Mitel SX-200 ICP - 1.0 5020 User manual

Release 4.0
CX/CXi Controller
TECHNICIAN’S HANDBOOK

ii
SX-200 ICP CX Technician’s Handbook
NOTICE
The information contained in this document is believed to be accurate in all
respects but is not warranted by Mitel Networks™ Corporation (MITEL®). The
information is subject to change without notice and should not be construed in any
way as a commitment by Mitel or any of its affiliates or subsidiaries. Mitel and its
affiliates and subsidiaries assume no responsibility for any errors or omissions in
this document. Revisions of this document or new editions of it may be issued to
incorporate such changes.
No part of this document can be reproduced or transmitted in any form or by any
means - electronic or mechanical - for any purpose without written permission from
Mitel Networks Corporation.
MITEL, SX-200, LIGHTWARE, SUPERSET, MiTAI are trademarks of Mitel
Networks Corporation.
HYPERTERMINAL is a trademark of Hilgraeve Inc.
VT100 is a trademarks of Digital Equipment Corporation.
All other product names specified in this document are trademarks of
their corresponding owners.
SX-200 ICP CX/CXi Technician’s Handbook
Document # 51009228
Release 4.0
October 2006
® ™Trademark of Mitel Networks Corporation
©Copyright 2006, Mitel Networks Corporation
All rights reserved

iii
Table of Contents
Chapter 1 : Introduction
About this Handbook ............................................................................................3
Purpose of this handbook ................................................................................3
Who this handbook is written for......................................................................3
Where you can find more information..............................................................4
Contacting Mitel ...............................................................................................6
Symbols used in this handbook .......................................................................7
Important safety instructions............................................................................7
About the SX-200®ICP CX/CXi ............................................................................8
System packages.............................................................................................8
System configurations......................................................................................9
DSP configurations ........................................................................................11
Supported Peripherals ........................................................................................13
Default Database Configuration ..........................................................................14
Telephone related..........................................................................................14
Voice mail related...........................................................................................15
Trunk related..................................................................................................15
System related...............................................................................................15
Chapter 2 : Basic Installation
Before You Begin ................................................................................................19
Quick Installation ................................................................................................19
SX-200 ICP CX/CXi Hardware ............................................................................21
Hardware Ports and Connectors....................................................................21
Controller Components..................................................................................22
Identify the Required Components.................................................................23
Installation Checklist ......................................................................................24
Basic Installation Overview .................................................................................27
Installing the SX-200 ICP CX/CXi Controller ......................................................28
Installing Optional Controller Hardware ..............................................................29
Precautions....................................................................................................29
Removing the cover.......................................................................................30
Install the Analog Option Board (AOB) ..........................................................32
Installing optional DSP module(s)..................................................................35
Installing an optional T1/E1 Combo module ..................................................36
Installing the optional Quad CIM Module(s)...................................................38
Installing an optional system hard drive.........................................................39
Installing an optional Application Processor Card..........................................42
Installing an APC hard drive...........................................................................45
Installing the Stratum clock............................................................................47

iv
SX-200 ICP CX/CXi Technician’s Handbook
Installing Controller Software Using an External CompactFlash Card
(Optional Initial Install) ........................................................................................48
Installing APC Software ......................................................................................50
Wall or Rack Mounting .......................................................................................51
Wall mounting the controller..........................................................................51
Rack mounting the controller.........................................................................52
Installing an ASU II .............................................................................................53
Installing an External Layer 2 Switch for Increased IP Connections (CX/CXi) ... 55
Powering IP phones in an expanded system.................................................55
Layer 2 switch programming..........................................................................56
CDE programming.........................................................................................56
Connecting the Phones and Lines .....................................................................57
IP Phones......................................................................................................57
ONS/CLASS and LS/CLASS ports................................................................59
Adding a PKM ....................................................................................................60
Requirements ................................................................................................60
CDE programming.........................................................................................60
Installation .....................................................................................................60
Connecting Music on Hold, Paging and Door Phone/Door Opener ................... 61
Music on Hold (MOH) interface .....................................................................61
Paging ...........................................................................................................61
Door Phone/Door Opener..............................................................................63
Connecting a Night Bell and Alarm Device ........................................................64
CDE programming for a Night Bell................................................................64
CDE programming for an Alarm Device........................................................64
Setting up an FTP Server on a Maintenance PC ...............................................65
CDE Programming.........................................................................................65
FTP Server Setup..........................................................................................65
System Health Check .........................................................................................66
Chapter 3 : Basic Programming
Programming Overview ......................................................................................69
Preparing to Enter Customer Data .....................................................................70
PC Requirements ..........................................................................................70
Serial Connection to the Controller................................................................70
Secure Telnet Connection to the Controller...................................................71
Web Interface Connection to the Controller...................................................72
Port Usage.....................................................................................................73
Enabling MOSS Options ....................................................................................74
System Options to Avoid ....................................................................................75

v
Table of Contents
Programming the Customer Data Entry (CDE) Forms ........................................75
Programming Features for each Phone ..............................................................76
Before you begin............................................................................................76
Programming Embedded Voice Mail ..................................................................82
CDE Programming for Embedded Voice Mail................................................82
Voice Mail Forms ...........................................................................................83
Setting up RADs.............................................................................................85
Setting up Record a Call................................................................................87
Using the Administrator’s Mailbox..................................................................88
Testing Voice Mail Operation.........................................................................92
Programming Phonebook ...................................................................................93
Programming a Printer Port ................................................................................94
Programming Stations/Sets Automatically ..........................................................95
Deleting a Device and All Dependent Resources ...............................................97
Deleting a range of devices and dependent resources..................................97
Programming a Single Line Voice Station ..........................................................98
Programming a Multi-Line Set ............................................................................99
Programming a T1/E1 Trunk .............................................................................100
Programming a PRI Trunk ................................................................................101
Programming Analog Trunks ............................................................................ 106
Non Dial-In Trunks....................................................................................... 106
Dial-in Trunks...............................................................................................107
DISA Trunks.................................................................................................108
Programming T1 and PRI Trunks as DISA Trunks......................................109
Programming ANI/DNIS on an Incoming Trunk...........................................110
CLASS Trunks .............................................................................................113
Running the Line Quality Test for LS Trunks...............................................114
Programming IP Sockets for Hotel/ Motel terminals and ACD Monitor .............115
Programming Voice mail with PMS Integration .................................................117
Requirements...............................................................................................117
SX-200 ICP Programming............................................................................118
Setting up the Ether232 ...............................................................................118
Programming the PMS Interface on the SX-200 ICP ........................................119
Requirements...............................................................................................119
SX-200 ICP Programming............................................................................119
Programming SpectraLink Wireless Telephones ..............................................123
Requirements...............................................................................................123
Programming................................................................................................123
Programming Call Forwarding - External ..........................................................128
Feature Limitations ...........................................................................................129
CDE Cross Reference ......................................................................................132

vi
SX-200 ICP CX/CXi Technician’s Handbook
Chapter 4 : Advanced Installation and Programming
Overview ..........................................................................................................137
Networking Capabilities of the SX-200 ICP ......................................................138
Planning your Installation .................................................................................139
IP Networking ...................................................................................................140
Requirements for IP Networking - CX..........................................................140
Virtual LANs (VLANs)..................................................................................141
Requirements for IP Networking - CXi.........................................................150
Default Controller IP Addresses ..................................................................152
Implementing a Voice-Only Network ...........................................................156
Implementing a Voice and Data Network ....................................................157
IP Network Configuration Procedures .........................................................159
Networking Mitel IP-PBXs ................................................................................171
SX-200 ICP Programming...........................................................................172
Uniform Numbering Plan .............................................................................174
Chapter 5 : Routine Maintenance
Is the system healthy? ......................................................................................177
System health checklist...............................................................................177
Checking the System .......................................................................................178
Installing FRUs .................................................................................................179
Precautions..................................................................................................179
Powering the Controller Up or Down...........................................................179
System Reset ..............................................................................................180
System Shutdown........................................................................................180
Re-initializing the Controller.........................................................................181
Replacing the Hard Drive or CompactFlash .....................................................182
Replacing the Analog Main Board (AMB) ...................................................183
Other FRUs .................................................................................................184
Performing Backups .........................................................................................185
Backing up a database................................................................................185
Restoring a database ..................................................................................186
Installing an alternate database...................................................................187
Upgrading the System Software .......................................................................188
Upgrading from the external CompactFlash card........................................189
Upgrading by FTP .......................................................................................191
Replacing IP Phones ........................................................................................192
Restarting IP Phones .......................................................................................193
Measuring LS Trunks .......................................................................................194
Running the Line Quality Test.....................................................................195

vii
Table of Contents
Running the Distortion Test..........................................................................196
Running the Echo Test.................................................................................196
Maintenance Commands ..................................................................................197
Maintenance Port Characteristics................................................................197
Telnet Requirements....................................................................................197
Entering Command Sequences...................................................................197
Logging In ....................................................................................................198
Logging Out..................................................................................................199
Switching between Maintenance and CDE..................................................199
Displaying the Card Configuration ...............................................................199
Showing the System Identity........................................................................199
System Commands......................................................................................200
Report Commands.......................................................................................203
Traffic Measurement Commands.................................................................205
Log Commands............................................................................................206
Diagnostic Function Commands..................................................................207
Backing up Log and Trap Files using Kermit ....................................................208
Sending Logs and other System Files to an E-mail Address or FTP Server ....209
Retrieving Logs and other System Files using Kermit ......................................210
Maintenance Tips .............................................................................................210
Chapter 6 : Basic Troubleshooting and Repair
About this Chapter ............................................................................................213
Troubleshooting Tools ......................................................................................214
Before you Contact Technical Support .............................................................215
General Troubleshooting Steps ........................................................................216
Using the Phone Debug Option ...................................................................216
Checking the Status LEDs ................................................................................217
Troubleshooting Phones ...................................................................................220
Troubleshooting Analog Trunks ........................................................................222
Basic Troubleshooting..................................................................................222
Troubleshooting Signaling Problems ...........................................................223
Troubleshooting T1 Trunks (D4 DS-1) ..............................................................226
Synchronization............................................................................................226
Signaling Types............................................................................................227
Test/Verify (T1) ............................................................................................227
Troubleshooting Voice Mail ...............................................................................230
SX-200 ICP Property Management System Interface ......................................232
Property Management System Messages...................................................232
SX-200 ICP and PMS Cannot Communicate...............................................235
Testing the PMS Interface of the PBX.........................................................235

viii
SX-200 ICP CX/CXi Technician’s Handbook
Chapter 7 : Advanced Troubleshooting and Repair
About this Chapter ............................................................................................239
General Network Troubleshooting ....................................................................240
Check List....................................................................................................240
Troubleshooting IP Phone Connectivity ...........................................................242
Using a network analyzer to debug .............................................................242
Connectivity problems .................................................................................242
Troubleshooting IP Phone Registration.......................................................243
IP Phone Analyzer.......................................................................................251
Troubleshooting Phone Audio Quality ..............................................................253
Troubleshooting IP Trunks ...............................................................................256
CDE Check List ........................................................................................... 256
IP Check List ...............................................................................................258
Troubleshooting System Boot Failure ..............................................................259
Appendix A : Default Database Values..................................................261
Appendix B : Part Numbers ......................................................................319
Appendix C : System Cabling...................................................................329
Appendix D : Folio Views (E-Docs) Tips................................................335
Index

Chapter 1
Introduction

2
SX-200 ICP CX/CXi Technician’s Handbook

3
Introduction
About this Handbook
Purpose of this handbook
This handbook provides
•an overview of the system capabilities
•installation steps
•programming procedures
•maintenance procedures
•troubleshooting information
Who this handbook is written for
This handbook is for a qualified technician who has successfully
completed the SX-200®ICP Installation and Maintenance Course. The
course has two parts: basic and advanced.
SX-200 ICP Basic Installation and Maintenance Course
You need to take the Basic I & M course if you are installing the
SX-200 ICP as a voice system only.
This means that you are using the default settings for IP and you are not
planning on implementing Virtual LANs (VLANs).
The basic course is available in self-study format and you must have
completed your LIGHTWARE™ 19 RELEASE 3.2 certification.
SX-200 ICP Advanced Installation and Maintenance Course
You MUST complete the Advanced I & M course if you are planning to
•connect a PC to the PC port on the IP Phones (enable System Option 131)
•connect the SX-200 ICP in an existing LAN (Local Area Network)
•use an external DHCP (Dynamic Host Configuration Protocol) server
•implement VLANs (Virtual LANs)
•implement IP (Internet Protocol) Trunking
•network to a 3300 ICP via IP trunk or QSIG
The advanced course is available in a leader-led format. You must
complete the Basic I & M course before attending the advanced course.

4
SX-200 ICP CX/CXi Technician’s Handbook
Where you can find more information
The SX-200 ICP documentation set includes the following components:
•Printed documents
-Technician’s Handbook
-Safety Instructions
•Documents supplied on the SX-200 ICP software CD-ROM
-SX-200 ICP Technical Documentation in Folio (NFO) format.
-Technician’s Handbook
-Safety Instructions
-Telephone, Voice Mail, and Hotel/Motel Front Desk User Guides
-Technical Bulletins (TBs) and Release Notes (RNs)
Accessing Documentation on the software CD-ROM
1. Insert the CD in the CD-ROM drive.
2. Navigate to the Documentation folder.
3. Double-click Setup.exe to install the Technical Documentation and
Folio Viewer, the application used to view the documentation.
4. Toaccess userguides andother documentation, goto theappropriate
Language subdirectory. Use the index.html file to locate the required
guides.
Technical Training Materials
-SX-200 ICP Basic I & M Course
-SX-200 ICP Advanced I & M Course
Release Notes
Every software release is accompanied by Release Notes, which describe
software changes, bug fixes, outstanding issues, and hardware
compatibility considerations for the new software release. Read the
Release Notes before you begin a software upgrade.
The Release Notes are included on the system software CD-ROM. You
can also obtain the latest Release Notes from Mitel®OnLine at
www.mitel.com. Note that you must be a registered user to access Mitel
OnLine.

5
Introduction
Technical Bulletins
TechnicalBulletins (TBs) areissued byMitel TechnicalSupport toaddress
frequently asked questions regarding software and hardware problems.
Obtain the latest TBs from Mitel OnLine.
Mitel Knowledge Base
The Mitel Knowledge Base is a searchable database of problem-solving
information on the SX-200 ICP and other Mitel products. The database is
accessed through Mitel Online.
Accessing Mitel Online
You can access Mitel Online from the www.mitel.com Web site.
Access Product and Technical Documentation
1. Login to Mitel OnLine.
2. Navigate to Product Documentation (Technical Documents, User
Guides,and InstallationGuides) OR KnowledgeBase (ReleaseNotes
and Technical Bulletins).
View or Download a Document
To view a document:
•Click on the name of the document.
To download a document:
•Right-click on the name of the document and select Save Target As
OR
•When viewing a PDF document, click the disk icon.
Note: You must be a registered user to access Mitel Online.

6
SX-200 ICP CX/CXi Technician’s Handbook
Create Telephone User Guides with Manual Maker
1. Login to Mitel OnLine.
2. Navigate to Product Documentation.
3. Click Manual Maker.
4. Follow the instructions on the screen to register and use Manual
Maker.
Accessing Your Mitel Options Password
You must obtain your Mitel Options Password through Mitel Online
(www.mitel.com). This password is required during the upgrade
procedure, so you MUST keep a proper record of it. A new password is
issued to you if you are purchasing new options. Before attempting the
software upgrade, to confirm a current password or to purchase new
options and receive a new password, call Mitel Customer Service during
normal business hours.
Helpful websites
For definitions of technical terms
•http://www.techweb.com/encyclopedia
•http://www.whatis.com
For networking information
•http://www.practicallynetworked.com
•http://www.networktroubleshooting.com
Contacting Mitel
Order Desk
You can reach the Order Desk at 1-800-796-4835.
Repair Department
You must get a Return of Merchandise Authorization (RMA) form from the
Repairs Department before sending equipment back to Mitel Network
Corporation.
You can reach the Repairs Department at 1-888-222-6483.

7
Introduction
Technical Support - Mitel Dealers
Please contact Mitel Technical Support if you require technical assistance.
If you cannot resolve the problem by using the Troubleshooting chapter,
please collect the required information listed in “Before You Contact
Technical Support” on page 91 before calling Mitel Technical Support.
You can reach Technical Support at 1-800-561-0860 or 1-613-592-2122.
Symbols used in this handbook
Important safety instructions
See the system Safety Instructions that are shipped with the system for
complete safety information.
Indicates a hazardous situation which, if not avoided, could result
in injury or death.
Indicates a situation which, if not avoided, could result in damage
to the equipment.
Identifies an important note or a useful tip.
Failure to follow all instructions may result in improper equipment
operation and/or risk of electrical shock.

8
SX-200 ICP CX/CXi Technician’s Handbook
About the SX-200 ICP CX/CXi
The Mitel SX-200 Integrated Communications Platform (ICP) provides the
reliability and comprehensive features of a PBX, the ease of use and cost
effectiveness ofa key system, and the productivity-enhancingapplications
and networking efficiency of IP.
The CX provides a 10/100/1G LAN interface port and a Dynamic Host
Configuration Protocol (DHCP) server. In addition to these features, the
CXi includes an Internet gateway with firewall, and a powered 16-port
Layer 2 switch.
Tailored for small enterprises, the SX-200 ICP CX/CXi supports up to 100
IP phones, eight ONS/CLASS circuits, 12 LS/CLASS circuits, one T1 or
PRI link, up to 3 ASU IIs (with ONS/LS combo cards) and 16 IP trunks for
private networking.
System packages
TheCX/CXi controlleris sold aloneor aspartof the Basic System package
that includes the components shown in the table below. The Basic System
package does not include IP Phones.
Table 1: Basic System Package Components
Component Quantity/Description
LS/CLASS circuits 6
ONS circuits 4
Voice mail ports 4
DSPs 1 Dual DSP Module
Licenses
IP Phone
Voice Mailbox
TDM
ACD Agent
IP Channel
16
16
44
None
None
Software Options Feature Level 6
ONS CLASS Functionally
1 Digital Link
Voice Mail Softkey

9
Introduction
System configurations
The controller is configured at the factory as a square key telephone
system (KTS). It can be reconfigured by modifying the default database or
by installing one of the alternate databases supplied on the software
CD-ROM. For more information about alternate databases, see page 187.
The basic configuration is expandable through the purchase of additional
components, including DSP resources.
Table 2: SX-200 ICP System CX/CXi Configuration
Basic
Configuration Expanded Configuration How Expanded
6 LS/CLASS circuits 12 Add Analog Options Board
4 ONS/CLASS circuits 8Add Analog Options Board
16 IP Phone licenses 100 IP Phone licenses
and 16 IP trunks Purchase additional licenses Add Layer 2 swtich(es)
4 voice mail ports 16 ports Purchase Options and DSP
resources (incremental)
16 voice mailbox licenses 748 Purchase additional licenses
(incremental)
Approximately 11 hours of
voice mail message storage Up to 450 hours of voice mail storage Install internal hard drive
Three 3-party conferences 10 3-party Conferences
(30 conferees) Purchase DSP resources.
Dual DSP on motherboard - Dual DSP MMC and/or
T1/E1 Combo module
which includes one DSP
-Quad CIM MMC
Purchase modules
Notes:
1. Only Mitel-provided hard drives and CompactFlash cards should be
installed; those obtained elsewhere are not supported. See
Appendix B for part numbers.
2. Larger capacity media is strongly advised for systems with more
than 16 lines or above average usage of voice mail or Record a Call.

10
SX-200 ICP CX/CXi Technician’s Handbook
Figure 1: Basic SX-200 ICP System (CXi controller shown)

11
Introduction
DSP configurations
The table below lists some DSP requirements for the system. The
requirements are guidelines only; the actual number of DSPs needed
depends on the intended use of the system. The DSP Configuration
Option (Form 4, Option 132) to use with the CX/CXi is BUSINESS 1 as
shown in Table 3: Table 3: DSP Configurations
DSP Configuration Without Compression With
Compression
Base System (2 total) 3 three-party conf.
4 voice mail ports
0 G.729 channels
24 IP phones
8 ONS phones
12 LS/CLASS trunks
0 T1 ccts
Base + T1/E1 Combo
(3 total) 10 three-party conf. 16 voice mail ports
0 G.729 channels
64 IP phones
24 ONS phones
12 LS/CLASS trunks
24 T1 or 23 PRI ccts
Base + Dual DSP
(4 total) 10 three-party conf. 16 voice mail ports
0 G.729 channels
40 IP phones
40 ONS phones
16 LS/CLASS trunks
0 T1 ccts
3 three-party conf.
4 voice mail ports
8 G.729 channels
40 IP phones
8 ONS phones
12 LS/CLASS trunks
0 T1 ccts
Base + T1/E1 Combo +
Dual DSP
(5 total)
10 three-party conf.
16 voice mail ports
0 G.729 channels
80 IP phones
100 ONS phones
12 LS/CLASS trunks
24 T1 or 23 PRI ccts
10 three-party conf.
16 voice mail ports
8 G.729 channels
80 IP phones
100 ONS phones
12 LS/CLASS trunks
24 T1 or 23 PRI ccts
Base + Quad DSP
(6 total) 10 three-party conf. 16 voice mail ports
0 G.729 channels
80 IP phones
100 ONS phones
36 LS/CLASS trunks
0 T1
10 three-party conf.
16 voice mail ports
8 G.729 channels
80 IP phones
56 ONS phones
36 LS/CLASS trunks
0 T1
(Page 1 of 2)

12
SX-200 ICP CX/CXi Technician’s Handbook
Base + T1/E1 Combo +
Quad DSP (7 total) 10 three-party conf. 16 voice mail ports
0 G.729 channels
100 IP phones
100 ONS phones
16 LS/CLASS trunks
24 T1 or 23 PRI ccts
10 three-party conf.
16 voice mail ports
16 G.729 channels
100 IP phones
100 ONS phones
16 LS/CLASS trunks
24 T1 or 23 PRI ccts
Notes:
1. The number of conference, voice mail, and compression
resources is fixed by the purchased option and the number of
DSP devices available; the other values are adjustable.
Compression alters the number of resources available for the
system. For example, by adding 8 compression resources to a
system with 4 DSPs total, the maximum number of three-party
conferences drops to 3 and the maximum number of voice mail
ports drops to 4.
2. The controller supports the G.711 and G.729a audio codecs.
-The G.711 PCM audio codec for 56/64 kbps generally
provides the best voice quality and is comparable to
TDM-type connections.
-The G.729a audio codec for 8/13 kbps provides a good
reduction in bandwidth with only minor loss in voice quality.
-A purchasable MOSS option (Option 120, Number of
Compression Resources) controls the number of G.729a
codecs available to IP devices in the system. Compression
enables more devices to share the available bandwidth. The
option is purchasable in multiples of 8 to a maximum of 16.
The default value is 0. The quantity entered must exactly
match the quantity on the MOSS sheet.
3. A hard drive is strongly recommended for systems that have more
than eight voice mail ports or when Record a Call is frequently used.
4. The base CX/CXi contains an Analog Main Board (AMB) that
supports 4 ONS and 6 LS circuits. By installing an Analog Option
Board (AOB), capacity doubles to 8 ONS and 12 LS circuits. The
AOB does not require extra DSP resources.
Table 3: DSP Configurations (continued)
DSP Configuration Without Compression With
Compression
(Page 2 of 2)
