Mandik FDMS Series User manual

1
These technical specifications state a row of manufactured sizes and models of fire dampers (further only dampers) FDMS.
It is valid for production, designing, ordering, delivery, assembly and operation.
Description........................................................................................................................................................
2
Damper design..................................................................................................................................................
3
Communication and control devices.................................................................................................................
6
Dimensions and weights....................................................................................................................................
7
Placement and assembly..................................................................................................................................
8
Installations opening.........................................................................................................................................
9
Statement of installation....................................................................................................................................
9
Descriptions of particular installations...............................................................................................................
10
Pressure loss....................................................................................................................................................
21
Noise data.........................................................................................................................................................
22
Entry into service and revisions........................................................................…..............................................
26
In case of products with "P-mark" certification from RISE Institute in Sweden these technical specifications must be meet in
addition to the standard design:
■In addition to activation by means of thermal fuses or links in the actuator, the damper must also be activated by smoke
detectors and/or heat detectors that have been installed in suitable positions.
■The smoke and heat detectors used together with the fire damper must be designated and constructed in accordance with
one of the following standards EN 54-5, EN 54-7, EN 54-12 or EN 54-20.
■The damper must be controlled by an actuator connected to a higher-level supervisory and constrol system.
■Correct operation of the damper must be verified by automatic testing of its function at least once per 48 hours.
After reaching o these requirements the product will be provided with this certificate:
■Certified body - RISE Certifiering.
■Number of the certificate - SC1433-17.

2
Fire dampers are shutters in ventilation duct systems that preventing spreading the fire and combustion gases from one fire
compartment to the other one by shutting of closing the air duct in the positions of fire separating constructions. Dampers blade
closes automatically air duct using a shutting spring or an return spring of its actuating mechanism in case of fire. The return spring
of the actuator is started when the thermal fuse is activated. In the case of thermos electrical fuse the activation (closing)
procedure starts, when a reset button on fuse is pushed or when a power supply of the actuating mechanism is stopped. In case
of mechanical control with thermal fuse, the return spring is activated after the moment, when thermal fuse is melted. The
damper´s blade is sealed with a silicon gasket/packing preventing smoke penetration after closing the blade. At the same time,
the damper´s blade will be tighten by intumescent tape, which will be expanding in the case of fire. Dampers have no inspection
door. For inspection of the damper, there is an inspection hole for camera. For others service works there must by installed
inspection door externally on the duct, next to the fire damper. The damper is equipped with additional collar, around the position
of the blade. On the collar, there are positioned several metallic plates (fixtures for easy installation on the wall or ceiling construction.
■CE certified acc. to EN 15650
■Tested in accordance with EN 1366-2
■Classified acc. to EN 13501-3+A1
■Fire resistance EIS 60
■External casing leakage class min. C, internal leakage class 2 acc. EN 1751
■Cycling test in class C 10 000 acc. to EN 15650
■Corrosion resistant acc. to EN 15650
■ES Certificate of conformity No. 1391-CPR-2017/0092
■Declaration of performance No. PM/FDMS/01/17/1
Fire damper´s proper functioning is determined by the following working conditions:
■Maximum air speed: 12m/s.
■Maximum pressure difference: 2500 Pa.
■Operation of the dampers does not depend on the direction of air-flow (circulation).The dampers can be located in any
(arbitrary) position.
■Dampers are suitable for ventilation air systems not containing any abrasive, chemical and adhesive particles.
■Dampers are designed for macroclimatic areas with mild climate according to EN 60721-3-3.
■Temperature in the place of installation is permitted to be in the range from - 30°C to + 50°C.

3
AC 230V / 5A
IP 67
-25°C … +120°C
1(COM) - black wire
2(NC) - gray wire
4(NO) - blue wire
This limit switch is possible to connect in following two versions:
a) if the arm is moving … connect wire 1+2
b) if the arm is moving … connect wire 1+4
Design with mechanical control with a thermal protective fuse which actuates the shutting device within 120 seconds, when the
nominal temperature reaches 72°C. Automatic initiation of the shutting device is not activated if the temperature does not exceed 70°C.
Design with mechanical control can be complemented with a limit switch signaling the damper´s blade position "CLOSED". Limit switch
is possible connect to the building management system or superordinate control system by wires, which are mounted to the switch.
Design with mechanical control can be complemented with a limit switch signaling the damper´s blade position "CLOSED". Limit switch
is possible connect to the building management system or superordinate control system by wires, which are mounted to the switch.

4
The damper can be equipped with electric actuating mechanism. There are several actuators: BELIMO BFL, BFN230-T (version .40)
or BFL, BFN24-T (version .50). After connection to the power supply AC/DC 24V or AC230V, the actuating mechanism displaces the
damper blade into operation position "OPEN". At the same time is pre-stretched back spring inside the actuator. When the actuator is
under voltage (on power supply), the damper´s blade is in the position "OPEN". The back spring is pre-stretched. Time needed for full
opening of the damper blade from the position "CLOSED" to the position "OPEN" is maximum 140s (for type BF) or 60s (for type BFL,
BFN). If the power supply of the actuator is cut off (due to disconnection of power supply, or pressing the reset button on the
thermo-electrical starting mechanism BAT (thermal fuse), the back spring displaces the damper´s blade into the safety position
"CLOSED". The time needed for displacing of the blade from the position "OPEN" to the position "CLOSE" takes maximal 20s. In the
case that the power supply is restored again (the blade can be in arbitrary position), the actuator starts re-displacing the damper´s
blade position into the emergency position "OPEN". The thermos-electrical mechanism BAT, which contains two thermal fuses Tf1
and Tf2, is a part of actuator. These fuses are activated when temperature +72°C has been exceeded. The fuse Tf1 measures the
temperature in the outside of the damper and Tf2 measure the temperature inside the air duct. Both fuses, they are in serial
connection. It means in fact, that when one of them is activated, the power supply of the actuator is cut-off and the actuator displaces
the blade in safety position "CLOSED". The signalization of damper position "OPEN" or "CLOSED" is provided by two limit switches,
which are built-in inside the actuator. The thermal fuse BAT can be also installed separately, into the spiral air duct, outside of the fire
damper (order code for this option is .4V or .5V - see the product code).
12S3
S1 S2 S5S4 S6
Connection via safety isolating transformer.
<5° <80°
BAT
Tf Tf LED
Parallel connection of other actuators possible. Observe the performance data.
Combination of power supply voltage and safety extra-low voltage not permitted
at the both auxiliary switches.
~
- +
Application examples for integration
into monitoring and control systems
or into bus networks can be found in
the documentation of the connected
communication and power supply unit.
1 = blue
2 = brown
S1 = violet
S2 = red
S3 = white
S4 = orange
S5 = pink
S6 = grey
12S3
S1 S2 S5S4 S6
NL1
Caution: Power supply voltage!
<5° <80°
BAT
Tf Tf LED
The actuator must be protected by a fuse that does not exceed 16 A.
Parallel connection of other actuators possible. Observe the performance data.
Combination of power supply voltage and safety extra-low voltage not permitted
at the both auxiliary switches.
1 = blue
2 = brown
S1 = violet
S2 = red
S3 = white
S4 = orange
S5 = pink
S6 = grey

5
AC 230 V 50/60 Hz AC 24 V 50/60 Hz
DC 24 V
- motoring
- holding
3,5/5 W
1,1/2,1 W
2,5/4 W
0,8/1,4 W
6,5/10 VA (Imax 4 A @ 5 ms) 4/6 VA (Imax 8,3 A @ 5 ms)
II III
IP 54
- motor
- spring return
<60 s
~ 20 s
- normal duty
- safety duty
- non-operating temperature
- 30 °C … 55 °C
The safe position will be attained up to max. 75°C
- 40 °C … 55 °C
- motor
- auxiliary switch
cable 1 m, 2 x 0,75 mm² (BFL/BFN 24-T-ST) with 3-pin plug-in connectors
cable 1 m, 6 x 0,75 mm² (BFL/BFN 24-T-ST) with 6-pin plug-in connectors
duct outside temperature 72 °C
duct inside temperature 72 °C
This is design with the communication and supply device BKN230-24 and the actuator BFL(or BFN)24-T-ST. It simplifies electrical
wiring and interconnection of fire damper. This design facilitates checking of the damper on site and enables central control and check
of fire damper during by a simple "2-wire" wiring with superordinate control unit. BKN230-24 is working as a decentralized network
device for supplying of the actuator BFL(BFN)24-T-ST on one hand and on the other hand it transmits the signal information about the
fire damper position and failure. Control command SWITCH-ON and SWITCH-OFF from superordinate system controls via the same
wiring to the actuating mechanism. To allow more simple connection, the actuator BFL(BFN)24-T-ST is equipped with two connecting
plugs (one with three jacks and one plug with six jacks). They are inserted directly to BKN230-24. BKN230-24 is supplied with a
conductor and EURO-plug for connecting to the 230V mains. Two wire cable from superordinate system is connected to BKN230-24
by means of clamps 6 and 7 in BKN. If the drive is supposed to be controlled without any signal from the superordinate, it can be
switch-on by means of a bridge between clamps 3 and 4 in BKN. A green LED diode on BKN230-24 is lighting in case the voltage 24V
is present in the drive. If the TEST button on BAT is switched-on or if the power supply (e.g. by a signal from ELECTRICAL FIRE
SIGNALISATION) is disconnected, the fire damper position will be "FAILURE". It means damper blade goes in position "CLOSED".
Communication and supply device BKN230-24 has to be placed near the damper (BKN isn´t mounted on damper body). It is necessary
for easy connection of actuator equipped by BKN230-24 device.
AC 230V 50/60Hz
3,5 W (operating position)
11 VA (including actuating mechanism)
II
IP 42
- 30 °C … + 50 °C
- 40 °C … + 50 °C
- mains
- drive
- terminal board
Cable 0,9 m with EURO plug of 26 type
6 pole plug, 3 pole plug
screw terminals for conductor 2x1,5 mm

6
Current Failure 15 16 K2 contact is on if all the dampers are
open 14 11
17 18
No Failure 15 16
K2 contact is on if the damper No. 1 is
open 14 12
K2 contact is on if all the dampers are
closed 14 open
BKS24-9A communication and control device is used for group control and checks of 1 to 9 fire dampers with the actuator BFL
(BFN)24-T-ST in connection with the supply and communication device BKN230-24. Signalization of the damper blade position
is individual for each damper (9 LED diodes), but the dampers can be controlled and tested only as a group. BKS24-9A is intended
for use in superordinate control system, which can display operation mode and failure reports of the connected fire dampers.
BKS24-9A receives signals from BKN230-24 through two wire cable. Proper damper operation is indicated by two light LED diodes:
Control LED "OPEN" = damper blade in emergency position OPEN
Control LED "CLOSE" = damper blade in safety position CLOSED
If the damper does not reach the required position within the preset time, the appropriate on-board FAULT LED flashes and, at
the same time, the fault contact K1 is activated (K1 is group alarm for all 9 dampers). This contact is overridden as soon the
defective damper reaches the required position. The on-board FAULT LED remains on, until the fault is reset. Auxiliary contact
K2 is provided for signaling the positions of dampers to a supreme communication controlling system. The function of the auxiliary
contact can be programmed via terminal 14 according the next table.
The BKS24-9A unit can be clipped directly onto a 35mm DIN mounting rail and external wiring is connected by two 9-pin terminal
connectors.
Functional testing can be performed by pressing the TEST pushbutton. While this button is held depressed, the dampers run to
the safe position. Any malfunctions are indicated by the internal FAULT LED´s.
BAT

7
AC 24 V 50/60Hz
3,5 W (operating position)
5,5 VA
III (safe small voltage)
IP 30
0 … + 50 °C
Terminals for conductor 2 x 1,5 mm
caM
caS
= for the actuator - BFL 86mm, BFN 110mm
= the height of the actuator - BFL 48mm, BFN 52mm
øD
70 ± 2
164
70
61
øD
øD1
220
41 50
50
øD
øD
øD1
250
41 50
50
A
54 B6,75
146

8
2,2 2,6 3,2 3,6 4 4,5 5,1 5,8
–
6,7 7,7 9 10,4 12 14,1 16,7 –
3,3 3,7 4,3 4,7 5,1 5,6 6,2 6,9
–
7,8 8,8 10,1 11,5 13,4 15,5 18,1 –
BFL24-T(-ST), BFL230-T 100, 125, 160, 180, 200, 225, 250, 280, 315, 355, 400, 450
BFN24-T(-ST), BFN230-T 500, 560, 630
Fire dampers are suitable for installation in arbitrary position in vertical and horizontal passages of fire separating constructions.
Damper assembly procedures must be done so as all load transfer from the fire separating constructions to the damper body is
absolutely excluded. Back-to-back air-ducting must be hung or supported so as all load transfer from the back-to-back piping to
the damper is absolutely excluded. Installation gap must be filled by approved material perfectly in all the installation space volume
(installation gap). To be able to provide inspection, inside of the fire damper is the damper with camera inspection hole standardly
equipped. For other service works, the external access door (inspection hole) must be installed on the air duct, next to the fire
damper.
The distance between the fire damper and the construction (wall, ceiling) must be minimum 75 mm. In case that two or more
dampers are supposed to be installed in one fire separating construction, the distance between the adjacent dampers must be at
least 200 mm according to EN 1366-2 paragraph 13.6.
The control mechanism has to be protected (covered) against damage and pollution during installation process. All fire dampers
has to be closed during installation process. The damper body should not be deformed in the course of bricking in. Once the
damper is built in, its blade should not grind on the damper body during opening or closing.
98 190 – – – 313 405 – 12 70
123 215 – – – 353 445 2 32 90
158 250 – – – 398 490 24,5 54,5 112,5
178 270 – – 2,5 448 540 49,5 79,5 137,5
198 290 – – 12,5 498 590 74,5 104,5 162,5
223 315 – – 25 558 650 104,5 134,5 192,5
248 340 – – 37,5 628 720 139,5 169,5 227,5
278 370 – – 52,5 – – – – – –
Collar
* Other values - see the installation details for installation
flange to flange and next to ceiling or/and wall.

9
The dimensions of installation opening for the connected air duct depends on the type of sealant- see the table.
Mat: thick 13mm, Paper: thick: 6mm
from outside Firestop Acrylic sealant CFS-S ACR or similar D+28, D+14
Mat: thick 9mm
from outside Firestop Acrylic sealant CFS-S ACR or similar D+20
Firestop Acrylic sealant CFS-S ACR or similar D+10
Orstech LSP H thick 20mm + from outside mastic
Firestop coating CFS-CT or PROMASTOP-P or K or similar D+40
Fire mortar CFS-M RG or similar D+80
Ø D2
Ø D
Solid wall construction (t≥100mm) Dry Fire resistant sealant or stone wool or
glass fiber fabric
Solid wall construction (t≥100mm) Wet Mortar or gypsum
Outside solid wall construction with t≥100mm
(insulation of the pipe between wall and dam-
per made from stone wool)
Dry Fire resistant sealant or stone wool or
glass fiber fabric
Outside solid wall construction with t≥100mm
(insulation of the pipe between wall and dam-
per made from stone wool)
Wet Mortar or gypsum
Solid ceiling construction (t≥125mm for aera-
ted concrete) Dry Fire resistant sealant or stone wool or
glass fiber fabric
Solid ceiling construction (t≥125mm for aera-
ted concrete) Wet Mortar or gypsum
Outside solid ceiling construction with
t≥125mm for aerated concrete (insulation of
the pipe between wall and damper made from
stone wool)
Dry Fire resistant sealant or stone wool or
glass fiber fabric
Outside solid ceiling construction with
t≥125mm for aerated concrete (insulation of
the pipe between wall and damper made from
stone wool)
Wet Mortar or gypsum
Gypsum wall construction (t≥100mm) Dry Fire resistant sealant or stone wool or
glass fiber fabric
Gypsum wall construction (t≥100mm) Wet Mortar or gypsum
Outside gypsum wall construction with
t≥100mm (insulation of the pipe between wall
and damper made from stone wool)
Dry Fire resistant sealant or stone wool or
glass fiber fabric
Outside gypsum wall construction with
t≥100mm (insulation of the pipe between wall
and damper made from stone wool)
Wet Mortar or gypsum
Sandwich wall (insulated wall panel) construc-
tion Dry Fire resistant sealant or stone wool or
glass fiber fabric
Outside sandwich wall (insulated wall panel)
construction with insulation of the pipe Dry Fire resistant sealant or stone wool or
glass fiber fabric
The damper is designed for installation on a wall or intermediate floor for circular air-duct connection.

10
Fire classification:
Solid wall construction
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Anchor for damper collar (e.g.FISCHER - type ZYKON FZA M8x30)
Fixing part of the pipe between wall and pipe (only recommended)
Hanging ring (e.g. FISCHER - type LGS)
Connecting surface between damper collar
and wall fulfil with fire resistant sealant before
instalation of the damper (recommended type
of sealant - e.g. PROMAT K84 or HILTI CFS-S)
≥ 100
View B:
Ø D

11
Fire classification:
≥ 96 ≥ 47
≥ 47
≥ 96
≥ 96

12
Solid wall construction
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Pipe insulation with minimal fire resistance EI60 (e.g. ISOVER Ultimate protect Wired MAT 4.0 ALU1)
Fixing part of the pipe between wall and pipe (mandatory)
Hanging ring (e.g. FISCHER - type LGS)
≥ 100
Fire classification:
Connecting surface between wall and pipe insulation
fulfil with fire resistant sealant before instalation of
the insulation (recommended type of sealant - see
instalation instructions of the insulation contractor).
Installation of pipe insulation perform according instructions of the manufacturer (e.g. ISOVER, ROCKWOOL,PAROC ...).
Minimal wool density for pipe insulation must be 66kg/m.
This fixing part isn't mandatory if the installation opening was fulfill by mortar or gypsum. In other cases of the fire
resistant fill is this fixing part of the pipe mandatory. This fixing part can by mounted on the both sides of the wall.
View A:
Ø D
Nut M8 with anchor
8-fixing part of the pipe (see only
example and recommneded type
on this picture)
Holes for rivets
Ø D+200

13
Gypsum wall construction
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Anchor for damper collar (threaded rod and nuts M8 or e.g. anchor FISCHER - type KD8)
Fixing part of the pipe between wall and pipe (only recommended)
Hanging ring (e.g. FISCHER - type LGS)
View B:
Ø D
Fire classification:
≥ 100
Connecting surface between damper collar
and wall fulfil with fire resistant sealant before
instalation of the damper (recommended type
of sealant - e.g. PROMAT K84 or HILTI CFS-S)

14
Fire classification:
≥ 96 ≥ 47
≥ 47
≥ 96
≥ 96

15
Gypsum wall construction
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Pipe insulation with minimal fire resistance EI60 (e.g. ISOVER Ultimate protect Wired MAT 4.0 ALU1)
Fixing part of the pipe between wall and pipe (mandatory)
Hanging ring (e.g. FISCHER - type LGS)
≥ 100
Fire classification:
Connecting surface between wall and pipe insulation
fulfil with fire resistant sealant before instalation of
the insulation (recommended type of sealant - see
instalation instructions of the insulation contractor).
Installation of pipe insulation perform according instructions of the manufacturer (e.g. ISOVER, ROCKWOOL,PAROC ...).
Minimal wool density for pipe insulation must be 66kg/m.
This fixing part isn't mandatory if the installation opening was fulfill by mortar or gypsum. In other cases of the fire
resistant fill is this fixing part of the pipe mandatory. This fixing part can by mounted on the both sides of the wall.
View A:
Ø D
Screw M8 and anchor
8-fixing part of the pipe (see only
example and recommneded type
on this picture)
Holes for rivets
Ø D+200

16
Solid ceiling construction
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Anchor for damper collar (e.g. FISCHER - type ZYKON FZA M8x30)
Fixing part of the pipe between wall and pipe (mandatory)
Hanging ring (e.g. FISCHER - type LGS)
Fire classification:
View A:
Nut M8 and anchor
8-fixing part of the pipe (see only
example and recommneded type
on this picture)
Holes for rivets
150*
Connecting surface between damper
collar and wall fulfil with fire resistant
sealant before instalation of the damper
(recommended type of sealant - e.g.
PROMAT K84 or HILTI CFS-S)
Ø D
Minimal thickness of the ceiling is for concrete 110mm and fo aerated concrete 125mm.

17
Fire classification:
≥ 96 ≥ 47
≥ 47
≥ 96
≥ 96

18
Nut M8 and anchor
8-fixing part of the pipe (see only
example and recommneded type
on this picture)
Holes for rivets
View A:
Solid ceiling construction
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Pipe insulation with minimal fire resistance EI60 (e.g. ISOVER Ultimate protect Wired MAT 4.0 ALU1)
Fixing part of the pipe between wall and pipe (mandatory)
Hanging ring (e.g. FISCHER - type LGS)
150
Installation of pipe insulation perform according instructions of the manufacturer (e.g. ISOVER, ROCKWOOL,PAROC ...).
Minimal wool density for pipe insulation must be 66kg/m.
Minimal thickness of the ceiling is for concrete 110mm and fo aerated concrete 125mm.
This fixing part isn't mandatory if the installation opening was fulfill by mortar or gypsum. In other cases of the fire resistant
fill is this fixing part of the pipe mandatory. This fixing part can by mounted on the both sides of the wall.
Fire classification:
Ø D
Connecting surface between wall
and pipe insulation fulfil with fire
resistant sealant before instalation of
the insulation (recommended type of
sealant - see instalation instructions
of the insulation contractor).
Ø D+200
3

19
Insulated wall construction (e.g. KINGSPAN - type KS1150 FR)
Spiral pipe
Fire resistant fill (for recommended materials see separate table)
Threaded rod and anchor to the wall (or ceiling) (e.g. threaded rod M8 and anchor type according pipe weight)
Fire protection mastic min. thickness 1mm (e.g. PROMASTOP-P or K)
Fire damper FDMS
Anchor for damper collar (threaded rod and nuts M8)
Fixing part of the pipe between wall and pipe (only recommended)
Hanging ring (e.g. FISCHER - type LGS)
Installation ring
View B:
Ø D
Fire classification:
≥ 100
Before instalation of the fire resistant
stopper inside the instalation opening
put special connection ring. This ring
cover insulation inside the panel and
connect outside and inside plane of
the panel.
Connecting surface between damper collar
and wall fulfil with fire resistant sealant before
instalation of the damper (recommended type
of sealant - e.g. PROMAT K84 or HILTI CFS-S)
DETAIL
A
