Nogueira VFN 5000 User manual

Forage Wagon - Vagónes Forrajeros
VFN 5000 / 8000 / 10000

Dear Owner
Congratulations on your purchase of the NOGUEIRA Forage Wagon. This
product is the highest quality, specially designed to meet your needs. This
manual contain operating instructions and when properly abided by assure
good operation, safety, and durability of your NOGUEIRA Forage Wagon.
We recommend carefully reading it before beginning to operate the
machine.
There is an identification plate fastened on the machine, which displays the
manufacturing serial number. Write this number on the guarantee certificate
in the end of this manual. This information is extremely important for
identifying your machine.
Nogueira S/A is always at your disposal to answer any questions or doubts
and supply efficient and permanent technical support.
The images displayed in this manual are only for illustrative purposes. Thus to facilitate
your viewing, the images show cutaway or the safety shielding removed to display it
more clearly. Do not operate the machine under any circumstances without these
respective protective shields.
3
FORAGE WAGON
English

4Instruction Manual
Index
Introducing the forage wagon
DISPENSER
JACK
SINGLE WHEEL
TANDEM WHEEL
DRIVESHAFT
REAR DOORS
CONVEYOR BELT
DECOMPACTOR
ROLLERS
TOW HITCH
SIDE UNLOADER COMING
FROM THE HELIX TRANSPORTER
OR CONVEYOR BELT
fig.01
fig.02
Introduction 03
Introducingtheforagewagon 04
Environmentalconservation 05
Safety 06
Safetyadhesivelabels 09
Application/Actuation 10
Couplingtothetractor 11
Driveshaftpreparationandcoupling 12
Heightadjustmentofthe(VFN5000)unloader 14
Sideunloader(wagonequippedwithpre-driedconveyorbelt) 15
Sideunloader(wagonwithhelixtransporter) 16
Rearunloader(wagonwithpre-driedconveyorbelt) 16
Rearunloader(wagonwithhelixtransporter) 17
Unloaderoptions/Dispenser(optional) 19
Maintenance 21
Safetysystem 22
Conveyorbeltadjustment 23
Practicalguide/Technicalcharacteristics 26
Additionalinformation 27
Technicalassistance 28
Guaranteecertificate 29

Nogueira is continually concerned with the environmental conservation, in the
developmentphase,aswell in the utilization of processes and materials ecologically
appropriateinitsproductionanditsproducts.
PROTECT AND RESPECT THE ENVIRONMENT, remember that conservation is
thesocialresponsibilityofeveryone.Theseconceptsincludecompliancewithlegally
defined disposal of used lubrication products and fluids, old tires, and packaging.
Never dispose of these products or empty packaging in swamplands, lakes, rivers,
puddles etc. Share these recommendations with others and make other people
awareoftheimportanceofconservingtheenvironment.
Environmental conservation
5
FORAGE WAGON
English

Nogueira is concerned about the safety of the
people involved in operating and performing
maintenanceontheForageWagon.
We have considered every detail in designing
the machine, in order to avoid unexpected
accidents which could occur while operating.
We have developed safety shields in order to
eliminatehazardoussituations.
We have defined as primary importance
preserving the health and physical integrity of
thepeople.
Wehavepreparedthismanual, sothatthe user
will become familiar with the Forage Wagon
andthen,operateitmorecorrectlyandsafely.
We recommend carefully reading it before
using it the first time. If the user is in doubt,
please get in touch with us at your Nogueira
dealeroratourTechnicalSupportDepartment.
SAFETYRECOMMENDATIONS
- Read the instructions manual before turning
on the machine. Pay close attention and
respect all the operating and safety
recommendations while operating. SHARE
THISINFORMATIONWITHOTHERUSERS.
- Do not operate the machine while or after
drinking alcoholic beverages or medications
which affect your normal condition. Pay
attention to what you are doing and use your
good sense. Any lack of attention while
operating the machine can result in a serious
accident.
- Disconnect the power take-off, the tractor
motor, and remove the key from the ignition
before performing any adjustment, lubrication,
or any maintenance job on the machine. Never
try to perform any repairs while the machine is
turnedon.Alwayspaycompleteattention!
- Before turning on the machine, check to see if
there are any tools or other objects on the
machineorinsidethewagonbody.
- Look around the machine before turning it on.
Keep animals and spectators away at a safe
distance.Beespeciallyofchildren.
- Dress appropriately when operating the
machine. Tie back long hair and do not wear
clothing which is too loose. Remove rings,
chains, and other elements which could get
stuckinthemovingpartsormechanisms.
- Wear personal protective equipment - PPE -
when operating the machine, as prolonged
exposure to noise can cause hearing damage
or loss. Wear hearing protectors and safety
glasses.
Safety warnings alert on situations that can be
dangerousinsomeway.
They are accompanied by instructions for
protectingtheoperatorandotherusers.
This type warns on dangerous situations and
informs on necessary precautions in order to
avoidanypossibleaccidents.
This warning refers to dangerous situations,
which may result in serious accidents and be
lifethreatening,iftheinstructionsarenotstrictly
abidedby.
SAFETY WARNING
SYMBOL
SAFETY WARNINGS
CAUTIONwarnings!
DANGERwarnings!
Safety
6Instruction Manual

- Never try to clean or remove scraps of products when the machine is turned on. Disconnect from
the power take-off and wait until the machine is completely motionless before touching any part of
themachine.
- Keep away from the conveyor belt, decompactor roller and the unloader helix transporter while
operating.
-Neverputyourhands,feet,oranyotherpartofyourbodynearthemovingconveyorbelt,rollers,or
helixtransporter.
-Whileunloading,stayoutsideoftheareawheretheproductisbeingunloaded.Alwayskeepasafe
distancefromthemachinewhenitisoperating.
- Never touch the chains or gears when the machine is turned on. Keep your hands away from the
movingparts.
- Keep the safety adhesive labels in good condition and legible. Replace them whenever
necessary.
- Keep all the shields and protections in their proper locations and do not operate the machine
withoutthembeinginstalled.
- It is prohibited to stand on the tow hitch, feed mixer, or inside the wagon when it is operating or
transporting a load. Whenever, it is necessary to get on the machine to perform any adjustment,
repair, or manual moving of a store product, disconnect the wagon from the power take-off of the
tractor,removetheignitionkey,andwaitforalltheparts/componentstobemotionless.
-Nevertrytocleanorunblocktheunloaderhelixtransporterortheconveyorbeltwhenthemachine
isturned on.Always turnoffthe tractorand removethe ignitionkey beforeperforming anycleaning
ormaintenancejobonthemachine.
-Donottrytoremovethesafetyshieldswhenthemachineisturnedon.
- Disconnect the power take-off and remove the ignition key from the tractor before stretching the
chainsorunloaderconveyorbelt.
- Moving components, due to inertia, continue moving for some time even after the machine is
turned off. So, before touching any component or part, disconnect the actuation source, look and
listen to see if there is any sign of movement. Only touch the component if you are sure it is
motionless.Alwayspaycloseattention!
-Ifitisnecessarytoworkonthemachinewhenitishydraulicallysuspended,itisnecessarytoplace
it on supports for extra safety. Hydraulic mechanisms can slip without warning or due to leakage
andcauseanaccident.Neverbraceamachineoncementblocksorhollowbricksorothersupports
astheycancrushundertheprolongeffectfromtheheavyload.
-Examinethelocationbeforestartingtowork.Putmarkingsindangerousplacesorwherethereare
obstacleswhichcanbedangeroustooperatingthemachine.
Safety
7
FORAGE WAGON
English

- If you observe any abnormality in the operation: vibrations, different noises etc., turn off the
machineimmediately.Checkandeliminatethecausebeforeturningitonagain.
-Neveroperatethedriveshaftwithoutthesafetyshielding.
- Never operate the machine inside closed environments and without ventilation, as gases are
releasedbythetractormotor,whicharetoxicandextremelyharmfultoyourhealth.
-Thetractormustalwaysbemaneuverable.Placecounterweightsonthefronttirestokeepenough
contactwiththeground.
- Be especially careful when coupling and uncoupling the machine from the tractor. Check to see if
thecouplingpiniswell-latched.Alwaysinstallthecotterpinsothepindoesnotunlatchaccidentally.
- When towing the machine carrying a load; we recommending being careful and slowing down in
ordertoavoidaccidents.
- Pay extra attention when working on sloped terrains. If you notice any imbalance, reduce
acceleration.Alwayskeepthetractorengagedwhengoingdownhill.
- When driving the tractor with the machine on public roadways, obey the current valid legislations
regardingthemaximumheightoftheload,especiallywhengoingunderoverpasses.
- Never leave the tractor when the machine is turned on. Stop the motor, disconnect it from the
powertake-off,engagetheparkingbrake,andremovethekeyfromtheignitionbeforegettingout.
- Comply with and do not exceed the maximum load capacity recommended for your Forage
Wagon.
-Donotusethisequipmentforapplicationswhicharenotmentionedandconsideredunacceptable
in the manual and not authorized by the manufacturer. Making adaptations or using after-market
partscan compromise theoperation, be dangerousto the safetyof the operator,andinvalidate the
guarantee.
-Bepreparedincaseofanaccident.Keepafirst-aidkiteasilyaccessible.Knowhowtouseit.
- Follow the safety recommendations and pay attention. Lack of attention while operating can
causeaccidents.
Safety
8Instruction Manual

Safety adhesive labels
Read the instruction manual before
turning on the machine. Pay close
attention to all the operating and safety
recommendations,inordertoavoidany
unexpected accidents that may occur
whileoperatingthemachine.
Turn off the tractor and remove the key
from the ignition before performing any
maintenance, adjustment, lubrication,
cleaning jobs etc., on the machine.
Thereby you will avoid any accidental
actuation and avoid dangerous
situations that may cause serious
accidents.
Do not stay on the machine while it is
operating or carrying loads. Sudden
jolts, starting, or stopping can cause
falling, causing an accident. Avoid all
dangeroussituations.
Keep your distance and never place
your hands near the moving helix
transporter, as contact can cause a
seriousaccident.
Donotgetclosetothemachineuntilitis
completely motionless. Remember
rotating parts do not stop moving
immediately after turning the machine
off. Some parts continue moving also
unnoticeably,butyoucannotseethem.
Donotopen orremove
covers or safety
shields from the
machine when it is
operating.
Keepyourhandsaway
from chains and other
m o v i n g p a r t s ,
grabbing them and
causeinjuries.
9
FORAGE WAGON
English

Adesivos de segurança
Application
Actuation
Keep away from the articulating area,
between the machine and the tractor.
Sideway movements from the machine
canhityouandcauseanaccident.
Keep your distance
and never place
your hands near the
m o v i n g h e l i x
transporter, as
contact can cause a
seriousaccident.
When operating the harvester, wear
personal protective equipment (PPE).
Prolonged exposure to noise, without
noise protection can cause hearing
loss.
This displays the RPM (revolution per
minute) and the rotation direction of the
powertakeoff.
The Nogueira Forage Wagon was designed for transporting and automatically unloading silage or
dailyanimalfeeddirectlyintoafeedingtrough.ThemachinemaybeequippedwiththeNOGUEIRA
DISPENSER,whichaddsconcentratedanimalfeedandotheradditivestoprovideahomogeneous
andextremelynutritiousmixtureforyoulivestock.
NogueiraWagonsareactuatedbytractorpowertake-offswithaminimum55HPand540RPM.
10 Instruction Manual

Coupling to the tractor
TheForageWagonmustbecoupledtothetractortowhitch.
NOTE:Itcanalsobeuseddirectlyinharvesting,coupletoaNogueiraForageHarvester.
COUPLINGTOTHETRACTOR:
RemovethecouplingpinfromtowhitchA.
DrivethetractortowardsthemachinesothatthetowbarfitsintothetowhitchoftheForageWagon.
InsertthecouplingpinAandlatchB.
IMPORTANT:RemembertoinsertlatchBinthecouplingpin.
NOTES:
Usethejacktoadjusttheheightofthetwohitch.
After coupling, retract the jack and place it in the retracted position. The Wagon with 2 axles is not
equippedwithajack.
fig.03 fig.04
fig.05 fig.06
A
A
B
11
FORAGE WAGON
English

Driveshaft preparation and coupling
Beforeoperatingthedriveshaft,itisnecessarytoverifyifthelengthisadequateforthetractor.Most
ofthetimes,itcanbeusedwithoutanyneedforadjustments.
If the driveshaft is too long or too short, adjust the tractor tow bar, adjusting it to the distance
between the machine and the tractor (consult your tractor manual for instructions on adjusting the
towbar).Beforecuttingthedriveshaft,checkallpossiblemannerstouseitintheoriginalsize.Ifitis
necessary to decrease the length, cut equal sizes pieces from the tube and the bar. Also cut the
plasticcovershield.
CHECKINGTHEDRIVESHAFTLENGTH
Before coupling the driveshaft and the machine is hitched, and then turn the steering wheel of the
tractor towards either side (right or left) and then drive the tractor in reverse until the tire almost
touchesthetowhitchofthemachine.Afterthat,followingtheinstructionsbelow:
-Separatethetwopartsofthedriveshaft(maleandfemale).
- Couple the female part to the power take-off of the tractor and the male part to the axle of the
machine.
-Placethemaleandfemalepartssidebyside(fig.07).
-Checkifthereisenoughofplay,50mmatleast,onbothendsofthedriveshaft.
-Ifnecessary,marktheendsforcutting,andleaveatleast50mmplay(fig.07).
-Removethedriveshaftfromthemachineandthetractorandcuttheends.
-Jointhetwopartsofthedriveshaftwhilekeepingtheforksaligned(fig.10).
-Couplethefemalesidetothetractorandthemalesidetotheaxleofthemachine.
WARNING! If there is not enough of play, the driveshaft can be damaged when turning the
machine.
Ifisthe exclusiveresponsibilityoftheauthorized Nogueiraresellertocutthe driveshaftand
thenperformthefirsttryoutactuationofthemachine.
fig.07 fig.08 fig.09
50 mm
50 mm
1. Mark the end for cutting leaving
minimumplayof50mmonbothends. 2. Saw the plastic protective
shielding. 3.Sawthemaleandfemale bars.
12 Instruction Manual

Driveshaft preparation and coupling
After cutting the parts, use a file to do the finishing on the driveshaft. Lubricate with a thin layer of
grease.
After installing the driveshaft, fasten the safety chains so that it can articulate in any operating
conditions.
Thecutpiecesofthedriveshaftmustbethesamelength.
Itisalwaysnecessarytocheckthelengthofthedriveshaftwhenusingadifferentmodeloftractor.
Cleanand lubricate thepower take-offaxles(in the tractorand themachine)before couplingto the
driveshaft.
Seethedetailedcuttinginstructionsonthepamphletattachedtothedriveshaft.
Alwaysassemblethedriveshaftafteraligningtheends:
We recommend in normal operating conditions for the machine to move in a straight line and
contact area between the male and female parts to be at least 2/3 of the length of the closed
driveshaft (measurement L in the following figure). In the most critical conditions, when making
sharpturns,thismeasurementcannotbelessthan1/3ofthelength(fig.12).
When operating, the articulation angle of the driveshaft cannot exceed 15 (degrees) (fig.13). We
recommenddisconnectingthepowertake-offwhenturningthecoupledmachine.
CORRECT WRONG
fig.10
fig.12
fig.11
L
L (recommended)
2
3
fig.13
maximum 15 degrees
(when operating)
13
FORAGE WAGON
English

Height adjustment of the (VFN 5000) unloader
Operation
The VFN 5000 is shipped from the factory adjusted to the typical unloading height. Its chassis is
equippedwith adevice foradjustingthe unloadingheight, makingitpossible toadapt thewagon to
diversefeedingtroughheights.
Beforeturningonthewagon,checkthefollowing:
-Makesure,therearenopeopleofanimalsnearby.Theymustbekeptawayatasafedistancefrom
themachine.
-Makesurethedriveshaftiswelllatched(tothetractorandthewagon).
AftertheWagonisproperlycoupled,startthetractormotor,turnonthepowertake-offandincrease
theaccelerationlittlebylittle,untilreaching540RPM(inmosttractors,540RPMinthepowertake-
offcorrespondstobetween1700to2100RPMonthetachometer).
IMPORTANT:While filling the Wagonfrom harvesting, do not unload the product around the
decompactor rollers. The excess product around the rollers hinders the operation of these
rollers,whichcancausethefusetobreakwhenstartingtounloadintothefeedtrough.
During the first few hours of operation, constantly check the unloading conveyor belt.
Removeanyexcessiveplay,byadjustingthechains,asdescribedinthismanual.
ADJUSTMENT:
-RemovescrewsAfromthe3turnbucklesB.
-Usingarod,turnthe3turnbucklesB,movingthewagonbodyequally.
-Whenyoureachthedesiredheight,assemblethe6screwsagainA.
CAREFUL!
Do not perform the following described adjustment without first securely
immobilizing the machine (with chocks). We recommend letting the authorized
NogueiraResellerperformthisadjustment.
fig.14 fig.15
AA
BB
B
14 Instruction Manual

Side unloader (Wagon equipped with pre-dried conveyor belt)
Thetractorpowertake-offmustbedisconnected:
1-Remove pinAandpulltheknoboutto the“SIDE UNLOADER” position (fig.16below). Replace
thepinafterlatchingtheknob.
2-OpenthefrontshieldB,placethepininthesprocketCandlatchusingtwocotterpins.
3-ClosethefrontshieldB.
CAUTION! Before beginning the unloading, check if the adjustment is correct. If the knob is in the
wrong position, the unloading will come out the back part of the wagon and, if the rear doors are
closed,themachinewillbedamaged.
A
B
C
fig.16 fig.17
fig.18 fig.19
SIDE
UNLOADER REAR
UNLOADER
Keep the pin in the sprocket.
15
FORAGE WAGON
English

Side unloader (Wagon with helix transporter)
Rear unloader (Wagon with pre-dried conveyor belt)
Thetractorpowertake-offmustbedisconnected:
1- Remove pin Aand pull the knob to the “SIDE UNLOADER” position (the following figure).
Replacethepininordertolatchtheknob.
Thetractorpowertake-offmustbedisconnected:
1-Completelyopenthetworeardoorsofthewagon.
TIP: Ifyou find itdifficult to placetheknob in theindicated position,
quicklyturn onand offthetractor powertake-off.Themovement of
themechanismwillfacilitatetheadjustment.
WARNING! Before beginning to unload, check if the adjustment is correct. If the knob is in the
wrong position, unloading will be done from the rear part of the wagon and, if the rear doors are
closed,theequipmentwillbedamaged.
A
B
fig.20 fig.21
SIDE
UNLOADER REAR
UNLOADER
fig.22
16 Instruction Manual

2- Remove pin Aand push the knob to the “REAR UNLOADER” position (fig.23 below). Replace
thepintolatchtheknob.
3-OpenthefrontshieldBandremovethepinfromthesprocketD.
4-ClosetheshieldB.
TIP:Ifyoufinditdifficulttoplacetheknobintheindicatedposition,quicklyturnonandoffthetractor
powertake-off.Themovementofthemechanismwillfacilitatetheadjustment.
A
B
D
fig.24fig.23
fig.25 fig.26
REAR
UNLOADER SIDE
UNLOADER
Keep the pin in the sprocket.
Rear unloader (Wagon with helix transporter)
Thetractorpowertake-offmustbedisconnected:
1-Completelyopenthetworeardoorsofthewagon.
fig.27
17
FORAGE WAGON
English

2- Remove pin Aand push the knob to the “Rear unloader” position (fig.28 below). Replace the
pintolatchtheknob.
3-OpenthesideshieldCandremovedoublechainD.
4-ClosesideshieldC.
NOTE:WhenunloadingtheWagonfromtherear,withoutremovingthedoublechain,theworkgear
andthedecompactorrollerswillcontinueoperatingnormally.
TIP:Ifyoufinditdifficulttoplacetheknobintheindicatedposition,quicklyturnonandoffthetractor
powertake-off.Themovementofthemechanismwillfacilitatetheadjustment.
A
B
fig.29fig.28
REAR
UNLOADER SIDE
UNLOADER
fig.30
fig.31
Remove the double chain:
the helix transporter and the
decompactors will stop operating.
18 Instruction Manual

Unloader options
Dispenser (optional)
-HELIXTRANSPORTER:
This is recommended for unloading corn,
sorghum, sugarcane, and grasses, except for
pre-driedproducts.
Wagons equipped with Feed Dispensers are
supplied only with a helix transporter system,
whichare alsoresponsible formixing feedwith
forage.
Connect the two hoses from the hydraulic
systemtocontrolthequantitycomingoutofthe
dispenser, activate the hydraulic control valve
and watch the movement of the pointer on the
dispenser scale, until it reaches the desired
position.
The DISPENSER makes it possible to automatically add feeds to forage. Open the two covers
present on the top part of the wagon and load the product. In the back of the dispenser, there is an
opening from where the added product is unloaded and mixed with the forage. The flow of the
product is controlled by a valve and based on its opening, it controls the quantity of the product
addedtotheforage.
READJUSTINGTHEDISPENSERFLOW
There is a dispenser scale found on the front cover of the wagon, for defining the product flow. The
settingsonthisscaledefinetheprecisebalanceofthemixture.
-CONVEYORBELTFORPRE-DRIED:
The rubber conveyor belt is especially
designed for unloading pre-dried products,
such as: alfalfa, oatmeal, ryegrass, coast-
cross,rhodes,tifton,andothersfromanyother
type of harvest, it can also be used for corn,
sorghum,sugarcaneorgrasssilage.
fig.32 fig.33
DISPENSER SCALE
fig.34
19
FORAGE WAGON
English

HOWTOCALCULATETHEDISPENSERFLOW:
Thefollowinginformationisnecessaryforcalculatingtheflow:
-Numberoflivestockheadsbeingfed.
-Amountoffeedperhead.
-Lengthofthefeedtrough.
-Travelspeedofthetractor(basedonthegearused).
Let’stakealookatthefollowingsituationsothatwecandemonstratehowtocalculatethis:
-Numberoflivestockheadsbeingfed=100
-Amountoffeedperhead=2kg
-Lengthoffeedtrough=80meters
-Travelspeedoftractor=3km/hour
Thecalculation:
TOTALFEEDPERFEEDING
NumberofheadsXamountoffeedperhead=100x2=200kg
FLOWPERFEEDING
Totalfeedperfeeding=200kg=2,5km/m
Lengthoffeedtrough 80m
REQUIREDFLOWPERFEEDING
FlowperfeedingXTractorspeed=2,5Kg/mX3Km/h=125Kg/min
0,06 0,06
PRACTICALTESTFORCHECKINGFLOW
Openthedispenser(placethedispenserscalepointerinthe5)position.
TurnontheWagon.
Letitflowforabout10seconds,inordertofilltheWagonchutewiththeproduct.
Closethedispenser(placethedispenserscalepointeragaininthe0)position.
Place a recipient (a bag, for example) in the opening of the chute, for collecting the product being
unloadedandthenafterwardsweighingit.
Openthedispenseragain(the pointerin5)positionand letitflowfor1 minute.Weightheunloaded
product,andthisishowtocalculatetheflowperkg/min.
IMPORTANT: The above test measures the actual flow of the product in the 5 position, then to
increaseordecreasetheflow,movethescaletomoreorless,basedonyourneeds.
NOTE:TheWagonmustbeemptyinordertoperformthetest.
20 Instruction Manual
