Nogueira SILONOG-F User manual

Instructions Manual
3
Dear Owner;
The pictures presented in this manual are purely
illustrative. In order to ease the visualization, the
images might show assembled or disassembled safety
protections. Do not use the machine without the respective
protections, under any circumstances.
The content of this manual cannot be reproduced without
previous, written authorization by the Dealer.
Congratulations for acquiring a NOGUEIRA’S
MIXER WAGON. A product of the nest quality,
specially designed to fulll your needs.
This manual provides the instructions for the proper
operations, preventative maintenance and safety,
which, when observed properly, will ensure the
correct running and durability of your Mixer Wagon.
Before operating the machine for the rst time,
read all the safety instructions as well as all further
information in this Manual.
Nogueira Agricultural Machinery will always be at
your disposal to get back to you on any enquiries,
o󰀨ering e󰀩cient and permanent technical support.

Instructions Manual
4
TABLE OF CONTENTS
Identication ........................................................5
Environment ........................................................5
Safety Precautions ..............................................6
General Safety.....................................................6
Safety in preparation ...........................................7
Operational Safety...............................................8
Safety in Maintenance.........................................9
Safety in Transportation.....................................10
Personal Safety .................................................10
Safety Stickers...................................................12
Safety Stickers...................................................13
Knowing how to Operate the Machine...............14
Truck or Wagon Transportation .........................15
Application.........................................................16
Advantages .......................................................16
Functioning........................................................17
Activation...........................................................17
Items that come with your Bagger.....................17
Tractor Coupling ................................................18
Uncoupling.........................................................19
Transportation when coupled to a tractor ..........19
Levelling ...........................................................20
Cutting and Cardan shaft Coupling ...................21
Choosing a proper place for bagging ................24
Placing the bag in the Bagger ...........................25
Closing the bag..................................................30
Hose Coupling...................................................31
Placing the conveyor belt in working position....32
Braking and Compaction ...................................33
Adjusting the Brakes..........................................34
General Recommendations...............................35
Before turning on the machine ..........................36
Operation...........................................................36
Getting the bag ready........................................37
Cutting the bag ..................................................38
Turning o󰀨 the Bagger.......................................38
Maintenance......................................................39
Chain Maintenance............................................40
Tensioning the Conveyor belt ............................41
Brake uid change.............................................42
Bleed of braking system ...................................43
Lubrication.........................................................45
Transmission Chain (a) Lubrication ...................... 47
Tire Maintenance...............................................47
Conservation .....................................................48
Technical Characteristics...................................49
Maintenance Program .......................................50
Maintenance Program .......................................51
Key Gauge Table...............................................53
Torque Table......................................................54
Warranty Terms .................................................57

Instructions Manual
5
We constantly strive to protect the environment,
from the development of our products to the use of
processes and materials, which are environmentally
friendly.
Protecting and respecting the environment is the
responsibility of everyone. Dispose used uids and
lubricants, old tires, packaging etc. according to
current laws. Never dispose these products directly
into the environment! Share these pieces of advice,
making other people aware of the importance of the
environment preservation!
ENVIRONMENT
Your Bagger is identied with a serial number, found
on the tag xed on the machine body.
Write down your machine serial number:
1- By sending messages or requesting Nogueira
Technical Support, always inform your serial
number and the machine model, found on the
identication tag.
2 - By replacing parts, always make use of
genuine Nogueira items. Only genuine parts are
manufactured in accordance with the pictures,
materials and project specications, going through
a rigorous standard of quality.
IMPORTANT!
IDENTIFICATION

Instructions Manual
6
The word CAUTION indicates situations where
there is potential risk or hazard, and, if not avoided,
might cause serious injuries
The Bagger operator must be familiar
with operating and maintenance
procedures, as well as safety
information, found in this manual.
You will nd good practices regarding
safety, which must be respected
when using the machine. We
recommend the careful reading of
this material before using it.
We remind you that health
preservation and physical integrity
of people must always come rst.
In case there are any enquiries,
please get in contact through your
Authorized Dealer or our Technical
Support Department.
SAFETY ALERT
SYMBOL
The word DANGER indicates a clear risk situation,
whose consequences, if not avoided, might cause
very serious injuries or even death.
DANGER Warning!
In this Manual and the stickers found
on the machine, you will nd the
safety alert symbol, accompanied
by the warnings CAUTION and
DANGER, followed by specific
instructions. These instructions are
intended to safeguard your own
safety as well as the other people’s,
who work or are found standing
near the machine. When you nd
the safety warnings in this Manual,
read them carefully and follow the
instructions that follow rigorously.
CAUTION Warning!
Read this Instructions Manual before you turn on
the machine, paying attention and respecting all
the safety uses and recommendations during the
operation. SHARE THIS INFORMATION WITH
OTHER USERS.
Every equipment must be solely used to
conceived ends, according to specications in
this manual. The equipment use in applications
that have not been mentioned here is considered
inadmissible and is not authorized by the
manufacturer.
Adaptations or use of non-original parts
compromise the functioning and shorten the
machine service life, as well as putting the
operator at risk and result in loss of warranty.
Observe and pay attention to all safety
recommendations in this manual. Lack of
attention during the operation might result in a
serious accident.
Keep a rst-aid kit at hand (and be sure you
know how to use it in case there is an accident).
GENERAL SAFETY
SAFETY PRECAUTIONS

Instructions Manual
7
SAFETY IN THE PREPARATION
Make sure the machine is
appropriately coupled to the
tractor, and the coupling pin is
properly locked.
Before you initiate the operation,
perform a machine general check-
up, observing if there are no loose
bolts, worn parts, cracks, leaking,
loose chains etc. Make sure to
always make necessary repairs,
paying attention to instructions in
this manual.
When you uncouple the machine
from the tractor, choose a
flat surface, in order to ease
the procedure and the follow
coupling. Make sure the machine
is stationary and, if necessary, add
shims to the wheels.
Be especially careful when you
couple and uncouple the machine
to the tractor. Observe if the
coupling pins are securely locked.
Always make use of counter
pins to avoid that pins loosen
accidentally.
In order to provide a better
understanding, certain images
or pictures are presented without
their safety protections. However,
the machine can never be used
without them. Before you turn
the machine on, check if all the
protections are in place.
Fix the edges from the cardan
shaft protection covers in xed
points of the tractor and the
implement, through specific
chains for this purpose, so that they remain
static, without rotating. Never use the cardan
shafts without their protection covers.

Instructions Manual
8
OPERATIONAL SAFETY
Never operate the machine in
case you have ingested alcoholic
beverages or taken medicine,
which might change your state of
alert and coordination. Keep alert
and focused during the operation
and always act with good sense.
A moment of recklessness or
inattention might result in a
serious accident.
Before you turn on the machine,
verify if there are no tools or other
objects on it.
Observe the surroundings of
the machine before you put it
in operation. Keep animals and
people at a safe distance. Special
care must be taken if there are
children nearby.
Due to its practical necessity,
the endless screw is not fully
protected, which requires special
care during its functioning. Never
approach or touch the screw when
the machine is working.
It is forbidden to stand on the
machine when it is working or
being used for transportation.
Whenever it is necessary to climb
on the machine to perform any
adjustments or repair, turn off
the tractor PTO and wait until all
the components are completely
stationary.
Do not allow children or curious people to
approach the machine when it is in operation or
during maneuvers.
Keep all the covers and protections in their
proper places and do not operate the machine
without them.
When you maneuver the machine coupled to
the tractor, observe if there is enough space to
perform the movements.
Always drive the tractor in compatible speeds, in
accordance with eld or road conditions and the
tractor size. Avoid sudden maneuvers, especially
in rough terrain. In order to tow a load when
its weight is heavier than the tractor’s, do not
exceed the maximum speed of 16kmph.
Never operate the machine for extended periods
in enclosed places or without ventilation. Carbon
monoxide gases expelled though the tractor’s
exhaust system are extremely toxic.
The tractor must always be maneuverable. Be
sure to have enough ballast so that the tractor’s
front tires have su󰀩cient contact with the ground.
Pay special attention when you transit through
steep terrain when the machine is coupled.
In case you notice any imbalance, reduce the
speed. When you are going down a steep road,
always keep the tractor engaged.
This equipment is dangerous for children and
people who are not familiar with its operations.
Do not allow them to approach the machine
when it is working.
In case you notice any abnormality in its
operation, vibrations, unusual noises etc., turn
o󰀨 the machine immediately, check and eliminate
the source before you turn it back on.

Instructions Manual
9
SAFETY IN
TRANSPORTATION
Turn off the tractor PTO, the
engine and remove the key
from the ignition before you
regulate, lubricate or perform
any maintenance services in
the machine. Never perform any
repairs or adjustments when the
machine is on.
Always put all hydraulic controls
of the tractor with gear lever in
neutral before you turn it o󰀨 or
work on the hydraulic system.
Make sure all systems components
are kept in good state.
Replace immediately damaged,
crushed or spoiled hoses.
In case you have been injured
by high-pressure hydraulic uids,
seek medical help immediately.
Serious infection or a toxic reaction
might occur when hydraulic uid
gets in contact with the skin
surface.
Make use of appropriate protection
on hands and eyes when you
check if there are any high-
pressure leaks in the hydraulic
system. Use a piece of wood or a
card instead of using your hands
to isolate and identify a hydraulic
uid leakage.

Remember: moving components due to inertia keep
moving for longer even when the machine is turned
o󰀨. Before you touch any machine parts, turn o󰀨
the power supply, check and listen if there is no
evidence of movement. Only touch any machine
components if you are absolutely sure that they are
stationary. Always be alert!
HYDRAULIC SYSTEM
If it is necessary to work on the machine when
it is suspended by the hydraulic system, you
must lean the machine in a safe way. Hydraulic
systems can lower by themselves, or due to leaks
and might cause an accident.
Do not lean the machine on concrete blocks,
hollow bricks or any other supports that might
crumble by the e󰀨ect of extended loads.
Never work under a machine only suspended by
a jack. Always use a safe support.
Always put all hydraulic controls of the tractor
with gear lever in neutral before you turn it o󰀨 or
work on the hydraulic system.
Make sure all systems components are kept in
good state.
Replace immediately damaged, crushed or
spoiled hoses.

Instructions Manual
10
Personal safety as well as other people’s is
one of our major concerns in the design and
development of a machine. However, every year
there are a lot of accidents that could have been
prevented. They happen mainly due to lack of
attention and observation of safety rules during
the operation. Read this manual carefully and
keep alert all the time.
Never operate the machine if you are under
the e󰀨ect of alcoholic beverages, medicine or
drugs that might harm your alert state or your
coordination.
Wear Personal Protective Equipment – PPE
– when you operate the machine. Prolonged
exposure to noise might cause harm or hearing
loss.
Dress appropriately when you operate the
machine – tying long hair and not wearing
loose-tting clothes is highly recommended.
Take o󰀨 rings, necklaces and other objects that
might get stuck in the machine parts or moving
components. Loose-tting clothes and long hair
might get caught by mechanisms in operation.
Always keep your hands at a safe distance from
moving parts.
Do not enter or allow anyone to enter the
bag, since there is risk of imprisonment and
su󰀨ocation.
Never attempt to clean or clear the endless screw
when the machine is turned-on. This procedure
can only be performed when the PTO is o󰀨, the
ignition key is removed from the tractor and the
machine is completely stationary.
Never put your hands in the grinding mill when
the machine is on.
Transportation of the machine
while it is coupled to the tractor
must not be done on public roads
and highways. This practice must
be limited to properties and rural
areas. Check the Department of
Transportation on the rules and
applicable laws in your region, as
well as the existing possibility of
transporting the machine with the
tractor on certain parts of roads.
Ask for guidance, authorization
and procedures in writing.
Keep alert regarding the height of
transportation, especially under
viaducts.
Never exceed a safe transportation
speed. Reduce your speed and be
careful in rough terrain as well as
in winding roads. Always drive
the tractor in compatible speeds,
in accordance with eld or road
conditions.
Never allow people to stand on
any parts of the machine while it
is being used for transportation
or operation.
When you transport the machine,
be extra cautious with the power
grid, since there is risk of shock if
there is contact with the electrical
wiring. Keep away from high
voltage power lines. Risk of
electrocution. (Death caused by
electrical energy).
Do not drink and drive.
TRANSPORTATION SAFETY PERSONAL SAFETY

Instructions Manual
11
Moving components due to inertia
keep moving for longer even when
the machine is turned o󰀨. Before
you touch any machine parts,
turn o󰀨 the power supply, check
and listen if there is no evidence
of movement. Only touch any
machine components if you are
absolutely sure that they are
stationary. Always be alert!
Never enter the screw conveyor
(endless screw) when the machine
is working. There is imminent risk
of crushing by the propellers.
Turn o󰀨 the tractor and remove
the key from the ignition before
you perform any maintenance
of screw.

Instructions Manual
12
Read this Instructions Manual before you turn on
the machine.
Make sure all the moving parts are completely
stationary before you touch them.
The tractor must be turned o󰀨 and the key removed
from the ignition in order to perform any kinds of
maintenance, adjustment, lubrication, cleaning etc.
in the machine.
Keep away from the articulation area, between the
machine and the tractor.
SAFETY STICKERS
Do not open or remove covers and safety protections
when the machine is working. Keep your hands at a
safe distance from the belts and such parts, which,
when in motion, might cause serious injuries.
Never approach your hands when the conveyor
belt is moving.

Instructions Manual
13
Never approach your hands of the endless screw
when it is moving.
Do not use the cardan shaft without its safety
protection.
SAFETY STICKERS
Number of rotations per minute.

Instructions Manual
14
1
2
5
6
KNOWING THE BAGGER
13
8
4
11
12
3
7
10
8 Jack
9 Conveyor Belt Tensioner
10 Right wheel
11 Screw (Endless screw)
12 Tray
13 Hydraulic pump
1 Conveyor Belt
2 Hydraulic engine
3 Front cover
4 Manometer
5 Brake
6 Hitch
7 Cardan Shaft
9

Instructions Manual
15
TRUCK TRANSPORTATION
The Bagger coupled to a tractor must only transit
within the property, observing the maximum speed
of 5km/h. Whenever it is necessary to transport the
machine over long distances, or whenever there is
the need of using it on public roads, transportation
must be done on a truck or wagon. The machine
must be completely inside the bodywork.
It is essential that the hitch is xed on the bodywork
oorboard, as well as adding wooden shims, which
must be xed on the oorboard. Use a su󰀩cient
supply of cables, moorings, ropes etc., to immobilize
the load and keep it stable over the truck or wagon.

Instructions Manual
16
APPLICATION
ADVANTAGES:
Designed to bag chopped green material, used for
daily treatment of your animals, in polyethylene
bags, in a safe and economical way. Ideal for
bagging maize forage, sorghum, sunflower,
sugarcane etc., pastures such as alfalfa, summer
or winter crops, such as barley, rye, oat etc.
The silage process in bags guarantees a better
sealing, keeping the nutritious qualities and
conserving the silage for longer.
Daily extraction, only as necessary, to treat your
cattle, avoiding leftovers and wastes.
It maintains the quality after the feedstock
extraction, due to its opening and closing feature.
It is easy to seal when the bags are eventually
open.
Storage in a strategic place in the property,
providing labor cost savings as well as
transportation in the silage making process.
It is an excellent tool to reduce costs of cattle
feed.
It increases protability of breeding and conning
activities.
It solves the problem of storing certain types
of forage (for cattle consumption) for a longer
period.

Instructions Manual
17
The forage is unloaded onto the conveyor belt
that transports it, and unloads it inside the screw
conveyor compartment. The screw transports it and
pressurizes the forage towards the bag. When it is
pressurized, the material becomes more compact
and pushes the set machine/tractor, which moves
forward. As the machine shifts, the folds of the bag
gradually loosen, and the bag is made.
The Bagger is activated through the PTO of
agricultural tractors, with horsepower ranging from
45, 540RPM.
Instructions Manual (01)
Elastic Clip (01)
Cardan Shaft (01)
FUNCTIONING
ACTIVATION
ITEMS THAT COME WITH THE BAGGER
NOTE!
The feeding of this Bagger, in general, is performed
by Forage Wagons or similar ones.
In order to guarantee the maximum compaction
and elimination of air in the process, the Bagger
features a system of disk brakes, hydraulically
activated, with pressure control to provide uniform
braking on both wheels.
IMPORTANT!
The use of a tractor with very superior recommended
power (very heavy) will demand excessive e󰀨orts
from the machine, mainly the screw, and might
seriously damage it.

Instructions Manual
18
The Bagger operates coupled to the tractor’s
drawbar. When you couple it, proceed as follows:
Choose a at and levelled surface, since it makes
the procedure easier and safer.
If it is impossible to perform the coupling on a at,
leveled surface, you should add shims to the wheels
in order to make the machine stationary.
The hitch (E) can be mounted in three di󰀨erent
height positions. In order to change its height,
remove the four nuts, washers and xing bolts (F).
Place the hitch in its desired position and xate it
with the nuts, washers and bolts (F).
TRACTOR COUPLING
1. Approach the tractor carefully, aligning the
drawbar with the machine hitch. The drawbar
must t the Bagger’s hitch.
2. In order to couple the Bagger to the drawbar,
put the hitch pin (B) and lock it with the counter-
pin (C)
3. After coupling, retract the jack (D), turn it and
put it in the rest position.
IMPORTANT!
After coupling, make sure that the header is
securely locked to the tractor’s drawbar. Always
lock it with a counter-pin (C). The accidental
Bagger uncoupling, when it is being towed,
might result in a serious accident.
CAUTION!
Check if the hitch is securely coupled and if it is not
loose. If necessary, adjust the height of the hitch.
C
F
B
E
D

Instructions Manual
19
Choose a flat and leveled surface to park the
Bagger. In case this is not possible, you must add
shims to the wheels to ensure that the machine is
completely stationary.
1. Uncouple the hoses of the valves from the
tractor’s remote control.
2. Unlock the jack and lower it to the ground.
3. Using the jack, lift the hitch a little, until you
soften the weight over the tractor’s drawbar.
4. Remove the lock (C) and the coupling pin (B).
5. Move the tractor, so that it is uncoupled from
the machine.
UNCOUPLING
TRANSPORTATION WHEN COUPLED TO
THE TRACTOR
IMPORTANT!
Transportation of the machine while it is coupled
to the tractor must not be done on public roads
and highways. This practice must be limited to
properties and rural areas. Check the Department
of Transportation on the rules and applicable laws
in your region, as well as the existing possibility of
transporting the machine with the tractor on certain
parts of roads. Ask for guidance, authorization and
procedures in writing.
When you transport the Bagger coupled, put the
conveyor belt in the transportation position.
Never allow the presence of people near the
header with coupling adjustment or onto any parts
of the machine during transportation.
Remember to release the brakes from the Bagger
before you start moving.
Do not manoeuver when the cardan shaft is
coupled and the PTO is on.
D
B
C

Instructions Manual
20
It is recommended for the Bagger to be with its rear
end slightly tilted downward (with the bag by the
side). This will allow the bag to be manufactured
without any folds.
Before you start the operation, observe the machine
laterally and, if necessary, the height of the hitch (E)
can be adjusted. Instructions on the item - Coupling
to the Tractor - in this manual.
LEVELLING
E
