Nespresso Aeroccino 4 User manual

AEROCCINO 4

EN 2

www.nespresso.com/recipes



















Overview

Lid

Seal

Whisk

Spring

Jug

Cold froth

Hot milk

Hot froth for Cappuccino (airy foam)

Hot froth for Latte Macchiato (dense foam)

10 Bottom connector

11 Base connector

Content

Overview 2

Safety Precautions 3

Milk preparation 7

Cleaning and maintenance 11

Troubleshooting 13

Speciﬁcations 14

Warranty 14

Disposal and Environmental Protection 15

Safety Precautions

CAUTION / WARNING

ELECTRICAL DANGER

DISCONNECT DAMAGED SUPPLY CORD

CAUTION: These instructions are part of the device.

Carefully read all instructions and all safety

instructions before operating the device. Save these

instructions and pass them on to any subsequent owner.

Avoid risk of fatal

electrical shock and ﬁre

• Only plug the base into a suitable, earthed power

socket. Make sure that the voltage of the power source

is the same as that speciﬁed on the rating plate.

• The device must only be used with the base provided.

• The use of accessory attachments is not recommended

for the device and may result in ﬁre, electric shock or

injury.

• To disconnect the device, stop any preparation, then

remove the plug from the power socket.

• Disconnect by pulling out the plug and not pulling the

cable, as this may damage the cable.

• Do not pull the cable over sharp edges, clamp it or allow

it to hang down. Keep the cable away from heat and

moisture.

• To avoid hazards, never place the device on or beside

hot surfaces, for example, radiators, stove tops, gas

burners or similar.

• Do not operate the device with a damaged cable or plug

or if it has malfunctioned, been dropped or is damaged

in any manner. A damaged cable, plug or device can

cause electric shocks, burns and ﬁre. Return device to

EN Safety Precautions

the nearest authorised service facility for examination,

repair, or electrical or mechanical adjustment.

• Short power-supply cords reduce risks resulting from

becoming entangled in or tripping over a long cord.

• Longer (or detachable) cords may be used if care is

exercised in their use, and:

1) the marked electrical rating is at least as great as the

electrical rating of the device

2) a grounding-type 3- wire cord is used

3) cord (s) is arranged so that it will not drape over the

counter top or table top, where it can be pulled on or

tripped over by anyone.

• If an extension lead is required, use only an earthed cable

with a conductor cross-section of at least 1.5 mm2.

• This device is intended to be used in households,

farm houses and similar applications only such as

staff kitchen areas in shops, ofﬁces and other working

environments, by clients in hotels, motels and other

residential type environments; bed and breakfast type

environments.

Avoid possible harm when operating the device

• Always keep the lid closed during use.

• Scalding may occur if the lid is removed during use.

• Extreme caution must be used when moving a device

containing hot liquids.

• Avoid contact with moving part.

• If the device is dropped do not use it anymore. There

is a risk of water entering the electrical compartment

through any small cracks generated by this incident. Unit

is not dishwasher safe if dropped.

• Never leave the device unattended during operation. The

device is only for use by persons who have sufﬁcient

experience and knowledge and are physically, sensory,

and mentally able to operate the device safely in

accordance with these instructions.

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capacities or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety.

• Children should be supervised to ensure that they do not

play with the appliance.

• Keep the device and its cord out of reach of children

under the age of 8 years old.

• Do not use outdoors.

• Do not use the device for anything other than its

intended use.

• The device is intended to prepare beverages according

to these instructions. No liability is accepted for other

purposes, faulty operation or non-professional repairs.

Guaranteed services are also excluded in such cases.

• Do not open the device. Hazardous voltage inside.

• To protect against ﬁre, electric shock and injury to

persons do not immerse cable, plugs and base in water

or other liquid.

• Care should be taken when the device is used by or

near to children.

• Do not place the device in a cabinet when in use.

• For perfect foam, use refrigerated UHT or pasteurized

milk skimmed or semi-skimmed (approximately 4-6 °C).

• You can use soy or almond or oat drink for your

preparations. For people with lactose intolerance or milk

allergy we would recommend having a separate device.

• This equipment is not suitable for use with other

products such as enriched milks, reconstituted

powdered milks or ﬂavoured milks.

EN Safety Precautions

• Avoid spillage on the connector.

• Heating element surface is subject to residual heat after

use.

Cleaning

• Unplug device when not in use for a long period and

before cleaning. Allow to cool down before putting on or

taking off parts, and before cleaning the device. Remove

the device from the base before cleaning.

•

Please make sure the bottom of the

device and area underneath the base is

dry, especially the connector area, prior

to use. Electricity and water together can

cause a fatal electric shock.

• Never immerse the base in water. Electricity and water

together can cause a fatal electric shock.

• All the components of the device, including the jug, are

dishwasher resistant, with the exception of the base

(base includes cable and plug), but cannot be washed

at a temperature higher than 70 °C. Please check your

dishwasher main cycle temperature prior to use.

SAVE THESE INSTRUCTIONS

Milk preparation

WARNING: Risk of electrical shock and ﬁre! Make sure the underside of the device and area underneath the base

is dry. Do not operate with a damaged cable or plug or if it has malfunctioned, been dropped or is damaged in

any manner. A damaged cable, plug or device can cause electric shocks, burns and ﬁre.

TIPS: For optimal milk froth use semi skimmed, refrigerated (4-6 °C) milk. Milk which has been frozen will not froth. For hygiene and machine maintenance reasons: only use freshly

opened, refrigerated, heat treated milk (pasteurised or UHT); do not use enriched milks, reconstituted powdered milks or ﬂavoured milks; do not add syrups, sugar, chocolate powder or

other substances into the jug. These can damage the coating during use. You can use soy, almond or oat drink for your preparations. Warning: Plant-based beverages contain allergens (soy,

almond, gluten) and should be handled carefully by persons suffering from food allergies. The volume of froth depends on the nature of the beverage used, and its temperature.

EN Milk preparation

Fill the device up to one of the two «Max» level indicators:

Lowest “Max foam” level indicator (120 ml) is for hot and cold milk froth preparations. Highest “Max

milk” level indicator (240 ml) is for hot milk preparation only. Minimum level volume of “milk foam”.

Cover the whisk to reach the minimum level volume of “milk foam”.

Clean before the ﬁrst use and after each use

according to the cleaning instructions. Place the

whisk in the jug.



Maximum foam Maximum milk

NOTE: The milk froth volume depends on the type of milk that is used and its temperature.

Put the lid on the device. Make sure the connector is dry

before you plug the device to the base. When the four buttons

illuminate, the device is ready to use.



Pour the prepared milk into the cup. Only use non-metallic spoons to collect the foam in

the jug. For hot and cold milk froth, preparation takes approx. 80 sec.

Device turns off automatically after 1 minute of non-use. Press any of the 4 buttons to

switch ON the device.

Choose your milk preparation by pressing the dedicated button to start. Button pressed

blinks during preparation and becomes steady on when the preparation is ready. For

hot milk, preparation takes approx. 150 sec. Preparation can be stopped at any time

by pressing the blinking button or removing the device from the base.

 



Button Preparation Function Recipes options Recipes Instructions Maximum Capacity Level indicator

Cold milk froth Frothing only Iced Cappuccino,

Iced Latte Macchiato

Iced Cappuccino: 3 big ice cubes + Coffee: 40 ml + cold

milk froth: 60 ml / Iced Latte Macchiato: 3 big ice cubes +

Coffee: 40 ml + cold milk froth: 120 ml

120 ml of milk MAX FOAM

Airy hot milk froth Frothing and heating Cappuccino Coffee: 40 ml + milk froth: 60 ml 120 ml of milk MAX FOAM

Dense hot milk froth Frothing and heating Latte Macchiato Coffee: 40 ml + milk froth: 120 ml 120 ml of milk MAX FOAM

Hot milk Heating only Hot chocolate,

Caffè Latte

Hot chocolate: cocoa powder + generous amount of hot

milk / Caffè Latte: Coffee: 2 x 40 ml + generous amount

of hot milk

240 ml of milk MAX MILK

Milk preparation

Cleaning and maintenance

CAUTION: Clean the jug, whisk and lid immediately after each use according to the cleaning instructions. Remove

with care, rinse with cold water immediately to cool down the device to avoid risk of burns. In case the base needs

to be cleaned unplug it ﬁrst and use only a damp cloth. Do not immerse the base in water. Do not put the base in the

dishwasher. Do not use abrasives cleaning materials, sharp objects or brushes which may scratch/ damage the jug

coating. Do not place directly over the dishwasher pin as it may cause damage to inner coating. If the bottom part

of the jug is wet, dry it before putting it back in contact with the base connector. Do not immerse the device in water

or clean it with water if the cable or the plug is damaged or if it has malfunctioned, been dropped or is damaged in

any manner. A damaged cable, plug or device can cause electric shocks, burns and ﬁre. Return device to the nearest

authorised service facility for examination, repair, or electrical or mechanical adjustment.

Remove the jug from the base.

Remove the seal from the lid.

Remove the whisk from the jug, and

the spring from the whisk.



Dry all device parts with a clean towel,

cloth or paper and reassemble all parts.



Make sure the connector and the

recessed areas are clean and dry before

next use.



A: Dishwashing: put all parts except the base in the dishwasher at maximum 70 °C.

B: Hand washing: wash inside the jug, seal, lid, whisk and spring with mild detergent and rinse with

warm / hot water. Do not use abrasive material that might damage the surface of the equipment.



Cleaning and maintenance

NOTE: It is recommended to wash the jug, lid, seal, whisk and spring in dishwasher for more efﬁcient

cleaning.

The device does not

start

- Ensure the jug is correctly positioned on the base, and the whisk is correctly positioned in the jug.

Device will start only if the connectors are dry.

Quality milk froth not

up to standard or milk

is burnt

- For optimal milk froth, use cold and semi skimmed milk at refrigerated temperature (about 4-6° C). To guarantee hygiene conditions, use heat treated milk

(pasteurized), refrigerated & freshly opened only.

Milk which has been frozen will not froth.

Be sure the jug and the whisk are clean.

- Do not use enriched milks, reconstituted powdered milks or ﬂavoured milks.

Fast red lights blinking

on the 4 buttons

(device error)

- The device is too hot: clean the jug under cool water.

- Not enough milk: ﬁll the device up to one of the two “max” level. All the 4 buttons (1 blue and 3 red) blink rapidly.

- Clean the device and check that there is no water on the base.

- If no change, then please call Nespresso.

Milk overﬂows - For milk froth preparation ensure the milk does not exceed the MAX FOAM level (120 ml).

- For hot milk preparation, ensure the milk does not exceed the MAX MILK level (240 ml).

Troubleshooting

Aeroccino 4 4194

220-240 V, 50-60 Hz, 410-490 W

~ 0.85 kg

Speciﬁcations

Warranty

Nespresso warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. During this period, Nespresso will either repair or replace,

at its discretion, any defective product at no charge to the owner. Replacement products or repaired parts will be guaranteed for only the unexpired portion of the original warranty or six months,

whichever is greater. This limited warranty does not apply to any defect resulting from accident, misuse, improper maintenance, or normal wear and tear. Except to the extent allowed by applicable

law, the terms of this limited warranty do not exclude, restrict or modify, and are in addition to, the mandatory statutory rights applicable to the sale of the product to you. If you believe your

product is defective, contact Nespresso for instructions on where to send or take it for repair. Please visit our website at www.nespresso.com to discover more about Nespresso.

Disposal and Environmental Protection

Disposal

Your device contains valuable materials that

can be recovered or recycled. Separation of the

remaining waste materials into different types facilitates

the recycling of valuable raw materials. Leave the device

at a collection point. You can obtain information on

disposal from your local authorities.

הביבסה תנגהו קוליס

קוליס

םיגוסל םירתונה תלוספה ירמוח תדרפה .רוזחמל וא רוזחשל ןתינה ךרע ילעב םירמוח ליכמ ךלש רישכמה

לע עדימ לבקל לכות .ףוסיא תדוקנב רישכמה תא וריאשה .ךרע ירקי םלג ירמוח רוזחימ לע הלקמ םינוש

.תימוקמה תושרב וא וסרפסנ רתאמ קוליס

תיָרֲחַא

לש בויח לכ אללו התעד לוקיש יפ לע ,םוגפה קלחה / רישכמה תפלחה וא ןוקיתל גאדת וסרפסנ ,וז הפוקת ךלהמב .ויקלחב וא רצומב רוצי ימגפ ןיגב השיכרה םוימ הנש ךשמל הפקת הז רצומל תוירחא

הפקת הניא תוירחאה .עבוקה אוה םיינשה ןיבמ ךוראה ןמזה קרפ ,םישדוח השיש ךשמל ןיפוליחל וא תירוקמה תוירחאה תפוקת םות דע קר תוירחא תחת ויהי םינקותמה וא םייפולחה םיביכרה .שגורה

וא םיליבגמ ,םיללוש םניא וז תלבגומ תוירחאל םיאנתה . הז ךירדמב תוטרופמה תוארוהה יפל אלש שומיש וא המיאתמ אל הקוזחת ,םלוה יתלב שומיש ,הליפנ בקע רישכמב םירצונה םימגפ לש פירקמל

רשק ורצ ,םכידיבש רצומב והשלכ םגפ שיש םינימאמ םתא םא .קוחב םיעובקה ,ןפוד יאצוי םירקמב דבלמו ןהל ףסונב םידמוע אלא ,הז ןיעמ רצומ תשיכר יבגל קוחב תונגועמה הנוקה תויוכז תא םינשמ
