ORiNG IGAP-420 series User manual

I
IG GA AP P- -4 42 20 0/ /6 62 20 0 S Se er ri ie es s
I
IG GA AP P- -6 66 62 20 0 S Se er ri ie es s
I
IE EE EE E 8 80 02 2. .1 11 1 b b/ /g g/ /n n A Ac cc ce es ss s P Po oi in nt t
I
IE EE EE E 8 80 02 2. .1 11 1 a a/ /b b/ /g g/ /n n A Ac cc ce es ss s P Po oi in nt t
I
IE EE EE E8 80 02 2. .1 11 1 a a/ /b b/ /g g/ /n n D Du ua al l R RF F A Ac cc ce es ss s P Po oi in nt t
U
Us se er r’ ’s s M Ma an nu ua al l
V
Ve er rs si io on n 1 1. .0 0
N
No ov v, , 2 20 01 12 2
w
ww ww w. .o or ri in ng g- -n ne et tw wo or rk ki in ng g. .c co om m

COPYRIGHT NOTICE
Copyright © 2011 ORing Industrial Networking Corp.
All rights reserved.
No part of this publication may be reproduced in any form without the prior written consent of
ORing Industrial Networking Corp.
TRADEMARKS
is a registered trademark of ORing Industrial Networking Corp.
All other trademarks belong to their respective owners.
REGULATORY COMPLIANCE STATEMENT
Product(s) associated with this publication complies/comply with all applicable regulations.
Please refer to the Technical Specifications section for more details.
WARRANTY
ORing warrants that all ORing products are free from defects in material and workmanship
for a specified warranty period from the invoice date (5 years for most products). ORing will
repair or replace products found by ORing to be defective within this warranty period, with
shipment expenses apportioned by ORing and the distributor. This warranty does not cover
product modifications or repairs done by persons other than ORing-approved personnel, and
this warranty does not apply to ORing products that are misused, abused, improperly
installed, or damaged by accidents.
Please refer to the Technical Specifications section for the actual warranty period(s) of the
product(s) associated with this publication.
DISCLAIMER
Information in this publication is intended to be accurate. ORing shall not be responsible for
its use or infringements on third-parties as a result of its use. There may occasionally be
unintentional errors on this publication. ORing reserves the right to revise the contents of this
publication without notice.
CONTACT INFORMATION
ORing Industrial Networking Corp.
3F., No.542-2, Zhongzheng Rd., Xindian Dist., New Taipei City 23148, Taiwan (R.O.C.)
Tel: [phone] // Fax: [phone]
Website: www.oring-networking.com
Technical Support
E-mail: [e-mail]
Sales Contact
E-mail: [e-mail] (Headquarters)
[e-mail] (China)

Table of Content
Getting to Know Your Access Point............................................................ 1
1.1 About the ORing Access Point......................................................................................1
1.2 Software Features .........................................................................................................1
1.3 Hardware Features........................................................................................................1
Hardware Installation.................................................................................... 2
2.1 Installation device on Din-Rail.......................................................................................2
2.2 Wall Mounting Installation .............................................................................................3
Hardware Overview....................................................................................... 5
3.1 Front Panel.....................................................................................................................5
3.2 Front Panel LEDs ..........................................................................................................9
4.1 Ethernet Cables...........................................................................................................10
4.2 Wireless Antenna.........................................................................................................10
Management Interface.................................................................................11
5.1 Explore IGAP-420/620 ................................................................................................11
5.1.1 Open-Vision_Commander.......................................................................................... 11
5.2 UPnP Equipment.........................................................................................................12
5.3 Configuration by Web Browser...................................................................................13
5.4 About Web-Based Management.................................................................................13
5.5 Main Interface..............................................................................................................14
5.5.1 Overview...................................................................................................................15
System Info ........................................................................................................................15
Lan Info..............................................................................................................................15
Wireless Info.......................................................................................................................16
5.5.2 Basic Setting..............................................................................................................16
System Info Setting.............................................................................................................16
Lan Setting .........................................................................................................................17
Time Setting .......................................................................................................................19
DIDO .................................................................................................................................20
5.5.3 Wireless Setting.........................................................................................................20
AP Mode ............................................................................................................................20
AP-Client Mode..................................................................................................................27

Client Mode........................................................................................................................28
Bridge Mode.......................................................................................................................29
Wireless Options.................................................................................................................33
Extra parameters for Client Mode(X-Roaming) ...................................................................35
5.5.4 Advanced Setting.......................................................................................................36
Filters.................................................................................................................................36
Misc. Settings.....................................................................................................................37
5.5.5 Even Warning Settings...............................................................................................38
System Log.........................................................................................................................38
E-Mail................................................................................................................................40
SNMP.................................................................................................................................42
Relay..................................................................................................................................43
5.5.6 System status.............................................................................................................44
Client status........................................................................................................................44
DHCP Clients List ..............................................................................................................44
Traffic/Port Status...............................................................................................................44
System Log.........................................................................................................................45
5.5.7 Administrator.............................................................................................................45
Password ............................................................................................................................45
Configuration......................................................................................................................46
Firmware Upgrade ..............................................................................................................47
Load Factory Default ..........................................................................................................47
Restart................................................................................................................................47
Technical Specifications ............................................................................ 48

IAP-420/620/6620 Series User’s Manual
1ORing Industrial Networking Corp.
Getting to Know Your Access Point
1.1 About the ORing Access Point
IGAP-420/620/6620 is reliable IEEE802.11b/g/n;
IEEE802.11 a/b/g/n WLAN with 2 ports LAN Access Point.
It can be configured to operate in AP/Client/Bridge/AP-Client
mode. You can configure IGAP-420/620/6620 by Window
Utility or WEB interfaces via LAN port or WLAN interface.
IGAP-420/620/6620 provides dual Ethernet ports, so you can
use Daisy Chain to reduce the usage of Ethernet switch ports.
Therefore, IGAP-420/620/6620 is one of the best
communication solutions for wireless application.
1.2 Software Features
High Speed Air Connectivity: WLAN interface support up to 300Mbps link speed
connection
Highly Security Capability: WEP/WPA/WPA2/Radius/TKIP supported
Support AP/Client/Bridge/AP-Client Mode
Switch Mode Supported: Daisy Chain support to reduce usage of switch ports
Secured Management by HTTPS
Event Warning by Syslog, Email, SNMP Trap, Relay
1.3 Hardware Features
Redundant Power Inputs: Dual 12~48 VDC
10/100/1000 Base-T(X) Ethernet port
Casing: IP-30
Dimensions(W x D x H) : 74.3(W) x 109.2(D) x 153.6(H) mm
Operating Temperature: -10 to 60oC
Storage Temperature: -40 to 85oC
Operating Humidity: 5% to 95%, non-condensing

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 2
Hardware Installation
2.1 Installation device on Din-Rail
Each device has a DIN-Rail kit on rear panel. The DIN-Rail kit helps device to fix on the
DIN-Rail.
Step 1: Slant the router and mount the metal spring to DIN-Rail.
Step 2: Push the device toward the DIN-Rail until you heard a “click” sound.

IGAP-420/620/6620 Series User’s Manual
3ORing Industrial Networking Corp.
2.2 Wall Mounting Installation
Each device has another installation method to fix it. Awall mount panel can be found
in the package. The following steps show how to mount the device on the wall:
Step 1: Remove DIN-Rail kit.
Step 2: Use 6 screws that can be found in the package to combine the wall mount panel.
Just like the picture shows below:
The screws specification shows in the following two pictures. In order to prevent the

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 4
device from any damage, the screws should not larger than the size that used in it.
Pozidrive
Step 3: Mount the combined device on the wall.

IGAP-420/620/6620 Series User’s Manual
5ORing Industrial Networking Corp.
Hardware Overview
3.1 Front Panel
The following table describes the labels that stick on the IGAP-420/620/6620.
Port
Description
10/100/1000 Base-T(X)
fast Ethernet ports
10/100/1000 Base-T(X) fast Ethernet ports support
auto-negotiation.
Default Setting : auto speed
Relay Output
Relay output to carry capacity of 3Aat 24VDC
Redundant power inputs
Dual Power Inputs. 12~48 VDC
DIDO
4 digital input / 4 digital output

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 6
IGAP-420/620 IGAP-420+/620+

IGAP-420/620/6620 Series User’s Manual
7ORing Industrial Networking Corp.
1. 2.4/5GHz antenna with typical 2 dBi antenna for 5GHz and 2.4GHz.
2. LED for PWR1 and system status. When the PWR1 links, the green LED will be light
on.
3. LED for PWR2 and system status. When the PWR2 links, the green LED will be light
on.
4. LED for Ethernet port1 status.
5. LED for Ethernet port2 status.
6. LED for WLAN link status.
7. LED for Fault Relay. When the fault occurs, the red LED will be light on.
8. Power Input port
9. Ethernet port1 connector
10. Ethernet port2 connector
11. Digital input
12. Digital output
13. Reset button
14. LED for P.O.E Status (IGAP-420+/620+)

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 8
IGAP-6620 IGAP-6620+

IGAP-420/620/6620 Series User’s Manual
9ORing Industrial Networking Corp.
1. 2.4/5GHz antenna with typical 2 dBi antenna for 5GHz and 2.4GHz.
2. LED for PWR1 and system status. When the PWR1 links, the green LED will be light
on.
3. LED for PWR2 and system status. When the PWR2 links, the green LED will be light
on.
4. LED for Ethernet port1 status.
5. LED for Ethernet port2 status.
6. LED for WLAN frequency using.
7. LED for Fault Relay. When the fault occurs, the red LED will be light on.
8. Power Input port
9. Ethernet port1 connector
10. Ethernet port2 connector
11. Digital input
12. Digital output
13. Reset button
14. LED for P.O.E Status (IGAP-6620+)
3.2 Front Panel LEDs
LED
Color
Status
Description
PWR1
Green
Green On
DC power 1 activated.
PWR2
Green
Green On
DC power 2 activated.
ETH1
Green/Amber
On
Port link up at 10Mbps /1000Mbps.
Green
On
Port link up at 100Mbps.
Blinking
Data transmitted.
ETH2
Green/Amber
On
Port link up at 10Mbps/1000Mbps.
Green
On
Port link up at 100Mbps.
Blinking
Data transmitted.
WLAN
Green
On
WLAN activated.
Blinking
WLAN Data transmitted.
2.4GHz
Green
On
In using
5GHz
Green
On
In using
Fault
Red
On
Fault relay. Power failure or Port
down/fail.

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 10
Cables and Antenna
4.1 Ethernet Cables
The IGAP-420/620/6620 WLAN AP has two 10/100/1000 Base-T(X) Ethernet ports.
According to the link type, the AP use CAT 3, 4, 5,5e,6 UTP cables to connect to any other
network device (PCs, servers, switches, routers, or hubs). Please refer to the following
table for cable specifications.
Cable Types and Specifications
Cable
Type
Max. Length
Connector
10Base-T
Cat. 3, 4, 5 100-ohm
UTP 100 m (328 ft)
RJ45
100Base-T(X)
Cat. 5 100-ohm UTP
UTP 100 m (328 ft)
RJ45
1000Base-T(X)
Cat 5e,6
UTP 100 m (328 ft)
RJ45
4.2 Wireless Antenna
2.4GHz/5GHz antenna is used for IGAP-420/620/6620 and connected with a reversed SMA
connector. External RF cable and antenna also can be applied with this connector.

IGAP-420/620/6620 Series User’s Manual
11 ORing Industrial Networking Corp.
Management Interface
5.1 Explore IGAP-420/620/6620
5.1.1 Open-Vision_Commander
IGAP-420/620/6620 can also be configure through Oring’s window utility Open-Vision
Step 1: Open the commander and click “Discover”, the AP devices will show on the list.
Step 2: Choose your access point, and it will show the AP function tree. Simultaneity,
you can login and then set theAP.
User interface of commander

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 12
5.2 UPnP Equipment
Step 1: To check whether the UPnP UI of the computer is connected to the
IGAP-420/620/6620, go to Control Panel > Add or Remove Programs > Windows
Components Wizard > Networking Servers > UPnP User Interface and pitch on the
UPnP User Interface.
UPnP configuration page
Step 2: At the right-below corner of the computer, you will find a sign of the UPnP
equipment.

IGAP-420/620/6620 Series User’s Manual
13 ORing Industrial Networking Corp.
Step 3: Click the sign of the UPnP equipment, then you will find the UPnP equipment in the
network neighborhood.
Step 4: Right click the UPnP equipment to choose “Properties”, it will show as the following
pictures:
Step 5: Right click the UPnP equipment or double click the UPnP equipment to transfer; it
will go to the web page.
5.3 Configuration by Web Browser
This section introduces the configuration by Web browser.
5.4 About Web-Based Management
An embedded HTML web site resides in flash memory in the system. It contains
advanced management features and allows you to manage the AP from anywhere on the
network through a standard web browser such as Microsoft Internet Explorer.
The Web-Based Management function supports Internet Explorer 5.0 or later. It is based
on Java Applets with an aim to reduce network bandwidth consumption, enhance access
speed and present an easy viewing screen.
Note: By default, IE5.0 or later version does not allow Java Applets to open sockets. You need to explicitly modify

IGAP-420/620/6620 Series User’s Manual
ORing Industrial Networking Corp. 14
the browser setting in order to enable Java Applets to use network ports.
Through the front section’s information, you will see as follows, enter your user name
(admin) and your password (admin), and then click OK to continue.
Login screen
For security reasons, we strongly suggest you change the password. Click on
Administrator Password and modify the password.
5.5 Main Interface
The Home screen will appear. Please click “Run Wizard” to go to the Home > Setup
Wizard page to quick install theAP.

IGAP-420/620/6620 Series User’s Manual
15 ORing Industrial Networking Corp.
Main interface
5.5.1 Overview
System Info
System Info
Lan Info
Lan Info
