thermoelectric
activation device BAT
II. DESIGN
Design with manual control

Page 5Version 2023-10-31 Fire damper - FDML
TPM 130/17
Actuator BELIMO BFL 230-T(-ST)
Actuator BELIMO BFL 24-T(-ST)
BELIMO - 4 N.m
Actuator BELIMO BFL 230-T(-ST), BFL 24-T(-ST)
Actuator BELIMO - 4 Nm/ 3 Nm Spring BFL 230-T(-ST) BFL 24-T(-ST)
Power voltage AC 230 V
50/60Hz
AC/DC 24 V
50/60Hz
Power consumption - in operation
- in rest position
3,5 W
1,1 W
2,5 W
0,8 W
Dimensioning 6,5 VA (Imax 4 A @ 5 ms) 4 VA (Imax 8,3 A @ 5 ms)
Protection class II III
Degree of protection IP 54
Running time - motor
- spring return
< 60 s
~ 20 s
Ambient temperature
- normal duty
- safety duty
- non-operating temperature
-30°C … +55°C
The safe position will be attained up to max. +75°C
-40°C … +55°C
Connection - supply/control
- auxiliary switch
cable 1 m, 2 x 0,75 mm² (BFL 2xx-T-ST) with 3-pin plug-in connectors
cable 1 m, 6 x 0,75 mm² (BFL 2xx-T-ST) with 6-pin plug-in connectors
Response temperature thermal fuse duct outside temperature +72°C
duct inside temperature +72°C
S2S1 S3 S5S4 S6
2
1
<5° <80°
N L1
BAT
Tf Tf LED
S2S1 S3 S5S4 S6
2
1
<5° <80°
BAT
Tf Tf LED

Fire damper - FDMLPage 6 Version 2023-10-31
TPM 130/17
Actuator BELIMO BFN 24-T(-ST)
BELIMO - 9 N.m
Actuator BELIMO BFN 230-T(-ST), BFN 24-T(-ST)
Actuator BELIMO - 9 Nm/ 7 Nm Spring BFN 230-T(-ST) BFN 24-T(-ST)
Power voltage AC 230 V
50/60Hz
AC/DC 24 V
50/60Hz
Power consumption - in operation
- in rest position
5 W
2,1 W
4 W
1,4 W
Dimensioning 10 VA (Imax 4 A @ 5 ms) 6 VA (Imax 8,3 A @ 5 ms)
Protection class II III
Degree of protection IP 54
Running time - motor
- spring return
< 60 s
~ 20 s
Ambient temperature
- normal duty
- safety duty
- non-operating temperature
-30°C … +55°C
The safe position will be attained up to max. +75°C
-40°C … +55°C
Connection - supply/control
- auxiliary switch
cable 1 m, 2 x 0,75 mm² (BFN 2xx-T-ST) with 3-pin plug-in connectors
cable 1 m, 6 x 0,75 mm² (BFN 2xx-T-ST) with 6-pin plug-in connectors
Response temperature thermal fuse duct outside temperature +72°C
duct inside temperature +72°C
Actuator BELIMO BFN 230-T(-ST)
S2S1 S3 S5S4 S6
2
1
<5° <80°
N L1
BAT
Tf Tf LED
S2S1 S3 S5S4 S6
2
1
<5° <80°
BAT
Tf Tf LED

Page 7Version 2023-10-31 Fire damper - FDML
TPM 130/17
Actuator BELIMO BF 230-TN(-ST)
Actuator BELIMO BF 230-TN(-ST), BF 24-TN(-ST)
Actuator BELIMO - 18 Nm/ 12 Nm Spring BF 230-TN(-ST) BF 24-TN(-ST)
Power voltage AC 230 V
50/60Hz
AC/DC 24 V
50/60Hz
Power consumption - in operation
- in rest position
8,5 W
3 W
7 W
2 W
Dimensioning 11 VA (Imax 8,3 A @ 5 ms) 10 VA (Imax 8,3 A @ 5 ms)
Protection class II III
Degree of protection IP 54
Running time - motor
- spring return
120 s
~ 16 s
Ambient temperature
- normal duty
- safety duty
- non-operating temperature
-30°C … +50°C
The safe position will be attained up to max. +75°C
-40°C … +50°C
Connection - supply/control
- auxiliary switch
cable 1 m, 2 x 0,75 mm² (BF 2xx-TN-ST) with 3-pin plug-in connectors
cable 1 m, 6 x 0,75 mm² (BF 2xx-TN-ST) with 6-pin plug-in connectors
Response temperature thermal fuse duct outside temperature +72°C
duct inside temperature +72°C
BELIMO - 18 N.m
Actuator BELIMO BF 24-TN (-ST)
S2S1 S3 S5S4 S6
2
1
<5° <80°
N L1
BAT
Tf Tf LED
S2S1 S3 S5S4 S6
2
1
<5° <80°
BAT
Tf Tf LED

Fire damper - FDMLPage 8 Version 2023-10-31
TPM 130/17
Thermoelectric activation device BAT 72 (95/120/140)
Power voltage AC/DC 24 V
50/60Hz
Rated current 1 A
AC/DC throughput resistance <1 Ω
Protection class III
Degree of protection IP 54
Probe length 65 mm
Ambient temperature
Storage temperature
Ambient humidity
-30°C … +50°C
-40°C … +50°C
Max. 95% RH, non-condensing
Connection supply Cable 1 m, 2 x 0.5 mm², Betaflam cable heatresistant up to 145°C
Response temperature thermal fuse Duct inside temperature +72 (95/120/140)°C
Duct outside temperature +72 (95/120/140)°C
■If the thermal fuse Tf1 is interrupted (due to temperature
outside the duct), it is necessary to replace the spring
return actuator. Thermoelectric activation device BAT is
integral part of the actuator.
■If the thermal fuse Tf2 is interrupted (due to temperature
inside the duct), only the spare part ZBAT 72 (95/120/140)
needs to be replaced (acc.to the activation temperature).
■When one of the thermal fuses responds, the supply
voltage is interrupted permanently and irreversibly.
■The function (interruption of the supply voltage) can be
checked by pressing the test button.
■Installation is carried out with the pre-assembled, self-
tapping screws.
BELIMO ZBAT 72
Black (BK) = 72°C (standard)
BELIMO ZBAT 95
Grey (GY) = 95°C
BELIMO ZBAT 120
Orange (OG) = 120°C
BELIMO ZBAT 140
Red (RD) = 140°C
Thermoelectric activation device BAT

Page 9Version 2023-10-31 Fire damper - FDML
TPM 130/17
■Design .41 or .51 with actuator and smoke detector ORS
142 K. The voltage can be AC 230 V or 24 V DC. Design .41
with voltage AC 230 V is equipped with power supply
device ZNP-10-24 and with actuator BF 24-TN (BFL 24-T,
BFN 24-T).
■The smoke detector is activated when smoke spreads in
air duct system. Deactivation of the smoke detector alarm
status is provided by interruption of supply voltage for
min. 2s.
■Signalisation of damper blades position "OPEN" and
"CLOSE" is provided by two microswitches.
■Optical smoke detectors ORS 142K and power supply unit
ZPN-10-24 are delivered in bulk
Design .41 and .51
Design .41 with actuator BF 24-TN (BFL, BFN 24-T), with smoke detector ORS 142 K and with power supply device ZNP-10-24
(voltage AC 230 V)
Power supply device ZNP-10-24
Supply voltage AC 230 V (50-60Hz)
Power consumption - no-load (max.) 9 VA/2 W
Power consumption - under load (max.) 16 VA/13 W
Output voltage DC 24 V volatile
AC 24 V
Voltage - no-load AC (max.) 32 V
Voltage - no-load DC (max.) 43 V
Degree of protection IP40 front panel / IP20 clamps
Ambient temperature
Storage temperature
-20°C … +40°C
-20°C … +60°C
Dimensions 90 x 52 x 65 mm
Weight 368 g
Design .51 with actuator BF 24-TN (BFL, BFN 24-T), with smoke detector ORS 142 K (voltage 24 V DC)
1
2S2S1 S3 S5S4 S6
24 V DC
2
3
4
5
6
1
BAT
Tf Tf LED
1
2S2S1 S3 S5S4 S6
Tf2
Tf1 Tf3 LED
BAT
2
3
4
5
6
1
AC 230V
L
N
Mean Well
230V AC 24V DC
L
N+
-
LN+-

Fire damper - FDMLPage 10 Version 2023-10-31
TPM 130/17
Optical smoke detector ORS 142 K with the socket 143A
33
Ø 80
33
50
■The smoke detector ORS 142 K is used for early smoke
detection in rooms or inside the ventilation system.
■The sensor operates on the light scatter principle. Inside
the scanning chamber is a light source and a light sensor,
in the normal state the light from the source does not fall
on the senzor. Only when smoke enters the scanning
chamber the light is scattered and falls on the senzor.
■The smoke detector can be connected directly to the
actuator (design .51) or to the ZNP-10-24 power supply
unit (design .41)
■By early detection of smoke, it can be effectively
prevented from spreading of smoke through the
ventilation system. In addition to smoke detection, the
sensor can distinguish and signal slight and heavy
contamination, e.g. the presence of large amounts of dust.
■The ORS 142 K smoke detector has an alarm memory, i.e.
if the alarm is triggered, the safety relay opens and stays
in this state even if the smoke disappears from the
scanning chamber. The sensor remains in the alarm state
until the power supply is briefly reset.
■On the pin 3, an external device can be connected via
RS-Bus communication to report the status of the sensor.
■Pin 6 has no connection to the detector and is designed as
a load-bearing structure in the base.
ORS 142 K
2
3
4
5
6
1
RS-Bus communication
relay contact
relay contact
Optical smoke detector ORS 142 K with the socket 143A
Operating voltage 18 … 28 V DC
Residual ripple ≤ 200 mV
Power Consumption Socket (without actuator) max. 22 mA
Degree of protection IP 42
Ambient temperature -20°C … +75°C
Aditional temperature senzor +70°C
Connection - net
- motor
- power supply device ZNP-10-24
Cabel 1m, connected to terminals 1, 2 and 4
Actuator connected on the terminals 2 and 5
Cabel 1m, connected to terminals 1, 2, 4 and 5
Socket 143A
Relay contact LED
In operation Green Shines
Slight contamination Green / Yellow Flashes
Heavy contamination Green / Yellow
Flashes
Fault Yellow Shines
Alarm Red Shines
Power Off Off –
4
5
4
5
1 ORS 142 K
2 Socket 143A
3Side cable entries Ø 9mm
4Rear cable entries Ø 9mm
5Fixing hole Ø 4,5 mm
6Fixing hole Ø 3,7 mm
Ø 80
33
59,5

Page 11Version 2023-10-31 Fire damper - FDML
TPM 130/17
1 Damper casing
2 Cover grille
3 Damper blade
4 Cable glands
III. DIMENSIONS
164*
150**
30 B
A190 30
30
* Depth with cover grilles
** Depth of a damper casing
Connecting dimensions of nuts M6
B ≤ 400 (without nuts) 400 < B ≤ 600 (one nut) B > 600 (two nuts)
B [mm] R [mm] Q [mm] S [mm] B [mm] R [mm] Q [mm] S [mm]
300 / / / 650 220 230 /
315 / / / 700 240 245 /
355 / / / 710 240 250 /
400 / / / 750 250 265 /
450 / / 240 800 270 280 /
500 / / 265 850 290 295 /
560 / / 295 900 300 315 /
600 / / 315 950 320 330 /
630 210 225 / 1000 340 345 /
15 A15
190
B15
15
15 A15
190
B15
15
15 A15
190
B15
15
S
S
QRQ

Fire damper - FDMLPage 12 Version 2023-10-31
TPM 130/17
Technical parameters
A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua. A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua.
FDML* 1
KMM FDML* 1 KMM
200
x
300 2 15,3 1,0 0,0276
BFL
300
x
300 2 17,2 1,2 0,0444
BFL
315 2 15,9 1,1 0,0284 315 2 17,9 1,2 0,0457
355 3 17,1 1,1 0,0349 355 3 19,2 1,3 0,0562
400 3 18,8 1,2 0,0423 400 3 21,1 1,4 0,0681
450 4 20,8 1,3 0,0440 450 4 23,3 1,5 0,0708
500 4 22,8 1,4 0,0522 500 4 25,5 1,6 0,0840
560 4 25,0 1,5 0,0554 560 4 28,1 1,8 0,0892
600 5 26,1 1,6 0,0620 600 5 29,3 1,9 0,0998
630 5 27,4 1,7 0,0669 630 5 30,6 2,3 0,1077
650 5 28,0 1,7 0,0702 650 5 31,3 2,4 0,1130
700 6 29,7 1,8 0,0718 700 6 33,6 2,5 0,1156
BFN
710 6 30,3 1,8 0,0735 710 6 34,2 2,5 0,1183
750 6 31,9 1,9 0,0800 750 6 35,9 2,6 0,1288
800 6 33,6 2,4 0,0833 800 6 38,0 2,7 0,1341
850 7 35,2 2,5 0,0899 850 7 39,7 2,8 0,1447
900 7 37,4 2,6 0,0981
BFN
900 7 41,8 3,0 0,1579
950 8 38,8 2,7 0,0997 950 8 43,7 3,1 0,1605
1000 8 41,0 2,9 0,1079 1000 8 45,9 3,2 0,1737
250
x
300 2 16,3 1,1 0,0360
BFL
315
x
300 2 17,5 1,2 0,0469
BFL
315 2 16,9 1,2 0,0370 315 2 18,2 1,3 0,0483
355 3 18,1 1,2 0,0456 355 3 19,5 1,4 0,0594
400 3 19,9 1,3 0,0552 400 3 21,4 1,5 0,0720
450 4 22,0 1,4 0,0574 450 4 23,7 1,6 0,0748
500 4 24,2 1,5 0,0681 500 4 25,9 1,7 0,0887
560 4 26,5 1,7 0,0723 560 4 28,5 1,8 0,0943
600 5 27,7 1,7 0,0809 600 5 29,7 2,3 0,1055
630 5 29,0 1,8 0,0873 630 5 31,1 2,3 0,1138
650 5 29,7 1,8 0,0916 650 5 31,8 2,4 0,1194
700 6 31,8 2,3 0,0937
BFN
700 6 34,1 2,5 0,1222
BFN
710 6 32,3 2,4 0,0959 710 6 34,7 2,5 0,1250
750 6 34,0 2,4 0,1044 750 6 36,5 2,6 0,1362
800 6 36,0 2,6 0,1087 800 6 38,6 2,8 0,1417
850 7 37,6 2,7 0,1173 850 7 40,3 2,9 0,1529
900 7 39,6 2,8 0,1280 900 7 42,4 3,0 0,1668
950 8 41,4 2,9 0,1301 950 8 44,4 3,2 0,1696
1000 8 43,4 3,0 0,1408 1000 8 46,6 3,3 0,1836
280
x
300 2 16,8 1,2 0,0410
BFL
355
x
300 2 18,3 1,3 0,0536
BFL
315 2 17,5 1,2 0,0422 315 2 19,0 1,3 0,0552
355 3 18,7 1,3 0,0520 355 3 20,3 1,4 0,0679
400 3 20,6 1,4 0,0630 400 3 22,3 1,5 0,0823
450 4 22,8 1,5 0,0654 450 4 24,7 1,6 0,0855
500 4 25,0 1,6 0,0776 500 4 27,0 1,8 0,1014
560 4 27,5 1,7 0,0825 560 4 29,8 2,3 0,1078
600 5 28,6 1,8 0,0922 600 5 31,3 2,4 0,1206
BFN
630 5 30,0 1,9 0,0996 630 5 32,7 2,5 0,1302
650 5 30,7 2,3 0,1044 650 5 33,5 2,5 0,1365
700 6 32,9 2,4 0,1069
BFN
700 6 35,6 2,6 0,1397
710 6 33,4 2,4 0,1093 710 6 36,1 2,7 0,1429
750 6 35,2 2,5 0,1191 750 6 38,0 2,8 0,1557
800 6 37,2 2,7 0,1240 800 6 40,2 2,9 0,1621
850 7 38,8 2,8 0,1337 850 7 42,0 3,0 0,1748
900 7 40,9 2,9 0,1459 900 7 44,2 3,2 0,1908
950 8 42,8 3,0 0,1484 950 8 46,3 3,3 0,1940
1000 8 44,9 3,1 0,1606 1000 8 48,5 3,4 0,2099
* For design with ZNP-10-24 power supply, a weight of 0,4 kg must be added.

Page 13Version 2023-10-31 Fire damper - FDML
TPM 130/17
A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua. A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua.
FDML* 1
KMM FDML* 1 KMM
400
x
300 2 19,1 1,4 0,0612
BFL
560
x
300 2 22,2 1,7 0,0880 BFL
315 2 19,9 1,4 0,0630 315 2 23,1 1,7 0,0907
355 3 21,2 1,5 0,0775 355 3 24,8 1,8 0,1116
BFN
400 3 23,3 1,6 0,0939 400 3 27,2 2,3 0,1352
450 4 25,8 1,7 0,0976 450 4 30,0 2,5 0,1404
500 4 28,2 1,9 0,1158 500 4 32,8 2,6 0,1666
560 4 31,1 2,4 0,1230 560 4 36,3 2,8 0,1771
600 5 32,7 2,5 0,1376
BFN
600 5 37,7 2,9 0,1981
630 5 34,2 2,6 0,1485 630 5 39,4 3,0 0,2138
650 5 35,0 2,6 0,1558 650 5 40,3 3,1 0,2243
700 6 37,2 2,8 0,1594 700 6 42,9 3,3 0,2295
710 6 37,8 2,8 0,1631 710 6 43,5 3,3 0,2348
750 6 39,7 2,9 0,1776 750 6 45,7 3,4 0,2557
800 6 42,1 3,0 0,1849 800 6 48,6 3,6 0,2662
850 7 43,9 3,2 0,1995 850 7 52,3 3,7 0,2872
BF
900 7 46,2 3,3 0,2177 900 7 54,9 3,9 0,3134
950 8 48,4 3,5 0,2213 950 8 57,5 4,0 0,3186
1000 8 50,7 3,6 0,2395 1000 8 60,1 4,2 0,3448
450
x
300 2 20,1 1,5 0,0696
BFL
600
x
300 2 22,9 1,7 0,0948 BFL
315 2 20,9 1,5 0,0716 315 2 23,9 1,8 0,0976
355 3 22,2 1,6 0,0882 355 3 25,6 1,9 0,1201
BFN
400 3 24,7 1,7 0,1068
BFN
400 3 28,1 2,4 0,1455
450 4 27,3 1,8 0,1110 450 4 31,0 2,6 0,1512
500 4 29,8 2,4 0,1317 500 4 33,8 2,7 0,1794
560 4 33,0 2,5 0,1399 560 4 37,6 2,9 0,1906
600 5 34,2 2,6 0,1565 600 5 38,9 3,1 0,2132
630 5 35,8 2,7 0,1689 630 5 40,7 3,1 0,2301
650 5 36,6 2,8 0,1772 650 5 41,6 3,2 0,2414
700 6 39,0 2,9 0,1813 700 6 44,3 3,4 0,2470
710 6 39,6 3,0 0,1855 710 6 45,0 3,4 0,2527
750 6 41,6 3,1 0,2020 750 6 47,2 3,5 0,2752
800 6 44,1 3,2 0,2103 800 6 50,2 3,7 0,2865
850 7 46,0 3,3 0,2269 850 7 53,9 3,8 0,3091
BF
900 7 48,4 3,5 0,2476 900 7 56,6 4,0 0,3373
950 8 50,7 3,6 0,2517 950 8 59,3 4,2 0,3429
1000 8 53,2 3,8 0,2724 1000 8 62,1 4,3 0,3711
500
x
300 2 21,0 1,6 0,0780
BFL
630
x
300 2 23,5 1,8 0,0998 BFL
315 2 21,9 1,6 0,0803 315 2 24,5 1,8 0,1028
355 3 23,3 1,7 0,0988 355 3 26,2 1,9 0,1265
BFN
400 3 25,9 1,8 0,1197
BFN
400 3 28,7 2,5 0,1533
450 4 28,5 2,3 0,1244 450 4 31,8 2,6 0,1592
500 4 31,2 2,5 0,1476 500 4 34,6 2,8 0,1889
560 4 34,5 2,7 0,1568 560 4 38,5 3,0 0,2008
600 5 35,8 2,8 0,1754 600 5 39,9 3,1 0,2245
630 5 37,4 2,9 0,1893 630 5 41,6 3,2 0,2424
650 5 38,3 2,9 0,1986 650 5 42,6 3,3 0,2542
700 6 40,7 3,1 0,2032 700 6 45,4 3,5 0,2602
710 6 41,4 3,1 0,2079 710 6 46,1 3,5 0,2661
750 6 43,5 3,2 0,2264 750 6 48,4 3,6 0,2899
800 6 46,2 3,4 0,2357 800 6 51,5 3,8 0,3018
850 7 48,1 3,5 0,2543 850 7 55,2 3,9 0,3255
BF
900 7 50,6 3,7 0,2775 900 7 58,0 4,1 0,3552
950 8 54,7 3,8 0,2821 BF 950 8 60,7 4,3 0,3612
1000 8 57,2 4,0 0,3053 1000 8 63,5 4,4 0,3909
* For design with ZNP-10-24 power supply, a weight of 0,4 kg must be added.

Fire damper - FDMLPage 14 Version 2023-10-31
TPM 130/17
A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua. A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua.
FDML* 1
KMM FDML* 1 KMM
650
x
300 2 23,9 1,8 0,1032 BFL
750
x
300 2 25,8 2,0 0,1200 BFL
315 2 24,9 1,9 0,1062 315 2 26,9 2,0 0,1235
355 3 26,6 2,0 0,1308
BFN
355 3 28,7 2,6 0,1521
BFN
400 3 29,2 2,5 0,1584 400 3 31,4 2,8 0,1842
450 4 32,3 2,7 0,1646 450 4 34,8 2,9 0,1914
500 4 35,2 2,9 0,1953 500 4 37,9 3,1 0,2271
560 4 39,1 3,1 0,2075 560 4 42,2 3,3 0,2413
600 5 40,5 3,2 0,2321 600 5 43,6 3,5 0,2699
630 5 42,3 3,3 0,2505 630 5 45,5 3,6 0,2913
650 5 43,3 3,4 0,2628 650 5 46,6 3,6 0,3056
700 6 47,7 3,5 0,2689
BF
700 6 51,3 3,8 0,3127
BF
710 6 48,4 3,6 0,2751 710 6 52,0 3,9 0,3199
750 6 50,7 3,7 0,2996 750 6 54,5 4,0 0,3484
800 6 53,9 3,8 0,3119 800 6 58,0 4,2 0,3627
850 7 56,1 4,0 0,3365 850 7 60,3 4,3 0,3913
900 7 58,9 4,2 0,3672 900 7 63,3 4,5 0,4270
950 8 61,7 4,3 0,3733 950 8 66,3 4,7 0,4341
1000 8 64,5 4,5 0,4040 1000 8 69,3 4,9 0,4698
700
x
300 2 24,8 1,9 0,1116 BFL
800
x
300 2 26,8 2,1 0,1284 BFL
315 2 25,9 1,9 0,1149 315 2 27,9 2,6 0,1322
355 3 27,7 2,5 0,1414
BFN
355 3 29,7 2,7 0,1627
BFN
400 3 30,3 2,6 0,1713 400 3 32,6 2,8 0,1971
450 4 33,5 2,8 0,1780 450 4 36,0 3,0 0,2048
500 4 36,5 3,0 0,2112 500 4 39,2 3,2 0,2430
560 4 40,6 3,2 0,2244 560 4 43,7 3,5 0,2582
600 5 42,0 3,3 0,2510 600 5 46,8 3,6 0,2888
BF
630 5 43,9 3,4 0,2709 630 5 48,8 3,7 0,3117
650 5 44,9 3,5 0,2842 650 5 49,9 3,8 0,3270
700 6 49,5 3,7 0,2908
BF
700 6 53,1 4,0 0,3346
710 6 50,2 3,7 0,2975 710 6 53,8 4,0 0,3423
750 6 52,6 3,8 0,3240 750 6 56,4 4,1 0,3728
800 6 56,0 4,0 0,3373 800 6 60,0 4,3 0,3881
850 7 58,2 4,2 0,3639 850 7 62,4 4,5 0,4187
900 7 61,1 4,4 0,3971 900 7 65,5 4,7 0,4569
950 8 64,0 4,5 0,4037 950 8 68,6 4,9 0,4645
1000 8 66,9 4,7 0,4369 1000 8 71,8 5,1 0,5027
710
x
300 2 25,0 1,9 0,1132 BFL
850
x
300 2 28,0 2,6 0,1368
BFN
315 2 26,1 2,0 0,1166 315 2 29,2 2,7 0,1408
355 3 27,9 2,5 0,1436
BFN
355 3 30,8 2,8 0,1734
400 3 30,5 2,7 0,1739 400 3 33,7 3,0 0,2100
450 4 33,8 2,8 0,1806 450 4 37,2 3,2 0,2182
500 4 36,8 3,0 0,2143 500 4 40,6 3,4 0,2589
560 4 40,9 3,2 0,2278 560 4 45,2 3,6 0,2751
600 5 42,4 3,4 0,2548 600 5 48,4 3,7 0,3077
BF
630 5 44,2 3,5 0,2750 630 5 50,4 3,8 0,3321
650 5 45,3 3,5 0,2885 650 5 51,6 3,9 0,3484
700 6 49,9 3,7 0,2952
BF
700 6 54,9 4,1 0,3565
710 6 50,6 3,7 0,3020 710 6 55,6 4,1 0,3647
750 6 53,0 3,9 0,3289 750 6 58,3 4,3 0,3972
800 6 56,4 4,0 0,3424 800 6 62,1 4,5 0,4135
850 7 58,6 4,2 0,3694 850 7 64,5 4,7 0,4461
900 7 61,5 4,4 0,4031 900 7 67,7 4,9 0,4868
950 8 64,5 4,6 0,4098 950 8 71,0 5,1 0,4949
1000 8 67,4 4,7 0,4435 1000 8 74,2 5,2 0,5356
* For design with ZNP-10-24 power supply, a weight of 0,4 kg must be added.

Page 15Version 2023-10-31 Fire damper - FDML
TPM 130/17
A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua. A x B
[mm]
Number
of
blades
Weight
[kg] Effective
area
Sef [m2]
Actua.
FDML* 1
KMM FDML* 1 KMM
900
x
300 2 28,9 2,7 0,1452
BFN
950
x
650 5 54,9 4,2 0,3912
BF
315 2 30,2 2,8 0,1495 700 6 58,4 4,4 0,4003
355 3 31,8 2,9 0,1840 710 6 59,3 4,4 0,4095
400 3 34,8 3,1 0,2229 750 6 62,0 4,6 0,4460
450 4 38,5 3,3 0,2316 800 6 66,2 4,8 0,4643
500 4 41,9 3,5 0,2748 850 7 68,7 5,0 0,5009
560 4 46,8 3,7 0,2920 900 7 72,1 5,2 0,5466
600 5 49,9 3,9 0,3266
BF
950 8 75,6 5,4 0,5557
630 5 52,0 4,0 0,3525 1000 8 79,1 5,6 0,6014
650 5 53,2 4,1 0,3698
1000
x
300 2 30,8 2,9 0,1620
BFN
700 6 56,7 4,3 0,3784 315 2 32,2 3,0 0,1668
710 6 57,4 4,3 0,3871 355 3 33,8 3,1 0,2053
750 6 60,2 4,5 0,4216 400 3 37,1 3,3 0,2487
800 6 64,1 4,6 0,4389 450 4 42,6 3,5 0,2584
BF
850 7 66,6 4,8 0,4735 500 4 46,2 3,7 0,3066
900 7 69,9 5,0 0,5167 560 4 51,5 4,0 0,3258
950 8 73,3 5,2 0,5253 600 5 53,1 4,1 0,3644
1000 8 76,6 5,4 0,5685 630 5 55,3 4,3 0,3933
950
x
300 2 29,9 2,8 0,1536
BFN
650 5 56,6 4,4 0,4126
315 2 31,2 2,9 0,1581 700 6 60,2 4,6 0,4222
355 3 32,8 3,0 0,1947 710 6 61,1 4,6 0,4319
400 3 35,9 3,2 0,2358 750 6 63,9 4,8 0,4704
450 4 39,7 3,4 0,2450 800 6 68,2 5,0 0,4897
500 4 43,2 3,6 0,2907 850 7 70,8 5,2 0,5283
560 4 48,3 3,8 0,3089 900 7 74,3 5,4 0,5765
600 5 51,5 4,0 0,3455 BF 950 8 78,0 5,6 0,5861
630 5 53,6 4,1 0,3729 1000 8 81,5 5,8 0,6343
* For design with ZNP-10-24 power supply, a weight of 0,4 kg must be added.

Fire damper - FDMLPage 16 Version 2023-10-31
TPM 130/17
■The damper can be installed with blade axis vertically or
horizontally, temperature sensor (BAT) must always be in
damper upper part. The damper installation procedures
must be done so that all load transfer from the fire
separating constructions to the damper is absolutely
excluded. Following air-conditioning duct must be
suspended or supported so that all load transfer from the
following duct to the fire damper is absolutely excluded.
The gap between the installed damper and the fire
separating construction must be perfectly filled with
approved material.
■During the installation and plastering process, the
actuating mechanism must be protected (covered)
against damage and pollution. The damper casing should
not be deformed during bricking in. Once the damper is
built in, the damper blades should not grind against the
damper casing during opening or closing.
■The distance between the fire damper and the
construction (wall, ceiling) must be 75 mm at the
minimum, according to EN 1366-2. If two or more
dampers are to be installed in one fire separating
construction, the distance between adjacent dampers
must be 200 mm at the minimum, according to EN 1366-2.
■Fire dampers can be installed without following duct on
one or both sides. In the case of this installation, the fire
dampers must be equipped with cover grilles.
■For designs with an optical smoke detector, the best
conditions for detecting smoke and combustion products
must be ensured, i.e. the smoke detector must be located
at the upper part of the room.
■It is recommended to install the dampers according to the
local disposition in such a way that the side of the damper
with the thermoelectric activation device is in line with
the wall and the opening on the other side of the wall is
permanently covered by a second cover grille fixed e.g. in
the frame. The minimum thickness of the standard wall
construction is 100 mm. In the case of an installation
where one side of the damper is in line with the surface of
the construction and the other side extends more than 25
mm from the construction, the extending part must be
covered with fire-resistant boards. In the case of
installation in a gypsum wall, the opening must be lined
with reinforcement profiles.
■Dampers are not equipped with inspection openings. If
these dampers are used as dampers for simple mainte-
nance and revision they must be completed with connect-
ing inspection part installed just behind the damper.
Minimum distance between the fire dampers and the construction
■minimum distance 200 mm between dampers, according to EN 1366-2
■minimum distance 75 mm between damper and construction (wall/ceiling), according to EN 1366-2
IV. INSTALLATION
Placement and installation
≥ 75
≥ 75
≥ 75
≥ 200
≥ 75
≥ 200
≥ 200

Page 17Version 2023-10-31 Fire damper - FDML
TPM 130/17
Dimensions of an installation opening
Statement of installations
Placement
wall/ceiling min.
thickness
[mm]
Method of installation Fire resistance Page
In solid wall construction
100
Mortar or gypsum
EI 90 (ve i↔o) S
18
Weichschott system 19
In gypsum wall construction
Mortar or gypsum 20
Weichschott system 21
In solid ceiling construction 150 Mortar or gypsum EI 90 (ho i↔o) S 22
A
B
min. A+290
max. A+490
Grounding of the damper
Grounding screw
■It is necessary to ground the damper casing before installation.
min. B+100 max. B+300

Fire damper - FDMLPage 18 Version 2023-10-31
TPM 130/17
In solid wall construction
In solid wall construction - mortar or gypsum
■For connection of following duct → see page 27
1 FDML
2 Solid wall construction
3 Mortar or gypsum
4 Fire-resistant cover boards - only if one side of the damper is in line with the surface of the construction and the other side extends
more than 25 mm from the construction - (Promatect-H...) min. thickness 15 mm - connect the boards together with screws
XX
≥ 100
50…150
B
min. B+100
max. B+300
A+190
min. A+290
max. A+490
50…150
≥ 100
EI 90 (ve i↔o) S*
EI 120 (ve i↔o)**
* In case with connected duct and with forced air flow
** In case without connected duct with grilles on both sides and with natural air flow
150

Page 19Version 2023-10-31 Fire damper - FDML
TPM 130/17
1 FDML
2 Solid wall construction
Weichschott system HILTI***
3Mineral wool board - min. density 140 kg/m³ (HILTI CFS-CT B 1S 140/50...)
4 Fire stop coating - th. 1 mm (HILTI CFS-CT...) - coating is overcoated on the support construction and on the damper casing/duct
5 Fire-resistant mastic - (HILTI CFS-S ACR...) fill the gap from both sides of the fire separation construction and around the perimeter of
penetration and damper casing
6 Fire-resistant cover boards - only if one side of the damper is in line with the surface of the construction and the other side extends more
than 25 mm from the construction - (Promatect-H...) min. thickness 15 mm - connect the boards together with screws
In solid wall construction - Weichschott system
■For connection of following duct → see page 27
XX
≥ 100
50…150
50…150
B
min. B+100
max. B+300
A+190
min. A+290
max. A+490
≥ 20
≥ 100
* In case with connected duct and with forced air flow
** In case without connected duct with grilles on both sides and with natural air flow
*** HILTI system can be replaced by a similar system with the same or higher
thickness, density, fire reaction class, tested according to EN 1366-3.
150
EI 90 (ve i↔o) S*
EI 120 (ve i↔o)**

Fire damper - FDMLPage 20 Version 2023-10-31
TPM 130/17
In gypsum wall construction
In gypsum wall construction - mortar or gypsum
■For connection of following duct → see page 27
1 FDML
2 Gypsum wall construction
3 Mortar or gypsum
4 Fire-resistant cover boards - only if one side of the damper is in line with the surface of the construction and the other side extends
more than 25 mm from the construction - (Promatect-H...) min. thickness 15 mm - connect the boards together with screws
X
X
≥ 100
B
min. B+100
max. B+300
A+190
min. A+290
max. A+490
50…150
≥ 100
50…150
150
* In case with connected duct and with forced air flow
** In case without connected duct with grilles on both sides and with natural air flow
EI 90 (ve i↔o) S*
EI 120 (ve i↔o)**
