OCEE DESIGN SASS-0096 User manual

Assembly Instructions
DEN.Honeycomb
8 Person
1600w & 1950w odules
SASS-0096

850w Side Panel
A x2 1600w odule = 300w Back Panel
1950w odule = 650w Back Panel
3-Way Junction (120°)
Bottom Connector Link
C x5B x8
Z x44
1600w odule = 1334w Worksurface
1950w odule = 1684w Worksurface
G x1 6x20 Button Head Bolts Small Worksurface Fixing Bracket W x10 Y x5
Worksurface Components (per worksurface)
Shell Components
1600w odule = 300w Side Panel
1950w odule = 850w Side Panel
F x8
650w Back Panel
D x12
Tools
4mm Allen Key/Phillips Screwdriver Cushioned allet 13mm Spanner
2-Way Junction (120°)
E x10
DWG No: SASS-0096
Revision: -
Drawn by: CE
Drawn date: 06/11/15
DEN.Honeycomb Assembly Instructions

F-5
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-8
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
C-5
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
C-2
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
C-1
1600w Module = 300w Side Panel
1950w Module = 650w Side Panel
D-5
650wBackPanel
F-1
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-2
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
D-4
650wBackPanel
D-1
650wBack Panel
D-9
650wBackPanel
A-1
850wSidePanel
D-6
650wBackPanel
A-2
850w SidePanel
F-3
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-4
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-7
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-6
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
D-7
650wBackPanel
D-8
650wBackPanel
D-10
650wBackPanel
D-11
650w BackPanel
C-3
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
C-4
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
D-2
650wBackPanel
D-3
650wBackPanel
D-12
650wBackPanel
Z
Bottom Connector
Link x44
Y
Small Worksurface
Fixing Bracket
G-6
1600w Module = 1334w Worksurface 1950w Module = 1684w Worksurface
G-1
1600w Module = 1334w Worksurface 1950w Module = 1684w Worksurface
Y
Y
E-1
2-Way Junction
(120°)
E-6
2-Way Junction
(120°)
B-1
3-Way Junction
(120°)
B-3
3-Way Junction
(120°)
B-8
3-Way Junction
(120°)
G-2
1600w Module = 1334w Worksurface
1950w Module = 1684w Worksurface
G-3
1600w Module = 1334w Worksurface
1950w Module = 1684w Worksurface
G-4
1600w Module = 1334w Worksurface
1950w Module = 1684w Worksurface
G-7
1600w Module = 1334w Worksurface
1950w Module = 1684w Worksurface
G-8
1600w Module = 1334w Worksurface
1950w Module = 1684w Worksurface
G-5
1600w Module = 1334w Worksurface
1950w Module = 1684w Worksurface
E-2
2-Way Junction
(120°)
E-3
2-Way Junction
(120°)
E-4
2-Way Junction
(120°)
E-5
2-Way Junction
(120°)
E-7
2-Way Junction
(120°)
E-8
2-Way Junction
(120°)
E-9
2-Way Junction
(120°)
E-10
2-Way Junction
(120°)
B-6
3-Way Junction
(120°)
B-4
3-Way Junction
(120°)
B-2
3-Way Junction
(120°)
B-5
3-Way Junction
(120°)
B-7
3-Way Junction
(120°)
Y Y
Y
Y Y Y Y
Y Y YY
Y Y
Y Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Assembled Configuration Illustration (for Reference)
DEN.Honeycomb Assembly Instructions DWG No: SASS-0096
Revision: -
Drawn by: CE
Drawn date: 06/11/15

A-1
A-2
F-1
F-5
E-2
E-6
D-5
B-1
G-1
G-3G-2 G-4
F-2
F-3 F-4
F-6 F-7 F-8
B-5 B-7
B-2 B-4
B-6
B-3
B-8
E-7 E-8 E-9
E-10
E-3 E-4
E-5
E-1
C-1 C-2
C-4
D-1 D-2
D-3 D-4
C-3
C-5
D-6 D-7 D-8
D-9
D-10
D-11 D-12
Assembled Configuration Illustration (for Reference)
DEN.Honeycomb Assembly Instructions DWG No: SASS-0096
Revision: -
Drawn by: CE
Drawn date: 06/11/15

1.
Before assembly, make sure that the levellers on all components are set at a 20mm
height minimum.
2.
Insert the modular screws in the back panel into the keyholes in the junction, making
sure that all of the screws have engaged into the keyholes.
Panel
Connector
8 nut
Leveller
Junction
Z
Bottom Connector Link
DEN.Honeycomb Assembly Instructions
4.
Follow the method of steps 2-3 for each component on the assembly, use page 4 for
reference.
3.
After making sure all of the screws are engaged in the keyholes, tap the top of the
back panel with a cushioned mallet to fully engage. Tie the junction and the back
panel together using a bottom connector link (Z). Insert this over one of the levellers
(between the nut and the bottom of the panel/junction) in the hooked slot and pivot
around to insert the other leveller into the straight slot. Fully tighten both nuts using a
13mm spanner to trap the connector (Z).
20mm min
DWG No: SASS-0096
Revision: -
Drawn by: CE
Drawn date: 06/11/15

Z
Bottom Connector
Link x44
B-1
3-Way Junction
(120°)
D-1
650w Back Panel
F-1
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
A-1
850w Side Panel
A-2
850w Side Panel
B-2
3-Way Junction
(120°)
E-1
2-Way Junction
(120°)
E-2
2-Way Junction
(120°)
E-3
2-Way Junction
(120°)
E-6
2-Way Junction
(120°)
C-1
1600w Module = 300w Back Panel
1950w Module = 650w Back Panel
D-9
650w Back Panel
D-5
650w Back Panel
C-2
1600w Module = 300w Back Panel
1950w Module = 650w Back Panel
F-5
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-2
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
C-3
1600w Module = 300w Back Panel
1950w Module = 650w Back Panel
C-4
1600w Module = 300w Back Panel
1950w Module = 650w Back Panel
C-5
1600w Module = 300w Back Panel
1950w Module = 650w Back Panel
D-6
650w Back Panel
D-7
650w Back Panel
D-8
650w Back Panel
E-4
2-Way Junction
(120°)
E-5
2-Way Junction
(120°)
F-3
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-4
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
D-2
650w Back Panel
D-3
650w Back Panel
D-4
650w Back Panel
D-10
650w Back Panel
D-11
650w Back Panel
D-12
650w Back Panel
E-7
2-Way Junction
(120°)
E-8
2-Way Junction
(120°)
E-9
2-Way Junction
(120°)
E-10
2-Way Junction
(120°)
F-6
1600w Module = 300w Side Panel 1950w Module = 850w Side Panel
F-7
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
F-8
1600w Module = 300w Side Panel
1950w Module = 850w Side Panel
B-6
3-Way Junction
(120°)
B-4
3-Way Junction
(120°)
B-8
3-Way Junction
(120°)
B-5
3-Way Junction
(120°)
B-7
3-Way Junction
(120°)
B-3
3-Way Junction
(120°)
Shell Assembly
DEN.Honeycomb Assembly Instructions
Side Panel
Identifying Components
Back Panel
DWG No: SASS-0096
Revision: -
Drawn by: CE
Drawn date: 06/11/15

7.
Lower the worksurfaces (G) onto the brackets (Y) attached to the structure in steps
17. Attach the worksurface fixing brackets (Y) to the underside of the worksurfaces
(G) using 1x 6x20mm socket button head machine screw (W) per small bracket (Y).
Repeat steps 5 to 7 for the other 3x worksurfaces (G) on the unit.
200
250
250
200
200
250
200
25
200
250
25
250
250
250
250
200
200
25
25
200
200
200
25
200
200
25
200
200
25
200
25
200
W
M6 x 20mm Button
Head Bolts
(x40)
C
L
C
L
C
L
C
L
C
L
5.
Attach the worksurface fixing brackets (Y) to the Den structure using 1x 6x20mm socket button head machine screw (W) per small bracket (Y), in the positions shown above.
(See step 6 for more detail)
6.
Use the top holes/slots for a 730mm worksurface height and the bottom for a
750mm worksurface height (see above).
When fixing the small brackets (Y) to the structure, make sure to pass the machine
screws (W) through the 7mm hole.
Y
Small Worksurface
Fixing Bracket
W
6x20 Button
Head Bolts
WWW
W
W
G
1600w Den.Honeycomb= 1334w Worksurface
1950w Den.Honeycomb = 1684w Worksurface
4mm Allen Key
W
6x20 Button
Head Bolts
Y
Small Worksurface
Fixing Bracket
4mm Allen Key
W
WWW
W
750mm Worksurface height
Y
730mm Worksurface height
7mm
hole
DEN.Honeycomb Assembly Instructions DWG No: SASS-0096
Revision: -
Drawn by: CE
Drawn date: 06/11/15
